Kirisun DSJ-K9 User manual

DSJ-K9 Smart Device
DSJ-K9 Smart Device
User Manual
Dear Customer
We are very grateful for your purchasing Kirisun DSJ-K9 smart device. We believe the product can
bring great convenience to your work.
This smart device applies advanced technology and sophisticated techniques. We believe the
quality and features can be satisfying to you.

DSJ-K9 Smart Device
1
Notice
◆Please carefully read the user manual before using the product for your easy operation. We will
consider that you have read this manual when you use the product.
◆Please properly keep this manual for your future reference or for other users.
◆Relevant intellectual property rights of all parts including accessories of the product belongs to us
or its authorized parties. Any design or materials must not be copied, imitated, extracted or translated
without our authorization or our authorized parties.
◆Due to the update or modification of the product, we own the right to change the specifications of
software and hardware described in this manual without further notice. Specifications and information
contained in this manual are for reference only.
◆All the words are carefully proofread but mistake may be inevitable. We reserve the rights to final
interpretation.

User Manual
2
Safety Precaution
To prevent damaging the device and to prevent injury to others or yourself, please carefully read the notice
below before using the product and put these safety instructions within reach of others or yourself.
◆Please do not try to disassemble or modify the product.
◆Please do not use the product in the flammable or explosive atmosphere.
◆Please do not place the product anywhere near the heating device or at the place of extremely abundant
dust, damp or water splash. Pay attention to the notice below when charging with power adaptor:
◆Please use the power adaptor offered or sold by us.
◆Please keep the metal part of the power adaptor plug dry and clean. Failure to comply may lead to fire or
electric shock.
◆Please do not use power adaptor in thunderstorm. Failure to comply may lead to electric shock.
◆Please do not try to damage, modify and repair the power adaptor, nor heat the BWC or place it anywhere
near open fire.
◆Please use the USB cable offered or sold by us.
◆Non-technician must not try to repair the product or its accessories

DSJ-K9 Smart Device
3
Contents
1 Unpacking....................................................................................................................................................5
1.1 Supplied Accessories............................................................................................................................. 5
1.2 Optional Accessories..............................................................................................................................6
2 Introduction..................................................................................................................................................7
3 Basic Operation.......................................................................................................................................... 8
3.1 Power Key................................................................................................................................................8
3.2 Touch Operation..................................................................................................................................... 9
3.3 Operation Indication............................................................................................................................. 10
3.4 Charging Indication...............................................................................................................................10
3.5 PTT Key................................................................................................................................................. 10
3.6 Video REC Switch................................................................................................................................ 10
3.7 Audio REC Key..................................................................................................................................... 11
3.8 One-Shot/Multi-Shot Key.....................................................................................................................11

User Manual
4
3.9 White LED Lamp...................................................................................................................................12
3.10 Mic.........................................................................................................................................................12
3.11 Rotary Camera....................................................................................................................................12
3.12 SIM Card..............................................................................................................................................12
3.13 USB.......................................................................................................................................................13
3.14 Pogo Pin Connector........................................................................................................................... 13
3.15 Speaker................................................................................................................................................13
3.16 Display Screen....................................................................................................................................13
3.17 File Playback....................................................................................................................................... 13
3.18 Settings................................................................................................................................................ 14
3.19 GPS/BDS Positioning........................................................................................................................ 15
3.20 Replacing the Battery.........................................................................................................................16
4 Troubleshooting........................................................................................................................................17
5 Maintenance and Cleaning.....................................................................................................................18

DSJ-K9 Smart Device
5
1Unpacking
Please carefully open the package and check if the items listed below are included. Please contact your
local dealer for anything lost or damaged.
1.1 Supplied Accessories
Item Quantity
Smart Device 1
Power Adaptor 1
USB Cable 1
Belt Clip 1
User Manual 1
Certificate of Quality 1

User Manual
6
1.2 Optional Accessories
Item Quantity
Car Charger 1
Power Bank 1
Mounting Base 1
Bracket 1
Magnetic Charger 1

DSJ-K9 Smart Device
7
2Introduction

User Manual
8
3Basic Operation
3.1 Power Key
Power On
Press and hold the Power key to power on the device, and the login interface will be displayed. Enter a
user name and a password, and then click Login.After login, the main interface will be displayed.
Screen On/Off
Press the Power key to turn on/off the screen.
Power Off
To power off the device, press the Power key and hold
for 2 seconds, and then tap the screen as instructed.
Note:
The device has 2 sets multiple user management.
Normal user: The user name is ID1. The password is
123456 by default, which can be modified through the
DSJ-K9 PC software. Maximum 5 user IDs (ID1, ID2, ID3,
ID4 and ID5) can share this account. Different users have
different passwords.

DSJ-K9 Smart Device
9
Administrator: The user name is admin. The password is 456789 by default, which can be reset through
the DSJ-K9 PC software. After login with this account, the device time, administrator’s and normal users’
passwords, department name, department number, user name, device No., loop video, GPS on/off and
copy data can also be set through the software.
3.2 Touch Operation
Main Interface Setting Interface Playback Interface Application Interface Dial Interface Media Interface

User Manual
10
3.3 Operation Indication
The green indicator glows after the device is powered on.
The red indicator flashes once when a photo is taken, and
keeps flashing when a video is taken. The yellow indicator
keeps flashing during voice recording.
3.4 Charging Indication
The red indicator glows during charging, and the green
indicator glows after the battery is fully charged.
3.5 PTT Key
You can have talk and dispatch by logging in to the Smart
Dispatching software and then holding down the PTT key.
You can make an emergency call to an SOS contact by
pressing the User Definable key and holding for seconds.
3.6 Video REC Switch
In preview mode, slide the Video REC switch to one
end to start recording video, and the red indicator light

DSJ-K9 Smart Device
11
keeps flashing during recording. To stop recording and save the video, press this key again.
Note:
During recording, you can mark the video as important by pressing the Audio REC key and holding for
seconds.
In preview mode, you can set the followings.
Video Resolution: 1920*1080/1280*720/848*480 ppi
Video time: 5/10/30 min
Pre-Recording/Prolonged Recording: 3s/5s/10s/20s/30s/off.
3.7 Audio REC Key
In preview mode, press the Audio REC key to start recording voice, and the yellow indicator light keeps
flashing during recording. To stop recording and save the file, press the key ag
3.8 One-Shot/Multi-Shot Key
In preview mode, press the One-Shot/Multi-Shot key to take and save a photo. The red indicator light
flashes once.
In preview mode, you can set the followings.

User Manual
12
Image Resolution: 2560*1440/3264*2448/3968*2976/ 4736*3552/6528*4896 ppi
Photographing Mode: One-shot
Quick Multi-Shot: 5/10/20 shots
Shooting Interval: 2/3/5/10/20/30s
Timed Shooting: 5/10/15/30s
3.9 White LED Lamp
In preview mode, you can have the white LED lamp icon displayed by tapping the Lamp On/Off drop-down
menu as shown in the figure below.
3.10 Mic
The microphone is for sound collection during voice communication.
3.11 Rotary Camera
You can use the rotary camera to take a photo or video or have a video call.
3.12 SIM Card
The device supports a Nano-SIM card and six-mode 4G operation.

DSJ-K9 Smart Device
13
Supported Networks: 2G, 3G and 4G (TDD-LTE and FDD-LTE) networks.
3.13 USB
Plug in USB cable to exchange data between the device and a computer, or to charge the battery.
3.14 Pogo Pin Connector
You can charge the radio, or connect it to a PC or a USB camera via the pogo pin connector.
3.15 Speaker
The speaker outputs sound when you play an audio or a video file.
3.16 Display Screen
The device applies a 3.1’’ HD touch screen, on which you can play back image, audio and video files and
perform touch operation.
3.17 File Playback
You can play back an audio or video file by tapping the File Playback icon or a shortcut key in preview
mode.

User Manual
14
3.18 Settings
Network Settings: Wi-Fi, GPS positioning, Bluetooth, mobile data, BT shoulder lamp, NFC and APN.
Device Settings: Brightness, power saving mode, alarm clock, sound, SOS contact, data acquisition, voice
announcement, operation indicator and loop video.
System Settings: System info, date and time, language and screen on/off.
—— Browse
Browse ——

DSJ-K9 Smart Device
15
3.19 GPS/BDS Positioning
The built-in GPS/BDS modules realize global positioning, location reporting and track playback.
Note:
To
Location reporting and track playback is achieved by the device together with the Smart Dispatching
software.

User Manual
16
You may view the location and track of the device on the dispatching management platform.
3.20 Replacing the Battery
To replace the battery, move the battery latch in the direction as indicated in ①below, and then pull the
Latch handle upwards to open the battery cover.

DSJ-K9 Smart Device
17
4Troubleshooting
Failure Diagnosis Solution
Power-on
failure
Low Battery Charge it for 4 hours.
Damaged Power key Please obtain service from our authorized maintenance
station in your region or contact us.
The
computer
cannot
identify
device
Not logged in to the
PC software
After connecting the device to a PC using the USB cable,
please enter the password at the PC software to log in.
Bad data cable Change the data cable.
USB driver installed
improperly
Install the USB driver again.
Files cannot
be deleted
Insufficient account
permission
Under normal user account, only file reading is allowed.
To modify or delete files, please log in with the
administrator account.

User Manual
18
5Maintenance and Cleaning
The device adapts to harsh environments, but the operation standards and maintenance should be
complied with daily use to achieve its optimal performance.
◆Carefully protect the lens, all the moveable parts and screen as they are inclined to damage due to the
material and structure design requirements. Do not handle with force or press it. Prevent glass scratch if
the display screen is damaged and prevent the liquid of the screen touching the skin, eyes or mouth.
◆Battery
Please check the battery level before taking the product out in the field and charge it before hand if
necessary.
Stop the charging once the battery is full or the battery performance will be affected.
◆Cleaning
Lens: The lens and glass are vulnerable, so try to keep your hands off them. You can use balloon blow to
remove dust or lint. For stains which cannot be removed. You can use a clean soft cloth to wipe the lens
outwards from its center.
