kingparrot b2t User manual

*IMPORTANT– RETAIN FOR FUTURE REFERENCE*
PLEASE READ CAREFULLY
2 x Allen Keys Single Bed Hardware and parts list
Kingparrot Products
10 x
Wooden
dowels
2 x
Capping
nuts
0 x
20mm
Connecting
bolts
4 x
28mm
Connecting
bolts
0 x
54mm
Connecting
bolts
0 x
70mm
Connecting
bolts
B D IG
2 x Single bed base
4 x Single bed feet
2 x Base side supports
1 x Single bed foot
AUSTRALIA
27-37 Vallance Street
St Marys NSW
2760 Australia
Ph: 02 9833 3769 Fax: [phone]
UNITED KINGDOM
Westfield, East Garston
Hungerford
RG17 7HD UK
Ph: 44 14 8864 9663 Fax: [phone]
1 x Single bed head pelmet
NOTE: End panels of cot will become
the main base of your single bed.
Lay both panels flat on the floor.
2 x Single bed head sides
L
10 new dowels
supplied in case
of damage from
cot assembly
Re-Use 6 x from
cot assembly
18 left over
from cot assembly
1 x Bed foot support rail
NOTE: Pelmet is to be positioned with
the curve going to the back of the
bed head.
4 x Single
bed feet
1 x Fixed side = bed head 1 x Base
NOTE: Parts listed below were used in cot assembly
Re-Use 4 x from
cot assembly
Re-Use 9 x from
cot assembly
1left over
from cot assembly Re-Use 6 x from
cot assembly
2left over
C
B2T Baby To Teen Cot / Single Bed
V 07/06

B2T
Baby To Teen Cot / Single Bed
from newborn
to teenager
Maintenance of your Kingparrot Cot & Furniture
• TO ENSURE THE SAFETY OF YOUR COT OR BED, REGULARLY CHECK ALL THE CONNECTING BOLTS AND
GLIDE PINS MAKING SURE THEY ARE TIGHT, CARE SHOULD BE TAKEN THAT NO SCREWS ARE LOOSE
• GLIDE PINS AND BOLTS SHOULD BE TIGHTENED EVERY FOUR TO SIX MONTHS TO ENSURE
COT REMAINS STABLE
• TO CLEAN YOUR COT & FURNITURE USE A SOFT CLOTH DAMPENED WITH WATER
• DO NOT USE STRONG HOUSEHOLD CLEANERS
• AVOID CONTACT WITH SHARP OBJECTS
• WHEN MOVING YOUR COT, BED OR FURNITURE DO NOT DRAG, ALWAYS LIFT AND PLACE
IN POSITION
V 07/06

B2T Single Bed assembly instructions
Attaching the bed feet
1
2
Assembling the bed head
NOTE: Bed head pelmet curve must curve to the back.
3
Assembling the bed head
Screw single
bed head
pelmet to fixed
side using 3x G
bolts.
PLEASE NOTE: Before building your B2T single bed you must
disassemble the cot fully, including all capping screws and base.
Please re identify all parts including screws.
Due to the weight of this product assembly requires 2 people.
Place 6x Bwooden
dowels into top of
fixed side and place
single bed head
pelmet on top.
Lay the two end panels flat on the floor and attach 8 x single bed feet to the base using
8x Dbolts.
Screw 2 x bed head sides
to end panels using 2x G
bolts.
Place 4x B wooden
dowels into bed
head sides.
Screw bed head
to bed head sides
using 2x G bolts on
outside edge.
And 4x I bolts on
inside edge.
V 07/06

B2T Single Bed assembly instructions
Bed foot assembly
4
5
Base assembly
6
B2T single bed
Slide 2x base side supports through end panels and hook into ridge on base side support.
(Make sure stained edge of base side support is facing outside edge of bed)
Place base onto base
side supports making sure
base is facing up.
NOTE: The B2T single bed has
been manufactured for use with
a standard single bed size
mattress which measures
920mm wide x 1880mm long.
Attach bed foot
support rail to
inside of foot end
panel using 2x G
bolts.
Place single bed
foot onto foot
support rail and
screw together
using 2x Ibolts.
Fill holes on
front of foot
using 2x C
bolts and
2x Lcapping
nuts.
Fill 4 remaining holes in bed
base using 4x Cbolts.
V 07/06
