OVEN PARTS
1
30" BUILT−IN MICROWAVE
For Model: KBHS109SSS03
(Stainless)
7−10 Litho in U.S.A. (amd) (eeb) Part No. W10206136 Rev. B
For Model: KBHS109SSS03
(Stainless)

OVEN PARTS
2
For Model: KBHS109SSS03
(Stainless)
W10206136
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8304424 Installation
Instructions
W10162181 Use & Care Guide
Tech Sheet
W10220960 English
W10220961 French
8304375 Easy Set Guide
Safer Cooking Tips
9762761 English
W10065852 French
2 4448444 Grommet,
Mounting Rail
3 8304569 Support,
Microwave Module
4 Rail,
Mounting Side
8304621BL Right
8304622BL Left
5 Side, Chassis
8304546 Right
8303539 Left
6 8304216 Base, Chassis
7
W10165447 Trim, Bottom
8 8304509 Chassis, Back
9 9760213 Transformer,
Microwave UI
10 3400832 Screw
11 4449809 Screw
12 8285593 Connector Cover
13 8303519 Cover, Top
14 8303537 Channel, Rear
15 3400893 Screw

CONTROL PANEL PARTS
3
For Model: KBHS109SSS03
(Stainless)
W10206136
Illus. Part
No. No. DESCRIPTION
1 W10165445 Panel, Control
2 9760749 Bumper, Door
3
W10169348 Bracket,
Glass Touch
4 8304334 Keyboard,
Glass Touch
5
W10118736 User Inferface
6 8303719 Backer, Control
7 8303887 Bracket,Enclosure
8 4449154 Screw
9 3400805 Screw
10 4449809 Screw

MICROWAVE DOOR PARTS
4
For Model: KBHS109SSS03
(Stainless)
W10206136
Illus. Part
No. No. DESCRIPTION
1 8304588BL Button, Plug (2)
2
W10143304 Screw
3
W10120487 Door, Microwave
4 4449154 Screw (4)
5 8303033 Bracket, Handle
6 8304454 Glass Assembly
7
W10292380 Handle, Door
8
8304603SS Badge

CABINET AND STIRRER PARTS
5
For Model: KBHS109SSS03
(Stainless)
W10206136

CABINET AND STIRRER PARTS
6
For Model: KBHS109SSS03
(Stainless)
W10206136
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10120227 Control, Electric
2 8205669 Support
3
W10130892 Plate, Air
4
W10130901 Insulation, Side
Left
5
W10120471 Cover, Side Left
6
W10120223 Thermostat
7
W10120224 Element,
Convection
8 4375418 Fan
9
W10120233 Nut, Speed
10
W10130891 Holder
11
W10120220 Noise Filter
12
W10120228 Control, Electric
Converter
13
W10130909 Bracket, Support
14
W10131249 Screw
15 8205692 Transformer
16 4375427 Actuator
17 4375321 Fuse
18 4375231 Block, Fuse
19
W10130897 Bracket, Support
20 8205653 Filter, Noise
21 8205654 Thermostat
22
W10120113 Magnetron
23
W10130895 Plate, Air
24 4375319 Spring, Lamp
25 8205685 Spring
26 8205658 Housing, Lamp
27 4375348 Lamp
28
W10120222 Thermostat
29
W10131248 Switch
30 8205683 Holder, Switch
31 4375320 Reflector
32 4375318 Lens, Lamp
33
W10120231 Clip. Spring
34
W10120477 Top Vent
36 Trim, Side
W10120473 Right
W10120475 Left
37
W10120469 Bushing
38
W10130905 Bracket, Support
39 8205708 Bracket, Support
40 8205682 Shaft, Turntable
Turntable
41 8205681 Cover, Motor
Turntable
42
W10120234 Cover
43 4375252 Gasket, Shaft
44 8205655 Motor, Turntable
45 4375202 Screw
46 8205707 Support
47
W10120478 Hinge, Door
48
W10130903 Cover, Plate
49
W10130904 Cover, Rear
50 8205680 Cover, Side Right
51
W10120221 Convection, Motor
Assmebly
52 8205721 Blower Assembly
53
W10130907 Cover, Inverter
54
W10120229 Inverter
55
W10130906 Holder, Inverter
56
W10130890 Screw
57
W10130908 Baffle, Air
58
W10130899 Plate, Air
59
W10120235 Rod, Release
60
W10120225 Sensor
61 8205685 Spring
64 8205683 Interlock
65
W10130900 Insulation
66 8205704 Spring
67
W10130902 Insulation
68 8205689 Spring
69 8205688 Arm
70 8205686 Support
71
W10120236 Arm
72
W10120470 Pin, Damper
73 8205690 Sensor
74
W10130898 Duct, Magnetron

INTERNAL MICROWAVE PARTS
7
For Model: KBHS109SSS03
(Stainless)
W10206136
Illus. Part
No. No. DESCRIPTION
1 W10120480 Crisp Plate
2
W10120484 Steamer
3 4452220 Rack, Convection
4
W10120486 Plate, Baking
5
W10120483 Rack
6 8205676 Turntable
7 8205678 Ring
8 8205677 Drive, Turn Table
9
W10120481 Handle, Pan
10
W10120226 Grill Heater
11
W10120230 Cover, Plates (2)
12
W10120232 Bracket, Mounting

OPTIONAL PARTS
8
For Model: KBHS109SSS03
(Stainless)
W10206136
Illus. Part
No. No. DESCRIPTION
OPTIONAL PARTS NOT INCLUDED
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
FOLLOWING PARTS
NOT ILLUSTRATED
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
8304442 Harness, Main
8304373 Harness,
Communication
W10237644 Connector, Flex
4450800 Screw, Ground
W10140600 Conduit
4452400 Lead, Ground Strap
