Kingston Technology StorCase Technology Data Express DE100i-A100 User manual

StorCase® Technology
Data Express®
DE100i-A100
Removable
Ultra ATA133
Drive Enclosure
User's Guide
All manuals and user guides at all-guides.com
all-guides.com

i
DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
StorCase® Technology
Data Express®
DE100i-A100
Removable
Ultra ATA133
Drive Enclosure
User's Guide
Part No. D89-0000-0103 C02 October 2005
StorCase Technology, nc.
17600 Newhope Street
Fountain Valley, CA 92708-9885
Phone [phone] Fax [phone]
All manuals and user guides at all-guides.com

ii
StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev.
L M TED WARRANTY
STORCASE TECHNOLOGY, Incorporated (StorCase) warrants that its products will be free
from defects in material and workmanship, subject to the conditions and limitations set forth
below. StorCase will, at its option, either repair or replace any part of its product that proves
defective by reason of improper workmanship or materials. Repair parts or replacement
products will be provided by StorCase on an exchan e basis, and will be either new or
reconditioned to be functionally equivalent to new.
This warranty does not cover any product dama e that results from accident, abuse, misuse,
natural or personal disaster, external power sur e or failure, or any unauthorized disassem-
bly, repair or modification. StorCase will not be responsible for any software, firmware or other
customer data stored within, or interfacin with a StorCase product.
Duration of Warranty
Seven-Year Warranty: The followin StorCase products are covered by this warranty for a
period of seven (7) years from the ori inal date of purchase from StorCase or its authorized
resellers: all Data Express® removable device enclosures and all Data Silo®, Data Stacker® and
InfoStation® external expansion chassis, except for those components inte rated into or
purchased separately for use with these products which are identified and covered by the three-
year or hard drive warranties described below. All StorCase interface cables and other
accessories specifically intended for use with the StorCase products identified above are also
covered by this (7) year warranty.
Three-Year Warranty: The followin components inte rated into or purchased separately for
use with StorCase Data Express, Data Silo, Data Stacker and/or InfoStation products are subject
to warranty for a period of three (3) years from the ori inal date of purchase from StorCase or
its authorized resellers: all RAID controllers, power supplies, fans and blowers.
Two-Year Warranty: The followin StorCase products are covered by this warranty for a
period of two (2) years from the ori inal date of purchase from StorCase or its authorized
resellers: all Rhino®JR fixed external expansion chassis (model types FJR) and all RhinoJR
removable device enclosures (model types RJR).
One-Year Warranty: All StorCase products identified as Reconditioned or Special Inventory
are covered by this warranty for a period of one (1) year from the ori inal date of purchase from
StorCase or its authorized resellers. Reconditioned products may only be exchan ed for
reconditioned products.
Hard Disk Drive Warranty: All hard disk drives purchased from StorCase or throu h its
authorized resellers, whether purchased separately or inte rated into StorCase products, are
subject to the warranty terms and conditions provided by the drive manufacturer.
Third Party Software Warranty: All third party software purchased from StorCase for use
with and/or as part of StorCase products is subject to the warranty terms and conditions
provided by the software manufacturer.
All manuals and user guides at all-guides.com

iii
DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Warranty Claim Re uirements
To obtain warranty service, the defective product must be returned to your local authorized
StorCase dealer or distributor, or, with prior StorCase approval, to the StorCase factory
service center.
For defective products returned directly to StorCase, a Return Material Authorization (RMA)
number must be obtained by callin StorCase Customer Service at [phone]. The RMA
number must be prominently displayed on the outside of the return packa e. Shipments must
be frei ht-prepaid and insured, and must include the product serial number, a detailed
description of the problem experienced, and proof of the ori inal retail purchase date. Products
must be properly packa ed to prevent dama e in transit. Dama e resultin from improper
packa in will not be covered by this warranty. The StorCase factory service center is located
at 17650 Newhope Street, Receivin Dock, Gate #4, Fountain Valley, CA 92780, U.S.A.
Free Technical Support
StorCase provides free technical support. If you experience any difficulty durin the
installation or subsequent use of a StorCase product, please contact StorCases Technical
Support Department prior to servicin your system. This warranty covers only repair or
replacement of defective StorCase products, as described above. StorCase is not liable for,
and does not cover under warranty, any costs associated with servicin and/or installation
of StorCase products.
StorCase Technical Support can be reached in the U.S. at [phone] or toll-free at (888)
435-5460 (U.S. and Canada only). StorCase European Technical Support can be reached in
the U.K. at [phone].
Disclaimers
The foregoing is the complete warranty for the products identified above and
supersedes all other warranties and representations, whether oral or written.
StorCase expressly disclaims all warranties for the identified products, which are
not stated herein, including, to the extent permitted by applicable law, any implied
warranty of merchantability or fitness for a particular purpose. In no event will
StorCase be liable to the purchaser, or to any user of a StorCase product, for any
damages, expenses, lost revenues, lost savings, lost profits, or any other
incidental or conse uential damages arising from the purchase, use or inability
to use a StorCase product, even if StorCase has been advised of the possibility
of such damages.
Copyri ht © 2005 StorCase Technolo y. All ri hts reserved. All re istered
trademarks are the property of StorCase Technolo y. All other lo os and trademarks
are properties of their respective companies.
All manuals and user guides at all-guides.com

iv
StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev.
StorCase Technolo y, Inc.
17600 Newhope Street
Fountain Valley, CA 92708
17600 Newhope Street
Fountain Valley, CA 92708
Data Express DE100
DE100i-XXXX/XXX
ITE Emission
- EN 50081-1
- EN 61000-3-2 Harmonic Current
- EN 61000-3-3 Volta e Fluctuations and Flicker
- EN 50082-1
- EN 61000-4-2 - EN 61000-4-5
- EN 61000-4-3 - EN 61000-4-6
- EN 61000-4-4 - En 61000-4-8
- EN 61000-4-11
EN 60950
CAN/CSA-C22.2 No. 950-95
UL 1950
EN 60950: 2000
FCC Part 15, Class B
AS/NZS 3548 Information Technolo y Equipment
2000
Company Name:
Corporate Office Address:
Manufacturing Address:
Product Name:
Model Number:
Conforms to the followin standards:
EMC Directives:
(89/336/EEC)
Low Voltage Directive:
(73/23/EEC)
Safety Standards:
CSA (NRTL/C)
TUV
EMI Standards:
EMC Standards:
Year of Manufacture:
Si nature:___________________
Full name: Dieter Paul
Position: President
Declaration of Conformity
All manuals and user guides at all-guides.com

v
DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Table of Contents
INTRODUCTION ..................................................................................................................... 1
Packa in Information .................................................................................................. 1
Serial Numbers .............................................................................................................. 1
Packa e Contents......................................................................................................... 2
General Description ...................................................................................................... 3
Receivin Frame Front Panel ............................................................................... 4
Receivin Frame Rear Panel ................................................................................ 5
INSTALLATION ...................................................................................................................... 7
Installin the Drive into the Carrier ............................................................................... 7
Drive Activity Indicator Connector (J5) ....................................................................... 7
Installation ..................................................................................................................... 8
Installin the Receivin Frame ..................................................................................... 9
Selectin the Unit ID Number ...................................................................................... 10
Unit ID Select Switch Settin s ........................................................................... 12
I/O Connector J2 ................................................................................................. 13
APPENDICES ........................................................................................................................ 14
Appendix A - Specifications/Dimensions .................................................................. 15
Appendix B - Attachin the ON/OFF Key .................................................................. 17
Appendix C - Optional Accessories .......................................................................... 18
Carryin Case ..................................................................................................... 18
Drive Cover ......................................................................................................... 19
Drive Plu ............................................................................................................ 19
Solenoid Drive Lock ............................................................................................ 20
Reader's Comments ............................................................................................................ 21
All manuals and user guides at all-guides.com
all-guides.com

vi
StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev.
List of Figures
Fi ure 1: Packa e Contents .......................................................................................... 2
Fi ure 2: DE100i-A100 Receivin Frame and Carrier .................................................. 3
Fi ure 3: Receivin Frame Front Panel ......................................................................... 4
Fi ure 4: Receivin Frame Unit ID Number and Activity Display ................................. 5
Fi ure 5: Receivin Frame Rear Panel ......................................................................... 6
Fi ure 6: Drive Carrier Circuit Board ............................................................................. 7
Fi ure 7: Drive Installation Assembly ............................................................................ 8
Fi ure 8: Master/Slave Confi uration Jumper J5 ......................................................... 9
Fi ure 9: Receivin Frame Mountin Holes ................................................................ 10
Fi ure 10: Unit ID Select Switch Location .................................................................... 11
Fi ure A-1: DE100i-A100 Physical Dimensions .............................................................. 16
Fi ure B-1: Attachin the ON/OFF Key .......................................................................... 17
Fi ure C-1: Carryin Case ............................................................................................... 18
Fi ure C-2: Full Drive Cover ............................................................................................ 19
Fi ure C-3: Drive Plu ...................................................................................................... 19
Fi ure C-4: Solenoid Mechanism .................................................................................... 20
List of Tables
Table 1: Unit ID Select Switch Settin s ........................................................................ 12
Table 2: AT/IDE Interface Si nals ................................................................................. 13
NOTICE: This User's Guide is subject to periodic updates without notice. While reason-
able efforts have been made to ensure accuracy of this document, Stor-
Case Technolo y, Inc. assumes no liability resultin from errors or omissions
in this publication, or from the use of the information contained herein.
Please check the StorCase web site at http://www.storcase.com or contact
your StorCase representative for the latest revision of this document.
All manuals and user guides at all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Introduction 1
INTRODUCTION
Packaging nformation
The StorCase Technolo y Data Express® system is shipped in a container desi ned to provide
protection and prevent dama e durin shipment. The Data Express unit was carefully
inspected before and durin the packin procedure at the factory. Bent or broken connectors,
or evidence of other dama e to the Data Express should be reported to the shipper immediately.
Refer to Fi ure 1 for the packa e contents.
If the wron Data Express model has been received, please call your reseller or StorCase at
[phone] to arran e for a Return Material Authorization (RMA). StorCase cannot ac-
cept returns which do not display an RMA number on the outside of the packa e. Return the
unit with all the ori inal packin materials.
Before removin any component from its packa in , dischar e any static electricity by
touchin a properly rounded metal object.
Serial Numbers
Both the Data Express receivin frame and carrier are labeled with serial numbers. These
numbers must be reported to the StorCase Customer Service Representative in order to
receive a Return Material Authorization (RMA) for warranty claims. Locate the serial number
labels and record the numbers in the spaces provided below.
Receiving Frame:
Drive Carrier:
All manuals and user guides at all-guides.com

StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev. C02
2Introduction
Package Contents
The DE100i-A100 packa e contents include the followin items. If any items are missin
or dama ed, contact your StorCase dealer for a replacement.
Figure 1: Package Contents
0430e
Data Express
Drive Carrier
Disk Drive
(Not Included)
Power Cable
I/O Cable
Drive Mounting
Hardware (4ea)
Phillis # 6-32 x
3/16 Flat HD
ID Select Cable
0151
Cable
Cover
(Provided)
Cable Cover
Screws (2 lcs)
# 6-32 x 3/16
Flat HD
6. Inser t Sheet
7. #6-32 Phillips Machine Hd.
Mounting Screws
8. #6-32 Phillips F.H. Mounting
Screws
. Cable Cover
2. Alignment Tool
3. Drive Lock Keys
4. Receiving Frame
5. Drive Carrier
All manuals and user guides at all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Introduction 3
GeneralDescription
NOTE: For Ultra ATA133 (133MByte/sec) operation, an Ultra ATA/133 controller and hard
drive(s), and appropriate 40-pin, 80-conductor cable are required.
The StorCase Technolo y Data Express® DE100i-A100 is a removable drive carrier and
receivin frame desi ned to provide durable and reliable mountin for 3.5 Ultra ATA133 drives
within 5.25" half-hei ht peripheral slots (Fi ure 2). It is downward-compatible with earlier
technolo y IDE drives.
The DE100i-A100 allows a drive to be removed and transported to another DE100i-A100-
equipped computer or expansion chassis, and also provides the ability to secure sensitive data
by removin and storin the drive safely for future use.
Figure 2: DE100i-A100 Receiving Frame and Carrier
This User's Guide describes the steps required to install the StorCase Data Express
DE100i-A100 removable enclosure inside a computer peripheral bay. This uide supplements
documentation provided with the host computer system, operatin system, and the drive to
be installed within the Data Express carrier.
All manuals and user guides at all-guides.com

StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev. C02
4Introduction
Figure 3: Receiving Frame Front Panel
Receiving Frame
Front
Key Lock/Drive
Power Switch
2.
Unit ID Number
Indicator
Activity Indicator
0231A
Device S in
Down/U
Timer Switch
Carrier Guide
High Insertion
Count Mating
Connector
All Steel
Receiving
Frame
ReceivingFrameFrontPanel
(Fi ure 3)
Key Lock/Drive Power Switch performs three (3) functions. The key lock
assures proper seatin of the drive carrier within the receivin frame, turns power
to the drive carrier on and off, and prevents unauthorized removal or installation of
the carrier. For the computer to access data on the DE100i-A100 drive, the key must
be turned counterclock ise to the locked position.
Unit ID Number Display (Fi ure 4) shows the physical address of the DE100i-A100
drive carrier when the carrier is Installed and Locked in the receivin frame or
Removed from the receivin frame. If the drive carrier is Installed but Not Locked,
a "u" will be displayed. The unit ID number is selected by means of the unit ID select
switch located inside the receivin frame usin a special ali nment tool supplied with
the DE100i-A100. This procedure is explained later durin the installation process.
Activity Indicator is a small dot next to the Unit ID Number which flashes when the
host computer is accessin data on the DE100i-A100 carrier. Refer to Fi ure 6 on
pa e 7 and section "Drive Activity Indicator Connector (J5)" on pa e 8 for further
information.
Device Spin Down/Up Timer may be disabled by removin Jumper J6 P1-P2
(Fi ure 5). This feature allows the receivin frame unit number display to provide
a visual indication of drive spin down/up activity.
All manuals and user guides at all-guides.com
all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Introduction 5
ReceivingFrameRearPanel
(Fi ure 5)
 DC Power Connector (J3): The DE100i-A100 uses a standard 4-pin DC Power
Connector to accept DC power.
 I/O Connector (J2): The input/output connector provides a standard interface for
all IDE si nals. See Table 3 on pa e 13 for J2 pin assi nments.
 Master/Slave Selection Jumper (J5): Master Drive confi uration (default).
Forces master drive confi uration on receivin frame. Chan e jumper to set slave
drive confi uration. Refer to Table 1 on pa e 12 for further information.
Device Spin Down/Up Timer Jumper (J6): Jumper installed (Factory Default)
enables device spin down/up visual indicator. Receivin frame unit ID number
display (Fi ure 4) will flash to indicate device spin down/up.
Figure 4: Receiving Frame Unit ID Number and Activity Display
All manuals and user guides at all-guides.com

StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev. C02
6Introduction
Figure 5: Receiving Frame Rear Panel
All manuals and user guides at all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Installation 7
Figure 6: Drive Carrier Circuit Board
INSTALLATION
nstallingtheDriveintotheCarrier
NOTE: A #2 Phillips screwdriver will be required durin this procedure.
While performin the steps in this section, work on a soft surface to prevent excessive shock
to the drive bein installed. Also refer to the manufacturer's documentation provided with the
drive.
1. Remove the drive from its protective packa in .
2. Plastic Drive Bezel: If the drive came equipped with a plastic front bezel, it must
be removed before installin the drive into the drive carrier.
3. Master/Slave Drive Selection: In most cases, the drive will be factory-confi ured
as a Master Ultra ATA133 drive usin a jumper plu on the drive itself. No con-
fi uration chan es are required. For multiple drive confi urations, it is necessary
to set the first Ultra ATA133 drive as Master and the second Ultra ATA133 drive to
Slave. This can be done by chan in the jumper on the Ultra ATA133 drive itself
(refer to your drive manufacturer documentation for further information).
Drive Activity Indicator Connector J5 (Drive Carrier Circuit Board)
Jumper removed (factory default) disables drive activity indicator (Fi ure 4).
Jumper installed enables drive activity indicator.
NOTE: If two (2) drives are installed (with J5 enabled on both drives), both drive activity
indicators will flash simultaneously, even if only one drive is bein accessed.
All manuals and user guides at all-guides.com

8Installation
StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev. C02
nstallation
1. Attach the I/O cable on the drive carrier circuit board to the drive. Refer to Fi ure
7 for an illustration of the installation process.
2. Attach the power cable on the drive carrier circuit board to the drive. Carefully insert
the drive into the drive carrier at an an le, cable-end first. Make sure none of
the cables are pinched. Lower the front of the drive carefully into place. Fasten
the drive into the carrier with the four (4) screws provided as shown in Fi ure 7.
3. Install the provided cable cover.
Figure 7: Drive Installation Assembly
All manuals and user guides at all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Installation 9
nstallingtheReceivingFrame
The drive should be installed into the carrier before installin the receivin frame into the
mountin bay of a computer or expansion chassis.
NOTE: Use a #2 Phillips screwdriver for this procedure.
1. Turn OFF power to the computer.
2. Open the computer system accordin to the manufacturers instructions. If neces-
sary, temporarily remove any expansion boards that may make installation difficult.
3. Select the Master/Slave confi uration on the rear of the receivin frame by placin
a jumper on the appropriate (J5) pins (Fi ure 8). Remove the jumper if you wish
to use the Unit ID Select switch on the receivin frame to confi ure the Master/Slave
drive selection. Refer to Table 1 for further information.
NOTE: The unit ID select switch confi ures the unit ID display only. The
master/slave settin on must still be set on the drive itself (refer to the
drive manufacturer's documentation for further information).
0423A
Slave Drive Select
Master Drive Select
(Factory Default)
J5
4. With the drive carrier locked in place inside the receivin frame, install the
DE100i-A100 into the 5.25 drive openin in the computer or expansion chassis. Use
the appropriate uides to position the Data Express, and fasten it into place with the
four (4) #6-32 Phillips screws provided. Fi ure 9 illustrates the location of the
mountin holes. Mountin holes are provided on each side and the bottom of the
receivin frame to accommodate a variety of mountin confi urations. Use the
mountin holes which best suit the computer or expansion chassis confi uration.
Note that bottom mountin holes require self-tappin screws (not provided).
5. Adjust the front of the receivin frame so the carrier slides freely in and out on the
receivin frame uides. The position of adjoinin peripheral units may require ad-
justment.
Figure 8: Master/Slave Configuration Jumper J5
All manuals and user guides at all-guides.com
all-guides.com

10 Installation
StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev. C02
Mounting
Holes (Right)
Mounting
Holes (Bottom)
Front of Unit
Mounting
Holes (Left)
0086
Figure 9: Receiving Frame Mounting Holes
6. Connect the I/O cable from the host adapter to the receivin frame. The Pin 1 i n d ic at or
on the cable must be properly ali ned. Refer to Fi ure 5 for the correct Pin 1 location.
7. Connect the power cable from the DC power supply in the computer or expansion
chassis to the power connector on the DE100i-A100 receivin frame. Refer to
Fi ure 5 for the DE100i-A100 receivin frame power connector location.
8. Replace any expansion boards that may have been removed earlier. Replace the
system cover accordin to the manufacturers instructions.
9. Reconnect any system or peripheral cables removed earlier.
10. Turn ON power to the computer. If the installation has been successful, and all the
cables have been properly attached, the system should boot normally. Althou h the
computer may not reco nize the DE100i-A100 yet, the front panel display on the
DE100i-A100 receivin frame should illuminate.
11. The new drive may need to be formatted or initialized prior to use with the operatin
system and applications software. Refer to the drive and/or computer manufacturer's
documentation for formattin information.
SelectingtheUnit D Number
1. Verify that power is turned ON to the DE100i-A100 receivin frame by turnin on
your computer. A number will appear in the unit ID display window if the carrier is
locked in place.
2. Unlock the DE100i-A100 drive carrier and remove it from the receivin frame. A "u"
will be displayed initially when the unit is unlocked but will return to a number when
the carrier is removed from the receivin frame.
All manuals and user guides at all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Installation 11
Figure 10: Unit ID Select S itch Location
WARNING: Unlockin the carrier unit switches DC power off to the drive. Since
disk drives require a short amount of time to spin down, allow about
15 seconds before pullin the carrier unit out of the receivin frame
to avoid possible dama e to the drive.
3. Use the ali nment tool supplied with the DE100i-A100 to select the ID number of the
disk drive. Refer to Fi ure 10 for the location of the ID Select Switch inside the
receivin frame. Table 2 lists the valid unit ID numbers available for the drive.
4. After you have selected an appropriate unit number, replace the DE100i-A100
carrier in the receivin frame, and LOCK IT IN PLACE.
NOTE: The lock on the DE100i-A100 receivin frame functions as a lock and
a DC power switch for the carrier unit. The lock must be en a ed
in order to supply power to the carrier and installed drive.
5. Reboot the computer. The new disk is now ready for use, althou h it may have to
be formatted or initialized prior to use with your operatin system and applications
software.
Drive Carrier
Guide
Receiving
Frame
Unit ID Select
Rotating Switch
Drive Carrier
(removed)
Unit ID
Number
Dis lay
Lock
and DC
Power
Switch Front of Unit
0087
All manuals and user guides at all-guides.com

12 Installation
StorCase Technolo y, Inc. DE100i-A100 User's Guide - Rev. C02
Unit D Select Switch Settings
The followin table lists the Unit ID Select Switch settin s and the valid AT/IDE unit numbers.
Please note that all invalid switch settin s have X's throu h them and result in a blank display
in the receivin frame display window.
Table 1: Unit ID Select Switch Settings
NOTE: The unit ID number display is for ID display purposes only. The master/slave
settin must still be set on the drive itself (refer to the drive manufacturer's
documentation for further information).
Unit ID Select
Position
Ultra ATA/100
Drive
Unit ID Number
Display
(with both jumpers
removed from J5)
Drive
Selection
05321876 9
12
0
Master Slave Master Slave
Bla k 1 Bla kBla k 2 3
12
Bla k Bla kBla k
824
All manuals and user guides at all-guides.com

DE100i-A100 User's Guide - Rev. C02 StorCase Technolo y, Inc.
Installation 13
Table 2: AT/IDE Interface Signals
The I/O connector (J2) pin assi nments are as follows:
/O Connector J2
Pin Signal I/O Pin Signal I/O
01 Host Reset- O 02 Ground
03 Host Data 7 I/O 04 Host Data 8 I/O
05 Host Data 6 I/O 06 Host Data 9 I/O
07 Host Data 5 I/O 08 Host Data 10 I/O
09 Host Data 4 I/O 10 Host Data 11 I/O
11 Host Data 3 I/O 12 Host Data 12 I/O
13 Host Data 2 I/O 14 Host Data 13 I/O
15 Host Data 1 I/O 16 Host Data 14 I/O
17 Host Data 0 I/O 18 Host Data 15 I/O
19 Ground 20 Key No Pin
21 DMARQ O 22 Ground
23 DIOW- O 24 Ground
25 DIOR- O 26 Ground
27 Reserved 28 Reserved
29 Reserved 30 Ground
31 IRQ 14 I 32 Host IO16-(AT) I
33 Host ADDR 1 O 34 PDIAG- (16) Notes
35 Host ADDR 0 O 36 Host ADDR 2 O
37 Host CS0- O 38 Host CS1- O
39 DASP- Notes 40 Ground
- Indicates an active-low si nal.
Si nal direction is with respect to the host.
"I" indicates To the host
"O" indicates From the host
The /PDIAG and /DASP si nals are used for communication between master, slave, and the
host.
All manuals and user guides at all-guides.com
