KingNeed Q805 User manual

1
Q805/Q810/Q815/Q820 USER GUIDE
1. Features
GSM Voice Recorder with micro SD card slot
HD Recording, file format: 32kbs WAV
Recording Mode: Voice Activation & Schedule & Remote Voice DSP, clear record sounding voice within five meters
Support maximum 32G byte SD card Support artificial Sim card working mode
Drop-trigger alarm built-in
Water-Proof design with strong magnets built-in
Police & Detector’s Best Choice
2. Product Image
3. Product Performance
4. Button Operation
4.1 Power on/off
a. On: Press power button 5 times. The green indicating light will be on for 30 seconds. (System default as ON)
b. Off: Press power button 3 times. The blue indicating light will flash for 5 times
5. Operation Commands Guide
5.1 Set APN: (VERY IMPORTANT AND MUST BE DONE 1ST) For the device to send data to the server, this command
MUST be enabled.
SMS: *apn*AXXX*BXXX*CXXX* This command sets the telecom Access Point Name. BXXX refers to user name, CXXX
refers to password.
Recording mode
Q8 Series of Model
Q805
Q810
Q815
Q820
Keep recording, Never
stop
110 hours
220 hours
330 hours
440 hours
Wake up a hour per
day, in schedule sleep
mode
100 days
200 days
300 days
400 days
Drop Alarm
Yes
Yes
Yes
Yes
Battery Capacity
5000mAh
10000mAh
15000mAh
20000mAh
Size
117x59x30mm
153x58x34mm
153x58x39mm
153x58x45mm
Weight
227g
369g
465g
569g

2
If there is no user name and password required, send as *apn*AXXX*
If there is user name but no password required, send as *apn*AXXX* BXXX*
APN information can be checked on local telecom website.
You will receive the following text: "Notice: APN is set to XXX. User name: XX. Password: XX”
5.2 Registering the “Master” Controller
SMS to the device: *master*123456*+1XXXXXXXXXXXX*, (For instance, master controller phone number is
+1XXXXXXXXXXXX. +1 refers to the country code. XXXXXXXXXXXX is the cellphone number. Please make sure country
code is included, and digit 0 is not needed before cell phone number)
Device Response: "Notice: Cell Phone # xxxxxxxxxx is set to master controller, the password is 123456.” (The device
has a default password of “123456” to initially program in your PDA/Phone.
NOTE: The device will ONLY listen and respond to instructions from this number unless you choose to turn on the
multi controller function and open the device to any cell phone number
5.3 Changing the Password:
SMS: *password*654321* (654321 refers to new password)
You will receive the following text: "Notice: The password change is successful for +1XXXXXXXXXX. The new password
is 654321.”
Note: Changing password command has to be sent from master controller number.
6. Recording Function Settings
6.1 Record On/Off
6.1.1 Record Activation
a. Button On: Once device attached on the metal surface, system will enable recording function.
b. Timing On
c. SMS On: SMS Command *recordon*
6.1.2 Record Off
a. Button Off: Press button 2 time to turn recording function off
b. SMS Off: SMS Command *recordoff*
6.2 Record Mode
6.2.1 Voice Control (Default Settings)SMS: *recordmode1*
a. Voice Control Recording Time
SMS: *silenttime*1-999*(1-999 represents minutes of silence)
System will end recording function and turn to standby mode after appointed silent time. System default as 3 minutes.
6.2.1 Alway On
SMS: *recordmode2*
6.3 Remote Control
a. Remote Listening
SMS: *callin*
System will enable the master number to call the device to start listening the surrounding sound within 30mins after
the SMS is sent.
b. Remote Period Listening

3
SMS: *callin*XXXX*XXXX*
Check recording file during appointed period. The first XXXX refers to thedate, the second XXXX refers to time.
e.g. *callin*20140919*152530* refers to start listening recording from
15:25:30 PM of September 19th, 2014. Time format is military format.
User can hand off the call when finishing listening.
Note: Device has to be switched off before taking out the SD when recording is finished,
otherwise the last recording file can not be saved.
7.GSM System (With Working Sim Card Inserted)
GSM system is always at standby mode unless system is set to sleep mode for power saving.
7.1 Motion Awaken Sleep Mode
SMS: *motionon*1-99* (1-99 represents hours of recording)
System will enable deep sleep function and will be awaken and wait for new command when motion is detected. And
system will enter preset recording mode for appointed time. If no new command is received, system will enter sleep
mode again after appointed time. The circle repeats.
7.2 Timing Awaken Sleep Mode
SMS: *periodawakeon*XXXX*XXXX*
System will stay in sleep mode and will be awaken during appointed periods, up to 3 time periods. And system will
enter preset recording mode during awaken time. Time format need to be in military time.
e.g.*callin*08001100*14001830* refers to 8:30-11:00 and 14:00-18:30 of the day.
7.3 Voice Awaken Sleep Mode
SMS: *voiceon*1-99* (1-99 represents hours of recording)
System will enable deep sleep function and will be awaken and wait for new command when voice is detected. And
system will enter preset recording mode for appointed time. If no new command is received, system will entersleep
mode again after appointed time. The circle repeats.
7.4 Sleep Off
SMS: *sleepoff*
System will end deep sleep function and turns to standby mode.
8. Drop Alert
System will send Drop Alert to master number is device is dismounted with the metal surface over 1 minute.
9. System Settings
9.1 Status Check
SMS: *status*
System Health and status check. Returns text message indicating various system diagnostics
9.2 Info CheckSMS: *about*
System will reply device information including serial number and version information to master number.
9.3 File Management
All recoding files will be saved as 10 minute length files by date as default. SMS: *interval*5-60* (6-60 represents
minutes of recording file saving interval)

4
9.4 Timezone
System is UTC time format and time zone need to be set by SMS.
SMS: *timezone*0-24*(0-24 represents different timezone, default as 8) eg Italy= *timezone*2* UK= *timezone*0*
Australia Perth = *timezone*8*
9.5 Sim Card Switch
System supports artificial sim card mode if GSM system is not needed.
SMS: *card0*
System will enter artificial sim card mode after command is received.
SMS: *card1*
System will enter working sim card mode after command is received.
10.Recording Setting Files Management (With Artificial Sim Card Inserted)
10.1 RECORD setting file
All recoding settings including time, voice sensitivities, mute time, voice quality and record amplify and can revised by
editing a simcard setting file.
Connect device with PC via USB cable. There will be simcard.txt in the folder, content as below:
Voice Sensitivity (1-50)=10*
Silent Time(Minute 1-999)=3*
Record Mode (1-2)=1*
Sleep Mode (0-3)=0*
Record Status (0-1)=1*
File Saving Time (minute 10-999)=10*
end
Setting Explanation
Voice Sensitivity Settings
The smaller number of the sensitivity rate the higher voice required. Voice Sensitivity Range: 0-50
Default Rate: 10
Silent Time Settings
Device will stop recording after conversation ended for certain minutes.
Mute rate: 0-999 minutes
Default Rate: 3
Record Mode (1-2)=1*
Record Mode 1 is voice control Record Mode 2 is always on Default Rate: 1
Sleep Mode (0-2)=0* 0: Sleep Off1: Motion Awaken Sleep 2: Voice Awaken Sleep
Record Status (0-1)=1*
1: Record On 2: Record Off
File Saving Time (minute 10-999)=10*
Record file saving interval, default as 10 minutes
Note: All the TXT file in the folder can not be deleted, otherwise can not make the record.
