Kingdely KD27-01 User manual

PAG E
01
Congratulaons on your purchase of a Kingdely SRUF Inflatable Stand Up Paddle board. We are proud of providing the brilliant product
to our customers around the world. Your new item is an investment which deserves your care and aenon. This manual has been
compiled to help you to operate your product with safety and pleasure.
The manual contains the following informaon:
. Content of the package.
. Product details
. Assembly and disassembly
. Operaon instrucon
. Troubleshoong
. Warranes
To ensure safety and prevent tragic accidents, please read it carefully and familiarize
yourself with the product before using it.
The cauons and warnings below are advisories relave to various types of situaons.
Please read them before you use the product.
DENOTES AN IMMINENT HAZARD WHICH WILL RESULT IN SEVERE INJURY IF YOU DO
NOT COMPLY WITH THE INSTRUCTIONS.
CAUTION!
DEAR CUSTOMER:
WARNING! REMINDS YOU OF SAFETY MEASURES WHICH MUST BE OBSERVED. DENOTES ALSO UNSAFE
PRACTICES WHICH COULD RESULT IN INJURY OR PRODUCT OR PROPERTY DAMAGE IF YOU DO NOT COMPLY
WITH THE INSTRUCTIONS.
WARNING!

PAG E
02
Stand up paddling can be physically demanding and dangerous in certain condions. Users of this product should also understand that
you may be serious injured during the stand-up paddling if you not following all safety precauons. Always obey all applicable watercra
laws and common sense.
· Always paddle in safe condions.
· Always wear a leash aaching you to the board.
· Always wear a coast guard approved personal flotaon device (PFD).
· Always paddle with others.
· Avoid paddling in off shore winds or windy condions.
· Be sure not to exceed your paddling ability and beware' of your limits.
· Be aware of changing weather condions.
· Do not use alcohol or mind-altering drugs while using this product.
· Never use this product in dark without proper lighng.
· Never let a minor use the board without adult supervision.
· Before going on a long paddle, be sure to inflate your board 24 hours prior to using it to
make sure your board is airght.
GENERAL SAFETY
SAFETY CHECKLIST
IT IS THE OWNER'S RESPONSIBILITY TO MAKE SURE THAT ALL USERS WILL CAREFULLY READ AND FOLLOW THE
MANUAL AND INSTRUCTIONS FOR THE SAFE OPERATION OF THIS PRODUCT. OBSERVE ALL LOCAL AND NATIONAL
LAWS.
WARNING!

PAG E
03
· One Kingdely inflatable stand up paddleboard
· One 3-piece adjustable carbon sha paddle
· One removable Quick Lock tool-less fin set
· One inflate/deflate double acon hand pump
· One 10  coiled leash
· One storage and carry roller backpack
· One repair kit
MODEL LENGTH WIDTH THICKNESS WEIGHT VOLUME LOAD
KD27-01 10FT/305CM 31IN/80CM 6IN/15CM 20.9LB/9.5KG 246 L 230LB/104 KG
①CARRY HANDLES ②BUNGEE CORD ③D-RINGS ④EVA PAD
⑤AIR VALVE ⑥CENTER FIN
⑦ SIDE FINS
IN THE PACKAGE
TECHNICAL SPECIFICATION

PAG E
04
ASSEMBLY/ DISASSEMBLY
·DO NOT USE SHARP TOOLS!
·ANY USE OF AIR GOMPRESSORS WILL DAMAGE YOUR PRODUCT AND VOID ALL WARRANTIES.
·FOR FIRST INFLATION, IT IS RECOMMENDED TO INFLATE INDOOR AT ROOM TEMPERATURE WHERE THE BOARD
MATERIAL IS SOFT AND THE ASSEMBLY PROCESS IS EASIER.
WARNING!
Choose a smooth and clean surface to unfold your product.
INFLATION
1)The board is equipped with a high-pressure valve. To inflate, first open the cap by turning it counterclockwise. Check and make sure
the valve is in closed posion. To verify that, push the pin down.ff the pin stays down, you have now opened the valve. To close it, push
the pin again so it springs back up. Now the valve is closed. Inflaon is done in the CLOSED posion (pin UP), and deflaon is done in the
OPEN posion (pin DOWN).
PIN UP- VALVE CLOSED PIN DOWN- VALVE OPEN
2)The pump has two ports: the OUT port and the IN port on the handle. The OUT port is for inflaon, and the IN port is for deflaon.
Aach one end of the pump hose to the OUT port, and the other end to the high-pressure valve. Push the hose fing into the 'valve
and turn clockwise to lock the posion. Inflate unl the desired pressure is reached the recommended pressure (12 to 15 psi). Aer
inflaon, disconnect the hose and close the cap. The valve won't be airght unl the valve cap is closed.
3)Read the instrucons on the pump body about single acon pumping and double acon pumping. First pump in double acon mode to
generate large volume of air at low pressure. When you feel pumping becomes heavy, switch to single acon and inflate to the desired
pressure. Check board pressure with the gauge on the pump. Do not over-inflate the board. The recommended pressure for typical use is
12 to 15 psi.
FIN INSTALLATION
Aer inflaon, install the center fin on the boom of the board. Insert the one side of the fin into the box (a), and then push the fin into the
box to make sure it's fully inserted. Aer the fin is completely install into the box, put the small insert into the opposite groove for fixing (b).
(a) (b)

PAG E
05
The paddle consists of 3 secons: the handle, the sha, and the blade.
The sha is symmetric, so it doesn't maer which end connects to the
blade. To connect the blade and the sha, first open the clip on the
buckle. Align the spring ball on the blade with the lock hole on the sha,
then insert the blade into the sha and make sure the spring ball locks in
the hole (a). Close the clips on the buckle to secure the onnecon. For the
handle there is no spring ball. Simply use the buckle to secure the handle.
If the buckle becomes loose, open the clip and rotate clockwise to ghten
the connecon (b).
LEASH INSTALLATION
Affix one end of the leash to the back d-ring on the board, and the other end to your body.
WARNING!
DEFLATION
1)To deflate, open the valve cap and push the valve pin down to open the high-pressure valve.
2)Aer most air has emied, use the pump to extract the remaining air. To do so, aach one end of the pump hose to the IN port, and
the other end to the high-pressure valve. Pump ll the board is fully deflated, detach the hose, push the valve pin to close the valve,
and then close the cap.
STORAGE
1)Clean and check the board and all the accessories aer each use. Rinse it thoroughly with clean water and make sure to remove any
residues or salt if used in salt water. Do not use detergents or any type of silicone-based products. Make sure the product is completely
dry before pung away.
2)Roll it up from the tail. put it into the backpack. Rolling from the tail can contain the fin boxes and clips inside the wrap, which will
provide beer protecon than exposing them to the outside.
3)When storing your board, keep it in a clean and dry place that is not affected by major variaons in temperature and other damaging
factors. You may store it. deflated and rolled up in a bag or assembled and lightly inflated (not subject to deformaons). Store it away
from rodents.
PADDLE ASSEMABLY
ALWAYS WAR A LEASH WEHN PADDLING!
WARNING!
IF THE BOARD IS EXPOSED TO THE HOT SUN, CHECK THE PRESSURE AND MAKE SUR IT'S NOT OVERPRESSURED.
DEFLATE SLIGHTLY IF NECESSARY.
CAUTION!
(a) (b)
WARNING!
DO NOT STORE THE BOARD AT A TEMPEARTURE BELOW 0℃ / 32 ℉. IT WILL DETERIORATE THE MATERIAL AND
CAUSE PERMANET DAMAGE.
CAUTION!

PAG E
06
GENERAL PADDLING INFORMATION
The following are general steps to start paddling:
OPERATING INSTRUCTIONS
·BEWARE OF OFFSHORE WINDS AND CURRENTS!
·GET INFORMED ON LOCAL REGULATIONS AND HAZARDS RELATED TO THIS SPORT OR WATER ACTIVITIES.
·LEARN ABOUT YOUR PADDLING AREA. ASK LOCALS ABOUT TIDES AND CURRENTS.
·BEFORE USING THE PRODUCT, PLEASE CHECK CAREFULLY ITS FULLY FUNCTIONAL
·BE CAREFUL THAT YOU DO NOT OVERESTIMATE YOUR STRENGTH, YOUR ENDURANCE OR YOUR SKILL.
·BE CAREFUL NEVER TO UNDERESTIMATE THE FORCES OF NATURE.
·DO NOT EXCEED THE DESIGNED CAPACITY.
·AVOID ALL CONTACT BETWEEN THE BUOYANCY TUBES AND SHARP OBJECTS OR AGGRESSIVE LIQUIDS
(SUCH AS ACID).
·THIS PRODUCT IS DELIVERED WITH A BACKPACK. KEEP IT AWAY FROM CHILDREN. DANGER OF SUFFOCATION!
WARNING!
1)For the most comfortable start, choose a flat water locaon without too much wind,current or dal movement.
2) Push board out onto water unl fins can't touch the boom, usually knee deep.
3) Most people start with kneeing on the board. Hold the paddle in the middle while blade angled to the rear. Take 2 small strokes
then swap paddle to the other side and take two more.
4)Once you feel comfortable, try stand up. Place one foot on each side of the center of the board, shoulder width apart. If standing
up makes your feel nervous, you can knee down and try again.
5)Aer standing up, soen your knees and ghten your core for balance.
6)Pull your top arm towards your body to extend the paddle forward. Insert paddle into the water as far forward as possible and
bury the paddle into the water. Remove from water by rotang in as paddle comes in line with your body.
7)To make a wide turn keep paddling on one .side without switching. To make a narrow turn place your paddle near the tail of the
board and pull forward whilst shiing your torso to the desired direcon.
SOME TIPS FOR BEGINNERS
·Look forward horizontally. Do not look into the water.
·Keep paddling. Your paddle is another supporng point for keeping balance.
·When adjusng your paddle, make the handle 9'' or armlength overhead.

PAG E
07
TROUBLESHOOTING
PUMP NOT INFLATE/GAUGE NOT REGISTER
1.There are two ports on the pump, IN and OUT. Make sure you use the OUT port on the handle to inflate.
2.Do not bend too much when connecng the pipe to the valve, otherwise the pipe will easily fall off the valve. Please try to keep the
vercal connecon.
3.Check the pump gauge. Make sure the hose is detached. Pull up the pump handle. Block the OUT port with one hand, and then push
the handle down with the other hand. You should feel resistance, and the gauge pointer should move. If you don't feel resistance, then
the pump is leaking air. If you feel resistance, but the pointer does not move, the gauge is defecve.
FIN FALL OFF
1)Press the clip down fully to lock the fin.
2)There is a screw underneath the clip. Tighten the screw to secure the installaon.
LEAK
1)HIGH PRESSURE VALVE LEAKING
If the board is losing pressure check the board for leaks starng with the high-pressure valve, Inflate the board to around 7 psi and spray
the valve area with water, Ch6ck and see if there are air bubbles.
If leak is idenfied, deflate the board (a) and ghten the valve using the supplied wrench in the repair kit, Insert the wrench into the valve
and rotate clockwise (b), Aer ghtening, Inflate the board to check if leaking is fixed.
(a) (b)
If ghtening the valve does not fix leaking, the valve needs to be replaced. Take out the defecve
valve using the wrench to rotate counterclockwise. Install a new valve and check if leaking is fixed.
2)SMALL PUNCTURE LEAKING
If leak is not found at the valve, you may have a small puncture.
Small punctures-can be easily found by spraying all around the board to see where air bubbles
become visible. If you can't find any bubbles, inflate the board to 15 psi and listen for an air leak.
Note that for the repair to be successful, the humidity level should be less than 60%, temperature
between 18℃/25℃ or 65℉/77℉. Avoid carrying out repairs in the rain or in direct sunlight.
1) Draw the shape of the patch exactly where it will be applied, cut a round patch at least 1 cm/l/2" larger than the cut/damaged area.
2) Clean the damaged area and the corresponding side of the patch with a grease remover and allow it to dry for 5 minutes.
3) Apply 3 thin layers of glue on both the damaged area and the patch and allow each layer to dry for 5 minutes unl the glue feels tacky.
PAGE EIGHT

PAG E
08
Kingdely SURF offers 1 year Manufacturer Limited Warranty on the board (excluding aachments and other accessories in the package)
to the original owner from the date of purchase. We guarantee against any abnormal defect in workmanship and materials within this
period. Cosmec issues such as paint fading, and any customer-iniated modificaons to the product are not covered by warranty.
Kingdely SURF shall not be held liable for incidental and consequenal damages.If the board is found to be defecve, the owner may
return it to the store it was purchased from with the original sales receipt. Kingdely SURF shall not be responsible for any damage or lost
during transport. Aer inspecon, Kingdely SURF reserves to the right to either have the defecve part or product professionally repaired,
or replaced with an equivalent product.
This warranty commitment does not cover claim condions listed below:
·Boards purchased from vendors other than Kingdely SURF.
·Boards purchased in used condion.
·Boards used in rental, commercial, or teaching environment.
·Damage or defects caused by impact with any materials or objects (rocks, docks, other boards,etc).
·Damage or defects caused by use outside of its intended purpose.
·Damage or defects caused by normal wear and tear.
·Damage or defects caused by transport, loading, unloading, dropping, or out of water handling. Including marks le by over ghtening
transport straps.
·Damage or defects caused by heel dents also known as pressure dings.
·Damage or defects caused by inappropriate storage in temperatures over32℃/90℉ and under 0℃/32℉.
·Damage or delaminaon caused by overheang as a result of exposure to direct sunlight while not in use.
·Damage or defects caused by wave impact and/or impact with ocean/lake floor.
·Damage or defects caused by storage of the board in closed, damp condions (example a wet board bag).
·Damage to fin or fin box caused by impact to the fin
For more informaon of Kingdely SURF, please visit our website:
hps://www.kingdelysurf.com/
WARNING!
YOUR PRODUCT IS DESIGNED IN ACCORDANCE WITH THE STANDARDS FOR A SPECIFIC USE. ANY
MODIFICATIONS OR EXCESSIVE USES COULD RESULT IN SERIOUS RISKS FOR THE USER AND WILL
VOID THE WARRANTY.
WARNING!
WARNING!
PERFORIV ALL YOUR REPAIRS IN A WELL-VENTILATED AREA.
AVOID INHALING GLUE VAPORS OR SWALLOWING.
AVOID CONTACT WITH THE SKIN OR THE EYES.
KEEP ALL REPAIR MATERIALS(GLUE,SLOVENTS,ETC.)AWAY FROM CHILDREN
WARNING!
4) When the third layer of glue is dry, apply the patch without pressing and adjust the posioning if required. Press the air bubbles
which may have formed under the patch by smoothing the patch with a round object such as a spoon. Do this procedure by starng
in the center of the patch towards the outside. Clean any excess glue. Drying: 12 hours.
