KitchenAid KSRS25QWH11 User manual

1 Cabinet (Not A Serviceable Part
2 981128 Front Roller (2)
3 488681 Screw, 5/16-24 x 1-1/4
4 981122 Roller (Rear) (2)
5 488454 Screw, (4) 1/4-28 x 1/2
6 1118355 Mullion Rail
7 1110606 Heater Mullion
8 Front Mullion Rail
1123972 White
1123975 Almond
10 Filler Bottom Mullion
1118361 White
1118362 Almond
11 1110607 Clip Ground
12 1123514 Hinge, Top
13 1123515 Shim, Hinge Top
14 489284 Screw, Bind
15 Hinge Cover
987191 White
989887 Almond
16 986763 Hinge Bottom (R.H)
17 986759 Door Closer Lower Cam (2)
18 489296 Screw, (2)
19 986764 Hinge Bottom (L.H)
20 1129868 Spacer, Hinge
21 Filler, Wrapper
1110708 White
1110709 Almond
22 Grille
1125715 White
1125717 Almond
23 489327 Screw,
489297 Screw (Repair)
27 1114789 Clip, Grille Retainer (2)
29 1129178 Grommet
30 1123510 Hinge, Top (L.H.)
31 2147310 Tap Plate (2)
32 1129190 Cabinet Harness
33 489048 Screw, Ground
34 937357 Clamp
35 489242 Screw
489254 Screw (Repair)
36 1129193 Cover, Wiring
37 1108440 Wiring Shield, Short
38 1119063 Wiring Shield, Long
39 1105607 Tube Clamp (2)
40 937360 Service Cord
41 842258 Drain Ferrule
42 1108438 Extension Tube
43 1108439 Clip, Drain Tube
44 488978 Screw
45 1110626 Cover, Plug
46 1115322 Sealing Gasket
47 2147323 Cover, Unit
48 489084 Screw, 8 x 1/2 (6)
49 Hinge Cover
1119787 White

1119789 Almond
51 1118237 Insulation
52 549193 Clamp, Service Cord
53 548745 Clip, Wire
54 1129188 Wiring Assembly (Icemaker)
56 836472 Clamp, Water Line (2)

1 Liner (Not A Serviceable Part)
2 985468 Escutcheon, Meat Pan Control
3 984102 Slide Meat Pan Control
4 992358 Foam Pad
5 486214 Screw, 8-15 x 1/2
6 1125675 Stud, Pan Cover
7 1119096 Tube, Water
8 1110718 Stud (9)
9 1116794 Ladder, Shelf (2)
10 658944 Stud, Shelf (2)
11 489242 Screw (2)
12 487539 Screw, 8 x 1/2 (4)
13 487559 Screw (2)
15 1115399 Stud, Spacer (2)
16 1125913 Rack, Wine & Egg
19 1129177 Insert, Plastic Tube
21 1129179 Nut, Compression
22 1123919 Bracket Retainer
23 489290 Screw, (2)
24 1121327 Air Diffuser Assembly
25 1118430 Air Diffuser Cover
26 1123926 Cover, Conduit
27 488248 Screw,8x3/4
28 1123921 Cover, Wiring
29 851067 Socket
30 842534 Clip, Air Duct
31 1129170 Reservoir
32 1129176 Tube
33 527949 Light Bulb
34 1125586 Light Lens
37 488280 Screw (2)

1 1125597 Shelf Assembly, Cantilever (3)
2 1125593 Glass, Shelf
3 1125594 Retainer, Glass
4 1125786 Gasket, Front
5 1125655 Pan Cover Assembly (2)
6 1125705 Gasket, Cover (Front)
7 1125706 Gasket, Cover (Rear)
8 1125822 Glass, Cover (2)
9 1125599 Pan Shelf & Slide Assembly
10 1125595 Glass, Shelf
11 1125814 Gasket (Front)
12 1125817 Gasket (Rear)
13 1112308 Eyelet, Roller
14 1112303 Roller
15 489261 Screw
16 1125602 Crisper Pan (2)
17 1125603 Utility Pan

1 Liner (Not A Seviceable Part)
2 1125824 Shelf, Top Compartment
3 1125657 Door, Ice Compartment
4 1108436 Evaporator, Support
6 842534 Clip, Air Duct (2)
7 1115317 Support, Stud (4)
8 946355 Support, Stud (2)
9 1110779 Grommet (2)
10 Slide, Container
1119237 Left Side
1119293 Right Side
11 1125609 Shelf
12 489100 Screw (4)
13 942842 Terminal Block
14 1114607 Wiring Cover
15 489176 Screw
16 942768 Drain Fitting
17 Shelf Track
1114679 Right Side (3)
1114680 Left Side (3)
18 487042 Screw
19 1115373 Switch, Rocker Arm
20 489242 Screw
489254 Screw (Repair)
21 1125772 Basket, Small
22 1125770 Front, Basket
23 1125658 Basket, Upper
24 1125612 Front, Basket
25 1125659 Basket, Lower
26 1129195 Shim, Track
27 1115386 Stud, Shelf (4)
28 1115256 Shelf, Top Compartment
29 1115389 Light Lens

1 1118386 Bracket, Motor
2 1119024 Motor, Dispenser
3 1119027 Soleniod Assembly
4 1119025 Guide, Solenoid
5 487523 Screw (2)
6 1115374 Clip, Wiring
7 1119217 Wiring Assembly, Ice Dispenser
8 488906 Screw, 8-32 x 5/16 (4)
9 983663 Coupling, Motor
10 489242 Screw
489254 Screw (Repair)
11 851067 Socket, Light
12 1115339 Cover, Motor
13 487294 Screw, 8-32 x 3/8
14 1115372 Ice Container
15 983668 Coupling, Conveyor
16 1118480 Stop, Cone
17 1119074 Feeder Cone
18 1119005 Spacer, Step (3)
19 1119007 Spacer, Flat (2)
20 1119006 Blade, Rotary
21 1119012 Blade, Rotary
22 1119013 Blade, Rotary
23 489235 Washer, Plain
24 1119009 Blade, Fixed (2)
25 1119010 Block, Blade
26 489229 Roll Pin
27 1119003 Conveyor
28 1118471 Drum
29 1118470 Drive Bar
30 1119004 Floating Baffle
31 1119018 Nut, Bearing
32 2147138 Control Arm
33 1119020 Spring, Return
34 1119021 Retainer Clip, Rod
35 488886 Screw, 8-18 x 1/2
37 2149008 Housing, Crusher
38 1119017 Deflector, Ice
39 489234 Washer, Plain
40 489236 Retainer Ring
41 1121387 Tray, Ice Chips
42 1121386 Clip, Tray (2)
43 1119043 Deflector, Ice Container
44 1126036 Front Cover, Ice Container
45 527949 Light Bulb
46 983359 Light Lens, Dispenser

1 Refrigerator Door
1125954 White
1125961 Almond (Also Order Item 18)
3 1125733 Door, Compartment
4 1125695 Gasket, Door
6 1125936 Butter Dish
7 Insert, Handle
1125702 White
1125703 Almond
8 1125929 Door Gasket, Magnetic
9 509929 Cap, Hinge Sleeve
10 1107341 End Cap, Handle
11 941242 Screw Anchor (2)
12 489075 Screw (2)
14 1107215 Handle Assembly
15 487909 Screw, 8 x 1/2 (4)
16 1107651 Spacer, Handle
17 1126146 Panel, Interior Door
18 876029 Foam Insulation (Required When Replacing Exterior Door Panel)
19 489101 Screw, 7 x 1/2 (30)
489084 Screw (Repair)
20 986758 Door Closer, Upper Cam
21 1104787 Shim, Door Closer
22 488938 Screw,8x1/2
23 988420 Bracket, Door Stop
24 988421 Shim
25 488549 Screw,8x1/2
26 988402 Tap Plate
27 1107209 Retainer, Insert (Bottom)
28 1107243 Retainer, Insert
31 1119062 Trim, Door
32 534927 Hole Plug (2)
33 1118302 Gasket Retainer, Side (2)
34 1118301 Gasket Retainer, Top & Bottom
35 1125555 Shelf Bin (4)
Following Parts Not Illustrated (Optional Parts Only)
BLACK GLASS PANEL KIT (OPTIONAL KIT)
4318336 Trim Kit Trim Kit Panels
4211148 White
4211147 Almond Handle Inserts
4318339 Black
4318340 Woodgrain
4318417 Black Grille Kit

1 Freezer, Door Panel (Also Order Item 11)
1125957 White
1125963 Almond
2 988402 Tap Plate
3 1107215 Handle Assembly
4 939886 Seal, Hinge Pin
5 1107341 End Cap (2)
6 487909 Screw, 8 x 1/2 (4)
7 1107651 Spacer, Handle
8 489075 Screw (2)
9 1125676 Shelf Bin (4)
10 1125928 Door Gasket, Magnetic
11 876029 Foam Insulation
12 941242 Screw Anchor (2)
13 1125608 Panel, Interior Door
14 Insert, Handle
1125702 White
1125703 Almond
15 489101 Screw, 7 x 1/2 (28)
489084 Screw (Repair)
16 1125686 Trim, Door Shelf
17 1119212 Harness, Door (Includes Item 18)
18 936183 Connector, Plug
19 488889 Screw, 8-32 x 5/32
20 1119060 Tube, Door Wiring
21 227991 Wire Connector
22 1115345 Insulation, Dispenser
23 1119036 Chute, Ice
24 534927 Hole Plug (2)
25 2147080 Tube, Door Wiring
26 986758 Door Closer, Upper Cam
27 1104787 Shim, Door Closer
28 488938 Screw,8x1/2
29 988420 Bracket, Door Stop
30 988421 Shim
31 488549 Screw,8x5/8
32 1107243 Retainer, Insert
33 1118306 Gasket Retainer, Top & Bottom
34 1118302 Gasket Retainer, Side (2)
35 1107209 Retainer, Insert
36 1119062 Trim, Door
37 939101 Screw Anchor (2)

1 2149097 Heater, Dispenser
2 987048 Grommet
3 841707 Insert, Tube
4 Housing, Dispenser
1124715 White
1125969 Almond
5 488687 Screw, 8 x 5/8 (10)
6 987053 Tube, Water
7 Frame, Slides
1124724 White
1126023 Almond
8 Slide, Cube/Crush Switch
1124725 White
1126024 Almond
9 2147096 Door, Ice
10 1119198 Door Mechanism Assembly (Includes Item 9)
11 227991 Wire Connector
12 1120581 Mechanism Delay
13 983900 Grille, Overflow
14 987917 Clip, Bearing (2)
15 983697 Bearing, Lever (3)
16 983696 Spring, Lever (2)
17 1119041 Shield, Wiring
18 488500 Screw, 8-32 x 3/8
19 1119205 Switch, Light
20 488886 Screw, 8-18 x 1/2
21 488878 Clamp
22 Fitting, Water
2150328 White
2150329 Almond
23 487916 Screw, 8 x 3/8 (2)
24 Lever Assembly, Ice Dispenser
2147476 White
1125972 Almond
25 Guide, Ice
1124730 White
1126026 Almond
26 488892 Screw
27 Slide, Light Switch
1124726 White
1126025 Almond
28 482672 Seal
29 1121418 Lamp Holder
30 488361 Screw (4)
31 841336 Switch (2)
32 1119208 Insulator, Control Bracket
33 1119204 Bracket, Control
34 851389 Bulb, Light
35 489271 Screw (2)
36 489155 Screw,
37 934316 Switch
38 Lever Assembly, Water Dispenser
2147478 White
1125974 Almond
39 Insert, Cover
1125798 White
1125801 Almond

1125803 Black
40 Cover, Housing (Includes Item 39)
1125673 White
1125805 Almond
1125807 Black
41 1121404 Heat Shield, Frame
42 987049 Bracket, Water
43 488316 Screw, 8-18 x 3/4
44 1119209 Wiring Assembly, Door
45 489000 Screw, 9-12 x 1/2
46 488307 Washer (Repair)
