Kirsch ESSENTIAL-100 User manual

Philipp Kirsch GmbH ● D-77652 Offenburg ● Okenstraße 103
Tel.: [phone] ● Fax: [phone] ● [email protected] ● www.kirsch-medical.com
Company certified according to ISO 9001:2008 by TÜV SÜD Management Service GmbH
Translation of Original Operating Instructions
for the following products:
ESSENTIAL-100
ESSENTIAL-280
ESSENTIAL-460
ESSENTIAL-700

Page 2
Contents
Important information...................................................................................................................................................... 2
1. General functional description.................................................................................................................................... 3
2. Proper use ................................................................................................................................................................. 3
3. Safety information...................................................................................................................................................... 3
Transport and set-up.............................................................................................................................................. 3
Commissioning and operation................................................................................................................................ 4
Temporary decommissioning................................................................................................................................. 5
Disposal of obsolete devices.................................................................................................................................. 5
4. Overview of device control and display unit ............................................................................................................... 6
5. Commissioning........................................................................................................................................................... 6
6. Alarms........................................................................................................................................................................ 8
7. Modifying temperature setting and temperature warning limits:................................................................................. 9
8. Error and status messages ...................................................................................................................................... 10
EC Declaration of Conformity....................................................................................................................................... 11
Important information
Important information
Read and observe the information contained in the following Translation of the Original Operating Instructions in order to
avoid personal injuries (e.g. suffocation, electric shocks) and property damage (e.g. fire, short circuits). Store this
Translation of the Original Operating Instructions at the device's location. This document serves as an information
source for all users to avoid damage.

Page 3
1. General functional description
Thank you very much for choosing KIRSCH. Our refrigerator controllers and freezers offer the highest possible
reliability, minimal temperature differences and user-friendly operation thanks to:
A particularly thick insulated interior,
A refrigerating machine with interior evaporator for cooling,
A blower and air conduction in the interior,
An electronic temperature controller,
Electronic monitoring. This monitoring provides a visual and audible alarm in the case of the faults stated
hereinafter.
2. Proper use
KIRSCH refrigerators are only for commercial cold storage, not for domestic application.
3. Safety information
Transport and set-up
You may transport the device in motor-powered vehicles both standing up or on its side. If the device is
transported to its set-up location on its side, you may commission the device one hour after set-up at the ear-
liest. This allows the refrigerant to become correctly distributed in the refrigerant circuit again.
Note during transport and set-up that some devices are top-heavy. If the inclination angle is too great (greater
than 10 degrees), there is a risk of tipping!
Always transport the device on a pallet toprevent the (model-specific) defrost water receptacle from sustaining
damage!
Set up the device in a dry, well-ventilated location away from sources of heat. All refrigerators fulfil climate
category SN and ST, and can therefore be operated at ambient temperatures of +10°C to +38°C.
Ensure that children cannot access the device. After you have successfully set up the device, remove the key
from the door lock to prevent staff becoming locked in or suffocated.
Do not leave packaging material unattended. Plastic foil, plastic bags, cardboard packaging, polystyrene, etc.
can become dangerous toys for children. Danger of suffocation!
The device must stand in a fixed and level position. On devices with adjustable feet, adjust these feet to suit the
floor.
The connection cable must not contain kinks or be trapped. You must not operate devices with a faulty con-
nection cable! If this is the case, contact customer services.
The device must be sufficiently ventilated. The device will not function without sufficient ventilation. Fire haz-
ard!
oDo not set up devices immediately adjacent to one another. Minimum clearance: 2 cm.
oOn devices with a refrigerating machine installed underneath, adhere to the minimum wall clearance
as designated by the spacer. Never cover the ventilation slits.
oOn some models, inlet air and exhaust air flows through the ventilation slits at the front. Therefore, do
not block or face these slits with objects.
oDo not cover devices with a refrigerating machine located at the top.
oIf the device is to be installed, this work must be carried out by qualified personnel only. Always en-
sure that the refrigerating machine is sufficiently ventilated. Enquire at KIRSCH, if necessary.

Page 4
Device weights:
MODEL
Weight
net
net
net
ESSENTIAL-100
45 kg
52 kg
+ 5 kg
ESSENTIAL-280
73kg
85 kg
+ 7 kg
ESSENTIAL-460
109 kg
122kg
+ 10 kg
ESSENTIAL-700
146 kg
174 kg
+ 20 kg
Commissioning and operation
Do not commission a device that hasbeen damaged during transport or set-up. If in doubt, contact the supplier.
Do not damage parts of the refrigerant circuit. If the evaporator pipes are pierced by a sharpobject, other pipes
become kinked, or the surface finish is scratched off, refrigerant spraying out can cause eye injuries.
Connecting the device
oThe electrical connection conditions must match those stated on the type plate of the refrigerating
machine.
oKIRSCH refrigerating machines and freezers are ready-to-plug-in devices, operate at 220-240 volts
and at 50 or 60 Hz alternating current, depending on the model. Special designs that deviate from
these specifications are available; refer to the type plate in the upper right of the interior!
oConnect the device using a correctly installed plug with an earth connection.
oFuse: 10 amp.
oKIRSCH refrigerating machines and freezers are designed according to protection class I.
Cleaning
oClean the interior and exterior of the device before commissioning and at regular intervals thereafter.
oBefore you clean the device, switch it off and pull out the mains plug.
oCleaning water must not enter the electrical components.
oClean the interior container and equipment with warm water and some mild detergent. Cleaning
agents containing sand or acid, or chemical solutions are unsuitable.
oWipe down the door seal with clear water and rub this dry thoroughly.
oYou can remove drawers and wire shelves for cleaning.
oTreat white-coated exterior housing with a paint cleaner and care product. Treat stainless-steel ex-
terior housing with a stainless-steel cleaner and care product.
oTo ensure that the refrigerating machine's performance is not affected by dust, clean the condenser
with a brush or vacuum cleaner as appropriate according to the build-up of dust but at least every 6
months. The condenser is a black wire part, located on the external back wall or in the motor area,
depending on the model.
Maintenance
oKIRSCH refrigerating machines and freezers are maintenance-free.
oHowever, observe the prior section entitled "Cleaning".

Page 5
Repair
oRepairs and modifications must be carried out by expert personnel only. Improper repairs and modi-
fications can lead to severe personal injuries (e.g. electric shocks) or damage to property (e.g. fire,
damage of goods to be cooled).
oIf the device malfunctions, switch it off and pull out the mains plug.
Observe the maximum load of the drawers and shelves: 100 kg/m². If the load-bearing system breaks as a
result of these loads being exceeded, this can lead to personal injuries depending on the goods being cooled!
Store the keys for the door where only authorised staff can access them.
The emission sound pressure level on all models does not exceed 70 dB(A)
Temporary decommissioning
Leave the door open in order to avoid the formation of odours and mould inside. Observe the section entitled
"Cleaning".
Remove the key from the door lock and store it out of the reach of children.
Also observe the points entitled "Switching on" and "Switching off" in section 5"Commissioning".
Disposal of obsolete devices
Immediately render obsolete devices unusable. Pull out the mains plug and disconnect the connection cable.
Remove or destroy locks to prevent children from locking themselves in while playing, as this could be fatal.
Remove the door, if possible.
If your model is equipped with a battery, dispose of this in the proper manner at the designated disposal point.
Ensure that the battery is not damaged, burnt or short-circuited. Risk of explosion!
Contact your municipal waste disposal office for details of how to dispose of the device correctly. Ensure that
the refrigerating machine's pipes do not become damaged.

Page 6
4. Overview of device control and display unit
Device ON/OFF
Display
Cursor UP-button
Additional defrost
(Press button for min.4 seconds)
Light button (LED-strip optional)
Alarm OFF / Cursor DOWN-button
Diode illuminated during alarm
Diode illuminated when defrosting is in progress
Call set interior temperature
5. Commissioning
Before commissioning, observe the safety information from section 3 on set-up, operation, temporary decommis-
sioning and final decommissioning.
Switching ON:
oTo switch device ON, press button (1). Interior temperature will be shown on display (2)
oPush button (9) to call set of interior temperatur..
Information
After you have switched on the device, the temperature alarm is activated after the target temperature has been
achieved or after 2 hours, at the latest.
Switching OFF:
oTo switch device OFF, press button (1) for min. 6 seconds.
oIf the device is still connected to the power supply, "OFF" is shown in the display (2).
Switching OFF (with battery option)
oTo switch device OFF, press button (1) for min. 6 seconds.
oIf the device is still connected to the power supply, "OFF" is shown in the display (2).
oAfter disconnection from power supply, optical (diode 7) and acoustical warning will be effected, this
can be quit by pressing button(6) two times. First time toquit acoustical warning, a second time to quit
optical warning.

Page 7
Battery for network-independent warning (optional):
oServes the warning facility for approx. 72 hours in the case of power failure.
oThe battery is monitored by charging automation.
oWhen the "Acc" error message is displayed, replace the battery.
oTechnical data: Battery: 6 V, 4 A
Important Information
After disconnection from power supply the battery has to be switched off by pressing button (6) two times. Otherwise
battery wil be completely discharged.
Connect to central process control:
oConnect to the remote warning system (e.g. GSM module) via the floating alarm contact "X10" (tri-
ple-pole change-over contact). The contact is located on the connection terminal, fitted on model
ESSENTIAL-700 at the top behind the display, otherwise on the rear of the device.
oThe contact switches in alarm state (see section 6). The "door open" alarm is not forwarded.
oThe contact is designed for a maximum of 42 V, 1 A.
Loading:
oWhen the operating temperature has been achieved, you may load the device.
oAfter the door has been closed, a vacuum is created in the interior due to the forced-in external air
cooling down. Expect increased resistance when you open the door; therefore, open the door care-
fully.
Drawers (optional) and wire shelves must be height adjusted (possible on models with notch rails):
oPull out the drawer until its end stop, lift up at the front and remove. Fold up the lateral rails and pull
them out of the notched slots. If you insert the guide rails, ensure that the clevis-type nibs are fitted at
the same height on all four notch rails. Observe the notch-rail designation for this purpose.
oWire shelf with rails: The wire shelves do not have a hinge, and can be removed from the guide rails
without you lifting them. Offset the guide rails as previously described.
oWire shelf with overlays: Lift the wire shelf and remove it. Offset the overlays as described for the
guide rails.
Defrost:
oThe device defrosts automatically every 12 hours. The defrost water is directed into an externally
located pan and evaporates there automatically.
oBy pressing button (4) for approx. 4 seconds an additional defrost will be effected..
oThe yellow diode is illuminated during defrosting (8).
oDevices that are optionally supplied without defrost-water evaporation, must be inspected regularly
and the defrost-water tray must be emptied manually.

Page 8
Interior light (optional):
oOn devices with the interior light option, the light switches on automatically when you open the door.
oPress button (5) to switch permanent lighting ON or OFF.
6. Alarms
Your KIRSCH refrigerating machine is equipped with alarm functions. The alarm is triggered visually and audibly.
You are also able to forward alarms via a remote warning contact; e.g. to a KIRSCH GSM module (optional) that
sends the alarm message by text message.
Temperature alarm:
oIf the set temperature warning limits are exceeded or undercut, an audible signal sounds, the remote
warning contact is triggered, and the current temperature flashes in the display (2)
oPush button (6) to switch off the alarm sound. If the cause of the alarm is not rectified, the alarm
sounds again every 30 minutes.
oIf the alarm sound is not switched off, but the error rectifies itself, the acoustic and optical warning is
quit automatically.
oThe display (2) shows the temperature of the goods to be cooled, not the air temperature in the in-
terior. Measurements are done due to an electronic time-delay.
"Door open" alarm:
oIf you open the door for longer than 60 seconds, the audible alarm sounds, and the error message
"F7" is displayed in the display (2) in alternation with the temperature.
oAfter you close the door, the visual and audible alarm messages are cancelled.
oIf you intentionally open the door for a longer period, push button (6) to switch off the alarm sound.
oThe "door open" alarm is not forwarded via the floating contact.
Information
The "door open" alarm is not forwarded by the remote warning contact.
Power-failure warning (optional):
oIn the case of a power failure, an audible alarm sounds and diode (7) shines. The remote warning
contact is triggered and the display (2) switches off to save battery power.
oThe audible and visual alarm is automatically cancelled after the power failure has been rectified.
oYou can quit the audible alarm during the power failure by pushing button (6). The visual alarm is then
shown with diode (7), until power is re-established.
oIf you quit the alarm and power supply is not re-established within 30 minutes, an audible alarm is
activated again. The monitoring unit remains in operation for approx. 72 hours.
Also observe the information in section 8 entitled "Error and status messages".

Page 9
7. Modifying temperature setting and temperature warning limits:
The values for the operating temperature and temperature warning limits are set at the factory. You must not
change these values. The following table also contains these values. The refrigerating machine requires a certain
amount of time to cool down to the set temperature. You can read the course of the temperature on the digital
display. The operating temperature is automatically maintained irrespective of changing ambient temperatures. The
condition for this is that the ambient temperature is at least 3°C above the set interior temperature.
WARNING!
Improper modifications to the temperature setting and warning limits can lead to irreparable damage to the
goods to be cooled! If in doubt, contact our customer services!
Changing the temperature setting:
oBy pressing button (9) setted interior temperature is shown in display (2).
oTo change the interior temperature, hold down button (9) and push buttons (3) and (6) to set the
desired target temperature.
Changing the temperature warning limits:
oBy pressing button (3) and (6) as the same time for approx. 1-2seconds, the parameter (A1) appears
in display (2). Then you can change upper temperature warning limit.
oAfter that press button (9) and target temperature is shown on display (2).
oTo change warning limits hold button (9) and adjust setting by pressing button (3) or (6).
oLet go button (9) and setting are saved automatically.
o–By pressing button (3) parameter (A2) is shown in display (2), to set lower temperature limits.
oTo change warning limits hold button (9) and adjust setting by pressing button (3) or (6).
oLet go button (9) and setting are saved automatically.
Information
On all devices, set the upper temperature warning limit at least 3°C higher, and the lower temperature limit at least 3°C
lower than the set interior temperature.
MODEL
Operating
tempera-
ture
°C
Lower warning
limit
°C
Upper warning limit
°C
ESSENTIAL-100
5
1
10
ESSENTIAL-280
5
1
10
ESSENTIAL-460
5
1
10
ESSENTIAL-700
5
1
10

Page 10
8. Error and status messages
Error messages are shown in alternation with the current temperature. If several errors have occurred, they are
displayed one after another. If there is no audible alarm, the error or status message is only an indication that there
has been an error.
Display
Cause
Effect
F1L
Error refrigeration room sensor R1,
Short-circuit
Inspect sensor R1.
Inform customer services immediately
F1H
Error refrigeration room sensor R1,
Interuption
Inspect sensor R1.
Inform customer services immediately
F2L
Error refrigeration room sensor R2,
Short-circuit
Inspect sensor R2.
Inform customer services immediately
F2H
Error refrigeration room sensor R1,
Interuption
Inspect sensor R2.
Inform customer services immediately
Displayed temp. is flashing
Refrigeration room temperature is
beyond warning limits
Check temperature warning limits
Follow up if status normalizes itself after short
time. If this is not the case, there is a technical
defect. Inform customer services immediately
F7
Door-open alarm
Close the door
F8
Antifreeze
Check temperature settings
Inform customer services immediately.
Acc
Battery defective
Replace battery and insprct connection
Inform customer services immediately
Pr
Parameter have been changed
Alarm switches OFF automatically
CrC
Error in data-memory
Inform customer services immediately
EP
Error in data-memory
Inform customer services immediately
If you cannot rectify an error state immediately, transfer the goods to be cooled into another cabinet, and decommission
the device until a service technician inspects the problem.When you contact customer services, state the device's serial
number. You can find this on the type plate on the top right-hand side of the interior (see type plate example).

Page 11
EC Declaration of Conformity
Philipp Kirsch GmbH, Okenstraße 103, 77652 Offenburg, solemnly declares that the product described below
complies with the protection requirements of the stated directives and standards at the time that the product was placed
on the market.
Philipp Kirsch GmbH is responsible for the documentation.
Type designation:
1.7.3 of Directive 2006/42/EC
Manufacturer
Device category
Type
Serial numbers
KIRSCH
Refrigerator
ESSENTIAL-100
from serial number 100 28 00100 onwards
KIRSCH
Refrigerator
ESSENTIAL-280
from serial number 280 28 00100 onwards
KIRSCH
Refrigerator
ESSENTIAL-460
from serial number 460 28 00100 onwards
KIRSCH
Refrigerator
ESSENTIAL-700
from serial number 700 28 00100 onwards
Directives:
EC Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility 2004/108/EC.
Harmonised standards
EN 55014-1:2006
EN 61000-3-2:2006, EN 61000-3-3:2008
EN 62233:2008, EN 55014-2:1997+A1:2001+ A2:2008
EN 60335-2-89:2002 / A2:2007
Standards:
EN 60335-2-89: 2010
Year of CE marking (Low Voltage Directive): 2010
Offenburg, 15 June 2010
Georg Kirsch
Managing Director

Innovation and quality –since 1865
Since 1865, we have been synonymous with high-quality products fulfilling the most stringent standards and providing a
high level of reliability. Our products are used all overthe world: from the tropicsright up to the Arctic. The experience we
gain is fed continuously into our product innovations. Our policy of manufacturing our own housings enables us to
coordinate the components of our refrigerators and freezers optimally with one another. This has enabled us to become
a world leader in terms of temperature stability.
Our product range
Pharmaceutical refrigerators
Pharmaceutical freezers

Blood bank refrigerators
Blood plasma freezers

Laboratory refrigerators
Laboratory freezers

Multi-user refrigerators

Temperature documentation
Philipp Kirsch GmbH
P.O. 1840
77608 Offenburg
Tel.: [phone]
Fax: [phone]
in[email protected]
www.kirsch-medical.com
D295_04.13 Printed on 100%-recycled, CO2 -neutral manufactured paper Subject to alternations without notice
