CABINET PARTS
1
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
10−07 Litho In U.S.A. (tpm) Part No. W10144702 Rev.B
REFRIGERATOR

CABINET PARTS
2
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
67006616 Tech Sheet
W10136989 Owners Manual
W10138143 Tag, Energy
2 M0114003 Clip
3 67003405 Plate, Pivot
4 B5759649 Gasket
5 67006118 Roller Assembly
6 12627302 Clip, Grille
7 A3076901 Plug, Bottom
8 67006611 Bolt, Adjustable
9 67006521 Screw
10 12456801 Bracket, Roller
11 67006380 Screw
12 M1205302 Pin, Roller
13 Cover, Left Hinge
12684201W White
12684201B Black
14 67006303 Screw
15 Hinge, Center (2)
67006379 White (RT)
67006277 White (LT)
67006443 Black (RT)
67006442 Black (LT)
16 67004092 Block, Filter
17 Cover, Corner
67003484 White
67003485 Black
18
12566605ED Hinge, Top Left
19 67007174 Bracket, Foot
20 67006564 Screw
21 12579702 Shim, Hinge
22 Grille Assembly
(Includes Clips)
67006377 White
67006375 Black
23 67004102 Track, Water Line
24 M0286708 Nut, Speed
25 67006425 Screw
26 67003331 Cover, Water Line
27 67004098 Cover, Water Valve
28 67006626 Screw
30
12575101ED Cover, Unit
31
W10137519 Fill Tube Asm
32 67006506 Power Cord
33 67003796 Insulation, Sound
34 67003868 Foot Brake
35 67006697 Bolt, Adjusting
(Rear)
36 M0104106 Clip, Tube
37 67001066 Tube, Drain
38 67001067 Clip, Drain Tube
39 M0104102 Clamp, Cord
40 Cabinet (Not a
Serviceable Part)
41
12566604ED Hinge, Top Right
42 Cover, Right Hinge
12684202W White
12684202B Black
43 67005127 Roller

FREEZER LINER PARTS
3
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702

FREEZER LINER PARTS
4
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 12002497 Gear (2)
(Includes RT & LT)
4 67003905 Cover, Light
5 67004017 Shaft
6 8170839 Socket, Light
8 67006473 Screw
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005873 Cover, Evaporator
12 67006425 Screw
13 Bracket, Door
67004732 Left
67004733 Right
14 67003906 Housing, Lighting
15 67005633 Clip, Evap Motor
16 12002646 Switch, Light
18 Bracket, Basket
67004728 Left
67004729 Right
19 67004863 Slide, Drawer (2)
20 67003731 Gasket, Bottom
21 Bracket, Slide
67004971 Left
67004972 Right
22 13024802 Grille, Fan Shroud
23 67002777 Shroud, Evap Fan
24 12217201 Blade, Fan
(Evaporator)
25 67002780 Grommet (2)
26 67003636 Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67004892 Screw
33 67006530 Screw
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)

REFRIGERATOR LINER PARTS
5
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702

REFRIGERATOR LINER PARTS
6
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67004078 Bracket, Control
and Lights
3 67005949 Overlay
4 67005444 Housing,
Electronic Control
5 67005397 Electronic Control
6 C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light
10 8170839 Socket, Light
11 67003900 Insert,
Damper Cover
12 67006602 Screw
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
16 12002355 Thermister
17 61006182 Union, Tube
19 67004091 Tank, Water
20 67002979 Dispenser
21 67006287 Screw
22 67001668 Plate, Filter
23 67006524 Head, Water
Filter Assembly
24 12568001 Cover, Filter
25 67006469 Filter, Water
26 12664501 Plug, Filter
Bypass
27 B8390302 Clip, Waterline
28 67006400 Screw
29 67005674 Facade, Dispenser
30 12575501 Switch, Limit
31 67002742 Plate, Switch
32 67002816 Clip, Water Tube
33 67002743 Guide, Water
Line
Following Parts Not Illustrated
8208197 Harness,
Damper Control
67005417 Harness, Controls
(Refrigerator)
(Includes # 16)

REFRIGERATOR DOOR PARTS
7
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702

REFRIGERATOR DOOR PARTS
8
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Door, Left
13024006W White
13024006B Black
W10137005 Stainless Steel
2 Bushing, Door
(Bottom Left)
67002732 White
67002721 Black
3 67003819 Compartment, Door
(Includes Item 4)
4 67001279 Tray, Dairy
5 67005672 Bin, Shelf(2)
(Medium)
6 67006786 Screw
7 67002935 Screw
8 Gasket, Door
W10137006 White
12723206B Black
9 Door Handle
2319727W White
2319727B Black
2319727S Stainless
10 67004790 Stud, Handle
12 67005673 Bin, Shelf (2)
(Large)
14 Mullion, Door
67003434 White
67004131 Black
15 67005626 Caddy, Can
16 Closure, Door
67003638 White
67003639 Black
17 Stop, Door
12968202W White
67007011 Black
18 Plug, Vent
10712401 White
67004838 Black
19 Bushing, Door
(Upper Left)
67002722 White
12395501B Black
20 Bushing, Door
(Upper Right)
67004977 White
67004978 Black
21 67006287 Screw
22 Bushing, Door
(Lower Right)
67002732 White
67002731 Black
23 Door, Right
13024005W White
13024005B Black
W10137008 Stainless Steel
25 Nameplate
W10046670 White
W10046640 Black
W10046610 Grey

UNIT PARTS
9
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702

UNIT PARTS
10
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2 67004952 Blade, Fan
3 67005889 Base
4 67006573 Screw
5 67004954 Screw
6 67005421 Cover, HV Box
7 67005679 Harness, Evap
Heater
8 67007175 Drain Pan
9 61004743 Grommet (3)
10 67002493 Evaporator Heater
11 C8931612 Capacitor
(See Item # 12)
12 67005560 Overload/Relay
(Capacitor Incl.)
13 61003210 Seal
14 67003426 Bi−Metal
15 67005680 Grommet (7)
16 67006615 Screw
17 67007052 Strap
18 67006131 Condenser
19 67006550 Screw
20 67002490 Tray, Drip
21 67005719 Spacer
22 12002041 Evaporator
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060201 Harness, Unit
27 2317845 Drier (Service)
28 12002634 Compressor
(Includes Items
11, 12, 17,
27 & 35)
29 12782027 Control Board
30 12972902 Harness, Wiring
31 12575305 Shroud
32 67004953 Bracket, Fan Motor
33 67005718 Box, Control
34 10547003 Clip, Drier
35 67003493 Grommet (4)
36 10623002 Clip, Evaporator
37 67006737 Screw
38 67006432 Screw
40 67004700 Tube, Discharge
41 67006425 Screw
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)

SHELF PARTS
11
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702

SHELF PARTS
12
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67002332 Glass, Pantry
2
W10136387 Egg Bin
3 67001310 Screw
4 67006010 Support, Pantry(2)
5 67002330 Brace, Pantry (2)
6 67001719 Track, Pantry
8 67004127 Divider,
Upper Basket
9 67002329 Gasket, Pantry
10 67005625 Housing, Control
11 67005676 Shelf, Slide (4)
12 67003793 Slide, Temperature
14 67007026 Glide, Drawer(2)
15 67006287 Screw
16 Track, Pantry
67005862 Left
67005860 Right
17 Pan, Crisper (2)
18 67002488 Support, Crisper
Cover
19 67005675 Trim, Crisper
20 67006185 Frame, Crisper
21 67006655 Glass, Crisper
Cover
22 67003036 Ladder, Center
23 67003037 Ladder, Side
24 67006400 Screw
25 67006360 Screw
26 67006415 Screw
27 67005864 Slide, Humidity
Control
28 67003794 Bar, Temperature
Control
29 67003530 Drawer, Pantry
30 67003791 Knob, Temperature
Control
31 67005930 Door,
Pantry Drawer
32 67006026 Basket, Freezer
(Lower)
33 67004812 Divider,
Lower Basket
34 67004988 Basket, Freezer
(Upper)
39 67002321 Divider,
Pantry Drawer
W10143396

FREEZER DOOR PARTS
13
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Freezer Door
(Includes
Insulation)
67004810 White
67004808 Black
W10136412 Stainless Steel
2 Handle
2319727W White
2319727B Black
2319727S Stainless
3 67006408 Screw
4 Gasket, Door
W10133249 White
W10131754 Black
5 67002935 Screw
7 Plug, Vent (2)
10712401 White
67004838 Black
9 67004790 Stud, Handle

ICEMAKER PARTS
14
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Mold & Heater
Assembly
(Not Available −−
Order D7824706Q)
2 67004028 Arm, Shutoff
3 628356 Cup, Fill
4 627843 Ejector
5 2182124 Ice Stripper
6 2195914 Support & Motor
Assembly
7 2315522 Retainer,
Thermostat
8 Thermostat
(Not Available −−
D7824706Q)
9 681249 Screw
10 67001255 Pan, Ice
11 67004101 Bracket,
Tube Support
12 67006531 Valve, Dual
Water Inlet
13 A3223101 Insert, Tube
14 67003729 Tubing, Plastic
15 67006614 Harness, Ice Maker
16 625910 Bracket
17 681390 Screw
18 67004710 Cover
19 Module Assembly
(Not Available −−
Order D7824706Q)
20 67006287 Screw
100
D7824706Q Complete Icemaker

OPTIONAL PARTS (NOT INCLUDED)
15
For Models: KBFS20ETWH00,KBFS20ETBL00,KBFS20ETSS00
(White) (Black) (Stainless Steel)
W10144702
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−up kit
(Black)
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
Refinishing Material
799340 Enamel, Black
(1 Qt. Uncut)
799344 Enamel, White
(1 Qt. Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
876370 Kit, Insulation
(2 Pcs. x 3" x 24"
X 48")
876305 Kit, Insulation
(14 Pcs. x 3"
x 24" x 48")
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
X 2−5/8)
876029 Kit, Foam Slab
(30" x 32−1/2"
x 1−1/2")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
D7824706Q Ice Container
Assembly
18001005 Icemaker Install
Kit
TORX SCREW WRENCH
1117510 Torx Key
