Kingsbottle Wcd25 User manual

Wine Rack/Cube Assembly Instructions | WCD25

STEP 1 - BOTTOM FRAME

•Assemble the bottom metal frame on a flat surface.#

•Line up and hammer the timber slats into the metal

frames using a rubber mallet. Make sure it’s fully

hammered in.#

•Start from the center. #

( Instruction Video )

STEP 2 - TOP FRAME

Insert one section of the metal frame only halfway

down into the wood pieces.#

( Instruction Video )

Insert the 2nd section of the metal frame into the 1st

and use a rubber mallet to complete the installation

into the wood pieces.

STEP 3 - ASSEMBLE THE CUBE FRAME

Screw the top board into a side board as

shown. Please do not tighten the screws #

Screw the bottom board into the other side board

same as previous step, then screw all boards. #

Top and bottom Board

Side board

Screws

STEP 4 - INSERT THE WINE RACK INTO THE CUBE FRAME

Screw the top shelf into a side shelf as shown.Please do not tighten the screws.Parts includedStep1Step2Step3Step4Put the wood tenon insert into the holes which in the long plank and add the white glue.Put the short wooden blocks insert into the wood tenon.Put the wooden tenon insert into theholes which in the another side of the short wooden blocks andadd the white glue again.Put the wooden tenon insert into the anotherlong plank after assembled all the tenons andshort wooden blocks.Adjust and tap gently the base till to stable.Long plankShort wooden blockswhite glue Instruction ManualListThe whole installation process is done.Attention:This instruction is applicable to other similar wood bases.Step1Step2Step3Step4Step5Step6*1①②③④Screw the bottom shelf into the other side shelf same as step1,then screw all shelves.Crossive insert two middle shelves into one, and then insert crossing middle shelves into the wood frame as shown.Tighten all screws with a hex wrench to keep it stable.Top and bottom shelf*2Side shelfMiddle shelfScrews

Remarks: 1.The caps is used to cover the screw holes. 2.Please use the hammer to tap them to be stable.Caps:8 pcs*2*2*12*1Ļ

Hex wrenchM6*25X-module Wine Rack Assembly Instruction
