OVEN PARTS
1
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
5−09 Litho in U.S.A. (amd)(bay) Part No. W10269260 Rev. A
27" BUILT−IN ELECTRIC
DOUBLE OVEN
THERMAL CONVECTION

OVEN PARTS
2
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
W10269260
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8304336 Installation
Instructions
W10162180 Use & Care Guide
Tech Sheet
W10220954 English
W10220955 French
8304335 Easy Set Guide
Safer Cooking Tips
9762761 English
W10065852 French
2
W10153090 Bracket, Base
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 8303829 Exhaust,Vent Slope
6
W10181198 Divider, Center
Vent
7
W10204469 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10169756 Lens, Light
11
W10009940 Oven Light
Assembly
12
W10169757 Bulb, Light
13 3400832 Screw (2)
14 8304629 Frame, Front
15 Gasket, Door
8304494 Lower
4455381 Upper
16 3196176 Screw
17 4449040 Screw
18 4449154 Screw
19 4451477 Support, Insulation
20
W10169348 Bracket,
Thermostat
21 Mounting Rail,Side
Right
8303677BL Black
8303677WH White
Left
8303678BL Black
8303678WH White
22
W10195935 Latch, Mortorized
23 4449743 Screw
24 4449748 Screw
25 4455641 Side, Chassis
26 8304304 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 8304452 Thermal Fuse 105C
29
W10131825 Sensor
30 8303724 Vent, Center
31 8303772 Base, Chassis
32 8304478 Retainer, Gasket
33 8303517 Cover, Back
34 Trim, Bottom Vent
8303706BL Black
8303706WH White
W10165444 Stainless
35 4448444 Grommet, Mounting
Rail
36 3400893 Screw (12)
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303966 Insulation, Wrap
8303968 Insulation, Back

CONTROL PANEL PARTS
3
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
W10269260
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8303717BL Black
8303717WH White
W10165446 Stainless
2 8303687 Support, Appliance
Manager
4 8303880 Control Panel,
Glass Touch
5
W10172472 User Inferface
6 8303720 Backer, Control
7 8303887 Bracket,
Enclosure (2)
8 4449154 Screw
9 3400832 Screw
10
W10119142 Appliance Manager
11 8304441 Resistor, Drop

OVEN DOOR PARTS
4
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
W10269260
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8304522 Bumper, Door
2
W10174288 Hinge, Door (2)
3 3196183 Screw
4
8304580BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6
8303738BL Door Liner
7 8303732 Glass, Inner
8 4449743 Screw
9 Cover, Hinge
W10137044 Right
W10137043 Left
10 8304523 Seal
11
8304361BL Bracket, Handle
12 Door Glass,
Assembly
Lower Includes #17
8304001 Black
8304003 White
W10237352 Stainless
Door Glass,
Assembly
Upper No Badge
8304002 Black
8304004 White
W10237353 Stainless
13 Door Handle
8303775BL Black
8303775WH White
8303775SS Stainless
15
8303745BL Frame,Door Side(2)
16 8303754 Door, Top Bracket
17 Badge
8304603BL Black
8304603WH White
8304603SS Stainless

INTERNAL OVEN PARTS
5
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
W10269260
Illus. Part
No. No. DESCRIPTION
1 8304602 Element, Broil
Shield
2 9760774 Element, Broil
3 4449154 Screw
4 8303842 Rack, Oven
5 8303840 Oven Rack
(Sliding)
6 9760768 Element, Bake
7 4455036 Tray, Bake
8 4450039 Cover, Bake Tray
9 4449809 Screw
10
8304422BU Cover, Fan
11 9760769 Element
Convection
12
W10116351 Blade, Fan
13
W10116349 Nut
14
W10116228 Fan, Convection
15 9755543 Jack, Meat Probe
16 9755542 Probe, Meat
17 9755547 Washer, Lock
18 9755546 Nut, Hidden

TOP VENTING PARTS
6
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
W10269260
Illus. Part
No. No. DESCRIPTION
1 9752759 Relay (2)
2 8304643 Duct, Air Outlet
3 4449809 Screw
4 8303972 Blower, 60mm
6 8285593 Connector, Cover
7
W10111628 Transformer,
Control
8 4450118 Nut
9 4449868 Block, Terminal
10 3400080 Screw
11 8303722 Vent, Control
Panel
12 Side, Control Top
8303518 Right
8304255 Left
13 8303520 Back, Control
14 8304220 Cover, Top
15 112432 Nut (3)

OPTIONAL PARTS (NOT INCLUDED)
7
For Models:KEBS278SBL04, KEBS278SWH04, KEBS278SSS04
(Black) (White) (Stainless)
W10269260
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
W10143473 Harness, Latch
W10155291 Harness, Keyboard
W10171560 Harness, GOC
8304051 Harness, Main
W10155291 Connector, Flex
8304439 Conduit, Double
7103P027−60 Nut
4450800 Screw,Ground
4452260 Spacer, Foam
Miscellaneous
4448950 Screw, Install (4)
98997 Clip
