KitchenAid KSSS36DAW00 User manual

1 Cabinet (Not A Serviceable Part)
2 1112019 Leveler, Front (2)
3 1113249 Retainer (2)
4 1112023 Roller, Front & Rear (4)
5 1112695 Leveler, Adjustable (2)
6 2000670 Adjusting Rod (2)
7 1113250 Sleeve, Retainer (2)
8 1112937 Bushing, Rod (2)
9 489359 Screw
10 1112939 Hole Plug, Leveler
11 1112849 Cap, Grommet
12 1112970 Grommet, Water Tube
13 1113122 Grommet, Wiring
14 2000830 Wiring Harness, Cabinet
15 1112848 Drain Fitting
16 Gap, Cover Assembly (Top)
2000305 Left Side
2000304 Right Side
17 2001295 Shoulder Screw
18 Hinge (Top)
2000306 Left Side
2000307 Right Side
19 2000770 Shim, Hinge Top
20 1112805 Guard, Wiring
21 487534 Screw (2)
23 1112992 Door Closer Assembly (2)
24 2000333 Bracket, Door Closer
25 486194 Screw,8x1/2
26 1112973 Tap Plate, Hinge Butt (2)
27 1113227 Fastener (3)
28 Gap, Cover Assembly (Bottom)
2001200 Left Side
2001199 Right Side
29 Hinge (Bottom)
2000308 Left Side
2000309 Right Side
30 1112942 Shim, Hinge (1)
1112943 Shim, Hinge (2) Bottom (4)
31 2000490 Screw, 1/4-28 x 3/4
32 2000854 Spacer, Lower Door Hinge
33 2001266 Tube clamp
34 1112137 Grille Base, Front
35 489238 Screw (6)
36 2000727 Cover, Rear
37 1113123 Grommet, Wiring
38 1113079 Grommet, Flexible
39 1112926 Grommet, Tube
40 1113078 Grommet (2)
41 2001377 Screw
42 2000530 Grommet
43 2000671 Screw (4)
44 489359 Screw

1 2000650 Breaker Trim & Retainer Assembly
5 1112682 Magnet, Side (4)
6 1112683 Magnet, Freezer (2)
7 1112679 Magnet, Refrigerator (2)
9 2000321 Cabinet, Trim R.S
10 2000322 Cabinet, Trim L.S
11 2001297 Screw
12 1112800 Cabinet, Trim (Bottom)
13 488649 Screw, 8-32 x 1/2 (8)
14 2000780 Cabinet, Trim Top
15 2000007 Retainer, Unit Base (2)
16 487944 Washer (2)

1 1112640 Control Panel
2 2000974 Inlay, Control Panel
3 2000789 Circuit Board
4 1116853 Control Knob
5 837444 Retainer, Knob
6 1108112 Switch, Rocker Arm
7 1113133 Seal, Control Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113773 Shield, Control Panel
11 1112613 Socket, Light (2)
12 547225 Light Bulb (2)
13 486194 Screw,8x1/2
14 2001074 Control, Panel Harness
15 2001141 Channel, Wiring
16 1115375 Clip, Wiring (2)

1 LINER (Not A Serviceable Part)
2 1112591 Spacer, Control Panel (3)
3 843436 Grommet, Screw (3)
4 842339 Grommet
5 2001117 Ladder, Shelf (2)
6 520965 Screw Support, Ladder (8)
7 488357 Screw, 8 x 1-1/4 (8)
8 486194 Screw,8x1/2
9 1112257 Hole Plug
10 2000740 Meat Pan, Air Duct Cover (Also Order 12)
11 2000337 Meat Pan, Air Duct
12 2001302 Inlay, Control Meat Pan
13 2001326 Seal, Air Duct
14 1112218 Damper Control, Meat Pan
15 1112258 Control Knob, Meat Pan
16 837444 Retainer, Knob
17 2000343 Air Baffle Assembly
20 2001073 Wiring Harness, Air Baffle
21 2001146 Seal
22 1116793 Cover, Thermistor
23 1116959 Thermistor
25 2000736 Air Baffle Cover
26 2000527 Guard, Air Return

1 1112595 Control Panel
2 1113963 Inlay, Control Panel
3 1113466 Thermostat & Barrier Assembly
4 488974 Screw (2)
5 851387 Switch, Rocker Arm (Dispenser Motor)
6 1113132 Seal, Control Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113767 Shield, Control Panel
11 1112613 Socket, Light
12 486194 Screw,8x1/2
13 547225 Light Bulb
14 1112707 Channel, Wiring
15 1108112 Switch, Rocker Arm (Light)
16 1112592 Knob, Thermostat
17 1115375 Clip, Wiring
18 1105570 Thermostat Barrier

1 Liner (Not A Serviceable Part)
6 538533 Support Clip, Icemaker (2)
7 2000193 Grommet, Screw (2)
8 488552 Screw, 10-12 x 3/8 (2)
9 992720 Stud, Support (4)
12 486194 Screw,8x1/2
13 1112591 Spacer, Control Panel (3)
14 842534 Clip, Air Duct (4)
15 842339 Grommet (15)
16 1112260 Support, Evaporator
17 658944 Stud, Shelf (8)
18 487559 Screw, 8-15 x 1-1/4 (8)

1 1112365 Solid Shelf
2 2000885 Front, Ice Compartment
3 1113564 Shelf, Fixed (2)
1113636 Shelf, Deep
4 1113639 Basket
5 1113642 Trim, Basket
15 1113870 Roller
16 1113871 Eyelet, Roller
17 489211 Screw, 10-16 x 3/4
18 488307 Washer
22 2000061 Slide, Basket R.S.
2000062 Slide, Basket L.S.
24 1113169 Stop, Roller
25 486194 Screw,8x1/2

1 1113542 Frame, Shelf
2 1112297 Glass, Shelf
3 1113546 Reflector, Shelf
4 1113790 Gasket, Glass (2)
5 1125913 Rack, Wine
7 1113550 Frame, Assembly
9 1113893 Cover, Crisper
10 2000154 Glass, Crisper
11 2000742 Meat Pan, Connector
14 2000887 Crisper Pan
15 1113870 Roller
16 1113871 Eyelet, Roller
17 489211 Screw, 10-16 x 3/4
18 488307 Washer
19 2000891 Utility Pan
20 2000815 Meat Pan
23 1112324 REtainer, Glass
25 1112165 Crisper Spacer, Right Side (2)
27 1113169 Stop, Roller
28 1113890 Crisper Spacer, Left Side (2)
29 486194 Screw,8x1/2

2 2001053 Decorative Panel Assembly
3 1113313 Back Up Panel
9 2000844 Top Grille Assembly
10 2001088 Cover, Unit
11 486194 Screw,8x1/2
12 1113300 Cover, Component Assembly
