KINGSONG KS-18L User manual

KS-18L
KS-18XL
User
Manual

CAUTIONS
Electric unicycle is designed for the outdoors and sho
distance personal transpo.
SAFETY IS THE NUMBER ONE PRIORITY!
PLEASE RIDE UNDER LOCAL LAW!
The user manual below is a quick and convenient guide of
safety & item functions/features to end user. We can’t ensure all
types of situation emergency are covered. Therefore, we
STRONGLY remind you to read this guide ve carefully, and
ride with attention to ensure your safety.
Riding like all outdoor activities comes with it’s risks. You risk
serious danger and inju if you fall, collide or lose of control
when riding, please ride with caution and at your own risk.
Thanks you for purchasing King Song sma electric unicycle!

Contents
1. Product Details----------------------------------------01
2. Safety Instructions-------------------------------------07
3. APP---------------------------------------------------11
4. Learn to Ride------------------------------------------12
5. Warning-----------------------------------------------15
6. Maintenance-------------------------------------------19
7. Warranty----------------------------------------------21

Tire
Pedal
Speaker
RGB light
Headlight
USB po
Power button
Handle
Rear fender
Charge po
Pad
USB po
Tail light
Rear
Front
Accessories
-----------------------------------------------------------------------------------
Charging Adapter User Manual
1. Product Details
1.1 Diagram: KS-18L/18XL
1

Around 9hrsAround 14hrsCharging time
Input AC 80~240V / Output DC 84V 1.5AAdapter specs
120kgMax load
Around 95-105kmsAround 140kmsMileage
Rated Power: DC 72V
Top Charging Voltage: DC 84V
Rated Capacity: 1554Wh(18XL) / 1036Wh(18L)
Batte pack with equalization, overcharge and
sho circuit protection.
Batte
Around 35°Grade-ability
Full speed unlocked after 10km. Max speed of
50km/h (Facto alarm settings: 18km/h rst level
alarm, 19km/h second level alarm, 20km/h third
level alarm and warp plate).
Max speed
4000WPeak power
2200WRated power
KS-18LKS-18XLModel No.
1.2 Specications
2

45° left and right side. ( Motor stalls when over 45° ) Roll protection
Lift sensor accurately senses and determines when
wheel is lifted o the ground to stop tire rotation.
Lift sensor
Protective Measures
Led shows batte level when EUC on at rest.Batte indicate
Charge po*2, Power button, Light sensor,
USB po*2.
Po
Around 21.6kgAround 25.4kgWeight
18*2.5inchTire size
160mm
Pedal distance
from the ground
565(L)*260(W)*760(H)mmPackage size
495(L)*225.3(W)*590(H)mmProduct size
Appearance & weight
White, Rubber blackColor
-10℃ / +60℃
Working
temperature
3

The protection pad are ergonomically designed to
use the safe foams, which is moderate, easy to
accelerate and decelerate and also better to
protect the body.
Power pad
Uniform force on the pedals with raised small
columns which is more eective than traditional
sand sticking to protect anti-skid, greatly improving
safety peormance and riding experience.
Pedals anti-slip
protection
The motherboard is treated with sealant, greatly
enhancing the waterproof peormance.
Motherboard
Waterproof
Protection
When the motherboard reaches 80℃ it will result
tilt-back. When the motor reaches 120℃ it will result
in tilt-back.
Higher
temperature
protection
Low batte protection activated on 30% batte,
speed will decreases linearly; when the batte is
lower than 5%, voice alarm for charge, when batte
at 0%, the front pa of the pedal will rise to
decelerate until full stop.
Low batte
protection
Beep alarm or voice alarm when exceed limit speed.
Speed limit
protection
Place the machine veically on the ground will
resta automatically, no need to resta manually.
4

Front and rear light sensing system to ensure your
safety at night.
Headlight & tail
light
Bluetooth 4.0. stronger compatibility and allowing
strong stable data transmission.
Bluetooth
The motherboard is attached to the magnesium
alloy base for better heat dissipation, which
provides a strong guarantee for fast and stable
operation. The turbine inveer fan automatically
adjusts the air volume according to the temperature
of the main board.
Motherboard
Hardware Features
The EUC down buzzer beeps alarm 5s
Voice prompt function: “Your device is in low batte,
please charge it” “Please decelerate” “Bluetooth is
connected” “Bluetooth is disconnected” “Be caution,
over voltage” “Be caution, over power”.
Voice remind
Led shows batte level when EUC power on at rest.Batte indicate
Sho press power key: turn on
Long press: hear a click then turn o
Switch On/O
Alarm & Features
5

1*Charger, 1*User manual, 1*QC ceicateStandard
accessories
Package
Equipped with surround sound Bluetooth audio,
better sound quality.
Bluetooth
speaker
With the dual functions of acceleration pad and
protection pad, the acceleration and deceleration
during riding are more stable and safer.
Protection pad
Using 18650 batteries, the 18XL is designed with
two independent batteries, the batte protection
board adopts a new batte management system,
real-time monitoring of batte cell safety.
Batte
Higher power 2200W motor that provides a
maximum torque of 104N.m providing fast
acceleration.
Motor
Aluminum constructed handle designed for
ergonomic pushing of the wheel or lifting of the
wheel.
Handle
Temperature of the motherboard and motor is
continually monitored to ensure rider safety.
Temperature
system
Full coverage of RGB lights, music spectrum
beating, riding more cool.
RGB light
6

2. Safety Instructions
● 18XL is an enteainment product, Which is dierent from
motor vehicles driving on the road. Before mastering riding
skills, you need to practice. Kingsong is not responsible for any
injuries or damage caused by a rider's inexperience or failure to
follow the instructions in this document.
● Please understand that you can reduce the risk by following
all the instructions and warnings in this manual, but you cannot
eliminate all the risks. Remember that whenever you ride the
18XL you risk inju or death from loss of control, collisions, and
falls. When entering into public spaces always comply with the
local laws and regulations. As with other vehicles, faster speeds
require longer braking distance. Sudden braking on smooth
suaces could lead to wheel slip, loss of balance, or falls. Be
cautious and always keep a safe distance between you and
other people or vehicles when riding. Be ale and slow down
when entering unfamiliar areas.
● Respect pedestrians by always yielding the right of way. Pass
on the left whenever possible. Avoid staling pedestrians.
When approaching from behind, announce yourself and slow
7

down to walking speed when passing.
● In places without laws and regulations governing
selalancing electric vehicles, comply with the safety
guidelines outlined in this manual. Kingsong is not responsible
for any propey damage, personal inju/death, accidents, or
legal disputes caused by violations of the safety instructions.
● Make sure each new rider wears a helmet and other
protective gear.
● Before each ride check for loose fasteners, damaged
components, and low tire pressure. If the 18XL makes abnormal
sounds or signals an alarm, immediately stop riding. Contact
your dealer/distributor for seice.
● Always wear a helmet when riding. Use an approved bicycle
or skateboard helmet that ts properly with the chin strap in
place, and provides protection for the back of your head.
● Do not attempt your rst ride in any area where you might
encounter children, pedestrians, pets, vehicles, bicycles, or
other obstacles and potential hazards.
8

● Use caution when riding in new environments.
● To reduce risk of inju, you must read and follow all
“WARNING” notices in this document. Do not ride at an unsafe
speed. Under no circumstance should you ride on roads with
motor vehicles. Always follow these safety instructions:
A) The following people should not ride 18XL:
i. Anyone under 18 years old or above 50 years old.
ii. Anyone under the inuence of alcohol or drugs.
iii. Anyone who suers from disease that puts them at risk if
they engage in strenuous physical activity.
iv. Anyone who has problems with balance or with motor
skills that would inteere with their ability to maintain
balance.
B) Comply with local laws and regulations when riding this
product. Do not ride where prohibited by local laws.
C) To ride safely, you must be able to clearly see what is in
front of you and you must be clearly visible to others.
9

D) Do not ride in the snow, in the rain, or on roads which are
wet, muddy, icy, or that are slippe for any reason. Do not
ride over obstacles (sand, loose gravel, or sticks). Doing so
could result in a loss of balance or traction and could
cause a fall.
E) Do not accelerate or decelerate suddenly. Do not
accelerate when the 18XL tilts back or sounds an alarm.
Do not attempt to override the speed limiter.
F) While the Kingsong App is useful, do not allow the App to
distract you while you are riding. Always pay attention to
your surroundings.
● Never resta and ride your 18XL after it has indicated an
empty batte condition or powered o due to low batte.
Your 18XL may not have enough power to keep you balanced,
especially if you demand a lot of power at once. If you resta
and continue riding, you risk falling. Also, you risk damaging
your batteries, resulting in reduced batte life and capacity.
● Do not inse the power cord if the charge po is wet.
10

● Use a surge protector when charging to help protect your
16X from damage due to power surges and voltage spikes. Do
not use a charger from any other product.
● Always shut down your 18XL and unplug the AC Power Cord
before peorming any maintenance.
● Do not modify your 18XL. Modications to your 18XL could
inteere with the operation of the 18XL, could result in serious
inju or damage, and could void the Limited Warranty.
3. APP
● For Android apk: Please download from Google play,
‘kingsong’ is the exact one.
● For IOS app: Please download from apple store, ‘kingsong’ is
the exact one.
KingSong APP(Android) KingSong APP(IOS)
11

4. Learn to Ride
4.1 Precautions
• Please nd a suace to practice on.
• Warm up your body and ensure you're wearing safety gear
such as helmets, knee pads, elbow pads and wrist guards.
• Ensure the wheel's batte level.
• Check the unicycle for impeections such as any
looseness, abnormal sound. We also highly suggest
pushing the unicycle by ahnd to see if there's any friction
between tire and the case of the wheel.
• Please do not accelerate or decelerate rapidly, please also
t to avoid over leaning or leaning too fast to prevent
rider inju.
4.2 Sta Learning to Ride
• Like riding a bicycle or unicycle, it takes a ceain skill level
to ride Kingsong 18XL. For dierent customers, it may take
2-20 hours to ride well.
12

04. After you are able to comfoably
glide for a few seconds, t
gliding for 10-20 ft (3-5 m) with
both feet on the pedals.
03. With one foot on a pedal, slowly
lean forward. Push o with your
other foot and glide for 1-2
seconds.
02. Using a friend, wall, or handrail:
put both feet on Kingsong 18XL
and practice riding slowly
forward and backward.
01. Get used to the way Kingsong
18XL: step on one pedal, then
swing your leg back and foh to
feel the controls.
13

07. To get o: come to a stop by
centering your weight, then step
o Kingsong 18XL with one foot.
06. Turn by pressing harder on one
pedal than the other, and by
shifting your weight slightly.
05. Practice travelling forward and
backward by controlling your
body's center of gravity. The
fuher you lean, the faster you
go.
14

● Use caution when riding over
any changes in terrain.
● Watch your head when
passing through doorways.
● Use caution when riding on
slopes. Avoid riding on steep
slopes.
● Always wear a helmet and
protective clothing when
riding.
5. Warning
• You must read and understand the Warning Instructions
section of this manual before attempting to ride the 18XL.
15

● Do not ride double or car
any passengers.
● Do not rock back and foh
or shift your weight abruptly.
● Do not ride over holes, curbs,
steps, or other obstacles.
● Do not ride on limited
traction suaces.
16
