KitchenAid KSRS25QAAL02 User manual

1 Cabinet (Not A Serviceable Part)
2 2152011 Front Roller (2)
3 489393 Screw
4 981122 Roller (Rear) (2)
5 488454 Screw
6 2155013 Clip, Grille
7 489242 Screw
9 836196 Shim
12 1117937 Hinge Top (R.H.)
13 1123515 Shim, Hinge Top
14 489284 Screw
15 Hinge Cover
1129262 White
2150343 Almond
16 2151629 Hinge Bottom (R.H)
19 2151630 Hinge Bottom (L.H)
20 1129868 Spacer, Hinge
21 Filler, Wrapper
1110708 White
1110709 Almond
22 Grille
1125715 White
1125717 Almond
23 489367 Screw
30 1123510 Hinge, Top (L.H.)
31 2147310 Tap Plate (2)
35 489337 Screw
40 937360 Service Cord
41 940139 Drain Fitting
42 1108438 Tube, Extension
43 1108439 Clip, Drain Tube
47 2161367 Cover, Unit
49 Hinge Cover
1119787 White
1119789 Almond
50 489366 Washer
52 549193 Clamp, Service Cord
53 489084 Screw
54 986759 Door Closer, Lower Cam
55 489375 Screw

1 Liner (Not A Serviceable Part)
2 985468 Escutcheon, Meat Pan Control
3 984102 Slide Meat Pan Control
4 992358 Foam Pad
6 1125675 Stud, Pan Cover
8 1110718 Stud (9)
9 1116794 Ladder, Shelf (2)
10 658944 Stud, Shelf (2)
11 486298 Screw (2)
12 487539 Screw
13 487559 Screw (2)
14 941839 Plug, Hole
16 1126137 Rack, Wine & Egg
22 1123919 Bracket Retainer
23 489290 Screw, (2)
24 2161251 Air Diffuser Assembly
25 2152019 Air Diffuser Cover
26 2150331 Cover, Conduit
29 851067 Socket, Light
30 842534 Clip, Air Duct
31 2155290 Reservoir
33 527949 Light Bulb
34 1125586 Light Lens
37 488280 Screw (2)

1 1125597 Shelf Assembly, Cantilever (2)
2 1125593 Glass, Shelf
3 1125594 Retainer, Glass
4 1125786 Gasket, Front
5 1126154 Cover, Pan Assembly (2)
6 1125705 Gasket, Cover (Front)
7 1125706 Gasket, Cover (Rear)
8 1125822 Glass, Cover (2)
9 2161760 Pan Shelf & Slide Assembly (Includes 13, 14, & 15)
10 1125595 Glass, Shelf
11 1125814 Gasket (Front)
12 1125817 Gasket (Rear)
13 1112308 Eyelet, Roller
14 2161749 Roller
15 489212 Screw
16 2161893 Crisper Pan (2) (Includes 13, 14 & 19)
17 2161892 Utility Pan
19 489261 Screw
20 1116917 Container
22 2161683 Glass, Shelf
23 2161809 Reflector
24 2161686 Gasket, Front
25 2161706 Frame And Roller
26 2161806 Frame And Roller Assembly (Cantilever)

1 Liner (Not A Seviceable Part)
2 1125824 Shelf, Top Compartment
3 1125657 Door, Ice Compartment
5 946356 Stud, R.S. Front
6 842534 Clip, Air Duct (2)
7 1115317 Support, Stud (4)
8 946355 Support, Stud (2)
9 1110779 Grommet (2)
10 Slide, Container
1119237 Left Side
1119293 Right Side
11 2155683 Shelf
12 489100 Screw (4)
14 2155572 Cover, Wiring
15 489176 Screw
16 2155556 Drain Fitting
17 Shelf Track
1126354 Right Side (3)
1126355 Left Side (3)
18 487042 Screw
19 1115373 Switch, Rocker Arm
20 489242 Screw
21 2155685 Basket, Middle
22 1125770 Front, Basket
23 2152093 Basket, Upper
24 1125612 Front, Basket
25 2152102 Basket, Lower
27 1115386 Stud, Shelf (4) Compartment
29 1115389 Light Lens
30 1106982 Stud, R.S. Rear
32 851067 Socket, Light
33 527949 Bulb, Light

1 1118386 Bracket, Motor
2 2155263 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Solenoid
6 1115374 Clip, Wiring
7 2149192 Wiring Assembly, Ice Dispenser
8 489399 Screw
9 983663 Coupling, Motor
10 489242 Screw
11 851067 Socket, Light
12 1115339 Cover, Motor
14 2152702 Ice Container
15 983668 Coupling, Conveyor
16 1118480 Stop, Cone
17 1119074 Feeder Cone
18 1119005 Spacer, Step (3)
19 1119007 Spacer, Flat (2)
20 1119006 Blade, Rotary
21 1119012 Blade, Rotary
22 1119013 Blade, Rotary
23 489235 Washer, Plain
24 1119009 Blade, Fixed (2)
25 2157405 Block, Blade
26 489229 Roll Pin
27 1119003 Conveyor
28 2157406 Drum
29 1118470 Drive Bar
30 2157404 Floating Baffle
31 1119018 Nut, Bearing
32 2155231 Control Arm
33 1119020 Spring, Return
34 1119021 Retainer Clip, Rod
35 488886 Screw
37 2157407 Housing, Crusher
38 1119017 Deflector, Ice
39 489234 Washer, Plain
40 489236 Retainer Ring
41 2152700 Housing, Filler
42 2152021 Sleeve-Auger
43 1119043 Ice Deflector
44 1126036 Front Cover, Ice Container
45 527949 Light Bulb
46 983359 Light Lens, Dispenser
Parts Not Illustrated and Optional Parts (Not Included)
Customer Touch Up Material
350942 *Primer, White (13 Oz. Spray Can)
350941 *Leveler, Enamel (13 Oz. Spray Can)
350939 *Enamel, Black (13 Oz. Spray Can)
350930 *Enamel, White (13 Oz. Spray Can)
350956 *Enamel, Almond (13 Oz. Spray Can)
72017 Brush Touch-Up Kit (White)
72107 Brush Touch-Up Kit (Almond)
72032 Brush Touch-up kit (Black)
Miscellaneous

212643 Sealer, Gum (4 Feet)
479502 Tape, Vinyl (3/4 x 108")
876370 Kit, Insulation (2 Pcs. x 3" x 24" X 48")
876305 Kit, Insulation (14 Pcs. x 3" x 24" x 48")
978941 Insulation, Fiberglass (63-1/2" x 35-1/2" X 2-5/8)
876029 Kit, Foam Slab (30" x 32-1/2" x 1-1/2")
505587 Sealer, Mastic (1 Qt.)
503695 Cork, Sealer (1/4 Pound)
511873 Touch-Up, White Porcelain (2 Oz.)
542638 Grease, Silicone (1/2 Oz.)
542639 Cement, Alumilastic (1-1/4 Oz.)
606755 Bag, Insulation (36-5/8" x 46")
799833 Kit, Evaporator Repair (Aluminum Epoxy)
833938 Kit, Terminal Connector
515393 Transformer (115-230 Volts)
2152710 Ice Container Asm
2149072 Ice Crusher Asm
Refinishing Material
799340 Enamel, Black (1 Qt. Uncut)
799344 Enamel, White (1 Qt. Uncut)
978883 Enamel, Almond (1 Qt. Uncut)
LITERATURE PARTS
LIT2161900 Use And Care Guide
LIT2155697 Service & Wiring Sheet
LIT2168636 Energy Label
LIT628370 Modular Icemaker Service Sheet
TORX SCREW WRENCH
1117510 Torx Key

1 Refrigerator Door (Includes #7)
2159404 White
2159405 Almond
2 1117999 Load, Lock (4)
3 2159136 Door, Compartment
4 1125981 Holder, Beverage
5 1125936 Butter Dish
6 Insert, Handle
1117948 White
1117949 Almond
7 2159079 Door Gasket, Magnetic (Service)
8 1107341 End Cap, Handle
9 489075 Screw
10 1107215 Handle Assembly
11 487909 Screw
12 1107651 Spacer, Handle
13 1104787 Shim, Door Closer
14 488938 Screw
15 2157611 Bracket, Door Stop
16 1117952 Retainer, Insert (Bottom)
17 1107243 Retainer, Insert
18 1119062 Trim, Door
19 1125555 Shelf Bin (4)
Following Parts Not Illustrated (Optional Parts Only)
BLACK GLASS PANEL KIT (OPTIONAL KIT)
4318336 Trim Kit Acrylic Panel Kit
4210348 Black
4211148 White
4211147 Almond Handle Inserts
4318339 Black
4318340 Woodgrain
4318417 Black Grille Kit

1 Freezer Door (Includes #8 And Dispenser Front Parts)
2159351 White
2159352 Almond
2 1107215 Handle Assembly
3 1107341 End Cap (2)
4 487909 Screw
5 1107651 Spacer, Handle
6 489075 Screw
7 2156016 Shelf Bin (4)
8 2159078 Door Gasket, Magnetic (Service)
9 Insert, Handle
1117948 White
1117949 Almond
10 2157603 Trim, Door Shelf
11 2156006 End Cap
12 488889 Screw
13 2156146 Chute, Ice
14 1104788 Door Closer, Upper Cam
15 1104787 Shim, Door Closer
16 488938 Screw
17 2157611 Bracket, Door Stop
18 1107243 Retainer, Insert
19 1117952 Retainer, Insert
20 1119062 Trim, Door

4 Housing, Dispenser (Not A Servicable Item)
5 488687 Screw
6 Tube, Water (See Item #22)
7 Frame, Slides
2152717 White
2152718 Almond
8 Slide, Cube/Crush Switch
2152720 White
2152721 Almond
9 2157651 Door, Ice
10 2157650 Door Mechanism Assembly
12 1120581 Mechanism Delay
13 Grille, Overflow
1126120 White
1126121 Almond
14 987917 Clip, Bearing (2)
15 983697 Bearing, Lever (3)
16 983696 Spring, Lever (2)
17 2147165 Shield, Wiring
18 488500 Screw
19 625834 Spacer
22 2155018 Water Fitting Assembly (Includes Water Tube)
23 487916 Screw
24 Lever Assembly, Ice Dispenser
2155815 White
1125972 Almond
25 Guide, Ice
1124730 White
1126026 Almond
26 488892 Screw
27 Slide, Light Switch
2152726 White
2152727 Almond
28 489360 Screw
29 2147131 Lamp Holder
30 1127898 Switch
32 2147164 Insulator, Control Bracket
33 2147163 Bracket, Control
34 851389 Bulb, Light
35 488361 Screw (2)
36 489155 Screw,
37 313125 Switch
38 Lever Assembly, Water Dispenser
2159199 White
2159198 Almond
39 Insert, Cover
1125798 White
1125801 Almond
40 Cover, Housing (Includes Item 39)
1125673 White
1125805 Almond
41 2147172 Heat Shield, Frame
42 987049 Bracket, Water
45 489000 Screw
46 489336 Washer

1 486692 Speed Nut
2 1108179 Fan, Blade
3 2154011 Condenser Assembly
4 489337 Screw
5 2155658 Clip, Wire
6 489019 Screw
7 934011 Clip, Tube (3)
8 2161302 Sleeve
9 2158826 Dampener
11 Strap
943322 Production
938384 Service
12 Cover
1105055 Production
1108115 Service
13 Overload
2162218 Production (Includes Relay)
2154761 Service (Includes Relay)
15 Relay (See Overload)
17 Running Capacitor
1114291 Production
2154565 Service
19 509812 Screw Grommet
21 489242 Screw
22 2155501 Evaporator
23 2161324 Clamp
24 2154735 Fan, Motor
25 1110674 Tray, Evaporator
26 2149294 Heat Shield
27 2154002 Drier
28 2154562 Compressor (Includes Items 11, 12, 13, 15, 17, 38 & 56) (Also
Order)876765 Tube Kit
29 488687 Screw
30 2157396 Unit Mounting Frame
31 2149199 Unit, Harness
32 2162062 Fan, Motor Bracket
33 2161323 Heater, Defrost
34 2161330 Clip
35 2161331 Bi-Metal, Defrost
37 489387 Screw
38 1127675 Wire, Connector
39 Grommet (4)
2162067 Production
1100826 Service
40 489340 Screw
41 2149128 Air Baffle
42 2155547 Clip, Heat Shield
43 2161363 Unit Cover, Bottom
44 489396 Clip
48 1127906 Unit Mounting Rail
49 488624 Screw
50 1110663 Guard, Fan
53 489339 Screw
54 227991 Wire Connector
55 488649 Screw
56 487240 Screw

59 983659 Spring-Tube
63 2150347 Union
Following Parts Not Illustrated and Optional Parts Not Included
978025 Valve, Access (1/4")
978026 Valve, Access (5/16")
978027 Valve, Access (3/8")
978028 Valve, Access (1/2")
978029 Valve, Access (5/8")
978030 Valve, Access (3/4")
876764 Valve, Access (3/16")
REFRIGERANT CHARGE 6.5 oz.
Production Compressor Requires Production Electrical Components. Service
Compressor Requires Service Electrical Components. For Further Information,
Refer to Filmcard 19.1.
