KitchenAid SUPERBA KEBS276BBL1 User manual

1
UPPER OVEN PARTS
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
8−94 Litho in U.S.A.(jcn) Part No. 4174411
SUPERBA
27" BUILT−IN ELECTRIC
DOUBLE OVEN
Self Clean Upper and Lower Oven

Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2
UPPER OVEN PARTS
OPTIONAL PARTS (NOT INCLUDED)
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3185085 Button, Plug
2 3177545 Bracket, Mounting
3 3177623 Cabinet, Back
3185647 Screw
6 3178143 Cabinet, Top
3185647 Screw
7 3183748 Top, Module
3185647 Screw
8 Side, Cabinet
3177440 Left Hand
3177438 Right Hand
9 3181699 Tube, Vent
3185648 Screw (3)
10 3150505 Oven Light Assy.
11 3184533 Gasket, Light
12 311255 Bulb, Oven
Light
14 3186950 Frame, Front
15 3179813 Seal, Door
16 3179848 Clip, Oven Seal
17 3177681 Bracket, Switch
18 3177923 Insulator, Switch
19 3177621 Bottom, Module
20 3179220 Rail, Support (2)
3185647 Screw
21 Side Trim,
Door (2)
3187875 Black Model
3187878 White Model
22 3177434 Support, Oven
3185647 Screw
23 3178612 Shield, Radiation
3185647 Screw
24 3177433 Bracket, Hinge
3179795 Screw (6)
3185647 Screw
26 3177560 Back, Module
3185647 Screw
27 3185562 Liner, Oven
28 3178298 Hinge, Door (2)
31 4173553 Switch, Door
4159117 Nut (2)
313489 Screw (2)
33 3179587 Retainer, Seal
34 Vent, Middle Trim
3187883 Black Model
3187885 White Model
3188645 Screw (6)
4168863 Screw (6)
35 3183791 Vent, Tube
39 4168203 Cover, Cap Tube
4159445 Screw
40 4163883 Plate, Cover
41 3183752 Bracket, Mounting
Control Panel
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
3185551 Insulation, Wrap
3177872 Insulation, Back
SPLICING WIRES−−25FT.
LENGTH
18 Ga. 80 c Rating
350806 Yellow
16 Ga. 80 c Rating
242829 Blue
14 Ga. 150 c Rating
242820 Black
242821 Blue
242822 Brown
242823 Green
242824 Orange
242825 Red
242826 White
242827 Yellow
14 Ga. 200 c Rating
242830 Brown
242831 Red
242832 Yellow
12 Ga. 150 c Rating
242828 Black
242829 Red
PAINT, TOUCH−UP (1/2oz.)
72017 White
72107 Almond
72110 Harvest Gold
72112 Toast
72113 Platinum
72032 Black
261869 Citrine White
PAINT, PRESSURIZED SPRAY
(13 oz.)
350930 White
350956 Almond
261890 Harvest Gold
285365 Toast
285366 Platinum
830864 Black
350942 Primer
350941 Leveler (Primer)
PAINT, BULK (1 qt.)
799344 White
978883 Almond
261891 Harvest Gold
285367 Toast
285368 Platinum
ADHESIVE
482338 Sealer, Silastic
(3 Oz.)
591014 Adhesive, Loctite
(1/3 Oz.)
ACCESSORY PARTS
799832 Kit, Porcelain
Repair (White)
832985 Rack, Cooking
(Bi−Level)

3
LOWER OVEN PARTS
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411

4
Illus. Part
No. No. DESCRIPTION
LOWER OVEN PARTS
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
3 3183748 Top, Module
3185647 Screw
4 3181699 Tube, Vent
3185648 Screw (3)
5 3185562 Liner, Oven
7 311255 Bulb, Oven Light
8 3184533 Gasket, Light
9 3150505 Oven Light Assy.
12 3188161 Frame, Front
13 3179813 Seal, Door
14 3177681 Bracket, Switch
3177991 Screw (2)
15 3177923 Insulator, Switch
16 3177551 Bottom, Oven
17 3179220 Rail, Support (2)
3185647 Screw
18 3177433 Bracket Hinge (2)
3179795 Screw (6)
3185647 Screw
19 3177621 Bottom, Module
20 3178612 Shield, Radiation
3179795 Screw (6)
3185647 Screw
21 3177434 Support, Oven
3185647 Screw
22 3177560 Back, Module
3185647 Screw
24 3179848 Clip, Seal (3)
25 3178298 Hinge, Door (2)
26 3182814 Button, Plug
27 3185085 Button, Plug
28 3182159 Tube, Vent (Male)
3185647 Screw
29 3182160 Tube, Vent (Female)
30 4173553 Switch, Door
4159117 Nut (2)
313489 Screw (2)
32 3179587 Retainer, Seal
33 4168203 Cover, Cap Tube
34 Trim, Lower Vent
3177783 Black Model
3187957 White Model
35 4163883 Plate, Cover
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
3185551 Insulation, Wrap
3177872 Insulation, Back

5
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
CONTROL PANEL PARTS
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Membrane, Switch
3181779 Black Model
3184778 White Model
2 3181889 Bracket, Mounting
Switch Membrane
3 3181706 Microcomputer
4 3183705 Retainer, Bracket
3182939 Screw
5 3182985 Clip, Retainer
6 3182162 Trim, Door (2)
7 Door, Latch Handle
3182151 Black Model
3182154 White Model
8 3183702 Trim, Panel
3185647 Screw
9 3184321 Bracket
3182939 Screw
10 Frame, Control
Panel
3187954 Black Model
3187955 White Model
11 3184567 Clip, Control
Frame
3185647 Screw
309133 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT3185963 Tech Sheet
LIT3183659 Installation
Instructions
LIT3188200 Use & Care Guide

6
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
UPPER AND LOWER OVEN DOOR PARTS
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3185497 Liner, Door
3178001 Screw
2 3185462 Gasket, Window
3 3185457 Glass−Clear
4 3185460 Insulation, Door
5 3185437 Insulation
Retainer
4168863 Screw
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
7 3185458 Glass, Reflective
8 3185438 Plate, Latch
Strike
9 3185439 Retainer, Glass
3185647 Screw
10 3185459 Glass−Clear
11 Frame, Door
3187850 Black Model
3187852 White Model
12 Glass, Door
3187863 Black Model
3187865 White Model
13 Handle, Door
3185986 Black Model
3185987 White Model
14 3182138 Spacer, Door
Handle
15 3188599 Bushing, Door
Handle
3181637 Screw
342043 Screw
16 3188633 Foil−Adhesive
Backed
17 3188635 Foil−Adhesive

7
LATCH AND VENT PARTS
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411

LATCH AND VENT PARTS
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
8
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3183748 Module, Top
2 258076 Block, Terminal
308043 Screw
3 3183784 Switch, Latch
254225 Screw
4 3178668 Switch, Latch
98106 Screw
254225 Screw
5 3178185 Insulator, Switch
6 3177662 Guard, Latch
7 Handle, Latch
3177969 Upper Oven
3184037 Screw (2)
3181963 Lower Oven
3185414 Screw (2)
3179116 Screw
8 3184039 Knob, Latch Handle
3183294 Screw
9 3184040 Spacer, Latch
Handle
3184037 Screw
10 3178410 Latch Mechanism
11 3177496 Plate, Mounting
3177991 Screw
12 3185455 Baffle
311773 Screw
13 3183954 Nozzle, Vent
Bottom
14 3183955 Nozzle, Vent Top
15 3183999 Box, Vent
4173231 Screw
3179116 Screw
16 3183964 End, Vent Box
17 3183533 Bracket, Mounting
3177991 Screw
18 3183720 Blower, Fan
19 3183791 Tube, Vent
3185647 Screw
20 3149650 SPST Thermostat
3185647 Screw
21 3183785 Shield, Heat
3177991 Screw
22 3183953 Box, Vent
23 3183965 End, Box Vent
3185647 Screw
24 3183793 Tube, Vent
3185647 Screw
25 3183532 Clamp, Tube
3185647 Screw
26 313755 Seal, Foam
27 4159035 Bushing

Illus. Part
No. No. DESCRIPTION
UNIT PARTS
9
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 3185562 Liner, Oven
2 661415 Element, Broil
3 3147563 Grill, Broiler
4 3147845 Pan, Broiler
5 3185367 Rack, Offset
6 3185368 Rack, Oven
7 661416 Element, Bake
3185648 Screw (2)
8 4167277 Nut, Meat Probe
9 4163975 Gasket, Meat Probe
10 4167266 Probe Cover
11 4159557 Washer
12 3179672 Spacer, Tubing
13 3150107 Meat Probe Jack
14 3150144 Meat Probe
15 313570 Clip, Tubing
19 3180694 Bracket, Element
3185648 Screw (4)
20 3148440 Sensor, Heat
3185648 Screw
21 3149652 SPST Thermostat
3185647 Screw

Illus. Part
No. No. DESCRIPTION
WIRING HARNESS PARTS
10
For Model: KEBS276BBL1, KEBS276BWH1
(BLACK) (WHITE)
4174411
1 3187607 Harness Wire
(Door Switch
Upper)
2 3183656 Harness Wire
(Door Switch
Lower)
3 3185950 Harness Wire
(Lower Oven)
4 3185965 Harness Wire
(Upper Oven)
5 3185952 Harness, Wire
Latch Assy.
(Upper)
6 3179668 Standoff, Wire
3185647 Screw
7 313438 Clip, Harness
9 4159037 Clamp, Wire
10 3183361 Harness, Wire
Latch Assy.
(Lower)
