KingSo YG-11-03 User manual
MANUAL
BABY SAFETY GATE
Thank you for buying this safety gate, please read this manual carefully
before use the product. Any problem feel free to contact our distributor.
Please e-mail to us directly via [email protected], and we will
solve it as soon as possible.
YG-11-03
1
as possible
IMPORTANT! READ AND FOLLOW THESE
INSTRUCTIONS CAREFULLY AND KEEP
FOR FUTURE REFERENCE
As safety gate which has been subjected to misuse, abuse, abnormal use, excessive
wear and tear, improper assembly, negligence, environmental exposure, alteration
or accident or has had its serial number altered or removed invalidates any and all
claims against the manufacturer. Any damage to property during installation of
your playpen is the sole responsibility of the end user. Failure to follow these warnings
and the instructions could result in serious injury or death.
Ensure the safety barrier is attached between two clean structurally sound
surfaces and fixed with wall plugs. This product comes without a base. Before
using the playpen, customer should prepare a hexagonal mattress or pad which
must be not more 23 inches side length and not more than 5.5 inches thick.
Please check the playpen on a regular basis to ensure gate and parts are all in
proper working order. Ensure appropriate fixings are used for drywall, wood,
brick etc. Wall plugs are provided. If you are unable to secure to the wall satisfactorily,
consult with a hardware store for adequate fittings.
Please read, follow and retain this instruction booklet thoroughly to ensure
correct installation and for future reference. Please inspect your safety playpen
upon receipt. Please check that all parts are present, correct and in good order.
If you notice any damage or any parts missing, do not assemble. Either return
to place of purchase or contact us directly. We recommend that you carry out
the installation away from young children as some of the smaller parts may
present a chocking hazard.
2
ALWAYS install and use gate as directed using all required parts.
STOP using when a child can climb over or dislodge the gate.
Use only with the latching mechanism securely engaged.
NEVER use a gate to keep child away from pool.
· Stop using gate if any parts are missing or become damaged.
·Never leave child unattended.
· This product will not necessarily prevent all accidents.
· Gates that must be installed at least 10cm from the first step of the stair.
· Intended for use with children from 6 months through 24 months of age.
·
·
·
·
Children have died or been seriously injured when gates are not securely installed.
Notice:Hardware installation is required
Adult assembly required. Install according to the manufacturer’s instructions.
This product need to be closed manually; always check that it is correctly closed.
Never allow older children to climb on or over the barrier as this could result in an
accident.
This playpen/barrier should be check regularly to ensure they remain properly fixed
and secure. Never use this product if there are any loose or missing fasteners, loose
joints, broken parts, or mesh/fabric. Check before assembly and periodically during use.
Any additional or replacement parts should only be obtained from the manufacturer
or distributor.
This product will not necessarily prevent all accidents. Never leave a child unattended.
A swing gate can trap small hands.
Do not remove the safety notices; you may not always be the user.
Eventually your child will reach an age when they are capable of opening your gate.
Children will develop physically and mentally at different rates, therefore it is important
that you monitor your child’s capabilities.
Retain these instructions as you may wish to reposition the playpen/barrier.
To clean: use mild soap and wipe with a damp cloth.
Strings can cause strangulation! Never place items with a string around a child’s neck
such as hood strings or pacifier cords. Never suspend strings over product or attach
strings to toys.
Discontinue use of the product when child is able to clime out or reaches the
height of 35 inches(890mm).
Child can become entrapper and die when improvised netting or covers are placed
on top of a product. Never add such items to confine child in product.
When child is able to pull to standing position, remove bumper pads, large toys,
and other objects that could serve as steps for climbing out.
Never place product near a window where cords from blinds or drapes can strangle
a child.
Always provide the supervision necessary for the continued safety of your child.
When used for playing, never leave child unattended.
To reduce the risk of SIDS, pediatricians recommend healthy infants be placed
on their back to sleep, unless otherwise advised by your physician.
Never substitute parts.
If refinishing, use a nontoxic finish specified for children’s products.
The product, including side rail, must fully erected prior to use.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
When used as a safety barrier
When used as a playpen or a safety barrier
This safety barrier complies with EN1930:2011.
This product has been designed for domestic use only with children up to 24 months
of age
WARNING: Incorrect fitting or positioning of this safety barrier can be dangerous.
WARNING: The safety barrier must not be fitted across windows.
WARNING: Do not use the safety barrier if any components are damaged or missing.
WARNING: Stop using the barrier if the child is capable of climbing it.
WARNING: Do not leave the gate of the barrier open at any time. Remove barrier if
not in use for long periods.
When used as a barrier, the door closed and locks by itself.
This safety barrier is suitable for openings up to 320cm.
If the safety barrier is to be used at the top of the stairs it should not be
positioned below the top level. If the barrier is to be used at the bottom of the stairs,
it should be positioned at the front of the lowest tread possible.
!
!
!
3
23.6"
23.6"
29.1"
This gate is to protect baby and pet from danger.
applicated on staircase, kitchen, fireplace, doorways,
and hallways,墙角. This product will not necessarily prevent all
accidents. Never leave child unattended.
SPECIFICATION
4
corner. This product will not necessarily
prevent all accidents. Never leave child unattended
30"
doorways,
Net Weight: 16.5lb Gross Weight: 17.97lb
Installation width:33-80"
Material: Iron tube, plastic
Width of each panel: 23.6"
High of each panel: 30"
5
PARTS
A B C
Plastic Expansion
Pipe 8pcs Screw 8pcs Fixed Head 4 pcs
PRODUCT LIST
STEP 1
STEP 2
6
Installation Guide
UNLOCK THE KNOB
INSERT THE FIX HEAD
WALL WALL WALL WALL
1
STEP 3
WALL WALL
Measure the installa�on width where you install the gate, then choose the
below 5 methods to install. Please follow the below 5 method to install.
(No�ce: installa�on width have to under 80")
WALL
WALL
WALL
WALL
Installation Method
7
Application Scenarios
2
3 4 5
Rotate the both side
panel un�l the width
fits the installa�on place.
Then install the gate on the
wall like picture shows.
3-1
4-2-1
wood wall
2mm hole
:
8
>25.6"
4-1
STEP 4 WALL FIXING
4-3
non wood wall
5mm hole Insert
expansion pipe
4-2-2
9
10
Tighten the 4 knobs
4-5
4-4
2
1
3
4-6
FOLD UP THE GATE
5-1
11
STEP 5
Press the bu�on on the bo�om of the fixing
head to remove the gate from the wall. 2
1
5-2
12
Fold up the gate like the below picture show
5-3
