KitchenAid KEBS277DBL12 User manual

OVEN PARTS
1
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
7−01 Litho in U.S.A.(cre) Part No. 8185844
27" BUILT−IN ELECTRIC
DOUBLE OVEN
THERMAL CONVECTION
SELF−CLEAN

OVEN PARTS
2
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
8185844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Literature Parts
LIT8300655 Installation
Instructions
LIT8300664 Use & Care Guide
(Oven)
LIT4451879 Tech Sheet (Oven)
LIT4449264 Easy Set Guide
LIT3191638 Safer Cooking Tips
2 Trim, Side
4450850 RH Black
4450851 RH White
4452122 RH Biscuit
4450853 LH Black
4450854 LH White
4452123 LH Biscuit
8281236 Screw
3 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
4 4448520 Bumper, Door
6 4452200 Divider, Vent
4449809 Screw
7 4455285 Top Chassis
4449809 Screw
8 4452260 Spacer, Foam
9 4452158 Tube, Vent
3196176 Screw
10 4452163 Lens, Light
11 4448972 Oven Light Assy
4449748 Screw
12 4452164 Bulb, Light
14 4455611 Frame, Front
4449040 Screw
4450118 Nut
15 4455381 Gasket, Door
19 4451477 Support, Insulation
4449809 Screw
20 4451605 Cap, Spacer
21 Rail, Side
4450581 Right Side
4450582 Left Side
4448444 Grommet
4449154 Screw
22 4451896 Latch Assy
23 4452224 Solenoid
24 4452312 Micro Switch N.C.
4449154 Screw
25 4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26 4452233 Back, Chassis
4449809 Screw
27 Liner, Oven
(Not serviceable)
28 4451426 Switch, Micro
29 4455636 Sensor
4449154 Screw
30 4451537 Spring, Latch
33 4450280 Deflector, Vent
34 4452266 Vent, Center
3400832 Screw
37 4452223 Thermostat (TOD)
4449809 Screw
43 4455529 Base, Chassis
4449809 Screw
49 4448933 Retainer, Gasket
4449154 Screw
50 4451747 Cover, Back
4449809 Screw
51 Trim, Bottom
4448475 Black
4448476 White
4452414 Biscuit
3400832 Screw
53 4449845 Support, Bracket
4449809 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449315 Insulation, Wrap
4450364 Insulation, Back

CONTROL PANEL PARTS
3
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
8185844
Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Control Panel Assy.
W/Membrane Switch
8300383 Black
8300382 White
8300381 Biscuit
2 4451033 Gasket,
Control Panel
8281179 Screw
3 4453379 Microcomputer
4449745 Screw

OVEN DOOR PARTS
4
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
8185844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4455617 Door Liner
2 Hinge, Door
8300569 R.Side
8300570 L.Side
4449743 Screw
3 4449253 Glass, Inner
4 4451721 Insulation, Door
5 8300777 Retainer, Glass
4449809 Screw
7 4449257 Glass, Inner
12 Door Glass, Assy
4452071 Black
4452072 White
4452146 Biscuit
13 Door Handle
4448411 Black
4448412 White
4452128 Biscuit
14 4450813 Bracket, Handle
4451040 Screw
19 4450361 Shield, Heat
4449809 Screw
20 4451668 Retainer, Glass
4449809 Screw
21 8300819 Seal, Door Top
23 Retainer, Clip
4450863 Black
4450864 White
4452119 Biscuit
3400832 Screw
24 4455256 Glass, Inner

INTERNAL OVEN PARTS
5
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
8185844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 4452156 Element, Broil
4449154 Screw
3 3147563 Grill, Broiler
4 3147845 Pan, Broiler
5 3181534 Rack, Roasting
6 4448715 Rack, Oven
7 4452155 Element, Bake
8 4448881 Nut, Hex
9 4451583 Convection Motor
4449154 Screw
10 4452226 Blade, Fan
11 4448882 Washer, Lock
12 4452227 Nut
13 4451355 Jack, Meat Probe
14 4448948 Probe, Meat
15 4455036 Tray, Bake
17 4450039 Cover, Bake Tray
4449809 Screw
20 4452157 Element,
Convection
4449154 Screw
21 4448418 Cover, Fan
4449154 Screw

TOP VENTING PARTS
6
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
8185844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4451759 Vent, Exhaust
2 4451758 Foam, Block
3 Blower
6610168 Lower Oven
4455334 Upper Oven
4455352 Bracket, Blower
4455191 Plate, Service
4449809 Screw
5 6610122 Transformer,
(Lights)
4449809 Screw
7 4451789 Plate, Mounting
8 8300642 Transformer, Control
4449809 Screw
9 4455178 Elbow, Vent−Top
10 4455177 Elbow, Vent−Bottom
11 4451985 Suppressor
13 4448551 Vent,
(Control Panel)
4450038 Screw
14 Side, Control Top
4451597 Right
4451598 Left
4449809 Screw
4449154 Screw
15 4452244 Back, Control
4449809 Screw
16 4450550 Cover, Top Rear
4449809 Screw
17 4448664 Clamp
4449809 Screw
112432 Nut
18 4452366 Cover, Top Front
4449809 Screw
19 4449868 Block, Terminal
3400080 Screw

7
MISCELLANEOUS PARTS
For Models:KEBS277DBL12, KEBS277DWH12, KEBS277DBT12
(Black) (White) (Biscuit)
8185844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
4451926 Harness, Wire
(Latch)
4455726 Harness, Wire
(Main)
4450953 Conduit
4448664 Clamp
4450800 Screw, Ground
4452222 Spacer, Harness
4454835 Tie, Cable
4451761 Support, Wiring
4454842 Tie, Cable
313438 Harness, Clip
Miscellaneous
814381 Pin Hinge Kit
4448950 Screw, Install (4)
