OVEN PARTS
1
For Models: KEBU107SSS03
(Stainless)
4−09 Litho in U.S.A. (amd)(bay) Part No. W10269266 Rev. A
30" BUILT−IN ELECTRIC
SINGLE OVEN

OVEN PARTS
2
For Models: KEBU107SSS03
(Stainless)
W10269266
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10140563 Installation
Instructions
W10162200 Use & Care Guide
Tech Sheet
8304549 English
8304550 French
W10138788 Easy Set Guide
Safer Cooking Tips
9762761 English
W10065852 French
2
W10153090 Bracket, Base
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 8303829 Exhaust,Vent Slope
6
W10181196 Divider, Vent
7
W10204470 Top Chassis
8 4449809 Screw
9 3196176 Screw
10 4452163 Lens, Light
11 4448972 Oven Light,
Assembly
12 4452164 Bulb, Light
13 3400832 Screw
14
W10115861 Frame, Front
15 8304493 Gasket, Door
16 4452158 Tube, Vent
17 4449040 Screw
18 3400893 Screw
19 4451478 Support, Insulation
20
W10169348 Bracket,
Thermostat
21 Mounting Rail,Side
8303675BL Right
8303676BL Left
22
W10195935 Latch, Mortorized
23 4449743 Screw
24 4448444 Mounting Grommet,
Rail (6)
25 4455641 Side, Chassis
26
W10153104 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 8304452 Thermal Fuse
29
W10131825 Sensor
30 4449748 Screw
31 8303516 Base, Chassis
32
W10153361 Retainer, Gasket
33 8303517 Cover, Back
34
W10237368 Assembly,
Bottom Vent
35 9758597 Orifice, Boiler
Slip Fit
36
W10153098 Cover, BoilerOrifice
37 4449154 Screw
38
W10150076 Enclosure
39
W10077010 Gasket, Enclosure
40
W10111418 Valve, Solenoid
41
W10076760 Sensor, Conductivity
Slip Fit
44
W10076910 Tubing
45 9761146 Clamp, Crimp
46 9758598 Boiler Assembly
47
W10194453 Switch, Pressure
48
W10076930 Hose
(includes clamp)
49
W10142627 Tubing, Steam
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303965 Insulation, Wrap
W10141379 Insulation, Back

CONTROL PANEL PARTS
3
For Models: KEBU107SSS03
(Stainless)
W10269266
Illus. Part
No. No. DESCRIPTION
1 W10216219 Panel, Control
2 8303687 Support Appliance
Manager
4
W10016010 Control Panel,
Glass Touch
5
W10143289 User Interface
6 8303719 Backer, Control
7 8303887 Bracket,Enclosure
8 4449154 Screw
9 3400832 Screw
10
W10160958 Appliance Manager
11 8304441 Resistor, Drop
12
W10134765 Vapor, Stop
13 3400805 Screw

OVEN DOOR PARTS
4
For Models: KEBU107SSS03
(Stainless)
W10269266
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8303737BL Door Liner
2
W10174285 Hinge, Door (2)
3 3196183 Screw
4
8304581BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6 8303746 Door, Top Bracket
7 8303731 Glass, Inner
8 4449743 Screw
9
8303745BL Frame, Door Side
10 8304523 Seal
11
8304360BL Bracket, Handle
12
W10237350 Door Glass,
Assembly
13
8303774SS Door Handle
15
8304603SS Badge
16 8304522 Bumper, Glass
17 Cover,Hinge
W10137044 Right
W10137043 Left
18
W10143950 Screw

INTERNAL OVEN PARTS
5
For Models: KEBU107SSS03
(Stainless)
W10269266
Illus. Part
No. No. DESCRIPTION
1 9760774 Element, Broil
2 8303841 Rack, Oven
3 9760768 Element, Bake
4 4455037 Tray, Bake
5 4449154 Screw
6 4450039 Cover, Bake Tray
7 4449809 Screw
8
W10116228 Motor, Convection
Fan
9
W10116351 Blade, Fan
10
W10116349 Nut
11
W10141211 Cover, Fan
12 3400968 Nut
13
W10150011 Jack, Meat Probe
14 9755547 Lockwasher
15 9755546 Locknut
16 8304602 Shield, Broil
17
W10153105 Plate, Mounting
Convection Fan
18
W10116434 Element,
Convection
19 9755542 Probe, Temperature
20
W10208155 Oven Rack
(Sliding)

TOP VENTING PARTS
6
For Models: KEBU107SSS03
(Stainless)
W10269266
Illus. Part
No. No. DESCRIPTION
1 8304219 Cover, Top
2 8304643 Duct, Air Outlet
3 4449809 Screw
4 8303972 Blower
5 9760588 Transformer,
Lights
6 8285593 Connector, Cover
7 9762885 Transformer,
Control
9 4449868 Block, Terminal
10 3400080 Screw
11 8303684 Vent, Control
Panel
12 Side, Control Top
8303518 Right
8304255 Left
13 8303520 Back, Control
14 4450118 Nut

OPTIONAL PARTS
7
For Models: KEBU107SSS03
(Stainless)
W10269266
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
W10143473 Harness, Latch
W10157925 Harness, Main
8304318 Communication,
Harness
8304611 Conduit, Single
4450800 Screw, Ground
7103P027−60 Nut
Miscellaneous
4448950 Screw, Install (4)
W10111330 Filter, Cartridge
W10051680 Reducer, Stem
W10049700 Filter Assembly
W10076960 Elbow, Plug In
