Kingpin Hitman User manual
©
INSTRUCTION MANUAL
©
Congratulations on the purchase of your HITMAN-T passthrough electronic cigarette kit.
E-cigarettes are quickly becoming the most widely used alternative to tobacco use.
E-cigarettes are not tobacco products and can be used with or without nicotine. By
purchasing this kit, you are joining a growing community of ex-smokers who know that
there finally is a viable option to conventional cigarettes. The benefits include :
• Up to 75% cheaper than cigarettes.
• Can use in places that don’t allow smoking.
• Take one puff or ve. Use what you need, when you need it.
• No carcinogens. Tobacco smoke can have up to 40 carcinogens and
nicotine isn’t one of them.
• No smell or second hand smoke.
• No ame or ashtrays.
If issues occur which are not addressed in this manual or if you want more detailed
information, please refer to the special notes and videos on the Manuals and FAQs
section of our website. www.kingpincigs.com/manuals-faqs
1
©
2
EGO style 660 mah, 3.4 - 4.2 vDC
passthrough battery
USB to Nokia style plug
Retractable
110 - 120 vAC to
USB 5 vDC adapter
2.2 Ohm
510-T atomizer
1 ml
510-T cartridge
EGO style
Battery
USB Adapter USB Wall Charger
Atomizer Cartridge Cone
Parts
The HITMAN battery should only
be charged with the USB adapter
which can be hooked up to any
USB power supply. The battery
has Joye 510 compatible ttings
and can be used with any 510 or
EGO compatible atomizers. The
510-T cartridges and atomizers
are not compatible with standard
510 cartridges and atomizers.
3
Assembly
Remove the empty cartridge attached to the atomizer and throw it away. (this
cartridge does not have a silicone plug or e-liquid and will ruin the atomizer if used)
Screw the atomizer onto the battery.
If you have e-liquid, it is best to put 4 drops on the atomizer before connecting to
the cartridge. The new atomizer is dry and takes time to wick the e-liquid out of the
cartridge. The worst thing you can do is vape on a dry atomizer, it will give it a bad
taste that is hard to get rid of.
Remove a cartridge from its wrapper and remove its protective cap. If the cartridge
is empty, ll it with desired e-liquid. (see Relling portion of the Usage section)
Twistthe cartridge a full turn clockwise while slowly pushing it into the atomizers
to keep the silicone plug from getting stuck in the cartridge.
1
2
3
4
5
©
4
6
7
8
9
Allow to sit for 2 minutes so the e-liquid can soak in before using.
Screw the cone onto the battery which helps prevent liquid leakage and improves
aesthetics. (optional)
It is recommended to fully charge the battery for 2 - 4 hours before using. The
HITMAN passthrough battery has a charging port at the tip and can be charged
while using. (see Charging portion of the Usage section)
If the light doesn’t come on when you push the button, the battery may be in safe
mode; a feature to prevent unintended activation. To return to regular mode, press
the button quickly 4 times. (see Safety section)
©
5
Usage
1
2
3
Keep the e-cigarette tilted slightly downward when using. This will help keep
e-liquid on the atomizer and prevent it from getting into your mouth.
While drawing slowly into the mouth (not the lungs) push the button on the battery
for apx. 3 - 8 seconds, then inhale. Holding the button for longer than 10 seconds
will make the battery light blink 10 times, then it will operate normally.
Only depress the button on the battery when using. Depressing the button without
pung will overheat the atomizer and cause an undesirable taste.
Correct Incorrect
©
6
4
5
6
7
8
9
Use as you would a regular cigarette and allow "cool down" periods. Try not to puff
more than once every 10 seconds as it will overheat the liquid and could cause an
undesirable taste.
Switching batteries and atomizers daily (alternating) can greatly improve the life of
the batteries and avor of the atomizers.
The 510-T tank system pumps liquid into the atomizer by puff pressure. If the
atomizer is leaking, try taking softer puffs. If the atomizer tastes like its running dry
(burnt or no avor) try taking harder puffs.
If there is a bad avor when using, and cartridge has liquid in it, try taking a couple
of quick puffs without pressing the button to help the e-liquid to ow. (you should
be able to see small bubbles rise in the cartridge when you do this)
If the atomizer makes a gurgling sound while using, it is ooded and may not work
properly. To x, follow Method A of the Cleaning section.
Keep e-liquids and cartridges stored in a cool dry place to prolong life and promote
avor.
©
7
2
3
1When you see that the cartridge is low make sure to rell before continuing use.
Using the same method as inserting, remove the cartridge from the atomizer by
twisting a full turn clockwise while slowly pulling to ensure the silicone plug doesn’t
getting stuck in the atomizer.
If the silicone plug gets stuck or pushed into the cartridge or atomizer, use a thin
tool or paperclip in order to pry it out. The e-cigarette cannot be used if the plug is
stuck in either one.
Relling
Plug CartridgeAtomizer
©
8
4
5
It is recommended to use an e-liquid with a 70:30 PG to VG mix so that wicking
occurs at the proper rate. All Kingpin e-liquids are formulated for use in a tank
system as well as all other systems.
If the e-liquid bottle you’re using has a thin tip then you can ll the cartridge
without removing the plug from the cartridge. Other wise you will need to remove
the plug with your ngernail or thin tool, e.g., paperclip, toothpick. Once removed,
ll the cartridge leaving enough room to put the plug back in. Remove any excess
liquid from the plug with a paper towel and insert into the cartridge.
©
9
1
2
3
4
HITMAN batteries generally last a day on a full charge with regular use. When the
battery voltage is getting low, the light will blink 5 times. You might still be able to
use the battery for a short while longer but it will not have good vapor and it should
be charged. The battery can be charged around 300 times before needing
replacement.
The HITMAN passthrough battery should only be charged at the tip using the
retractable USB adapter. Charging with any other charger will damage the battery
and void the warranty.
You may continue to use the e-cigarette while it is charging. One of the great
benets of a passthrough battery.
After plugging the USB adapter into the tip of the battery, connect the USB male
plug to any USB power source.
Charging
©
10
USB Wall Charger
Laptop USB port USB Car Charger
5Once connected to the power source, the battery will begin to blink once every 3
seconds and will stop blinking once fully charged, apx. 2 - 4 hours.
©
11
Atomizer
1
2
Once every 2 weeks you will need to clean the connection ttings on batteries and
atomizers with cotton swabs to make sure they have a good electrical connection.
With regular use, the atomizers will begin to develop a bad taste. This is caused
because avor and nicotine don’t vaporize as easily as the vapor uid and will begin
to build-up in the atomizer. It is possible to decrease the concentrations by adding
low or no nicotine e-liquid but that doesn’t always work. This avor will not hurt you
but it is recommended to use one of the following methods to x it.
First remove the atomizer then :
Method : A Remove any excess liquid with a paper towel. While holding the battery
side of the atomizer in a paper towel, blow into the cartridge side to remove old
e-liquid. Add a 3 - 4 drops of e-liquid before you start using it again.
Cleaning
Cartridge SideBattery Side
©
12
Method : B Place the atomizer vertically (battery side down) on a paper towel. Drip 10
drops of low or no nicotine e-liquid in the cartridge side and let it sit for several hours
(over night) This can pull old e-liquid out and improve the taste. Perform Method A
before you begin using again.
Method : C Water Flush - Hold under hot running water (cartridge side up) for 30
seconds. Blow in the cartridge side to remove excess water. Alcohol Flush - Fill a squeeze
bottle or empty e-liquid bottle with high proof grain alcohol or vodka. While holding
over a small cup or shot glass, squeeze a generous amount of alcohol into the cartridge
side and allow to ow through. Use the squeeze bottle to suck the alcohol back up or
pour the alcohol back into the squeeze bottle, the alcohol may be reused several times
(do not consume). Blow in the cartridge side to remove excess alcohol. Burn O - Attach
the atomizer to the battery but not the cartridge. While blowing into the cartridge side
press the button on the battery for 10 seconds, you should see vapor coming out near
the button. Continue doing this until no vapor comes out. Smell the cartridge side of the
atomizer (a clean atomizer should have nearly no smell) Repeat Alcohol Flush and Burn
O a maximum of 2 times until no smell is present. Add a 4-5 drops of e-liquid before
using. See our website for a video on this method www.kingpincigs.com/manuals-faqs
©
13
Safety
The HITMAN battery has a safe mode feature in which the battery will not activate
when the button is pushed. To enable safe mode, press the button 4 times quickly.
Do the same to return to operating mode. The battery should always be kept in safe
mode when carrying or storing.
Charge and store batteries in a cool environment away from heat sources.
Never use atomizers or cartomizers with resistances lower than 1.5 Ohm.
Never bite down on the cartridge as it could cause it to rupture or come apart.
If you get e-liquid on your skin or in your eyes or mouth, wash off immediately.
Don’t ever use with liquid or substances not intended for use in e-cigarettes.
Keep all Kingpin products especially cartridges and e-liquid locked in a safe place
away from children and animals.
Press 4 times
©
14
Kingpin products are intended for use by smokers over the age of 21 and not intended
for pregnant or breast feeding women, those who are sensitive to nicotine, those who
have unstable heart conditions or those who are not addicted to tobacco products.
Although Kingpin products contain much less nicotine than real tobacco products,
nicotine is highly addictive and may be dangerous to your health. Nicotine in its pure
form is a poison and can cause harm. Avoid e-liquid contact with skin, eyes and mucous
membranes. In case of an accident or if you feel sick, seek immediate medical attention.
Use only as directed by manuals. Keep all Kingpin products especially cartridges and
e-liquid locked in a safe place away from children and animals. Kingpin products are not
intended nor approved to be smoking cessation or medical devices. They are not
intended to diagnose, treat, cure, or prevent any disease or condition. They are intended
as a smokeless alternative to conventional tobacco products. These products and
statements have not been evaluated by the FDA.
E-liquid Ingredients : USP Propylene Glycol <70%, USP Glycerin <30%, USP Nicotine
<3%, natural and articial avorings.
©
©
