KitchenAid KEBS207YBL1 User manual

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 Membrane, Switch
3183529 Black
3183530 White
3183531 Almond
2 3181889 Bracket, Mounting Switch Membrane
3 3181705 Microcomputer
3179117 Screw
5 3182985 Clip, Retainer
6 3182162 Trim, Door
7 Door, Latch Handle
3182152 Black
3182155 White
3182158 Almond
8 3183703 Trim, Panel
3148443 Screw
9 3185424 Bracket
3182939 Screw
10 3182149 Frame, Control Panel
11 3184567 Clip, Control Frame
FOLLOWING PARTS NOT ILLUSTRATED
LITERATURE PARTS
LIT3182131 Tech Sheet
LIT3182137 Installation Instructions
LIT3185643 Use & Care Guide
LIT3150693 Cookbook
LIT4174291 Repair Parts List
LIT3183987 Guide-Autoset
LIT3183739 Guide-Quickset

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 3176700 Frame Front
2 307985 Pin, Hinge Ear (2)
3 309111 Snubber, Door (2)
4 308306 Pushnut (2)
5 3182031 Oven 30"
311056 Screw (3)
6 310713 Bracket, Oven Mounting (2)
343641 Screw (6)
8 3185086 Button, Plug
9 310770 Insulation Tray
3148107 Screw (2)
10 311774 Support, Side Wrapper (4)
3148107 Screw (4)
11 Side Wrapper
311005 Right Side
311008 Left Side
3148107 Screw,
12 Hinge Ear
3185662 Right Side
3185663 Left Side
13 310659 Plate (2) (Side Panel)
308544 Screw (4)
14 3185664 Channel Arm (2)
15 307986 Pin, Hinge (2)
16 307594 Retainer Ring (2)
17 308125 Anchor Spring (2)
18 308126 Spring, Oven Door (2)
19 3183792 Tube, Vent
343641 Screw, Ground
20 310839 Eliminator, Smoke
21 310662 Plate Cover
3148107 Screw (2)
22 3185197 Seal, Pyro
24 3150505 Oven Light Assy.
25 311255 Bulb, Oven Light
26 3184533 Gasket, Light
28 3183796 Baffle, Top Insulation
3148107 Screw (2)
29 3182585 Bracket, Mounting Control Frame
3179847 Screw
312713 Screw
35 310345 Switch, Door
690989 Screw
40 3184099 Cover, Top
3148107 Screw (4)
41 Side Trim
310686 Left Side
310690 Right Side
42 3182052 Panel, Back
3148107 Screw (16)
43 Trim, Center vent
3183633 Black
3183644 Aluminum
309133 Screw (3)

44 311582 Stand Off
48 311011 Cover, Rear
3148107 Screw (9)
55 309102 Bracket Stand Off
3148107 Screw
58 3182042 Bracket, Motor
3179117 Screw
FOLLOWING PARTS NOT ILLUSTRATED
INSULATION
310433 Insulation, Wrap
310435 Insulation, Oven
3149328 Insulation, Top

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 3176700 Frame, Front
2 307985 Pin, Hinge Ear (2)
3 309111 Snubber, Door (2)
4 308306 Pushnut (2)
5 3182032 Oven 30"
311056 Screw (3)
6 3185086 Button, Plug
7 310713 Bracket, Oven Mounting (2)
9 3182814 Button, Plug
10 310770 Insulation Tray
3148107 Screw (2)
11 Side Wrapper
311007 Right Side
311010 Left Side
12 311774 Support, Side Wrapper (4)
3148107 Screw (2)
13 Hinge Ear
3185662 Right Side
3185663 Left Side
14 310659 Plate, Side Panel (2)
308544 Screw (4)
15 3185664 Channel Arm (2)
17 307986 Pin Hinge
18 307594 Retainer, Ring
19 308125 Anchor, Spring (2)
20 308126 Spring, Oven Door (2)
343641 Screw
21 3182159 Tube, Vent (Lower)
22 310839 Eliminator, Smoke
3148107 Screw (2)
23 310662 Plate Cover
3148107 Screw (2)
24 3182161 Tube, Vent (Upper)
25 3183796 Baffle, Top
26 3184533 Gasket, Light Insulation
3150532 Screw (4)
27 3150505 Oven Light Assy.
28 311255 Bulb, Oven Light
29 310345 Switch, Door
30 3185197 Seal, Door
31 3182052 Panel, Back
3148107 Screw (6)
32 255095 Angle Support (2)
3148107 Screw (6)
33 Side Trim
310685 Left Side
310689 Right Side
3148107 Screw (14)
338156 Screw, Chrome
34 Grill, Bottom
3150349 Black
3150350 White
3150351 Almond
309029 Screw, 8-15 x 1/2 Black (3)

35 311592 Angle Support (2)
37 310458 Cover, Bottom
3148107 Screw (4)
41 311013 Cover, Rear
3148107 Screw (11)
FOLLOWING PARTS NOT ILLUSTRATED
INSULATION
310433 Insulation, Wrap
310435 Insulation, Oven

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 3182045 Mounting Plate
2 4173193 Screw (3)
3 4173194 Lockwasher (3)
5 4173237 Nut(Left Hand)
6 4173236 Fan
7 3183220 Motor
8 4173238 E-Ring
10 4173230 Flatwasher
11 3181750 Bracket, Guard
12 3179790 Gasket, Foam

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 3183948 Baffle, Vent Mtg.
2 3184673 Block, Terminal
308043 Screw
112432 Nut, Hex (3)
4 3183784 Switch, Latch
98106 Screw
5 309245 Insulator, Switch
6 313035 Shield, Terminal
309258 Screw (2)
7 Handle, Latch
3184002 Upper Oven
3183637 Lower Oven
308422 Screw (2)
8 3184039 Knob, Latch
3183294 Screw
10 3183800 Latch Assembly
13 3183954 Nozzle, Vent Bottom
14 3183955 Nozzle, Vent Top
300890 Screw
15 3184078 Box, Vent
4173231 Screw
16 3183964 End, Vent Box
300890 Screw
17 3183533 Bracket, Mounting Fan
3177991 Screw
18 3183720 Blower, Fan
19 3183792 Tube, Vent
343641 Screw
20 3149650 SPST Thermostat
3148443 Screw
23 3183965 End, Vent Box Lower Oven
24 3183793 Tube, Vent Lower Oven
3148443 Screw
25 3183532 Clamp, Tube
3148443 Screw
26 3183949 Extension, Baffle
3148107 Screw

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 3172218 Liner, Door
3182346 Screw (5)
3 3148441 Seal, Flange (2)
4 3169202 Glass, Clear
3148443 Screw (4)
5 3148183 Seal, Door
6 3148159 Retainer,
7 3169203 Glass, Inner & Outer
8 3148187 Retainer, Glass (2)
9 3148182 Bumper (4)
10 Glass, Panel
3148185 Black
3150347 White
3150348 Almond
11 3148184 Foil, Door
12 Handle, Door
3183402 Black
3183403 White
3183404 Almond
355515 Screw (4)
13 3148680 Shield, Door
254225 Screw (2)
14 Top, Door
3148223 Black Model
3149355 White/Almond Model
355515 Screw (4)
15 3148282 Clip, Mtg. (2)
16 3148234 Frame, Inner
3148443 Screw (6)
19 3148235 Frame, Panel
20 3147951 Insulation, Door
21 3181363 Cap, Top

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 Liner, Oven
3182032 Self Clean
3182031 Convection
2 3182451 Element, Broil
3150532 Screw
3 3181534 Rack, Roaster
4 3181639 Rack, Offset
5 3147563 Grill, Broiler
6 3147845 Pan, Broiler
7 661416 Element, Bake
3150532 Screw (2)
8 4167277 Nut, Meat Probe
9 4163975 Gasket, Meat Probe
10 4167266 Probe Cover
11 3181638 Rack, Straight Oven
12 3179672 Spacer - Tubing
13 3150107 Meat Probe Jack
14 3150144 Meat Probe
15 313570 Clip, Tubing
19 3181724 Cover, Fan
3179117 Screw
20 3183003 Element, Convect.
23 3180694 Bracket, Element
3150532 Screw
25 3148440 Sensor, Heat
3148107 Screw

1 3183985 Wire Harness Upper Oven
2 3184033 Wire Harness Lower Oven
3 3183751 Wire Harness Lower Oven Light
5 3183361 Harness, Wire Lower Latch
6 98997 Harness, Clip
7 313438 Clip
246132 Screw
