KitchenAid KBFC42FTS00 User manual

CABINET PARTS
1
For Model: KBFC42FTS00
(Stainless Steel)
3−08 Litho In U.S.A. (dmm) Part No. W10133570 Rev. B
42" BOTTOM MOUNT
BUILT IN REFRIGERATOR

CABINET PARTS
2
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
2320682 Use & Care Guide
2320685 Energy Guide
2316852 Service & Wiring
Sheet
2317849 Main Control
Service Sheet
2317840 Modular Icemaker
Service Sheet
2320680 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2307584 Grommet, Crossover
Tube
4
W10138054 Roller,
Front & Rear (4)
5 Support, Leveler
Assembly
2318194 Refrigerator Side
2318193 Freezer Side
8 8281164 Screw
9 2307640 Mounting Bracket,
Grille
10
W10004850 Screw
11 488234 Screw 8−32 x 1/4
12
W10129069 Clip (6)
13 2314064 Tube, Drain
15 487415 Screw, 8−18 x 3/8
16 2305274 Clamp, Tube
17
W10005070 Screw, Door Stop
18 2316759 Hinge, Door
Refrigerator Top
19 2320509 Cam−Closer,
Door
20 2221070 Clamp, Tube
21 2006617 Bracket,
Support Door
22 2316758 Stop, Door
23 2260526 Housing,
Water Filter
24 2004517 Spring,
Door Closure
25 486194 Screw
26 4396841 Filter, Water
27 2316859 Bushing−Arm,
Extension
28 2004994 Bushing, Hinge (2)
(Lock−Adjustable)
29 2302889 Hinge, Bottom
Refrigerator Door
30 489464 Screw, 8−18 x 1/2
31 489282 Screw
32 2209025B Skirt, Grille
(Bottom)
33 2314023 Bushing, Hinge (2)
34 2325188B Grille Base,
Front
35 2215612 Cover, Air Duct
36 Arm, Extension
2266882 Right
2266881 Left
37 Bracket, Switch
2221097 Right
2221096 Left
38 2215938 Cover, Switch
39 2260518B Cap, Water Filter
40 8533913 Screw
41 1118894 Switch,
Rocker Arm (2)
42
W10005050 Screw, 8−18 x 1/2
43 2318190 Bracket, Mounting
(Filter)
44 8281163 Screw 8−16 x 1/2
45 2260503B Button, Filter
46 2318189 Tray, Drip Filter
47 8533980 Screw

3
CABINET AND BREAKER TRIM PARTS
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 Breaker, Trim
(Not Serviced)
2
W10132472 Cabinet Trim,
Right Side
3 1163283 Screw
4 2316687 Cabinet Trim,
Bottom
5 486194 Screw
6 2314017 Cabinet Trim, Top
7 Cam, Mullion
2316857 Top
2316858 Bottom
8 2005782 Cover, Hinge
9 2005925 Seal−Trim,Side
10
W10132541 Cabinet Trim,
Left Side
11 489464 Screw, 8−18 x 1/2
12 Contact, Mullion
2309230 Top
2309231 Bottom
13 486194 Screw
14 2316899 Cover, Screw (2)
(Square)
15 2317078 Cover, Screw (2)
(Round)
16
W10121451 Nutsert (4)

TOP GRILLE AND UNIT COVER PARTS
4
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 2316737S Top Grille
Assembly
2 2320502 Cover, Unit
3 2317881 Grille, Condenser
4 2256466 Back Panel
5 2307682 Front,
Unit Cover
6 487415 Screw
7 2187946 Wire Assembly,
Light Switch
8 2317923S Nameplate
9 489348 Clamp
10 489399 Screw (5)
11 2004333 Nut

REFRIGERATOR LINER PARTS
5
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

REFRIGERATOR LINER PARTS
6
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 Liner,
Refrigerator
(Not Servicable)
2 2317004 Cover,
Air Return (2)
3 2320663 Control Box
Complete
4 2317000 Clip, Control Box
5 2324969 Bracket,
Control Box
6 2309248 Shield, Light
7 487539 Screw, 8−15 x 1/2
8 488163 Screw
9 2223857 Socket, Light (3)
10 2309101 Bulb, Light (3)
11 2317917 Clip,
Diffuser Cover
12 2320523 Diffuser Assembly
13 2188820 Cover, Diffuser
14 2320519 Thermistor
16 2317105 Cover, Thermistor
17 2268249 Diffuser, Crisper
(Complete)(2)
18 2196483 Stud, Shelf
19 Spacer, Crisper
2268331 Left
2268332 Right
20 Spacer, Deli
2306475 Left
2306474 Right
21 Slide, Crisper Pan
2302952 Left (2)
2302953 Right (2)
22 Center Support
2313997 Left Half
2313996 Right Half
23 Slide, Deli Pan
2302956 Left (2)
2302957 Right (2)
24 2314054 Support,
Deli Cover (2)
25 2309083 Cover, Center
(Crisper Pans)
26 2318008 Cover, Center
(Deli Pans)
27
W10001160 Screw, 8−32 x 1/2
28 2171931 Valve, Tube−Body
29 2310164 Wire, Jumper

FREEZER LINER PARTS
7
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

FREEZER LINER PARTS
8
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 Liner, Freezer
(Not Servicable)
2 2306425 Mounting Bracket,
Drawer Slide (2)
3
W10071460 Screw
4 2320616 Drawer Slide,
Freezer Basket (2)
5
W10061370 Screw
6 2314022 Cover,
Light Switch
7 1118894 Switch, Rocker
8 486194 Screw
9 2223857 Socket, Light
10 2309101 Bulb, Light
11 2268299 Switch Assembly,
Icemaker (Includes
Emitter)
12 2306187 Cover, Wiring
(Icemaker)
13 2317005 Duct, Air Flow
(Icemaker)
14 2306100 Cover, Evaporator
15 2317829 Cover,
Evaporator Fan
16 487539 Screw
17 2306106 Spacer, Drawer
(Right Side)
18 Slide, Freezer Bin
2306117 Left (2)
2306116 Right (2)
19 488163 Screw
20 2317925 Divider,
Freezer Bins
(Includes
Receiver)
21 2306104 Support, Slide
(Right)
22 2317927 Shield
23 2306105 Support, Slide
(Left)
24 Bracket,
Evaporator Cover
2320512 Left Side
2317893 Right Side
25 488163 Screw
26
W10121940 Bracket,
Air Return
28 2317105 Cover, Thermistor
29 2188820 Thermistor
30
W10075920 Washer
31 2320526 Washer (EPDM)
32 8533928 Screw
33
W10135430 Air Deflector Asy
34 2198643 Lens, Receiver

SHELF PARTS
9
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

SHELF PARTS
10
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 Crisper Pan
Assembly
(Includes # 2)
2268173 Left
2268171 Right
2 2256247 Front, Crisper Pan
3 Deli Pan Assembly
(Incl. #4, 5 & 6)
2317940 Left
2317941 Right
4 2256365 Front, Deli Pan
5 2307810 Duct, Deli Pan
6 2317939 Air Deflector
7 2179404 Rack, Wine
9 2306174 Ice Pan Assembly
(Includes # 10)
10 2306175 Front, Ice Pan
11 2327511 Freezer Pan
Assembly
(Includes # 12)
12 2256367 Front, Freezer Pan
13 2327314 Ladder, Shelf (4)
14 520965 Support, Ladder
15 2268246 Shelf (4)
16 Cover, Deli Bin
2320665 Left
2320667 Right
17 2309400 Gasket, Rear
18 2309045 Cover, Crisper
19 2309396 Gasket, Front
(Crisper Cover)
20 2309395 Gasket, Front (2)
(Deli Cover)
21 8281251 Screw
22 2006475 Screw
23 488886 Screw, 8−18 x 1/2
25 Locking Clip, Bin
2327393 Right
2327394 Left

REFRIGERATOR DOOR PARTS
11
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

REFRIGERATOR DOOR PARTS
12
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 Door, Refrigerator
(Includes Item 2)
2307903 Left
2307902 Right
2 2268265 Gasket, Door
3 2320642 Hinge Assembly,
Top
4 2256381 Spacer−Hinge, Top
5 489282 Screw, 10−32 x 3/4
6 2257647 Spacer, Hinge
(Bottom)
7 Bottom Hinge
Assembly
2316752 Left
2316751 Right
8 2316732 Skin, Door
9 2316868 Handle, Door (2)
10 2306398 Plate, Door Handle
11 308544 Screw, 10−24 x 1/2
12 2309218 Filler, Foam
13 2314068 Spacer, Door Edge
(Handle Side)
14 2316768 Spacer, Door Edge
(Hinge Side)
15 2309204 Spacer, Door Edge
(Top / Bottom)
16 2006346 Washer
17 2316760 Bushing, Top Hinge
18 8281250 Screw, 8−15 x 1/2
19 2307938 Mullion Assembly
20 2222769 Shelf, Door (2)
(Gallon)
21 2222772 Shelf, Door (4)
22
W10131132 Door, Utility Bin
23 2222795 Rail, Lid
24 2222981 Gasket,
Utility Bin
25 2222921 Bin, Utility
26 End Cap,
Utility Bin
2222920 Left Side
2222919 Right Side

FREEZER DOOR AND BASKET PARTS
13
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

FREEZER DOOR AND BASKET PARTS
14
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 2327400 Freezer Door
(Includes #9)
2 2317101 Divider,
Basket (2)
3 2314024 Mat, Basket
4
W10135775 Screw, 5/16 x 3/4
5
W10135792 Screw, 8/32 x 1/4
6 2309219 Filler, Foam
7 2316788 Spacer, Door
Edge − Side
8 2309221 Spacer, Door Edge
Top & Bottom
9 2309216 Door Gasket,
Magnetic
10 308544 Screw, 10−24 x 1/2
11 2316868 Handle, Door
12 2316733 Skin, Door
13 8281250 Screw, 8−15 x 1/2
14 2327532 Basket Assembly,
Freezer
15 2207454 Nut, Hex
16
W10001190 Washer
17
W10001170 Screw, 5/16−24 x 1
(Basket to Slide)

UPPER UNIT PARTS
15
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

UPPER UNIT PARTS
16
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10133449 Inverter Box
2 489373 Screw, Compressor
Mounting (4)
3 2302967 Compressor
(Includes Items
6, 9 & 21)
(Also Order
876765 Tube Kit)
4 2307683 Housing,
Control Board
5 2303091 Control Board
6 1100826 Grommet, Mounting
7 2309002 Support, Condenser
(Right)
8 2303033 Transformer
9 2215676 Terminal Cover
10 2309001 Support, Condenser
(Left)
11
W10121049 Control Board
12 2203075 Spacer (9)
13 2256328 Bracket,
Inverter Box
14 487415 Screw
15 1157158 Screw
16 2307998 Condenser
17 2309431 Grommet (2)
18 2310207 Wire, Jumper
19 489399 Screw
20 2155774 Wire Tie
21 2317982 Drier
22 2215641 Bracket, Fan Motor
23 2206036 Motor, Fan
24 2190685 Blade, Fan
25 2003169 Orifice, Fan
26 486692 Speed Nut
27 8281160 Screw
28 2317031 Bracket, Vibration
(Condenser)
29 2317030 Arm, Vibration
(Condenser)
30 2307566 Tube, Transition
(Condenser/Drier)
31 2194319 Tube, Process
32 486194 Screw
33 2309000 Cover, Condenser
34 2310251 Service Cord
35 2307684 Bracket, Mounting
(Power Switch)
36 549193 Clamp, Cord
37 2266802 Switch, Power
Disconnect
38 487294 Screw, Ground
39
W10123227 Wiring Harness,
Unit Compartment
40 2309432 Gasket, Condenser
41 488937 Clamp, Tube
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
6.25 oz.
(R−134A)

LOWER UNIT AND TUBE PARTS
17
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

LOWER UNIT AND TUBE PARTS
18
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 2309072 Tube, Transition
(Condenser)
2 2309070 Tube, Transition
(Drier/Restrictor)
3 486194 Screw
4 2307944 Clip
5 2307945 Bracket, Mounting
6 2309076 Tube, Suction
7 2306176 Heater, Defrost
8 2306178 Scroll Assembly
9 2223986 Grommet, Motor
10 2259385 Motor, Fan
11 2223733 Retainer,
Fan Motor
12 2169142 Blade, Fan
13
W10121368 Tube, Discharge
14 2310137 Defrost Bi−Metal
15 2306485 Evaporator
(Includes #5 & 7)
16 2320615 Drain Pan Assembly
17 2316684 Cover, Box
18 2316683 Cover, Wiring
19 2215648 Dampener, Heater
20 2306180 Block, Evaporator
Water Filter
21 2155774 Wire Tie
22 2317920 Clip, Heater
24 2320554 Bracket, Drain Pan

ICEMAKER PARTS
19
For Model: KBFC42FTS00
(Stainless Steel)
W10133570

ICEMAKER PARTS
20
For Model: KBFC42FTS00
(Stainless Steel)
W10133570
Illus. Part
No. No. DESCRIPTION
1 486194 Screw
2 2221240 Heater, Fill Tube
3 489136 Screw (2)
4 2310108 Jumper, Heater
Fill Tube
5 628379 Clip, Fuse
6 2325170 Tube, Filter Inlet
7 2317848 Tube Assembly,
Water Inlet
8 1106508 Seal Gasket
9 2317912 Tube,
Filter Outlet
10 2307650 Valve, Solenoid
11
W10129653 Shield, Valve
12 489464 Screw
13 2221231 Heat Shield
15 489348 Clamp, Valve
16 488946 Clamp, Tubing
17 2310136 Wire Harness,
Icemaker
18 2257538 Cover
19 626691 Module Assembly
(Includes Items
3 & 21)
20 628228 Mold & Heater
(Also Order
542638 Silicone
Grease)
21 626683 Motor
22 628356 Cup, Water Fill
23 627843 Ejector
24 2182124 Ice Stripper
25 2195914 Support
26 2315522 Retainer,
Thermostat (2)
27 627985 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
29 2320559 Support, Valve
30 489276 Screw
31 2310193 Wire Assembly
(Water Valve)
100 2316895 Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
8537055 Cleaner,
Stainless Steel
W10129081 Handle Kit for
Previous Architect
Series (Stainless)
