KitchenAid KBFC42FSS00 User manual

®itchen_kid ®
BOTTOM-MOUNT
BUILT-IN REFRIGERATOR
For questions about features, operation/performance, parts, accessories or service, call: 1-800-422-1230
or visit our website at www.kitchenaid.com
In Canada, call: 1-800-807-6777 or visit our website at www.KitchenAid.ca
REFRIGERADOR EMPOTRADO CON
MONTAJE INFERIOR
Para consultas respecto a caracteristicas, operaci6n/desempe_o, partes, accesorios o servicio, Ilame al: 1-800-422-1230
o visite nuestra p_gina de Internet www.KitchenAid.com
En Canad& Ilame al: 1-800-807-6777 o visite nuestra p_gina de Internet www.KitchenAid.ca
P P P
REFRIGEILATEUR ENCASTRE AVEC
P
CONGELATEUR EN DESSOUS
Au Canada, pour assistance, installation ou service composez le 1-800-807-6777 ou visitez notre site web a www.KitchenAid.ca
Table of Contents/Indice/Table des matieres .................................................................. 2
2317821

TABLEOF CONTENTS
REFRIGERATOR SAFETY ............................................................. 3
Proper Disposal of Your Old Refrigerator .................................... 3
BEFORE USE .................................................................................. 4
Water Supply Requirements ........................................................ 4
REFRIGERATOR USE .................................................................... 4
Power On/Off Switch ................................................................... 4
Water System Preparation ........................................................... 5
Normal Sounds ............................................................................ 5
Ensuring Proper Air Circulation .................................................... 6
Using Controls .............................................................................. 6
Water Filter Indicator .................................................................... 8
Water Filtration System ................................................................ 8
Ice Maker and Storage Bin .......................................................... 9
REFRIGERATOR FEATURES ........................................................ 9
Refrigerator Shelves ..................................................................... 9
Dell/Crisper Pans ......................................................................... 9
Covered Utility Bin ..................................................................... 10
Wine Rack .................................................................................. 10
FREEZER FEATURES .................................................................. 10
Pull-out Freezer Pan and Ice Bin ............................................... 10
DOOR FEATURES ........................................................................ 11
Utility Compartment ................................................................... 11
Door Bins .................................................................................... 11
REFRIGERATOR CARE ............................................................... 11
Cleaning ...................................................................................... 11
Changing the Light Bulbs ........................................................... 12
Power Interruptions .................................................................... 13
Vacation Care ............................................................................. 13
TROUBLESHOOTING .................................................................. 13
ASSISTANCE OR SERVICE ......................................................... 15
In the U.S.A................................................................................ 15
In Canada ................................................................................... 16
Accessories ................................................................................ 16
WATER FILTER CERTIFICATIONS ............................................. 16
PRODUCT DATA SHEETS ........................................................... 17
WAR RANTY .................................................................................. 18
P
INDICE
SEGURIDAD DEL REFRIGERADOR ........................................... 19
C6mo deshacerse adecuadamente de su refrigerador viejo.... 19
ANTES DE USAR .......................................................................... 20
Requisitos del suministro de agua ............................................. 20
USO DE SU REFRIGERADOR ..................................................... 20
Interrupter de Encendido/Apagado ........................................... 20
Preparaci6n del sistema de agua .............................................. 21
Sonidos normales ...................................................................... 22
C6mo asegurar la debida circulaci6n del aire ........................... 22
Uso de los controles .................................................................. 22
Indicador del filtro de agua ........................................................ 24
Sistema de filtraci6n de agua .................................................... 25
Fabrica de hielo y dep6sito ........................................................ 25
CARACTERISTICAS DEL REFRIGERADOR .............................. 26
Estantes del refrigerador ............................................................ 26
Cajones para carnes frias/verduras ........................................... 26
Compartimiento de uso general con tapa ................................. 27
Portabotellas .............................................................................. 27
CARACTERISTICAS DEL CONGELADOR ................................. 27
Caj6n removible del congelador y dep6sito de hielo ................ 27
CARACTERISTICAS DE LA PUERTA ......................................... 28
Compartimiento de uso general ................................................. 28
Recipientes de la puerta ............................................................ 28
CUIDADO DE SU REFRIGERABOR ............................................ 28
Limpieza ..................................................................................... 28
C6mo cambiar los focos ............................................................ 29
Cortes de corriente ..................................................................... 30
Cuidado durante las vacaciones ................................................ 30
SOLUCION DE PROBLEMAS ...................................................... 30
AYUDA O SERVICIO TI_CNICO ................................................... 33
En los EE.UU.............................................................................. 33
En Canada .................................................................................. 33
Accesorios .................................................................................. 33
NOJA DE BATOS BEL PRODUCTO ........................................... 34
GARANTIA ..................................................................................... 35
TABLE DES MATIERES
SI_CURITE DU REFRIGERATEUR .............................................. 36
Mise au rebut de votre vieux refrigerateur ................................. 36
AVANT L'UTILISATION ................................................................ 37
Specifications de I'alimentation en eau ..................................... 37
UTILISATION DU REFRIGI_RATEUR .......................................... 37
Commutateur marche/arr_t ....................................................... 37
Preparation du systeme d'eau ................................................... 38
Sons normaux ............................................................................ 39
Pour s'assurer d'une circulation d'air appropriee ..................... 39
Utilisation des commandes ........................................................ 39
Temoin lumineux d'etat du filtre a eau....................................... 42
Systeme de filtration d'eau ........................................................ 42
Machine a gla£;ons et bac d'entreposage ................................. 42
CARACTERISTIQUES DU REFRIGI_RATEUR ........................... 43
Tablettes du refrig6rateur ........................................................... 43
Bac pour specialites alimentaires/bac a legumes ..................... 44
Casier utilitaire couvert ............................................................... 44
Casier a vin ................................................................................. 44
CARACTERISTIQUES DU CONGI_LATEUR ............................... 44
Bac de congelateur escamotable et bac a gla_ons .................. 44
CARACTI_RISTIQUES DE LA PORTE ......................................... 45
Compartiment utilitaire ............................................................... 45
Balconnets de porte ................................................................... 45
ENTRETIEN BU RI_FRIGERATEUR ............................................ 45
Nettoyage ................................................................................... 45
Remplacement des ampoules d'eclairage ................................ 46
Pannes de courant ..................................................................... 47
Entretien avant les vacances ..................................................... 47
DEPANNAGE ................................................................................. 47
ASSISTANCE OU SERVICE ......................................................... 50
Accessoires ................................................................................ 50
FEUILLES DE DONNI_ES SUR LE PRODUIT ............................. 51
GARANTIE ..................................................................................... 52

REFRIGERATOR SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Disconnect power before servicing.
• Replace all parts and panels before operating.
• Remove doors from your old refrigerator.
• Use nonflammable cleaner.
• Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
• Use two or more people to move and install refrigerator.
• Disconnect power before installing ice maker (on ice maker
kit ready models only).
• Use a sturdy glass when dispensing ice (on some models).
SAVE THESE INSTRUCTIONS
Proper Disposal of Your Old Refrigerator
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous
- even if they will sit for "just a few days." Ifyou are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.

BEFORE USE
Remove the Packaging
Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see "Refrigerator Safety."
•Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside
of your refrigerator before using it. See the cleaning instructions
in "Refrigerator Care."
important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
For your protection, tempered glass is designed to shatter
into many small, pebble-size pieces. This is normal. Glass
shelves and covers are heavy. Use special care when
removing them to avoid impact from dropping.
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 - 414 kPa):
• Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See "Water
Filtration System."
If you have questions about your water pressure, call a licensed,
qualified plumber.
REFRIGERATOR USE
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Read all directions before you begin.
IMPORTANT:
• When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. Ifyour refrigerator is not connected to a water
source, see "Connect to Water Line" in the Installation
Instructions. If you have any questions about your water
connection, see "Troubleshooting" or call a licensed, qualified
plumber.
• If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF. See "Ice Maker and
Storage Bin."
• All installations must meet local plumbing code requirements.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 - 827 kPa) is required to operate the water dispenser and ice
maker. If you have questions about your water pressure, see
"Troubleshooting" or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 - 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 - 414 kPa).
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
If you need to turn the power to your refrigerator On or Off, you
must remove the top grille assembly to access the power switch.
Turn the power to the refrigerator Off when cleaning your
refrigerator or changing light bulbs.
Architecf _,Overlay, Classic and Complete Series
To Remove TopGrille:
1. Grasp both ends of the top grille.

2. Push the top grille straight up, then pull straight out. Lay the
grille on a soft surface.
B A
A. Top grille
B. Cabinet side trims
To Replace Top Grille:
1. Insert top grille hooks (located on the back of the top grille)
onto mounting bolts on the side trim.
2. Pull grille down slightly to lock into place.
Pro Line _Series
To Remove Top Grille:
1. Grasp both ends of the top grille.
2. Push the top grille straight up, and then pull straight out.
3. Disconnect the wirin( harness from the back of the top grille.
4. Lay the grille on a soft surface.
5. Place wiring on the top of the cabinet, ensuring it is out of the
way of the doors.
To Replace Top Grille:
1. Reattach wiring harness into grille back.
2. Insert top grille hooks into slots on the side trim. Pull grille
down slightly to lock into place.
Turn Power On or Off
1. Remove top grille.
2. Press power switch to the On or Off position.
3. Replace top grille.
IMPORTANT: Be sure the power switch is set to the On position
after cleaning refrigerator or changing light bulbs.
A
Please read before using the water system.
Immediately after installation, follow the steps below to make
sure that the water system is properly cleaned.
1. Turn off the ice maker. Slide the ice maker ON/OFF control,
located on the left-hand side of the ice bin, to the OFF (down)
position as shown.
A. ON/OFF control
NOTES:
• If your model has a base grille filter system, make sure the
base grille filter is properly installed and the cap is in the
horizontal position.
Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.
Turn on the ice maker. Slide the ice maker ON/OFF control,
located on the left-hand side of the ice bin, to the ON (up)
position. Please refer to "Ice Maker and Storage Bin" for
further instructions on the operation of your ice maker.
• Allow 24 hours to produce the first batch of ice.
• Discard the first three batches of ice produced.
Your new refrigerator may make sounds that your old one didn't
make. Because the sounds are new to you, you might be
concerned about them. Most of the new sounds are normal. Hard
surfaces, such as the floor, walls, and cabinets, can make the
sounds seem louder. The following describes the kinds of sounds
and what may be making them.
• If your refrigerator is equipped with an ice maker, you will hear
a buzzing sound when the water valve opens to fill the ice
maker for each cycle.
Your refrigerator is designed to run more efficiently to keep
your food items at the desired temperatures and to minimize
energy usage. The high efficiency compressor and fans may
cause your refrigerator to run longer than your old one. You
may also hear a pulsating or high-pitched sound from the
compressor or fans adjusting to optimize performance.
• You may hear the evaporator fan motor circulating air through
the refrigerator and freezer compartments. The fan speed
may increase as you open the doors or add warm food.
• Rattling noises may come from the flow of refrigerant or the
water line.
• Water dripping on the defrost heater during a defrost cycle
may cause a sizzling sound.
A. Power switch

As each cycle ends, you may hear a gurgling sound due to
the refrigerant flowing in your refrigerator.
You may hear a gurgling sound at the defrost drain after the
door is closed.
Contraction and expansion of the inside walls may cause a
popping noise.
You may hear air being forced over the condenser by the
condenser fan.
You may hear water running into the drain pan during the
defrost cycle.
In order to ensure proper temperatures, you need to permit
airflow between the refrigerator and freezer sections. As shown in
the illustration, cool air enters the freezer section through vents in
the rear and top. The air flows forward through the freezer section
and recirculates under the freezer floor. Cool air enters the
refrigerator section through the top, flows down and across
shelves to the doors and recirculates to return air vents at the
bottom.
• If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
• The preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
• The actual temperature may differ from the display when a
door is open for an extended period of time or when the
refrigerator is in the defrost cycle.
NOTE: The factory recommended set points are 0°F (-18°C) for
the freezer and 37°F (3°C) for the refrigerator.
Turning Refrigerator On and Viewing Set Points
• Press the Cooling (ON/OFF) touch pad.
COOLING
NOTE:
• After the refrigerator is turned on, the Over Temperature audio
alarm and indicator light may activate every 11/2hours until
the refrigerator and freezer temperatures are below 48°F (9°C)
and 15°F (-9°C), respectively, or until the alarm is turned off.
Toturn off the audio alarm and indicator light, see "Master
Alarm Reset."
The ON/OFF touch pad on the control panel shuts down
refrigerator functions such as cooling, lighting, fans and
compressors. To turn the power off completely, use the
power ON/OFF switch located behind the top grille. See
"Power ON/OFF Switch."
Viewing the Celsius Temperatures
• Press °C touch pad. To redisplay degrees Fahrenheit, press
°C again.
Do not block any of these vents with food packages. If the vents
are blocked, airflow will be prevented and temperature and
moisture problems may occur.
IMPORTANT: Because air circulates between both sections, any
odors formed in one section will transfer to the other. You must
thoroughly clean both sections to eliminate odors. To prevent
odor transfer and drying out of food, wrap or cover foods tightly.
IMPORTANT:
• The refrigerator control adjusts the refrigerator compartment
temperature. The freezer control adjusts the freezer
compartment temperature.
•Wait 24 hours after you turn on the refrigerator before you put
food into it. Ifyou add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
lower (colder) setting will not cool the compartments any
faster.
NOTE: If the freezer temperature is below zero, the negative sign
next to the freezer display will light up. This is normal.
Adjusting Controls
NOTE: Wait at least 24 hours between adjustments. Recheck the
temperatures before other adjustments are made.
To Adjust Set Point Temperatures:
• Press the refrigerator or freezer PLUS (+) or MINUS (-) touch
pad until the desired temperature is reached.
Set to
) Recommended
Freezer Refrigerator
..............................................................................................................................TilMPilRATURE CONTROL

Press the Set To Recommended touch pad to reset the set
points to the factory recommended temperatures.
NOTE: The set point range for the freezer is -5°F to 5°F
(-21 °C to -15°C). The set point range for the refrigerator is
33°F to 45°F (0°C to 7°C).
CONDITION/REASON: 1EMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold REFRIGERATOR Control 1°
Not set correctly for conditions higher
REFRIGERATOR too warm REFRIGERATOR Control 1°
High use or room very warm lower
FREEZER too cold FREEZER Control 1° higher
Not set correctly for conditions
FREEZER too warm/too little FREEZER Control 1° lower
ice
High use or heavy ice use
Water Filter Indicator &Reset
See "Water Filter Indicator Section."
Max Cool
The Max Cool feature assists with periods of heavy ice usage, full
grocery loads, or temporarily warm room temperatures.
•Press MAX COOL to turn on the Max Cool feature. The Max
Cool indicator light will remain on for 24 hours unless
manually turned off.
Max Cool
NOTE: The temperature display will remain at 34°F (1°C) and -5°F
(-21 °C) for the refrigerator and freezer compartments,
respectively, while the Max Cool feature is enabled. After
24 hours, the refrigerator returns to the previous temperature set
points.
Holiday Mode
The Holiday Mode feature is designed for the traveler or for those
whose religious observances require turning off the lights and ice
maker. By selecting this feature, the temperature set points and
Dell Pan settings remain unchanged, the ice maker will be
disabled and the interior lights will turn off. For most efficient
refrigerator operation, it is recommended to exit the Holiday
Mode when it is no longer required.
• Press HOLIDAY MODE to turn on the Holiday Mode feature.
This feature will remain on until Holiday Mode is pressed
again.
Holiday Mode
NOTE: If the Max Cool feature has been selected prior to
turning on the Holiday Mode feature, then the set points will
remain at 34°F (1°C) and -5°F (-21 °C) for the refrigerator and
freezer compartments, respectively, until the Max Cool
feature times out. The refrigerator will then return to the
previous temperature set points chosen prior to the selection
of the Max Cool feature, but the lights and ice maker will
remain off until the Holiday Mode is pressed again.
Energy SaverTM Feature (42" Bottom Mount Only)
The Energy Saver feature controls the heaters located inside the
hinged seal between the refrigerator doors. The heaters help
keep external moisture from forming on the hinged seal.
• Press ENERGY SAVER control to turn on this feature for low
humidity conditions. The ring around the control will be lit
when Energy Saver is on. If moisture begins to collect on the
hinged seal between the doors, press ENERGY SAVER
control again to turn off this feature.
Energy Saver
Alarm Functions
Master Alarm Reset
Pressing Alarm Reset once will turn off the audio alarm and
indicator light. The audio alarm will not sound again for the
current condition that caused the alarm until a new condition
occurs or until a Master Alarm Reset is performed.
A Master Alarm Reset can be performed by pressing Cooling
(ON/OFF) twice or by turning the power to the refrigerator off and
on again. See "Power ON/OFF Switch." After performing a
Master Alarm Reset, the indicator light will reactivate if the
condition that caused the alarm is still present. See "Over
Temperature," "Call Service," or "Door Open."
Reset
Door Open •
Over Temperature •
Call Service •
COOLING ALARMS
Door Open
The Door Open indicator light will flash, an alarm will sound and
the interior lights will turn off when a door has been open for
longer than 10 minutes. When the door is closed, the audio alarm
will reset and turn off, but the Door Open indicator light will
continue to flash until the temperature is equal to or below 45°F
(7°C) and 15°F (-9°C) for the refrigerator and freezer
compartments, respectively.
NOTE: To deactivate the audio alarm and indicator light, see
"Master Alarm Reset."
Over Temperature
IMPORTANT: Ifthe Over Temperature Alarm activates, your food
may spoil. See the "Power Interruptions." Minimize door
openings until temperatures return to normal.
The Over Temperature feature is designed to let you know when
either the refrigerator temperature rises above 48°F (9°C) or the
freezer temperature rises above 15°F (-9°C) for longer than
11/2hours. The audio alarm will shut off automatically when the
temperature returns to normal, but the indicator light will continue
to flash until the Alarm is pressed to let you know that an over
temperature condition has occurred.
If the over temperature condition is still present when an Over
Temperature Reset is performed, the indicator light will continue
to reactivate every 11/2hours until refrigerator and freezer
temperatures are below 48°F (9°C) and 15°F (-9°C), respectively.
NOTE: To deactivate the audio alarm and indicator light, see
"Master Alarm Reset."

CallService
IftheCallServiceindicatorlightisflashing,callforservice.See
the"AssistanceorService"sectionforinformationoncallingfor
service.
NOTE:Todeactivatetheaudioalarmandindicatorlight,see
"MasterAlarmReset."
Top Grille Temperature Display (Pro Line® Models Only)
The top grille temperature display shows the freezer and
refrigerator temperatures. The display will show either Fahrenheit
or Celsius, depending on the selected reading inside the
refrigerator.
During the defrost cycle, the temperature display will show the
temperature set points.
A B
A. Freezer temperature display
B. Refrigerator temperature display
The water filter indicator, located on the control panel, will help
you know when to change the water filter.
A new water filter should display a reading of 99%. The reading in
the display will decrease as the filter life is used. A replacement
water filter should be ordered when "Order Filter" is displayed. It
is recommended that you replace the filter when "Change Filter"
is displayed or when water flow to your water dispenser and/or
icemaker decreases noticeably. See "Changing the Water Filter"
later in this section.
% Remaining Reset
After changing the water filter, press and hold RESET for
2 seconds until the status display changes to 99%.
]sVSi},@_;t
NOTE: Do not use with water that is microbiologically unsafe
or of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction may
be used on disinfected waters that may contain filterable
cysts.
Replacing the Water Filter
Locate the water filter cap in the front base grille. Rotate the
cap counterclockwise to a vertical position and pull the cap
and filter cartridge out through the base grille.
NOTE: There will be water in the filter. Some spilling may
occur.
Remove the cap by sliding it off the end of the old water filter.
The cap will slide to the left or right.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
Take the new water filter out of its packaging and remove the
protective cover from the o-rings. Discard the protective
cover.
4.
5.
Slide the cartridge cap onto the new cartridge. See
illustration in Step 2.
With cap in the vertical position, push the new water filter into
the base grille until it stops. Rotate the cap clockwise to a
horizontal position. Discard the first three batches of ice
produced after replacing the filter.
Using the Ice Maker Without a Water Filter
You can operate the ice maker without a water filter. Your ice will
not be filtered.
1. Remove the water filter.
2. Slide the cap off the end of the filter. With the cap in the
vertical position, insert the cap into the base grille until it
stops.
IMPORTANT: Do not discard the cap. It is part of your
refrigerator. Keep the cap to use with the replacement filter.
3. Rotate the cap to a horizontal position. The cap might not be
even with the base grille.

Turn the Ice Maker ON/OFF
The ice maker ON/OFF control is located on the left-hand side of
the ice bin.
1. Toturn on the ice maker, slide the ice maker ON/OFF control
to the ON (up) position.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin. The ice maker
sensors will automatically stop ice production, but the ice
maker control will remain in the ON (up) position.
2. To manually turn off the ice maker, slide the ice maker ON/
OFF control to the OFF (down) position as shown.
A
A. ON/OFF control
Ice Storage Bin Care
1.
2. Remove ice bin. See "Pull-out Freezer and Ice bin."
Empty the ice bin. Use warm water to melt the ice if
necessary.
NOTE: Do not use anything sharp to break up the ice in the
bin. This can cause damage to the ice container and the
dispenser mechanism.
3. Wash ice bin with warm water and a mild detergent, rinse well
and dry thoroughly. Do not use harsh or abrasive cleaners or
solvents.
REMEMBER:
• Allow 24 hours to produce the first batch of ice.
• Discard the first three batches of ice produced to avoid
impurities that may be flushed out of the system.
•It may take 3 to 4 days for the ice bin to completely fill, if no
ice is used.
• The quality of your ice will be only as good as the quality of
the water supplied to your ice maker.
Avoid connecting the ice maker to a softened water supply.
Water softener chemicals (such as salt) can damage parts of
the ice maker and lead to poor quality ice. If a softened water
supply cannot be avoided, make sure the water softener is
operating properly and is well maintained.
• It is normal for the ice cubes to be attached at the corners.
They will break apart easily.
• Do not store anything inside the ice bin.
REFRIGERATOR FEATURES
important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
For your protection, tempered glass is designed to shatter
into many small, pebble-size pieces. This is normal. Glass
shelves and covers are heavy. Use special care when
removing them to avoid impact from dropping.
The shelves in your refrigerator are adjustable to meet your
individual storage needs.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
Shelves and Shelf Frames
To Remove and replace a Shelf/Frame:
1. Remove the shelf/frame by tilting it up at the front and lifting it
out of the shelf supports. Pull shelf straight out.
2. Replace the shelf/frame by guiding the rear shelf hooks into
the shelf supports. Tilt the front of the shelf up until the rear
shelf hooks drop into the shelf supports.
3. Lower the front of the shelf and check to make sure that the
shelf is securely in position.
The 42" (106.7 cm) model includes two dell pans and two crisper
pans, while the 36" (91.4 cm) model has one dell pan and one
crisper pan.
A
A. Crisper pans
B. Dell pans

Dell Pan Settings
The Ingredient Care Center control panel located above each dell
pan has the following three temperature settings: Dell, Produce,
Meats (Cold to Coldest) and the Quick Chill setting. Select the
appropriate setting for the food being stored.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish ................. use same day as purchased
Chicken, ground beef, variety meat (liver, etc.) ......... 1-2 days
Cold cuts, steaks/roasts ........................................... 3-5 days
Cured meats ........................................................... 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
Quick Chill Setting
Each dell pan has a Quick Chill setting. Activating this selection
lowers the temperature of the pan for a period of one hour.
NOTE: This will lower the dell pan temperature below the freezing
point for liquids. Care should be taken on what items are in the
pan when this setting is selected.
Crisper Pan
Above each dell pan is a crisper pan (the larger of the pans)
which is for your larger produce items.
Remove and Replace the Dell/Crisper Pans
1. Slide the dell/crisper pan straight out to the stop. Lift the front
of the pan with one hand while supporting the bottom with
the other hand. Slide the pan out the rest of the way.
2. To replace the dell/crisper pan, pull out the pan slides until
they are fully extended and set the pan on the slides. Push
the pan in toward the back until it is in closed position.
3. Reopen the dell/crisper pan to make sure it has been
replaced properly.
NOTE: For long-term storage, store eggs in a covered container
or in their original carton on an interior shelf.
To Remove and Replace the Wine Rack:
1. Remove the rack by pulling it straight out from the shelf.
2. Replace the rack by sliding it in between the shelf and the
wall of the refrigerator.
FREEZERFEATURES
The freezer pan can be used to stere smaller items.
Remove and Replace the Freezer Pan and Ice Bin:
1. Slide the pan or ice bin out of the freezer and lift up and out.
A. Ice bin
B. Freezer pan
2. To replace the pan or ice bin, pull out the pan slides until they
are fully extended and set the pan on the slides. Push the pan
in toward the back until it is in closed position.
3. Reopen the pan or ice bin to make sure it has been replaced
properly.
Frozen Food Storage Guide
Storage times will vary according to the quality and type of food,
the type of packaging or wrap used (should be airtight and
moisture-proof), and the storage temperature. Ice crystals inside
a sealed package are normal. This simply means that moisture in
the food and air inside the package have condensed, creating ice
crystals.
Put no more unfrozen food into the freezer than will freeze within
24 hours (no more than 2 to 3 Ibs of food per cubic foot
[907-1,350 g per 28 L] of freezer space). Leave enough space in
the freezer for air to circulate around packages. Be careful to
leave enough room for the door to close tightly.
For more information on preparing food for freezing, check a
freezer guide or reliable cookbook.
10

DOOR FEATURES REFRIGERATOR CARE
The utility compartment can be placed in any position on the
refrigerator door.
To Remove and Replace the Utility Bin:
1. Remove utility compartment by grasping both ends and lifting
compartment up and out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Large door bins hold gallon containers and the smaller door bins
hold 2-liter bottles. The door bins are adjustable and removable
for easy cleaning and adjusting.
Gallon Door Bin
To Install Gallon Door Bin:
NOTE: The gallon door bin can only be placed on the lower
support.
1. Position gallon door bin above lowest door adjustment slot.
2. Push down to secure bin.
3. Adjust other bins, as necessary to allow for milk or beverage
container height.
Door Bins
To Remove and Replace the Door Bins:
1. Remove the bin by lifting it up and pulling it out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to prevent
odors from building up. Wipe up spills immediately.
To Clean Your Refrigerator:
1. Remove the top grille. See "Power On/Off Switch."
2. Press power switch to OFR
3. Remove all removable parts from inside, such as shelves,
crispers, etc.
4. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
• Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
• To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt
[26 g to 0.95 L] of water).
5. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners, or cleaners containing
chlorine. These can scratch or damage materials. Dry
thoroughly with a soft cloth. For additional protection against
damage to painted metal exteriors, apply appliance wax (or
auto paste wax) with a clean, soft cloth. Do not wax plastic
parts.
NOTE: To keep your stainless steel refrigerator looking like
new and to remove minor scuffs or marks, it is suggested that
you use the manufacturer's approved Stainless Steel Cleaner
& Polish.
IMPORTANT: This cleaner is for stainless steel parts only?
Do not allow the Stainless Steel Cleaner & Polish to come into
contact with any plastic parts such as the trim pieces,
dispenser covers or door gaskets. If accidental contact does
occur, clean plastic part with a sponge and mild detergent in
warm water. Dry thoroughly with a soft cloth. To order the
cleaner, see "Accessories."
11

6=
7.
Clean the condenser coils located behind the top grille
ventilation panel regularly. Coils may need to be cleaned as
often as every other month. This may help save energy.
• Use a vacuum cleaner with an extended attachment to
clean the condenser coils when they are dusty or dirty.
Clean defrost pan using mild detergent in warm water only.
Do not use cleaners containing chlorine. These can scratch or
damage materials. Dry thoroughly.
• Remove the water filter by rotating the cap a quarter turn
counterclockwise to a vertical position and pulling it out
through the base grille.
• Using a 1/4"hex-head screwdriver, remove the screws at
each end of the base grille. Remove the base grill.
NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to
replace the bulb with one of the same size and shape. The lights
require a 40-watt maximum appliance bulb. Replacement bulbs
are available from your dealer.
Refrigerator Lights
There are three light bulbs located in the top front of the
refrigerator compartment behind a light shield.
1. Remove the top grille. See "Power On/Off Switch."
2. Press power switch to the Off position.
3. Open the light shield. Grasp the light shield by the openings.
Gently push back and pull down, as shown, to access the
light bulbs.
8=
9.
• Remove the defrost pan by pushing up on the retaining
clip under the refrigerator while sliding the pan forward.
A B
A. Defrost pan
B. Retaining clip
• Replace the defrost pan by positioning the edge of the
defrost pan approximately 7" (17.8 cm) from the left side
of the refrigerator. Lift defrost pan into side guides. Push
back and place the front edge of the pan inside of the
retaining clip.
• Replace the base grille and the water filter.
Press the power switch to ON.
Replace the top grille. See "Power On/Off Switch."
A. Light shield
4. Remove the light bulb and replace it with one of the same
size, shape and wattage.
5. Close the light shield by raising it up into place.
NOTE: If needed, clean the light shield with a damp soft
cloth.
6. Press the power switch to the On position.
7. Replace the top grille. See "Power On/Off Switch."
Freezer Lights
There are two light bulbs located in the top of the freezer
compartment. One bulb is over the ice bin and the other bulb is
over the freezer pan.
1. Slide open the ice bin or freezer pan to access the light bulb.
2. Remove the light bulb and replace it with one of the same
size, shape and wattage.
A.L_htbu_s
12

If the power will be out for 24 hours or less, keep the door or
doors closed (depending on your model) to help food stay cold
and frozen.
If the power will be out for more than 24 hours, do one of the
following:
• Remove all frozen food and store it in a frozen food locker.
• Place 2 Ibs (907 g) of dry ice in the freezer for every cubic foot
(28 L) of freezer space. This will keep the food frozen for 2 to
4 days.
• If neither a food locker nor dry ice is available, consume or
can perishable food at once.
REMEMBER: A full freezer stays cold longer than a partially filled
one. A freezer full of meat stays cold longer than a freezer full of
baked goods. Ifyou see that food contains ice crystals, it may be
refrozen, although the quality and flavor may be affected. If the
condition of the food is poor, dispose of it.
Your refrigerator is equipped with the Holiday Mode feature,
which is designed for the traveler who wishes to turn off the lights
and ice maker. By selecting this feature, the temperature set
points remain unchanged, the ice maker will be disabled and the
interior lights will turn off. For most efficient refrigerator operation,
it is recommended to exit the Holiday Mode when it is no longer
required.
If You Choose to Leave the Refrigerator on While You're
Away:
1. Use up any perishables and freeze other items.
2. Press HOLIDAY MODE pad.
3. If your refrigerator has an automatic ice maker, shut off the
water supply to the ice maker.
4. Empty the ice bin.
5. When you return from vacation, press HOLIDAY MODE to
return to normal operation.
If You Choose to Turn the Refrigerator Off Before You
Leave:
1. Remove all food from the refrigerator.
2. If your refrigerator has an automatic ice maker:
• Turn off the water supply to the ice maker at least one day
ahead of time.
• When the last load of ice drops, slide the ice maker
control to the OFF (down) position.
3. Depending on your model, turn the Thermostat Control
(or Refrigerator Control) to OFR See "Using Controls."
4. Clean refrigerator, wipe it, and dry well.
5. Tape rubber or wood blocks to the tops of all doors to prop
them open far enough for air to get in. This stops odor and
mold from building up.
TROUBLESHOOTING
Trythe solutions suggested here first in order to avoid the cost of an unnecessary service call.
Your refrigerator will not operate
Electrical Shock Hazard
Plug into agrounded 3prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Is the power supply cord unplugged? Plug into a grounded
3 prong outlet.
Has ahousehold fuse blown, or has a circuit breaker
tripped? Replace the fuse or reset the circuit breaker. If the
problem continues, call an electrician.
Is the refrigerator or freezer control turned to the OFF
position? See "Using the Control(s)."
Is the refrigerator defrosting? Recheck to see if the
refrigerator is operating in 30 minutes. Your refrigerator will
regularly run an automatic defrost cycle.
Is the refrigerator not cooling? For models with digital
controls, turn the unit OFF then ON again to reset. See "Using
the Control(s)." If this does not correct the problem, call for
service.
The lights do not work
•Is the refrigerator in "Holiday Mode?" See "Holiday Mode."
• Is the power supply cord unplugged? Plug into a grounded
3 prong outlet.
• Is a light bulb loose in the socket or burned out? See
"Changing the Light Bulb(s)."
• Has the door been open more than 10 minutes? When the
door is held open for more than 10 minutes, the "Door Open"
indicator light will flash and the interior lights will shut off. See
"Door Open" in "Using the Control(s)."
There is water in the defrost drain pan
• Is the refrigerator defrosting? The water will evaporate. It is
normal for water to drip into the defrost pan.
• Is it more humid than normal? When it is humid, expect that
the water in the defrost pan will take longer to evaporate.
13

The motor seems to runtoo much
Is the room temperature hotter than normal? The motor
will run longer under warm conditions. At normal room
temperatures, expect your motor to run about 80% of the
time, Under warmer conditions, it will run even more,
Has a large amount of food just been added to the
refrigerator? Adding a large amount of food warms the
refrigerator. The motor normally will run longer to cool the
refrigerator back down,
Are the doors opened often? The motor will run longer
when this occurs, Conserve energy by getting all items out at
one time, keeping food organized, and closing the door as
soon as possible,
Are the controls not set correctly for the surrounding
conditions? See "Using the Control(s)."
Are the doors not closed completely? Close the doors
firmly. If they do not close completely, see "The doors will not
close completely" later in this section.
Are the condenser coils dirty? This prevents air transfer and
makes the motor work harder. Clean the condenser coils. See
"Cleaning,"
Are the door gaskets not sealed all the way around?
Contact a technician or other qualified person.
NOTE: Your new refrigerator will run longer than your old one
due to its high-efficiency motor.
The refrigerator seems to make too much noise
•The sounds may be normal for your refrigerator. See
"Normal Sounds,"
The ice maker is not producing ice or not enough ice
Has the ice maker just been installed? The ice bin holds
approximately 7 Ibs (3.2 kg) of ice. The ice bin can take three
to four days to completely fill, if no ice is used during this
time,
Is the freezer temperature cold enough to produce ice?
Wait 24 hours after ice maker hookup for ice production. See
"Using the Control(s),"
Is the ice maker ON/OFF control in the OFF (down)
position? Slide the ice maker ON/OFF control to the ON (up)
position. See "Ice Maker and Storage Bin."
Is the water line shutoff valve to the refrigerator not
turned on? Turn on the water valve. See "Connect Water Line
to Refrigerator" in the Installation Instructions.
Is an ice cube jammed in the ice maker ejector arm?
Remove the ice from the ejector arm with a plastic utensil,
See "Ice Maker and Storage Bin."
Does the ice maker mold have water in it or has no ice
been produced? Make sure your refrigerator has been
connected to a water supply and the supply shutoff valve is
turned on. See "Connect Water Line to Refrigerator" in the
Installation Instructions.
Has a large amount of ice just been removed? Allow three
to four days for an empty ice bin to completely fill, if no ice is
used during this time.
Are the controls set correctly? See "Using the Control(s)."
Is there a water filter installed on the refrigerator? The
filter may be clogged or installed incorrectly, Check the filter
installation instructions to ensure that the filter was installed
correctly and is not clogged. If installation or clogging is not a
problem, call a technician or other qualified person.
NOTE: If not due to any of the above, there may be a problem
with the water line, Call for service.
Off-taste, odor or gray color inthe ice
•Are the plumbing connections new, causing discolored or
off-flavored ice? Discard the first few batches of ice.
•Have the ice cubes been stored too long? Throw old ice
away and make a new supply.
•Does the freezer and ice bin or bucket need to be
cleaned? See the "Cleaning" or "Ice Maker and Storage Bin,"
•Has food in the freezer or refrigerator been wrapped
properly? Use airtight, moisture-proof packaging to help
prevent odor transfer to stored food.
•Does the water contain minerals (such as sulfur)? A filter
may need to be installed to remove the minerals.
Is there a water filter installed on the refrigerator? Gray or
dark discoloration in ice indicates that the water filtration
system needs additional flushing. Run additional water
through the water dispenser to flush the water filtration
system more thoroughly (at least 6 qt [5.7 L] or 3 to 4 minutes
initially), Discard discolored ice.
The divider between the two compartments iswarm
The warmth is probably due to normal operation of the
automatic exterior moisture control. If still concerned, call for
service.
Temperature is too warm
Are the air vents blocked in either compartment? This
prevents the movement of cold air from the freezer to the
refrigerator. Remove any objects from in front of the air vents.
See "Ensuring Proper Air Circulation" for the location of air
vents.
Are the door(s) opened often? The refrigerator will warm
when this occurs. Keep the refrigerator cool by getting all
items out at one time, keeping food organized, and closing
the door as soon as possible.
Has a large amount of food just been added to the
refrigerator or freezer? Adding a large amount of food
warms the refrigerator. It can take several hours for the
refrigerator to return to the normal temperature,
Are the controls set correctly for the surrounding
conditions? See "Using the Control(s)."
Is the refrigerator not cooling? For models with digital
controls, turn the unit OFF then ON again to reset. See "Using
the Control(s)." If this does net correct the problem, call for
service.
14

There is interior moisture buildup
•Are the air vents blocked in the refrigerator? Remove any
objects from in front of the air vents, See "Ensuring Proper Air
Circulation" for the location of air vents.
Are the door(s) opened often? Avoid humidity buildup by
getting all items out at one time, keeping food organized, and
closing the door as soon as possible.
Is the room humid? It is normal for moisture to build up
inside the refrigerator when the room air is humid,
Is the food packaged correctly? Check that all food is
securely wrapped, Wipe off damp food containers before
placing in the refrigerator.
Are the controls set correctly for the surrounding
conditions? See "Using the Control(s)."
Was aself-defrost cycle completed? It is normal for
droplets to form after the refrigerator self-defrosts.
The doors will not close completely
•Are food packages blocking the door open? Rearrange
containers so that they fit more tightly and take up less
space,
Is the ice bin out of position? Push the ice bin in all the way.
If the ice bin does not go in all the way, it may not be put in
straight. Pull it out and try again. See "Ice Maker and Storage
Bin."
Are the pans, shelves, bins, or baskets out of position?
Put the crisper cover and all pans, shelves, bins, and baskets
back into their correct positions. See "Crisper and Crisper
Covers."
• Are the gaskets sticking? Clean gaskets according to the
directions in "Cleaning."
•Does the refrigerator wobble or seem unstable? Level the
refrigerator. See "Adjust Doors" and "Level Refrigerator" in
the Installation Instructions.
The doors are difficult to open
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
• Are the gaskets dirty or sticky? Clean gaskets according to
the directions in "Cleaning."
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
"Troubleshooting." It may save you the cost of a service call. If
you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If You Need Replacement Parts
If you need to order replacement parts, we recommend that you
use only factory specified parts. Factory specified parts will fit
right and work right because they are made with the same
precision used to build every new KITCHENAID®appliance.
To locate factory specified parts in your area, call us or your
nearest designated service center.
Call the KitchenAid Customer eXperience Center
toll free: 1-800-422-1230.
Our consultants provide assistance with:
• Features and specifications on our full line of appliances.
• Installation information.
• Use and maintenance procedures.
• Accessory and repair parts sales.
• Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).
• Referrals to local dealers, repair parts distributors, and
service companies. KitchenAid designated service
technicians are trained to fulfill the product warranty and
provide after-warranty service, anywhere in the United States.
To locate the KitchenAid designated service company in your
area, you can also look in your telephone directory Yellow
Pages.
For Further Assistance
If you need further assistance, you can write to KitchenAid with
any questions or concerns at:
KitchenAid Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, M149022-2692
Please include a daytime phone number in your correspondence.
15

Call the KitchenAid Canada Customer Interaction Centre toll free:
1-800-807-6777.
Our consultants provide assistance with:
• Features and specifications on our full line of appliances.
• Use and maintenance procedures.
• Accessory and repair parts sales.
• Referrals to local dealers, repair parts distributors, and
service companies. KitchenAid Canada designated service
technicians are trained to fulfill the product warranty and
provide after-warranty service, anywhere in Canada.
For Further Assistance
If you need further assistance, you can write to KitchenAid
Canada with any questions or concerns at:
Customer Interaction Centre
KitchenAid Canada
1901 Minnesota Court
Mississauga, Ontario L5N 3A7
Please include a daytime phone number in your correspondence.
WATER FILTER
CERTIFICATIONS
State oi Cali(i>mia
Department of Heahh Scrwlces
Water Treatment Device
Certifica/c Number
03- 1551
Date l_sued January 21, ?O03
rr adomark/Mod,,I Designation Replacemenl Elemems Rated Ca_
Whlr(pt)ol Wt,-NI C2€0V NLC2dOV 240 gal
L('4(_IV 400 gal
Organic ('ont aminam_
To order accessories, call 1-800-442-9991 and ask for the
appropriate part number listed below or contact your authorized
KitchenAid dealer. In Canada, call 1-800-807-6777.
Stainless Steel Cleaner & Polish
Order Part #8171420
Replacement Water Filter:
NOTE: Do not use with water that is microbiologically unsafe
or of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction may
be used on disinfected waters that may contain filterable
cysts.
Order Part #4396548 (LC 400V)
llated Set _ice Fiow: 05gpm
Do not use where _ater is microbioloeieally unsale or with water of unknown qualit% except thai s3 steml
certified flJr cyst reducli_n may be _s_d on disinfected _at_rs that may contain filterable cysts.
16

PRODUCT DATA SHEETS
Base Grille Water Filtration System
Model WF-LC400V/LC400V Capacity 400 Gallons (1514 Liters)
Tested and certified by NSF International against ANSI/NSF Standard 42 for
the reduction of Chlorine Taste and Odor, Particulate Class I_; and against
ANSl/NSF Standard 53 for the reduction of Lead, Mercury, Atrazine, Benzene,
Toxaphene, p-dichlorobenzene, 2, 4-D, Cysts, Turbidity and Asbestos.
This system has been tested according to ANSl/NSF 42/53 for the reduction of the substances listed below. The concentration of
the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for
water leaving the system, as specified in ANSI/NSF 42/53.
Substance Reduction NSF Reduction Average Influent Challenge Maximum Average Minimum %Average %
Aesthetic Effects Requirements Influent Concentration Effluent Effluent Reduction Reduction
Chlorine Taste/Odor ->50% 2.1 mg/L 2.0 mg/L _+10% 0.06 mg/L 0.05 mg/L 97.1% 97.6%
Particulate Class 1" 5,366,667/mL 4,100/mL** 99.9%
_>85% At least 10,000 2,300/mL 99.3%
particles/mL
Contaminant NSF Reduction Average Influent Challenge Maximum Average Minimum %Average %
Reduction Requirements Influent Concentration Effluent Effluent Reduction Reduction
Lead: @ pH 6.5 0.Olmg/L 0.152 mg/L1- 0.15 mg/L _+10% 0.001 mg/L 0.001 mg/L 99.34% 99.34%
Lead: @ pH 8.5 0.01mg/L 0.143 mg/L1- 0.15 mg/L _+10% 0.001 mg/L 0.001 mg/L 99.30% 99.30%
Mercury: @ pH 6.5 0.002 mg/L 0.0061 mg/L 0.006 mg/L _+10% 0.0004 mg/L 0.0003 mg/L 93.5% 96.7%
Mercury: @ pH 8.5 0.002 mg/L 0.0057 mg/L 0.0058 mg/L _+10% 0.0008 mg/L 0.00051 mg/L 85.8% 91.2%
Benzene 0.005 mg/L 0.0162 mg/L 0.015 _+10% 0.0005 mg/L 0.001 mg/L 96.3% 96.3%
p-dichlorobenzene 0.075 mg/L 0.220 mg/L 0.225 _+10% 0.0005 mg/L 0.0005 mg/L 99.7% 99.7%
Toxaphene 0.003 mg/L 0.014 mg/L 0.015 _+10% 0.0014 mg/L 0.001 mg/L 90% 92.96%
Atrazine 0.003 mg/L 0.0086 mg/L 0.009 mg/L _+10% 0.0005 mg/L 0.0005 mg/L 94.25% 94.25%
2, 4-D 0.07 mg/L 0.197 mg/L 0.210 _+10% 0.058 mg/L 0.0137 mg/L 70.6% 93.06%
Asbestos 99% 26 x 107 107to 10_fibers/Ll-1 - 0.18 x 107 mg/L 0.18 x 107mg/L 99.93 99.93%
Cysts:[: 99.95% 111,000/mL 50,000/L min. 1 mg/L 1 mg/L 99.99% 99.99%
Turbidity 0.5 NTU 11.00 NTU 11 _+1 NTU 0.40 NTU 0.35 NTU 96.4% 96.8%
Test Parameters: pH = 7.5 + 0.5 unless otherwise noted. Flow = 0.5 gpm (1.9 Lpm). Pressure = 60 psig (413.7 kPa). Temp. = 63°F
(17.2°C).
• It is essential that operational, maintenance, and filter
replacement requirements be carried out for the product to
perform as advertised.
•Model WF-LC400V The filter monitor system measures the
amount of water that passes through the filter and alerts you
to replace the filter. When 90% of the filter's rated life is used,
the filter indicator light changes from green to yellow. When
100% of the filter's rated life is used, the filter indicator light
changes from yellow to red, and it is recommended that you
replace the filter. Use replacement cartridge LC400V, part
#4396548. 2005 suggested retail price of $39.99 U.S.A./
$49.95 Canada. Prices are subject to change without notice.
• The product is for cold water use only.
• Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used
on disinfected waters that may contain filterable cysts.
• Refer to the front cover or "Accessories" section for the
Manufacturer's name, address and telephone number.
• Refer to the "Warranty" section for the Manufacturer's limited
warranty.
Application Guidelines/Water Supply Parameters
Water Supply City or Well
Water Pressure 30 - 120 psi (207 - 827 kPa)
Water Temperature 33 ° - 100°F (0.6 ° -37.8 ° C)
Service Flow Rate 0.5 GPM (1.89 L/min.) @ 60 psi.
*Class I particle size: >0.5 to <1 um
**Test requirement is at least 100,000 particles/mL of AC Fine Test Dust.
1-These contaminants are not necessarily in your water supply. Performance may vary based on local water conditions.
1-1-Fibers greater than 10 um in length
SBased on the use of Cryptosporidium parvum oocysts
® NSF is a registered trademark of NSF International.
17

KITCHENAID ®REFRIGERATOR WARILANTY
TWO YEAR LIMITED WARRANTY
For two years from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or
furnished with the product, KitchenAid or KitchenAid Canada (hereafter "KitchenAid") will pay for factory specified parts and repair labor to
correct defects in materials or workmanship. Service must be provided by a KitchenAid designated service company.
On models with a water filter: 30 day limited warranty on water filter. For 30 days from the date of purchase, when this filter is operated and
maintained according to instructions attached to or furnished with the product, KitchenAid will pay for replacement parts to correct defects in
materials and workmanship.
THIRD THROUGH SIXTH YEAR LIMITED WARRANTY ON SEALED REFRIGERATION SYSTEM PARTS AS LISTED
In the third through sixth years from the date of purchase, when this major appliance is operated and maintained according to instructions
attached to or furnished with the product, KitchenAid will pay for factory specified parts and repair labor costs to correct defects in materials
or workmanship in the sealed refrigeration system. These parts are: compressor, evaporator, condenser, dryer, and connecting tubing.
Service must be provided by a KitchenAid designated service company.
SEVENTH THROUGH TWELFTH YEAR LIMITED WARRANTY ON SEALED REFRIGERATION SYSTEM
In the seventh through twelfth years from date of purchase, when this major appliance is operated and maintained according to instructions
attached to or furnished with the product, KitchenAid will pay for factory specified parts to correct defects in materials or workmanship in the
sealed refrigeration system. These parts are: compressor, evaporator, condenser, dryer, and connecting tubing.
LIFETIME LIMITED WARRANTY ON DOOR BINS
For the life of the product, when this major appliance is operated and maintained according to instructions attached to or furnished with the
product, KitchenAid will replace all Door Bins due to defective materials or workmanship. Not available on refrigerated drawers.
ITEMS KITCHENAID WILL NOT PAY FOR
1. Service calls to correct the installation of your major appliance, to instruct you how to use your major appliance, to replace or repair
house fuses or to correct house wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs, air filters or water filters. Those consumable parts are excluded from warranty
coverage.
3. Repairs when your major appliance is used for other than normal, single-family household use.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in accordance
with electrical or plumbing codes, or use of products not approved by KitchenAid.
5. Any food loss due to refrigerator or freezer product failures.
6. Replacement parts or repair labor costs for units operated outside the United States or Canada.
7. Pickup and delivery. This major appliance is designed to be repaired in the home.
8. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
9. Expenses for travel and transportation for product service in remote locations.
10. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in accordance with published
installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIRAS PROVIDED HEREIN.
IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. KITCHENAID SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES. SOME STATESAND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS, SO
THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU
MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATETO STATEOR PROVINCE TO PROVINCE.
Outside the 50 United States and Canada, this warranty does not apply. Contact your authorized KitchenAid dealer to determine if another
warranty applies.
Ifyou need service, first see the "Troubleshooting" section of the Use & Care Guide. After checking "Troubleshooting," additional help can be
found by checking the "Assistance or Service" section or by calling KitchenAid. In the U.S.A., call 1-800-422-1230. In Canada, call 1-800-
807-6777. 9/05
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need it.
You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label located on the product.
Dealer name
Address
Phone number
Model number
Serial number
Purchase date
18

SEGURIDAD DEL REFRIGERADOR
Su seguridad y la seguridad de los demas es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual yen su electrodomestico. Lea y obedezca siempre
todos los mensajes de seguridad.
Este es el sfmbolo de advertencia de seguridad.
Este sfmbolo le llama la atencion sobre peligros potenciales que pueden ocasionar la muerte o una lesion a
usted y a los dem_.s.
Todos los mensajes de seguridad iran a continuacidn del simbolo de advertencia de seguridad y de la palabra
"PELIGRO" o "ADVERTENCIA". Estas palabras significan:
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesion grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesion grave.
Todos los mensajes de seguridad le diran el peligro potencial, le dir_.n cdmo reducir las posibilidades de sufrir una lesidn y Io que
puede suceder si no se siguen las instrucciones.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
ADVERTENCIA: Para reducir el riesgo de incendio, cheque electrico, o lesiones personales al usar su refrigerador siga
estas precauciones basicas:
• Conecte a un contacto de pared de conexi6n a tierra de
3 terminales.
• No use un adaptador.
• No quite la terminal de conexidn a tierra.
• No use un cable electrico de extensi6n.
• Desconecte el suministro de energia antes de darle servicio.
• Vuelva a colocar todos los componentes y paneles antes de
hacerlo funcionar.
• Remueva las puertas de su refrigerador viejo.
• Use un limpiador no inflamable.
• Mantenga los materiales y vapores infiamables, tales como
gasolina, alejados del refrigerador.
• Use dos o mas personas para mover e instalar el
refrigerador.
• Desconecte el suministro de energia antes de instalar la
fabrica de hielo (en aquellos modelos que incluyen el juego
de instalaci6n de la fabrica de hielo).
• Use un vaso resistente para recibir hielo del despachador
(en algunos modelos).
CONSERVAR ESTAS INSTRUCCIONES
C6mo deshacerse adecuadamente de
su refrigerador viejo
Antes de tirar su refrigerador viejo o congelador:
• Saque las puertas.
• Deje los estantes en su lugar asi los nitros no pueden meterse
adentro con facilidad.
Peligro de Asfixia
Rernueva las puertas de su refrigerador viejo.
No seguir esta instrucci6n puede ocasionar la muerte
o da_o al cerebro.
IMPORTANTE: El atrapamiento y asfixia de ni_os no es un
problema del pasado. Los refrigeradores tirades y abandonados
son un peligro.., aOn si van a quedar ahi "por unos pocos dfas".
Si Ud. esta per deshacerse de su refrigerador viejo, per favor
siga las instrucciones que se dan a continuaci6n para prevenir
accidentes. J
19

ANTES DE USAR
Cbmo quitar los materiales de empaque
Quite los residues de la cinta y goma de las superficies de su
refrigerador antes de ponerlo en marcha. Frote un poco de
detergente lquido para vajilla sobre el adhesive con los
dedos. Limpie con agua tibia y seque.
No use instrumentos filosos, alcohol para fricciones, lquidos
inflamables o limpiadores abrasives para eliminar restos de
cinta o goma. Estos productos pueden daSar la superficie de
su refrigerador. Para mas informaci6n, vea la secci6n
"Seguridad del refrigerador".
• Deshagase de todos los materiales de embalaje o reciclelos.
Cbmo limpiar su refrigerador antes de usarlo
Una vez que usted haya quitado todos los materiales de
empaque, limpie el interior de su refrigerador antes de usarlo.
Vea las instrucciones de limpieza en la secci6n "Cuidado de su
refrigerador".
Informacion importante para saber acerca de los estantes
ytapas de vidrio:
No limpie los estantes y tapas de vidrio con agua caliente
mientras estan frfos. Los estantes y tapas pueden romperse
si se exponen a cambios bruscos de temperatura o impacto,
como serfa un golpe brusco. Para su protecci6n, el vidrio
templado se ha dise_ado para hacerse a_icos. Esto es normal.
Los estantes y tapas de vidrio son muy pesados. Tenga
mucho cuidado al sacarlos para evitar que se da_en al caer.
Lea todas las instrucciones antes de comenzar.
IMPORTANTE:
• Cuando se instal6 su refrigerador, la conexi6n de agua desde
la fuente de agua debi6 haber sido conectada a su
refrigerador. Si no se conecta el refrigerador a una fuente de
agua, vea "Conexi6n al suministro de agua" en las
instrucciones de instalaci6n. Si tiene preguntas acerca de la
conexi6n de agua, vea "Soluci6n de problemas" o Ilame a un
plomero competente autorizado.
• Si usa el refrigerador antes de conectar la tuberia de agua,
ponga la fabrica de hielo en la posici6n OFR Vea "Fabrica de
hielo y dep6sito".
• Todas las instalaciones deben hacerse de acuerdo a los
requerimientos locales de plomeHa.
Presibn del agua
Se necesita un suministro de agua fria con presi6n de agua entre
30 y 120 Ibs/pulg 2(207 a 827 kPa) para hacer funcionar el
despachador de agua y la fabrica de hielo. Si usted tiene
preguntas acerca de la presi6n de agua, vea "Soluci6n de
problemas" o, lame a un plomero competente autorizado.
Suministro de agua de bsmosis inversa
IMPORTANTE: La presi6n del suministro de agua que sale de un
sistema de 6smosis inversa y va a la vMvula de entrada de agua
del refrigerador necesitara ser entre 30 y 120 Ibs/pulg _(207 a
827 kPa).
Si se conecta un sistema de filtraci6n de agua de 6smosis
inversa al suministro de agua fHa, la presi6n de agua al sistema
de 6smosis inversa necesitara ser de un minimo de 40 a 60 Ibs/
pulg 2(276 a 414 kPa).
Si la presi6n del agua del sistema de 6smosis inversa es menor
de 40 a 60 Ibs/pulg _(276 a 414 kPa):
• F[jese si el filtro de sedimentos en el sistema de 6smosis
inversa esta bloqueado y reemplacelo si fuera necesario.
Deje que se vuelva a Ilenar el tanque de almacenaje del
sistema de 6smosis inversa despues del uso intense.
Si su refrigerador tiene un filtro de agua, se podra reducir la
presi6n ann mas si se usa en conjunto con un sistema de
6smosis inversa. Quite el filtro de agua; vea "Sistema de
filtraci6n de agua".
Si tiene preguntas acerca de la presi6n del agua, lame a un
plomero competente autorizado.
USO DE SU REFRIGERADOR
Peligro de Cheque Electrico
Conecte a un contacte de pared de cone×ion a tierra de
3terminales.
No quite la terminal de cone×ion a tierra.
No use un adaptador.
No use un cable electrico de extensi6n.
No seguir eetae instruccionee puede ocasionar
la muerte, incendio ocheque el_£ctrico.
Peligro de Explosi6n
Mantenga los materiales y vapores inflamables,
tales como gasolina, alejados del refrigerador.
No seguir esta inetruccion puede ocaeionar la muerte,
explosion, o incendio.
I; II_, I; _,ii. Io[ _Q ............... Ii'" 11] = ' "
Si necesita encender (ON) o apagar (OFF) su refrigerador, deberi
quitar el ensamblaje de la rejilla superior para poder alcanzar el
interruptor de Encendido/Apagado. Cuando limpie el refrigerador
o cambie los focos, p6ngalo en OFF (Apagado).
20
