KitchenAid KSSC48QMS03 User manual

1
CABINET PARTS
For Model: KSSC48QMS03
(Stainless Steel)
10−06 Litho In U.S.A. (dmm) Part No. W10114948
48" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
2320531 Use & Care Guide
2307359 Energy Label
2320627 Service & Wiring
Sheet
2306424 Icemaker and
Ingredient Care
Center Service
Sheet
2302865 Main Control
Service Sheet
2309069 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2320650 Clamp, Tube
4 1112023 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet,
Flexible
8 2186494B Cap, Water Filter
9 2006442 Mounting Stud,
Grill
10 2005004 Grommet, Crossover
Tube
11 2005783 Cam, Door Closer
12 2209022 Housing, Water
Filter
14 3400525 Screw
15 2255709 Filter, Water
16 489399 Screw
17 3400230 Screw, Door Stop
18 2257644 Hinge (Top)
19 2307582 Bracket, Mount
(Water Filter)
20 489464 Screw
21 2004994 Lock, Adjustable
Bushing
22 2300082 Bushing
23 2209090 Clamp, Filter
Housing
24 Spring, Door
Closure
2221242 Right Side
2004517 Left Side
25 486194 Screw
26 2005008 Retaining Ring,
Adjustable Bushing
27 2320677 Wire Clip (5)
28 2006342 Gap, Cover
Assembly (Bottom)
29 Hinge (Bottom)
2006780 Freezer Side
2006779 Refrigerator Side
30 2302876 Bushing,
Adjustable
31 8533913 Screw
32 2209026B Skirt−Grille,
Bottom
33 Extension Arm,
Door Closer
2266882 Right
2266881 Left
34 2209431B Grille Bottom,
Front
35 2005921 Screw
36 Bracket, Support
Base (Front)
2006616 Left
2006556 Right
37 1157158 Screw
38 2006617 Bracket, Support
Base (Rear) (2)
39 2006346 Washer
40 2266880 Bushing,
Extension Arm
41 1163283 Screw
42 2209709 Union
43 488946 Tube, Clamp
44 Switch, Rocker Arm
1118894 Refrigerator Door
Side
1115373 Freezer Door Side
45 2215938 Cover, Switch (2)
46 487415 Screw (2)
47 Bracket, Cover
2221097 Right
2221096 Left
48 2215612 Cover, Rear
49 2221070 Clamp, Tube

3
CABINET TRIM PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2222552S Cabinet, Trim
(Right Side)
3 8281250 Screw
4 2316688 Cabinet, Trim
(Bottom)
5 486194 Screw
6 2313993 Cabinet, Trim Top
7 2222553S Cabinet Trim
(Left Side)
9 2005925 Seal−Trim, Side
10 489464 Screw

4
FREEZER SHELF PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2302869 Wire Shelf
3 2302884 Shelf, Fixed (2)
4 2259086 Basket
5 2256271 Trim, Basket
6 Slide, Basket
2259317 Right Side
2259318 Left Side
7 8533928 Screw

5
REFRIGERATOR LINER PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

6
REFRIGERATOR LINER PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2302992 Spacer,
Air Baffle
3 2208970 Air Duct
4 2209204 Clip, Thermistor
5 2259077 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 2006475 Screw
8 486194 Screw
9 2306010 Thermistor
10 2302986 Lid, Baffle
Meat Pan
11 2320635 Baffle Control
Assembly
12 2171846 Release Valve
13 2310205 Harness, Air
Baffle
14 488357 Screw
15 2302937 Thermistor
17 2221296 Air Baffle
Assembly
18 2320660 Reservoir
19 488280 Screw
20 2259412 Seal, Air Duct
(Round Hole)
21 2309222 Diffuser Assembly
22 2317105 Cover, Thermistor
23 2188820 Thermistor
24 2259398 Seal, Air Duct
(Square Hole)
25 2309087 Cover, Diffuser

7
CONTROL PANEL PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2302773 Control Box
2 2303938 Insert, Control
Box
3 2302913 Circuit Board,
Housing Control
4 2310197 Control Box
Wire Harness
5 2306086 Display,
Ingredient Care
Center
6 2221121 Support, Control
Box
7 489006 Screw
11 2162085 Socket, Light
12 2255743 Light Bulb (2)
13 486194 Screw
14 8281185 Screw
15 2257520 Overlay
16 2302716 Shield, Light

TOP GRILLE AND UNIT COVER PARTS
8
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2257412S Panel, Decorator
2 2259320 Cover, Unit
3 2215910 Grommet, Flexible
4 2256466 Back Panel
5 2320678 Cover, Unit
Front
6 2005292 Nameplate
9 2004333 Nut
11 2254759 Bracket, Louver
12 2254762S Grille, Louver
13 488879 Screw
14 487415 Screw
15 2310194 Wire Assembly,
RC/FC Light Switch
16 489348 Clamp

REFRIGERATOR SHELF PARTS
9
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

REFRIGERATOR SHELF PARTS
10
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2222593 Frame, Shelf
5 2179404 Rack, Wine
6 2221071 Egg Bin
9 2302843 Meat Pan Cover
Assembly
10 2302836 Crisper Pan Cover
Assembly
13 2256367 Front,
Meat Pan
14 2252413 Crisper Pan (2)
16 2257583 Trim, Glass
Rear
17 Slide, Meat Pan
2302955 Right Side
2302954 Left Side
18 Trim, Glass
Front
(Not Serviceable)
19 2256255 Trim, Glass
Rear
20 2256370 Meat Pan
21 2256249 Front,
Crisper Pan
23 2252255 Trim, Glass Side
Crisper Pan
24 2256250 Trim, Glass Side
Meat Pan
25 Crisper Spacer,
2256222 Right Side (2)
2256223 Left Side (2)
27 Slide, Crisper
2302957 Right Side
2302956 Left Side
28 Meat Pan Spacer,
2256244 Right Side
2256243 Left Side
29 Screw
8533929 Right Side
8533928 Left Side

11
FREEZER LINER AND AIR FLOW PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

12
FREEZER LINER AND AIR FLOW PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2259385 Fan Motor
2 2198665 Tube, P.C. Board
3 2169142 Fan Blade
4 2223733 Retainer,
Fan Motor
5 2302817 Gasket, Cover
6 2223986 Grommet
7 486194 Screw
8 2259464 Wedge, Right
Air Duct
9 488500 Screw, Ground
10 2162085 Socket, Light (2)
11 488937 Clamp, Nylon
12 2255743 Light Bulb
13 489214 Screw
14 2182120 Scroll, Fan
15 2259465 Wedge, Left
Air Duct
16 2302925 Bracket, Vent Tube
17 2306047 Assembly, Air Duct
18 2198643 Lens
19 Block, Fan Scroll
2209482 Right
2209066 Left
20 2317088 Harness, Wire
(Includes Item 44)
Evaporator Fan
21 Liner (Not A
Serviceable Part)
22 2302924 Tube, Vent
23 2259025 Cover, Air Outlet
24 2259367 Light Shield
25 2314044 Cover, Evaporator
26 2317828 Block, Return Air
27 487539 Screw
28 2198635 Spring
29 2309284 Deflector,
Air Duct
30 1112260 Support,
Evaporator
31 2196483 Shelf, Stud (20)
32 8281158 Screw
33 Evaporator,
Cover Rail
2221107 Left Side
2259355 Right Side
34 2220904 Gasket (2)
Evaporator Cover
35 2302777 Seal, Light Socket
36 2259493 Cover, Receiver
37 2302851 Support, Air Duct
39 2188820 Thermistor
40 2209204 Clip, Thermistor
41 1116793 Cover, Thermistor
42 2006475 Screw
43 2257571 Bracket, Light
44 2317087 Defrost Bi−Metal
45 2259032 Ladder, Shelf (2)
46 2259445 Screw Support
49 2215650 Cover, Emitter
50 2198634 Pin
51 2220398 P.C. Board
Emitter
52 2198633 Flipper
53 2255563 Slide, Icemaker
Shutoff
54 2255114 P.C. Board
Receiver
56 8281185 Screw

MOTOR AND ICE CONTAINER PARTS
13
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

MOTOR AND ICE CONTAINER PARTS
14
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2222970 Ice Bin
2 2222969 Crusher Bin
3 2258222 Auger
4 2258220 Washer, Auger
5 1119007 Spacer, Flat (6)
6 2255460 Cover, Crusher
7 2257024 Blade, Rotary
8 1119005 Spacer, Step (2)
9 2257020 Blade, Fixed
10 2257023 Blade, Rotary
11 2198602 Block, Blade
12 489229 Roll Pin
13 2257022 Blade, Rotary
14 489235 Screw
15 2198661 Washer, Coupling
16 2188918 Coupling, Top
17 8281164 Screw
18 3400065 Screw
19 2252265 Button, Bin
20 2252208 Latch, Bin
21 2198608 Spring, Latch
22 2198671 Screw (2)
23 8281163 Screw
24 2188919 Holder
26 2198628 Seal
30 2188916 Drive Shaft
32 2315546 Dispenser, Motor
33 2222862 Cover
36 2315559 Sleeve, Coupling

REFRIGERATOR DOOR PARTS
15
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

REFRIGERATOR DOOR PARTS
16
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2252331 Refrigerator
Door
3 2266854 Hinge Assembly,
Top
4 2256381 Spacer−Door,
Top
5 489282 Screw
6 2302878 Hinge Assembly,
Bottom
7 2306398 Plate, Door−Handle
9 2222812 Door Gasket,
Magnetic
10 2306157 Door Skin
11 2005290 Handle, Door
12 308544 Screw
13 2257637 Door, Spacer
Bottom
14 2258951 Door Brace, Corner
15 8281250 Screw
16 2005327 Filler, Door
17 2005433 Spacer, Door (Top)
18 2005030 Spacer, Door
(Hinge Side)
19 2004935 Spacer, Door
(Bottom)
20 2222774 Door Shelf
23 2222797 Rail, Lid
24 2222983 Gasket,
Utility Bin
25 End Cap
2222919 Right Side
2222920 Left Side
26 2222923 Bin, Utility
Center
27 2222926 Door, Utility Bin
28 2165792 Butter Tray
30 2309060 Spacer, Door
(Handle Side)
32 2222771 Shelf, Gallon
Door

FREEZER DOOR PARTS
17
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

FREEZER DOOR PARTS
18
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 2320572B Freezer Door,
Service (Includes
Dispenser Items)
2 2258951 Door Brace, Corner
3 2306164 Door Skin
4 2252354 Spacer
5 2252392 Filler, Door
6 2302879 Hinge, Bottom
7 489282 Screw
8 2266854 Hinge, Top
9 2256381 Spacer−Door,
Top
10 2304896 Safety Barrier
14 2222810 Door Gasket,
Magnetic
16 2005290 Handle, Door
17 308544 Screw
18 2257637 Door, Spacer
20 8281250 Screw
21 2005433 Spacer, Door (Top)
23 2257386 Spacer, Door
(Bottom)
24 2005030 Spacer, Door
(Hinge Side)
25 2309060 Spacer, Door
(Handle Side)
28 2222777 Door Shelf

19
DISPENSER FRONT PARTS
For Model: KSSC48QMS03
(Stainless Steel)
W10114948

DISPENSER AND FRONT PARTS
20
For Model: KSSC48QMS03
(Stainless Steel)
W10114948
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 2195051 Strain Relief
3 2310199 Wire Harness
4 Cover, Dispenser
(Not Available
Order #25)
5 2304772 Spring, Torsion
6 2196195 Pin
7 2304355 Ice Door Mechanism
8 2180353 Door, Ice
9 489000 Screw
10 2259396B Lever, Ice
Dispenser
11 Switch Assembly
(Not Available
Order #25)
12 2259395B Lever, Water
Dispenser
13 2194719 Spring, Lever
14 2205686 Delay Mechanism
15 2183771 Bracket, Control
16 2162361 Switch (2)
17 2259209 Bracket,
Anti−Drip Valve
18 2180200 Lamp Holder
19 488500 Screw
20 2309372 Wire Assembly
21 2180224 Guide, Ice
22 3406124 Light Bulb
23 2302944B Grille, Overflow
24 Overlay, Cover
(Not Available
Order # 25)
25 2316787B Front Cover
Assembly
(Includes Items
4, 11, 20 & 24)
26 2320669 Valve, Anti−Drip
27 2252127 Sleeve, Delay
Mechanism
28 2306077 Spacer, Dispenser
Cover
29 8281163 Screw
