KitchenAid FOR THE WAY IT'S MADE KSSS48QDW00 User manual

1
CABINET PARTS
For Model: KSSS48QDW00
5−95 Litho In U.S.A. (RCG) Part No. 4379848
48" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Cabinet (Not A
Serviceable Part)
2 1112019 Leveler, Front (2)
4 1112023 Roller, Front &
Rear (4)
5 1112695 Leveler,
Adjustable (2)
6 2000670 Adjusting Rod (2)
7 1113250 Sleeve,
Retainer (2)
8 1112937 Bushing, Rod (2)
9 489359 Screw
10 1112939 Hole Plug, Leveler
11 1112849 Cap, Grommet
12 2002902 Stop Screw
13 1113122 Grommet, Wiring
14 2002805 Wiring Harness,
Cabinet
15 1112848 Drain Fitting
17 2001295 Shoulder Screw
18 Hinge (Top)
2001976 Left Side
2001975 Right Side
19 2000770 Shim, Hinge
Top
20 1112805 Guard, Wiring
21 487534 Screw (2)
22 2002903 Bushing
23 1112992 Door Closer
Assembly (2)
24 2000333 Bracket, Door
Closer
25 486194 Screw
26 1112973 Tap Plate,
Hinge Butt (2)
27 1113227 Fastener (3)
28 Gap, Cover
Assembly (Bottom)
2003386 Left Side
2003387 Right Side
29 Hinge (Bottom)
2001978 Left Side
2001977 Right Side
30 1112942 Shim, Hinge (1)
1112943 Shim, Hinge (2)
31 2000490 Screw
33 2001266 Tube clamp
34 2001961 Grille Base,
Front
35 489238 Screw (6)
36 2000684 Cover, Rear
37 1113123 Grommet, Wiring
38 1113079 Grommet, Flexible
39 2003472 Cup, Wiring
40 2003474 Seal
41 2001377 Screw
42 2150347 Union
43 2001415 Screw (4)
44 489359 Screw

3
CABINET TRIM PARTS
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2002195 Cabinet, Trim (2)
2 486194 Screw
3 2001297 Screw
4 2001190 Cabinet, Trim
(Bottom)
5 488649 Screw
6 2002233 Cabinet, Trim Top
7 2000007 Retainer, Unit
Base (2)
8 487944 Washer (2)
9 2002474 Retainer Clip

FREEZER LINER PARTS
4
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 1113649 Bracket, Light
3 1113650 Lens
4 1112613 Light, Socket
5 548049 Light, Bulb
6 538533 Support Clip,
Icemaker (2)
7 2000193 Grommet, Screw (2)
8 488552 Screw
12 486194 Screw
13 1112591 Spacer, Control
Panel (3)
14 842534 Clip, Air Duct (4)
16 1112260 Support,
Evaporator
17 658944 Stud, Shelf (8)
18 487559 Screw

5
REFRIGERATOR LINER PARTS
For Model: KSSS48QDW00
4379848

6
REFRIGERATOR LINER PARTS
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 LINER (Not A
Serviceable Part)
2 1112591 Spacer, Control
Panel (3)
5 2001117 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 488357 Screw
8 486194 Screw
9 1112257 Hole Plug
10 2000740 Meat Pan, Air
Duct Cover
11 2000337 Meat Pan, Air Duct
12 2003299 Inlay, Control
Meat Pan
13 2001326 Seal, Air Duct
14 1112218 Damper Control,
Meat Pan
15 2001735 Control Knob,
Meat Pan
16 837444 Retainer, Knob
17 2000343 Air Baffle
Assembly
20 2001073 Wiring Harness,
Air Baffle
21 2001146 Seal
22 1116793 Cover, Thermistor
23 1116959 Thermistor
25 2000736 Air Baffle Cover
26 2000527 Guard, Air Return

REFRIGERATOR CONTROL PANEL PARTS
7
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 1112642 Control Panel
2 2003303 Inlay, Control
Panel
3 2000789 Circuit Board
4 2001738 Control Knob
5 837444 Retainer, Knob
6 1118894 Switch, Rocker Arm
7 1113137 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113775 Shield, Control
Panel
11 1112613 Socket, Light (2)
12 548049 Light Bulb (2)
13 486194 Screw
14 2001074 Control, Harness
15 2001141 Channel, Wiring
16 1115375 Clip, Wiring (2)

8
FREEZER CONTROL PANEL PARTS
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 1113627 Control Panel
2 2003309 Inlay, Control
Panel
3 1113466 Thermostat &
Barrier Assembly
4 488974 Screw (2)
5 1115373 Switch, Rocker Arm
6 1113136 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113769 Shield, Control
Panel
11 1112613 Socket, Light
12 486194 Screw
13 548049 Light Bulb
14 2001974 Channel, Wiring
16 2001737 Knob, Thermostat
17 1115375 Clip, Wiring

REFRIGERATOR SHELF PARTS
9
For Model: KSSS48QDW00
4379848

REFRIGERATOR SHELF PARTS
10
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2174404 Frame, Shelf
2 2003377 Glass, Shelf
3 1112006 Reflector, Shelf
4 1113792 Gasket, Glass (2)
5 2179375 Rack, Wine
6 2164372 Egg Bin
7 2003327 Frame, Assembly
Meat Pan
8 2164373 Egg Carrier
9 1112247 Cover, Crisper
10 2003380 Glass, Crisper
(Includes #9)
11 2000742 Meat Pan,
Connector
12 2164374 Cover
13 489212 Screw
14 2003317 Crisper Pan (2)
15 2174388 Roller
16 1113871 Eyelet, Roller
17 489211 Screw
18 488307 Washer
20 2003322 Meat Pan
23 2002181 Retainer, Glass
25 2003411 Crisper Spacer,
Right Side (2)
27 1113169 Stop, Roller
28 2003410 Crisper Spacer,
Left Side (2)
29 486194 Screw

11
FREEZER SHELF PARTS
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2003144 Solid Shelf
2 2003135 Front, Ice
Compartment
3 1113638 Shelf, Fixed (2)
1112052 Shelf, Deep
4 2001626 Basket
5 2003114 Trim, Basket
6 Slide, Basket
2000061 Right Side
2000062 Left Side
7 486194 Screw

TOP GRILLE AND UNIT COVER PARTS
12
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2002587 Top Grille
Assembly
2 2003267 Cover, Unit
3 486194 Screw
4 2002484 Grille, Bracket
5 2001415 Screw
6 2002959 Decortive Panel
Assembly
7 2003480 Guard, Compressor
Wiring
8 2003483 Guard, Water
Valve Wiring

MOTOR AND ICE CONTAINER PARTS
13
For Model: KSSS48QDW00
4379848

MOTOR AND ICE CONTAINER PARTS
14
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2002759 Bracket, Motor
2 2155263 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Solenoid
5 Slide, Container
2002720 Right Side
2002721 Left Side
6 1113871 Stop, Roller
7 2002719 Wiring Assembly,
Ice Dispenser
8 489399 Screw
9 983663 Coupling, Motor
10 489242 Screw
12 1113130 Cover, Motor
13 486194 Screw
14 2002727 Ice Container
15 983668 Coupling, Conveyor
16 1118480 Stop, Cone
17 1119074 Feeder Cone
18 1119005 Spacer, Step (3)
19 1119007 Spacer, Flat (2)
20 1119006 Blade, Rotary
21 1119012 Blade, Rotary
22 1119013 Blade, Rotary
23 489235 Washer, Plain
24 1119009 Blade, Fixed (2)
25 2157405 Block, Blade
26 489229 Roll Pin
27 2160602 Conveyor
28 2171681 Drum
29 1118470 Drive Bar
30 2171682 Floating Baffle
31 1119018 Nut, Bearing
32 2002728 Control Arm
33 1119020 Spring, Return
34 1119021 Retainer Clip, Rod
35 488886 Screw
36 2174388 Roller
37 2157407 Housing, Crusher
38 1119017 Deflector, Ice
39 489234 Washer, Plain
40 489236 Retainer Ring
42 2152700 Housing, Filler
43 1113871 Eyelet, Roller
44 2002724 Front Cover,
Ice Container
47 489211 Screw

REFRIGERATOR DOOR PARTS
15
For Model: KSSS48QDW00
4379848

REFRIGERATOR DOOR PARTS
16
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2002834 Refrigerator
Door Panel
(Includes
Insulation)
2 939101 Screw Anchor (8)
3 2001983 Hinge Assembly,
Top
4 1113955 Gasket, Utility
Door
5 489282 Screw
6 2002073 Hinge Assembly,
Bottom
7 1112533 Gasket Retainer,
Side (2)
8 1112542 Gasket Retainer,
Top & Bottom
9 2001049 Door Gasket,
Magnetic
10 489089 Screw (40)
11 2002225 Handle, Door
12 2001230 Washer
13 2002007 Door, Spacer
Bottom
15 2001208 Screw
16 2002205 Trim (Top)
17 2001209 Screw
18 2002197 Trim (Side)
19 2002846 Trim (Bottom)
20 1113950 Panel, Interior
Door
21 1113949 Ladder, Shelf (2)
22 1113948 Retainer, Shelf
Ladder (2)
23 1112514 Back Up Plate (6)
24 486194 Screw
26 2003465 Door, Utility Bin
27 2003132 Door Shelf (4)
28 1125936 Butter Tray

17
FREEZER DOOR PARTS
For Model: KSSS48QDW00
4379848

FREEZER DOOR PARTS
18
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 2002864 Freezer Door
Panel (Includes
Insulation)
2 1112997 Tube, Wiring
3 1112928 Retainer, Tube
6 2002074 Hinge, Bottom
7 489282 Screw
8 2001984 Hinge, Top
11 2003475 Wiring Harness,
Freezer Door
12 1112533 Gasket Retainer,
Side (2)
13 1112539 Gasket Retainer,
Top & Bottom
14 2000878 Door Gasket,
Magnetic
15 489089 Screw (36)
16 2002227 Handle, Door
18 2002007 Door, Spacer
20 2001208 Screw
21 2002205 Trim (Top)
22 2001209 Screw
23 2002953 Trim (Bottom)
24 2002199 Trim (Side)
26 2002840 Panel, Interior
Door
28 2003129 Shelf Bin (2)
32 547217 Wire Connector
33 939101 Screw Anchor
34 2002733 Ice Chute

DISPENSER AND FRONT PARTS
19
For Model: KSSS48QDW00
4379848

DISPENSER AND FRONT PARTS
20
For Model: KSSS48QDW00
4379848
Illus. Part
No. No. DESCRIPTION
1 1124715 Housing, Dispenser
2 2147164 Insulator, Bracket
Control
3 2157746 Water Fitting
Assembly (Includes
Water Tube)
4 2152717 Frame, Slides
5 2152720 Slide, Cube/Crush
Switch
6 2152726 Slide, Light
Switch
7 2147172 Heat Shield, Frame
8 488361 Screw
10 987048 Grommet
11 2149097 Heater, Ice
Dispenser
12 2147167 Ice Door Mechanism
13 2147168 Door, Ice
16 489000 Screw
17 1124718 Lever, Ice
Dispenser
19 987917 Bearing, Clip
20 2159197 Lever, Water
Dispenser
21 488307 Washer
22 983696 Spring, Lever
23 983697 Bearing, Lever
24 1120581 Delay Mechanism
25 2147163 Bracket, Control
26 2162361 Switch (4)
27 625834 Insulation, Switch
28 489155 Screw
29 2147131 Lamp Holder
30 488500 Screw
35 2147166 Wiring Harness,
Door
36 2147165 Wiring Shield
37 1124730 Guiding, Ice
39 488892 Screw
40 487052 Screw
41 851389 Light Bulb
42 2002881 Front Cover,
Housing
(Includes #49)
44 2002730 Cover, Dispenser
Opening
45 2001161 Trim, Front (2)
47 1126120 Grille, Overflow
49 2002893 Overlay, Cover
53 487944 Washer (2)
54 488568 Screw (2)
55 482672 Seal
