King Kooker 1218 User manual

1218, 1218CAB, 1219, 1202F AND 1202FT
ASSEMBLY INSTRUCTIONS AND
USE AND CARE MANUAL
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY
FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING
AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN
USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
7:30 A.M. to 3:30 P.M. CST • Monday through Friday
[phone]
www.kingkooker.com
OUTDOOR COOKERS
MODEL/SERIAL # __________
FAILURE TO FOLLOW THESE INSTRUCTIONS
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON
MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
English

FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately
call your Fire Department.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION
WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3.05m) of any structure,
combustible material or other gas cylinder. Do not locate this
appliance under ANY overhead construction.
3. Only use propane burning units outdoors. Risks include fire and
carbon monoxide fumes. Lack of ventilation can cause injury or
death.
4. Never operate this appliance within 25 feet (7.5m) of any flammable
liquids or vapors.
5. Do not fill cooking vessel beyond maximum fill line (if
applicable).
6. When cooking with oil/grease, always use the thermometer
provided and never allow the oil/grease to get hotter than 350°F
(177°C). If the temperature exceeds 350°F (177°C) or if oil begins
to smoke, immediately turn the burner or gas supply OFF.
7. Heated liquids and equipment remain at scalding temperatures
long after the cooking process. Never touch cooking appliance
until liquids have cooled to 100°F (38°C) or less.
8. If a fire should occur, keep away from the appliance and immediately
call your Fire Department. Do not attempt to extinguish an oil/
grease fire with water. When cooking, have a Type BC or ABC fire
extinguisher readily available. A Type BC or ABC fire extinguisher
may, in some circumstances, contain the fire.
2
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN
FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD
CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
DANGER
DANGER

3
1) This is an ATTENDED appliance. Do NOT leave this appliance unattended
while the burner is lit or while heating oil, grease, water or cooking food.
Monitor the appliance when hot after use [oil, grease or water above 100 ° F
(38 ° C)]. Heated liquid and equipment can remain at scalding temperatures
long after cooking has ended.
2) Keep children, pets and unauthorized persons away from the appliance at
all times.
3) The use of alcohol, prescription or non-prescription drugs may impair
your ability to properly assemble or safely operate this appliance. Do NOT
assemble or operate this appliance if using alcohol, prescription or non-
prescription drugs.
4) This appliance is for OUTDOOR use only. Do NOT use in a building, garage,
tent or any other enclosed area. Do NOT use in or on a recreational vehicle
or boat. NEVER use this appliance as a heater.
5) Do not locate this appliance under ANY overhead construction. Keep a
minimum clearance of 10 ft. (3.05m) from the sides, front and back of the
appliance to ANY construction. Keep the area clear of ANY combustible
material. Do not use on or under ANY apartment or condo balcony or
deck.
6) When cooking, the fryer/boiler must be on a level, stable, noncombustible
surface such as brick, concrete or dirt. Not suitable are surfaces such as
wood, asphalt or plastic which may burn, blister or melt.
7) Check all cooker fittings for leaks before each use. Do not use a flame
to check for gas leaks. Keep the fuel supply hose away from any heated
surfaces. Only the LP hose/regulator assembly specified by Metal Fusion,
Inc. should be used with this appliance.
8) This appliance is not for frying turkeys.
9) When cooking with oil or grease, the thermometer provided MUST be
used. Follow instructions in this manual for proper installation and use of
thermometer. If the thermometer supplied with the fryer/boiler has been
lost or damaged, a replacement thermometer specified by Metal Fusion,
Inc. shall be obtained before using the appliance.
10) If the temperature of cooking oil exceeds 350 ° F (177 ° C) or if oil begins to
smoke, immediately turn the burner or gas supply OFF and wait for the
temperature to decrease to less than 350 ° F (177 ° C) before relighting burner
according to the instructions in this manual.
11) When cooking with oil/grease, have a Type BC or ABC fire extinguisher
readily available. In the event of an oil/grease fire, do not attempt to
extinguish with water. Immediately call the Fire Department. A Type BC or
ABC fire extinguisher may, in some circumstances, contain the fire.
12) NEVER overfill the cooking pot with oil, grease or water. Follow instructions
in this manual for establishing proper oil, grease or water levels.
READ AND UNDERSTAND BEFORE USING THIS PRODUCT
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove
will be used interchangeably to refer to the King Kooker®Outdoor Cooker.

4
13) Introduction of water or ice from any source into the oil/grease may cause
overflow and severe burns from hot oil and water splatter. When frying with oil/
grease, all food products MUST be completely thawed and towel dried before
being immersed in the fryer.
14) Never drop food or accessories into hot cooking liquid. Lower food and
accessories slowly into the cooking liquid in order to prevent splashing or
overflow. When removing food from the appliance, care shall be taken to avoid
burns from hot cooking liquids.
15) This appliance and pot, including handles and lids, gets dangerously hot in use.
Use well-insulated pot holders or oven mitts for protection from hot surfaces or
splatter from cooking liquids. Safety goggles are also recommended to protect
you from oil splatter. The oil remains dangerously hot hours after use.
16) Do NOT place an empty cooking vessel on the appliance while in operation.
Use caution when placing anything in the cooking vessel while the appliance is
in operation. Never use a cooking vessel larger than the capacity and diameter
specified in this manual.
17) In the event of rain, snow, hail, sleet or other forms of precipitation while
cooking with oil/grease, cover the cooking vessel immediately and turn off the
appliance burners and gas supply. Do not attempt to move the appliance or
cooking vessel.
18) Do NOT move the appliance when in use. Allow the cooking vessel to cool to
100 ° F (38 ° C) before moving or storing.
19) Avoid bumping of or impact with the appliance to prevent contact with hot
appliance, spillage or splashing of hot cooking liquid.
20) See Use and Care section for LP Gas Cylinder Information. A 20 pound
(9 kg) cylinder should be used with this cooker. The LP-gas supply cylinder
used must have a protective collar and must be constructed and marked in
accordance with the specifications for LP-gas cylinders of the U. S. Department
of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339,
Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods. Do
not store a spare LP-gas cylinder under or near this appliance. Never fill the
cylinder beyond 80% full. For proper vapor withdrawal, the 20 lb. (9 kg) cylinder
should be used in the proper upright position. Cylinder must be turned off while
not in use. Failure to follow these instructions and warnings could result in fire
or explosion which could cause property damage, personal injury or death.
21) This appliance is not intended for commercial use.
22) Use King Kooker® appliances only in accordance with state and local
ordinances, or in the absence of local codes, with the National Fuel Gas Code,
ANSIZ223.1/NFPA 54, Storage and Handling of Liquefied Petroleum Gases,
ANSI/NFPA 58 or CSA B149.1, Natural Gas and Propane Installation Code.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN
FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH
COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING YOUR KING KOOKER® PRODUCT
TABLE OF CONTENTS
Warnings ............................................................................................................................2-4
Table of Contents .......................................................................................................................5
Warranty...............................................................................................................................6
Owner’s Registration ..................................................................................................................7-8
Section I - King Kooker® Outdoor Cooker Assembly .........................................................................................9
Outdoor Cooker Assembly Instructions ...............................................................................................10
Casting Installation ...............................................................................................................10
Hose Assembly Instructions ........................................................................................................11
Section II - Use and Care of King Kooker® Outdoor Cookers and Accessories ..................................................................12
Thermometer Instructions and Safety Precautions for Deep Frying with Outdoor Cookers ......................................................12
Determining Proper Fill Levels for Cooking Vessels .....................................................................................13
LP Gas Cylinder Information........................................................................................................13
Connection Instructions ...........................................................................................................14
Leak Test Instructions.............................................................................................................14
Placement Instructions ............................................................................................................15
Lighting and Operating Instructions..................................................................................................16
Turning Off and Storing the Cooker after Use ..........................................................................................17
Maintenance Of Outdoor Cookers And Accessories.....................................................................................18
Caring For Aluminum and Cast Iron Cookware.........................................................................................19
Information Regarding Cooking Oil ..................................................................................................19
Section III - Recipes ....................................................................................................................20
 PanFry–DeepFry–StirFry .......................................................................................................20
 KingKooker®FriedCauliflower.....................................................................................................20
 KingKooker®FriedPorkChops ....................................................................................................21
 KingKooker®FriedFish ..........................................................................................................21
 KingKooker®BlackenedFish ......................................................................................................22
 KingKooker®DeepFriedHotWings ................................................................................................22
 KingKooker®Chili ...............................................................................................................23
 KingKooker®StirFry ............................................................................................................23
 KingKooker®CornFritters ........................................................................................................24
 KingKooker®PotRoast .......................................................................................................24-25
 KingKooker®TempuraShrimp ....................................................................................................25
Section IV - Frequently Asked Questions ...................................................................................26
5

6
METAL FUSION, INC.
LIMITED ONE-YEAR WARRANTY
WHAT THIS WARRANTY COVERS
This warranty covers all components of this outdoor cooker to be free from defects in materials and
workmanship, with the exceptions stated below.
HOW LONG COVERAGE LASTS
This warranty runs for one year from the date of purchase. Please keep your receipt with this manual
for future reference.
WHAT IS NOT COVERED
This warranty does not cover the following:
Incidental and Consequential Damages. This warranty does not cover incidental and
consequential damages arising in any way out of the use of this outdoor cooker. The liability of
Metal Fusion, Inc. is, in any event, limited to the amount of the original purchase price of this
outdoor cooker, and remains in force only as long as the product remains in its original, as-built
configuration. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
Neglectful Operation. This warranty does not cover any loss or damage arising in any way
due to the negligent operation of this outdoor cooker.
Altered, Repaired or Misused Equipment. This warranty does not cover any loss or
damage arising in any way out of the use of this outdoor cooker when it has been altered, repaired
by persons other than Metal Fusion, Inc., or when it has been abused or misused, or when it has
beenusedother thaninaccordance withthemanufacturer’soperating instructions,including,
withoutlimitation,anydamagetotheconsumer’spotsbecausetheywereplacedonalitcooker
while the pot is empty.
Other Assumed Responsibilities. Unless otherwise provided by law, this warranty does
not cover any responsibility or liability arising in any way out of the use of this product where that
responsibility or liability was purportedly assumed by any other person or agent.
Paint, Discoloration, and Rust. This warranty does not cover the paint on the outdoor
cooker, as in a normal use of the outdoor cooker, the paint will be burned off. Nor does this
warrantycoverdiscolorationorrusttothecookerastheseoccurrencesarepartofthecooker’s
normal wear and tear.
WHAT METAL FUSION, INC. WILL DO
Metal Fusion, Inc. will repair or replace any outdoor cooker that proves to be defective in materials
or workmanship. In the event repair is not possible or economically feasible, Metal Fusion, Inc. will
replace your outdoor cooker with an identical or substantially equivalent outdoor cooker. Metal
Fusion, Inc. will perform this service at no charge to you, except for the actual cost of shipping and
handling the outdoor cooker or replacement parts.
HOW TO GET SERVICE
In the event you have a problem or malfunction with your outdoor cooker, simply call Metal Fusion,
Inc. at [phone].
HOW STATE LAW APPLIES
This warranty gives you specific rights, and you may have other rights which vary from state to
state.

7
OWNER’S REGISTRATION
Dear Customer,
Thank you for purchasing a King Kooker®! Please take a moment to fill
out your registration form and return it to us.  We are always happy to hear
suggestions and comments from our customers about our products. Completion
of this registration allows us to contact you if the need arises. Please keep your
receipt with your instruction manual. It will be necessary as a proof of purchase
for us to help you if there is a problem with your cooker.
Name:__________________________________________________________________
E-Mail: _________________________________________________________________
Address:________________________________________________________________
________________________________________________________________________
________________________________________________________________________
Telephone: _____________________________________________________________
Model# ________________________________________________________________
Date of Purchase ________________________________________________________
Place of Purchase _______________________________________________________
Price Paid ______________________________________________________________
Wasthisagift_____ordidyou_____purchaseityourself?
________________________________________________________________________
________________________________________________________________________
Comments:
________________________________________________________________________
________________________________________________________________________
A SATISFIED CUSTOMER IS OUR MAIN GOAL. If you have any questions or
problems, please call us at 1-800-783-3885 before returning the product to the
point of purchase. Please have your receipt available when calling.
THANK YOU,
ENJOY YOUR COOKING EXPERIENCE.
CUT HERE

8
________________________
________________________
________________________
METAL FUSION, INC.
712 St. George Avenue
Jefferson, LA 70121
Place
Stamp
Here
FOLD
FOLD
TAPE HERE

TOOLS REQUIRED:
SCREWDRIVER, TORQUE WRENCH or ADJUSTABLE WRENCH, LEAK TESTING SOLUTION
1. Before assembling, check that all cooker components are included in the shipping carton.
Identify these cooker parts from the assembly drawing. Accessories such as pots may vary
according to model. Check the list of accessories on your cooker box. The following parts are
considered essential and should be included in your package regardless of model number.
Required Parts Lists:
Cooker Stand, Cast Burner, LP Hose and Regulator, Thermometer
If any of the above parts are missing, contact Metal Fusion, Inc. at 1-800-783-3885 between the
hours of 7:30 a.m. and 3:30 p.m. CST Monday through Friday for replacements.
2. Read assembly instructions, and understand sequence of assembly, before commencing to
assemble your cooker.
3. After reviewing assembly instructions, go to the Use and Care section of this manual for further
instructions.
9
SECTION I
OUTDOOR COOKER ASSEMBLY
THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD
BEFORE USING THE APPLIANCE
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be
usedinterchangeablytorefertotheKingKooker®OutdoorCooker.

10
1) Assemble bolts, washers and nuts as per diagram.
2)Wrenchtighten.Makesureallboltsetsareused
and unit stands sturdily.
ASSEMBLY INSTRUCTIONS
CASTING INSTALLATION
CONTENTS
(1) Bottom Ring
(3) Legs
(1) Flat Bar Casting Support Bracket
(1) Shroud with Welded Top Ring
(1) Casting/Air Shutter
(1) Hose/Regulator
(3) Foot Extensions
(16) Bolts, Lockwashers and Nuts
TOOLS NEEDED
Adjustable Wrench
Screwdriver
* Model May Vary From Picture
Leg
Flat Bar
Casting
Support
Bracket
Bottom Ring
Shroud
with Welded
Top Ring
A) Remove top nut from casting bolt. Leave bottom nut attached and tightened (if applicable.)
B)Placethecastingboltthroughtheholeontheflatbarcastingsupportbracketaspictured
below. The venturi tube of the burner should be located underneath the windshroud.
C) Reinstall nut to casting bolt. Tighten. Check to see if casting is pointing straight up and is
sturdy.
Bottom Nut
(If Applicable)
Top Nut
Casting Bolt Casting Bolt
Venturi Tube
Shroud Flat Bar
Casting Support
Bracket
* Model May Vary
From Picture
1
2
3
4
Legs bolt to outside of bottom ring (3
bolts, nuts and lockwashers).
Legs bolt to inside of shroud (6 bolts,
nuts and lockwashers).
Foot extensions bolt to outside of
bottom ring (3 bolts, nuts and
lockwashers).
Flat bar casting support bracket bolts
to inside of shroud (4 bolts, nuts and
lockwashers).
Foot
Extension

11
Tighten the hose fitting into the venturi with a torque wrench, up to a torque of 95 to 105 lb./in.
Alternatively, hand tighten securely and then, using a wrench, tighten an additional 1-1 1/2 turns.
ADJUSTABLE
REGULATOR
VENTURI TUBE
AIR SHUTTER
1/8 MALE PIPE THREAD
WITH ORIFICE
TYPE 1
CONNECTION
* Model May Vary From Picture
HOSE ASSEMBLY INSTRUCTIONS

READ AND UNDERSTAND BEFORE USING THIS APPLIANCE
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE,
EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
THERMOMETER INSTRUCTIONS AND SAFETY PRECAUTIONS FOR
DEEP FRYING WITH OUTDOOR COOKERS
1. Always use a deep fry thermometer when using this appliance as a fryer/boiler.
  a.Beforeeachuseoftheappliancemakesurethatthethermometerisproperlycalibratedby
placing the tip in a pot of boiling water. The thermometer should register within +/-20°of
212°F or +/-10°of 100°C. If the thermometer is miscalibrated, contact Metal Fusion, Inc. to
obtain a replacement before using the appliance.
b. Hang the thermometer on the inside of the pot with the probe immersed in the
cooking liquid. Never place a lid over a pot when monitoring the temperature of oil.
  c.Oncethefirehasbeenlitmonitorthetemperatureonthethermometeratalltimes.Water
boils at 212°F(100°C). The temperature of hot oil should never be allowed to exceed
350°F(177°C).
IMPORTANT:Oilcanigniteathightemperatures.MostKingKooker®thermometershaveaRed
Zone above 350°F(177°C) to signify Danger. Never allow the temperature to exceed 350°F(177°C). If
the temperature goes above 350°F(177°C) immediately turn the burner and gas supply OFF and wait
for the temperature to decrease to below 350°F(177°C) before relighting according to instructions
in the manual. If at any point during the cooking process the oil begins to smoke, immediately turn
the burner and gas supply OFF regardless of the reading on the thermometer. Allow time for the oil
to cool, then contact Metal Fusion, Inc. for further instructions.
  d.Whenthecookingiscompleteandthecookerhasbeenturnedoff,allowthetemperature
of the oil to fall below 100°F(38°C) before moving the pot, cooking oil, or cooker.
e. Please call Metal Fusion, Inc. at [phone] with any questions concerning the use or
operation of the thermometer.
2. Never cover the pot when cooking with oil.
3. Always thaw and dry food completely before placing it into hot oil. Frozen or wet food may cause
oil or grease to overflow.
4. Never put an empty pot over an open flame.
5. In the event of rain, snow, hail, sleet or other forms of precipitation while cooking with oil/grease,
cover the cooking vessel immediately and turn off the appliance burners and gas supply. Do not
attempt to move the appliance or cooking vessel.
6. When cooking with oil or grease, fire extinguishing materials shall be readily accessible. In the
event of an oil or grease fire do NOT attempt to extinguish with water. Immediately call your Fire
Department.ATypeBCorTypeABCfireextinguishermay,insomecircumstances,containthe
fire.
7. This appliance is not for frying turkeys.
12
SECTION II
USE AND CARE
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used
interchangeablytorefertotheKingKooker®OutdoorCooker.

LP GAS CYLINDER INFORMATION
King Kooker® Outdoor Cookers are manufactured for use with 20lb. (9 kg) LP Gas Cylinders.
Important information to remember about LP Gas cylinders include:
1. Alwaysreadandfollowthecylindermanufacturer’sinstructions.
2. Make sure that the gas cylinder is not overfilled. The maximum weight of a properly filled 20 lb.
(9 kg) LP gas cylinder is approximately 38 lbs (17 kg). Never fill the cylinder beyond 80% full.
3. Make sure that the cylinder valve has the proper connection for a Type 1 appliance fitting.
4. Do not store a spare LP gas cylinder under or near this appliance.
5. Disconnect the cylinder from the cooker for storage.
6. Store the cylinder out of the reach of children.
7. Do not use or store the cylinder in a building, garage or enclosed area.
8. Always use a 20 lb. (9 kg) cylinder in the proper upright position for the proper vapor withdrawal.
It should also be stored and transported in the upright position.
9. The cylinder must have a protective collar to protect the cylinder valve.
10. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type
of dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of
caps or plugs may result in leakage of propane.
11. Cylinder must be turned OFF while not in use.
ALWAYS READ AND FOLLOW THESE AND THE CYLINDER MANUFACTURER’S INSTRUCTIONS. FAILURE
TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE, EXPLOSION,
BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH.
13
DETERMINING PROPER FILL LEVELS FOR COOKING VESSELS
Never overfill the cooking vessel with oil, grease or water. Never fill a pot beyond the maximum fill
line. If the pot being used does not have a maximum fill line, follow these instructions to determine
the amount of cooking liquid to be used:
a. Place the food product in or on the holder.
b. Place the food product and holder into the empty vessel.
c. Fill the vessel with water until the food product is completely submerged. There must be a
minimum of 3 inches (7.5cm) between the water level and top of the vessel.
d. Remove the food product from the vessel and either mark the water level on the side of
the vessel or measure the amount of water in the vessel.
e. Remove the water and completely dry the vessel and the food product.
f. This is the amount of cooking liquid the vessel is to be filled with to cook the food product.

14
CONNECTION INSTRUCTIONS
1. Check that your hose assembly valve is set to not allow gas flow. Turn the regulator control
counterclockwise until it stops. This is the OFF position.
2. Attach the regulator to the cylinder valve by turning the Type 1 fitting clockwise. Hand tighten with
the regulator positioned upright. Refer to the assembly diagram for the appliance below.
3. Perform the Leak Test:
4. Beforelightingthecooker,checkthattheventuritubeisfreeofobstructionandthattheorificeis
properlythreadedintotheventuritubeaspertheinstructionsonpage11.Bothsituationsmustbe
corrected if necessary before lighting to prevent flashback.
LEAK TEST
 Beforelightingtheappliance,athoroughleaktestmustbesatisfactorilycompletedusing
a non-ammonia soapy water solution (50% non-ammonia soap and 50% water). This is to be
applied with a small brush to all gas joints after the cylinder valve is opened (no more than
1/2 turn). If bubbles are seen, indicating a leak, turn off the cylinder and tighten the leaking
connection until a further leak test shows no leaks.
If tightening the connection does not stop the leak, call Metal Fusion, Inc. [phone],
for assistance.
NEVER USE HOSE/REGULATOR ASSEMBLY IF LEAKING.
TYPE 1
CONNECTION
* Model May Vary From Picture
20 lb. LP
Gas Cylinder

15
PLACEMENT INSTRUCTIONS
1. Never operate this appliance within 10 ft. (3.05m) of any structure, combustible material or other
gas cylinder. Never operate this appliance within 25 ft. (7.5m) of any flammable liquids or vapors.
2. There must be no combustibles or roof overhead.
3.Keep24”(.61m)ofspacebetweentheLPgascylinderandtheappliance.
4. The LP gas cylinder and appliance must be located so that any wind is blowing the heat of the
appliance away from the propane cylinder. This also helps fire prevention by blowing the flames of a
grease fire away from the propane cylinder.
5. Center the pot over the burner on the cooker. Do NOT use any pot larger than the recommended
size for your cooker as listed below:
Model # Maximum Pot Size Pot - Height/Diameter
1218,1218CAB,1219,1202Fand1202FT 11qt.(10.41L)pot6”X14.25”(15.24cmX36.2cm)
20 lb.
LP Gas
Cylinder
(3.05m) (3.05m)
(.61m)
GROUND LEVEL
24 INCHES
10 FEET to
NEAREST
COMBUSTIBLE
(All Directions)
10 FEET to
NEAREST
COMBUSTIBLE
(All Directions)
CLEAR OVERHEAD
Keep twenty-four inches between the
cylinder and the appliance. Placing the
cylinder too close to the appliance could result in
fire or explosion which could cause property
damage, personal injury or death.
The hose connecting the appliance to the tank
poses a trip hazard. Do not step over the hose or
walk between the cylinder and appliance. Tripping
could cause the appliance or cylinder to tip over,
leading to fire or explosion which could cause
property damage, personal injury or death.
WIND DIRECTION
* Model May Vary From Picture

16
LIGHTING AND OPERATING INSTRUCTIONS
THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING
PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED.
1. Check the cooker to make sure that it is set up as per the diagram (Figure 1).
2. Make certain that the regulator control is turned to OFF by turning it counterclockwise until it reaches the stop.
3. Open cylinder control valve by turning it counterclockwise as per the diagram (Figure 2).
4. Insert a multipurpose lighter through the hole in the shroud as per Figure 3, or use a paper book match placed
above the casting as per Figure 4.Turntheregulatorcontroltowardthe“ON”positionuntilignitionoccurs.Turning
the regulator control clockwise increases the gas pressure to the burner and hence the flame size (Figure 2).
 Whenlightingthestove,ifignitiondoesnotoccurin3to5seconds,turntheregulatorandcylindervalveoff.Wait
5 minutes for gas to disperse. Repeat procedure.
5. Check that the flame is blue and that the flames are emitted from every port in the casting (Figure 5). If not, rotate
theairshutterpositionuntilthereisablueflame.Openingtheshuttertoomuchwillcausetheflameto“Lift”offthe
burner. If there is a yellow flame, or if some ports have no flame, this indicates there may be an obstruction in the
venturi tube or ports. Check the maintenance instructions on page 18 for more information regarding a yellow flame.
6. Always monitor the flame throughout the cooking process. If at any point in the cooking process the flame is
accidentallyextinguished,immediatelyturntheregulatorandcylindervalveOFF.Wait5minutesforgastodisperse
and relight the cooker according to the lighting instructions (#1-#5) in this section.
NEVER PUT HANDS OR FACE DIRECTLY OVER BURNER WHILE LIGHTING OR
WHILE THE APPLIANCE IS LIT.
Next
FIGURE 1
Turn Cylinder Handle
toward ON
(Counterclockwise)
Turn Regulator
Control toward ON
(Clockwise)
20LB. LP
GAS
CYLINDER
ADJUSTABLE
REGULATOR
* Model May Vary From Picture
MULTIPURPOSE
LIGHTER
PAPERBOOK
MATCH
FIGURE 2
FIGURE 3 FIGURE 4
FIGURE 5
Air Shutter
Air Shutter

TURNING OFF AND STORING THE COOKER AFTER USE
NEVER MOVE THE COOKER OR POT WHILE IN USE OR STILL HOT [ABOVE
100°F (38°C)].
1. AftereachuseturnOFFtheKingKooker®attheregulatorfirst,thenatthegascylindervalve.
Check to make sure there is no flame and all valves are off. Do not leave the cooker until it
hascooledcompletely.Whenremovingfoodfromthecookerwearprotectivemitts.
2. Disconnect the regulator from the cylinder by turning the Type 1 fitting counterclockwise until
the regulator is separated from the tank.
3. Storage of this cooker indoors is permissable only if the cylinder is disconnected and removed
from the cooker. Do not use or store cylinder in a building, garage or enclosed area. Read and
followallcylindermanufacturer’sinstructions.Thecylindermustbestoredoutofthereachof
children at all times. Keep entire unit in area to avoid insects and contamination that can clog
the venturi tube.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE,
EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
17

18
MAINTENANCE OF OUTDOOR COOKERS AND ACCESSORIES
1. The area where the cooker will be used must be kept clear and free from combustible materials,
gasolineandotherflammablevaporsandliquids.Beforeeachuseofthecookerinspectand
remove any combustible items.
2. The flow of combustion and ventilation of air must not be obstructed. The cooker must be set in
an open area with 10 ft. (3.05m) of space on all sides and no roof or overhang overhead. Check
the location and placement of the cooker before each use.
3. Beforeeachuseoftheappliancechecktheburner/venturitubeforinsects,insectnests,and
other obstructions. A clogged tube can lead to a fire beneath the appliance.
4. Follow all Lighting Instructions in the Use and Care Manual each time the cooker is used. Check
the flame for proper color and appearance. The flame should burn with a primarily blue color. If
a strong yellow flame is present, this could indicate an obstruction in the burner/venturi tube.
If there is any obstruction or a yellow flame, and the air shutter adjustment has not solved the
problem, turn off the cooker and allow time for it to cool. Disconnect the hose from the cooker.
Remove the air shutter using a phillips head screwdriver. Check the venturi tube with a flashlight
to see if there is a blockage. If a blockage is present use a wire such as a coat hanger to slide
into the venturi tube to remove the blockage. Reattach the air shutter to the venturi tube using
the phillips screwdriver. Assemble and light the cooker again as per the instruction manual. If
this does not resolve the problem, please call Metal Fusion, Inc. at [phone].
5. AlwaysusetheLPHose/Regulatorassemblysuppliedwiththeappliance.Beforeeachuseof
the appliance check the LP Hose for evidence of abrasion, wear, cuts or leaks. If there is any
damage to the hose, the hose/regulator assembly must be replaced prior to using the appliance.
Contact Metal Fusion, Inc. at [phone] for information regarding a replacement hose
assembly. Only the LP Hose/Regulator assembly specified by Metal Fusion, Inc. should be used
with the appliance.
6. For purchase of any replacement parts which may have become damaged or lost, please
contact Metal Fusion, Inc. at [phone] between the hours of 7:30am-3:30pm (CST)
Monday through Friday.
7. Cleaning of the appliance:
Cooker and LP Hose/Regulator: If neccessary, remove any oil or liquid which has spilled onto
the unit during cooking with mild soapy water on a rag and towel dry. Do not immerse the
burner unit or hose and regulator into water as this will cause rust.
Aluminum or Stainless Steel Pots: Clean after each use according to the directions on
page 19.
Cast Iron Cookware: Clean after each use according to the directions on page 19.
Thermometer: Clean after each use with mild soapy water and towel dry. Do not submerge in
liquid or put in dishwasher.

NEVER PLACE AN EMPTY ALUMINUM OR STAINLESS STEEL POT ON A LIT COOKER. A hole
will be burned in the bottom of the pot. Discoloration, scratching, and dimpling may occur with the
use of pots on outdoor cookers. This does not affect the performance of the pot.
Do not store used oil inside your aluminum pot. The salt used in cooking can corrode the pot causing
thepottoleak.Washthepotaftereachusewithhot,soapywaterandrinse.
SEASONING & CARE OF CAST IRON COOKWARE
NewCastIronPotsarecoatedwithparaffintopreventrusting.Beforeusingforthefirsttime,wash
with mild soapy water, rinse, and dry thoroughly. Never use abrasive detergents. Grease the entire
surface of the cookware with a thin coating of solid vegetable shortening. Do not use salted fat
(margarine or butter). Heat for 30-60 minutes in oven at 300-350°F (149-177°C). Remove from oven,
pour out excess grease, and wipe with a paper towel. This completes the seasoning process. Each
time the cast iron is used, coat the entire surface with a thin coat of solid vegetable shortening, wipe
with a paper towel, and store.
19
TIPS FOR CARING FOR
ALUMINUM FRY PANS AND BOILING POTS
It is not necessary to season aluminum pots before cooking with them. Wash with a liquid dish
washing detergent and towel dry.
After cooking, wash aluminum pots and fry pans in hot, sudsy detergent. If grease or black soot has
cooked to the outside of the pot while cooking with your outdoor cooker, scrub the outside of the pot
with a steel wool scouring pad.
DO NOT SPRAY OVEN CLEANER ON ALUMINUM POTS TO REMOVE GREASE OR SOOT. OVEN
CLEANER WILL CAUSE THE FINISH TO BECOME DULL.
If food remains stuck in the pan after cooking, add hot water and let soak. Then scrub the pan with
soap and steel wool to loosen the food.
If hard water causes darkening on the interior of your pot, fill to the level of the darkened area with a
water and cream of tartar or vinegar solution (mixed with the concentration of three cups of water to
onetablespooncreamoftartar,orvinegar).Boilfivetotenminutes.
INFORMATION REGARDING COOKING OIL
A good liquid vegetable oil must be used for deep frying.
SUGGESTIONS FOR KEEPING USED COOKING OIL:
Afterinitialuse,lettheoilcool.Whileslightlywarm,filteroutparticlesbeforestoringinoriginalcontaineror
similar sturdy plastic or glass container. This can be accomplished by using filter paper (coffee filters) or a
clean cloth (dishtowel). Never pour hot oil into a container. For best results store oil in a cool place. It can be
reused within 30 days. Discard after second use or when the flavor of reheated oil becomes objectionable to
taste.
Helpful Hint: Try frying a batch of french fried potatoes after cooking. This aids in improving the flavor of the
oil for the next use.

20
Directions and Recipes for using your King Kooker® Unique Deep Fryer Dutch Oven
outdoors on your King Kooker® Outdoor Cooker
Pan Fry – Deep Fry – Stir Fry
This is a pre-seasoned multi-purpose cast iron fry pan with two cooking levels in one pot.
1) Use only enough cooking oil in the base of the pot as you would use to pan fry in a shallow
fry pan. As food is cooked, place the cooked food on the ledge to keep it warm, as you continue to
pan fry the remaining food.
2) Or, fill the pot to half full with oil for deep frying larger quantities of food at one time.
3) Or, stir-fry as you would in a wok in the base of the pot with only a small amount of grease.
UsethepotoutdoorsonyourKingKooker®OutdoorCooker.Read,UnderstandandFollowall
ofthedirectionsinthecookermanualwhichaccompaniedyourKingKooker®OutdoorCooker.
King Kooker® Fried Cauliflower
Ingredients:
2 heads of cauliflower, cut, washed and par-boiled
 1–12oz.KingKooker®SeasonedFishFry
Salt and Pepper to Taste
Liquid Vegetable Oil for frying
Preparation: Cutcauliflower intoflorets ofthe desiredsize.  Washthe floretsand par-boilto
prepareforfrying.Boilonlylongenoughtosoften,donotboilsolongthatthecauliflowerfallsapart.
PlacetheKingKooker®SeasonedFishFryintoabowlfordippingthecauliflower.Dredgethe
cauliflower in the fish fry, one floret at a time.
PlacetheKingKooker®UniqueDeepFryerDutchOvenontheKingKooker®outdoorcooker
which you will be using for cooking. Fill the well at the bottom level of the pot with cooking oil. Light
the outdoor cooker according to the directions in the cooker manual. Use a deep fry thermometer to
monitorthetemperatureoftheoilwhenfrying.Whentheoilhasreached275°F, begin placing the
cauliflower florets into the hot oil. Fill the bottom of the pan with florets, and fry until the bottom side
is a golden brown. Monitor the temperature of the oil during cooking to keep it between 275°F and
375°F.Wearingmittsandusingafoodskimmer,turnthefloretsovertocooktheotherside.When
both sides are golden brown, remove the florets from the grease, and set on the raised sides of the
pot to keep them warm, while frying a second batch. Continue with this process until all of the florets
have been cooked. Remove them from the pot, arrange on the platter, and serve. Enjoy!
SECTION III
RECIPES
from
The King of Outdoor Cooking®
