KitchenAid KBMS1454SBL0 User manual

CONTROL PARTS
1
For Models: KBMS1454SBL0, KBMS1454SWH0, KBMS1454SBT0, KBMS1454SSS0
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
BUILT−IN MICROWAVE
3−09 Litho in U.S.A. (rek) (psw) Part No. W10141727 Rev. C
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10111676 Installation
Instructions
8205301 Use & Care Guide
W10141643 Cook Guide Label
8205302 Guide−Quick
Reference
8205304 Tech Sheet
2 Panel, Control
W10141639 Black
W10141638 White
W10141640 Biscuit
W10141637 Stainless
3
W10203481 Touch, Foil
4
W10124269 Board, Display
5 8205722 Support, Control
Panel
6 8205662 Board, Selector
7 8206313 Board, Interface
8 8205739 Holder, Control
Board
9 8205657 Holder, Display
Board
10
W10170864 Ring, Knob
11
W10170865 Knob
12
W10141641 Window (Display
Filter)

CABINET PARTS
2
For Models: KBMS1454SBL0, KBMS1454SWH0, KBMS1454SBT0, KBMS1454SSS0
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
W10141727
Illus. Part
No. No. DESCRIPTION
1 Trim, Side
8205715 RH Black
8205718 RH White
8205717 RH Biscuit
8205716 RH Stainless
8205712 LH Black
8205711 LH White
8205714 LH Biscuit
8205713 LH Stainless
2 8205720 Trim, Bottom
3 8205707 Support, Bottom
4 8205708 Bracket, Bottom
5 Chassis, Side
8205674 Left
8205680 Right
6 8205709 Top Plate
7 8205710 Back, Cover

DOOR PARTS
3
For Models: KBMS1454SBL0, KBMS1454SWH0, KBMS1454SBT0, KBMS1454SSS0
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
W10141727
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Door Assembly
W10141646 Black
W10141644 White
W10141647 Biscuit
W10141649 Stainless
2 8205733 Hinge Assembly (2)
3 8205687 Sliding Arm Assy
4 8205683 Switch Holder (2)
5 4375346 Switch (3)
6 8205684 Push−Rod (2)
7 8205685 Spring Cam
8 8205689 Spring
9
W10128850 Lift Arm & Spring
10 8205686 Support
11 8205704 Spring, Torsion
12 8205789 Gasket

TOP VENTING PARTS
4
For Models: KBMS1454SBL0, KBMS1454SWH0, KBMS1454SBT0, KBMS1454SSS0
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
W10141727
Illus. Part
No. No. DESCRIPTION
1 W10141633 Air Duct
2 8205740 Air Guide
3 8205692 Transformer, Lamp
4 8205721 Motor, Fan Assy
5 8206312 Control,
Electronic
6 8205669 Holder, Control
7 8205705 Top Chassis
8 8205719 Vent, Control
Panel
9 4357202 Screw
10
W10141634 Cover−Plate

OVEN INTERIOR PARTS
5
For Models: KBMS1454SBL0, KBMS1454SWH0, KBMS1454SBT0, KBMS1454SSS0
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
W10141727
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4375321 Fuse
2 4375231 Fuse Holder
3 8205650 Magnetron
4 8205651 Screw
5 8205652 Thermostat
6
W10141630 Thermostat
7 8205653 Mains Filter
8 8205655 Turntable Motor
9 8205656 Screw
10 8205659 Thermostat, Cavity
11 8205660 Power cord
12 8205679 Spring,
Lamp Holder
13 8205658 Socket, Lamp
14 4375348 Lamp
15 4375320 Reflector
16 4375318 Lens, Lamp
17 8205671 Transformer
18 8205672 Screw
19 8205673 Reducer, Humidity
20 4375349 H.V. Diode
21
W10141631 H.V. Capacitor
22 8205690 Sensor, Humidity
23 8205675 Cover, Inlet
24 8205676 Turntable, Glass
25 8205538 Ring, Turntable
26 8205539 Driver, Turntable
27 8205682 Shaft, Turntable
28 8205681 Holder, Motor
29 4375202 Screw
30 8205788 Holder, Capacitor
31
W10120231 Clip, Spring
32
W10120234 Cover, Motor
33 4375252 Gasket, Shaft

INSTALLATION PARTS
6
For Models: KBMS1454SBL0, KBMS1454SWH0, KBMS1454SBT0, KBMS1454SSS0
(BLACK) (WHITE) (BISCUIT) (STAINLESS)
W10141727
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10170866 Bracket, Mounting
2 8205755 6 pk. screws
3 Narrow Bracket
8205756 27" Left
8205757 27" Right
4 Narrow Trim
W10170867 27" White
W10170869 27" Black
W10170871 27" Biscuit
W10170873 27" Stainless
5 Wide Bracket
8205762 30" Left
8205763 30" Right
6 Wide Trim
W10170868 30" White
W10170870 30" Black
W10170872 30" Biscuit
W10170874 30" Stainless
7 4 pk. screws
8205768 White
8205769 Black
8205770 Biscuit
8205771 Stainless
Miscellaneous
W10141642 Mounting Kit
WIRING HARNESS PARTS
8205748 Harness, Main
8205749 Harness, Sensor
8205750 Harness, Lamp
8205751 Harness, Fan &
Turntable Motor
8205752 Cable, UI Board
Selector Board
8205753 Cable, UI Board
To Elec. Control
