1
REFRIGERATOR
CABINET PARTS
For Model: KSSS36DAW04
11−93 Litho In U.S.A. Part No. 4379204

2
CABINET PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Model: KSSS36DAW04
4379204
1 Cabinet (Not A
Serviceable Part)
2 1112019 Leveler, Front (2)
3 1113249 Retainer (2)
4 1112023 Roller, Front &
Rear (4)
5 1112695 Leveler,
Adjustable (2)
6 2000670 Adjusting Rod (2)
7 1113250 Sleeve,
Retainer (2)
8 1112937 Bushing, Rod (2)
9 489359 Screw
10 1112939 Hole Plug, Leveler
11 1112849 Cap, Grommet
12 1112970 Grommet, Water
Tube
13 1113122 Grommet, Wiring
14 2000830 Wiring Harness,
Cabinet
15 1112848 Drain Fitting
16 Gap, Cover
Assembly (Top)
2000305 Left Side
2000304 Right Side
17 2001295 Shoulder Screw
18 Hinge (Top)
2000306 Left Side
2000307 Right Side
19 2000770 Shim, Hinge
Top
20 1112805 Guard, Wiring
21 487534 Screw (2)
23 1112992 Door Closer
Assembly (2)
24 2000333 Bracket, Door
Closer
25 486194 Screw, 8 x 1/2
26 1112973 Tap Plate,
Hinge Butt (2)
27 1113227 Fastener (3)
28 Gap, Cover
Assembly (Bottom)
2001200 Left Side
2001199 Right Side
29 Hinge (Bottom)
2000308 Left Side
2000309 Right Side
30 1112942 Shim, Hinge (1)
1112943 Shim, Hinge (2)
Bottom (4)
31 2000490 Screw,
1/4−28 x 3/4
33 2001266 Tube clamp
34 2001217 Grille Base,
Front
35 489238 Screw (6)
36 2000727 Cover, Rear
37 1113123 Grommet, Wiring
38 1113079 Grommet, Flexible
39 1112926 Grommet, Tube
41 2001377 Screw
42 2000530 Grommet
43 2001415 Screw (4)
44 489359 Screw

3
CABINET TRIMS AND BREAKER TRIM PARTS
For Model: KSSS36DAW04
4379204

4
CABINET TRIMS AND BREAKER TRIM PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
TOP GRILLE AND UNIT COVER PARTS
For Model: KSSS36DAW04
4379204
1 2000650 Breaker Trim &
Retainer Assembly
5 1112682 Magnet, Side (4)
6 1112683 Magnet,
Freezer (2)
7 1112679 Magnet,
Refrigerator (2)
9 2001390 Cabinet, Trim R.S
10 2001391 Cabinet, Trim L.S
11 2001297 Screw
12 2001188 Cabinet, Trim
(Bottom)
13 488649 Screw,
8−32 x 1/2 (8)
14 2001387 Cabinet, Trim Top
15 2000007 Retainer, Unit
Base (2)
16 487944 Washer (2)
1 2001312 Decorative
Panel Assembly
2 1113313 Back Up Panel
3 2002116 Top Grille
Assembly
4 2001088 Cover, Unit
5 486194 Screw
6 1113300 Cover, Component
Assembly
7 1113317 Brace

5
REFRIGERATOR LINER PARTS
For Model: KSSS36DAW04
4379204

6
REFRIGERATOR LINER PARTS
Illus. Part
No. No. DESCRIPTION
For Model: KSSS36DAW04
4379204
1 LINER (Not A
Serviceable Part)
2 1112591 Spacer, Control
Panel (3)
3 843436 Grommet, Screw (3)
5 2001117 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 488357 Screw,
8 x 1−1/4 (8)
8 486194 Screw, 8 x 1/2
9 1112257 Hole Plug
10 2000740 Meat Pan, Air
Duct Cover
(Also Order 12)
11 2000337 Meat Pan, Air Duct
12 2001302 Inlay, Control
Meat Pan
13 2001326 Seal, Air Duct
14 1112218 Damper Control,
Meat Pan
15 1112258 Control Knob,
Meat Pan
16 837444 Retainer, Knob
17 2000343 Air Baffle
Assembly
20 2001073 Wiring Harness,
Air Baffle
21 2001146 Seal
22 1116793 Cover, Thermistor
23 1116959 Thermistor
25 2000736 Air Baffle Cover
26 2000527 Guard, Air Return

FREEZER LINER PARTS
Illus. Part
No. No. DESCRIPTION
7
For Model: KSSS36DAW04
4379204
1 Liner (Not A
Serviceable Part)
6 538533 Support Clip,
Icemaker (2)
7 2000193 Grommet, Screw (2)
8 488552 Screw,
10−12 x 3/8 (2)
9 992720 Stud, Support (4)
12 486194 Screw, 8 x 1/2
13 1112591 Spacer, Control
Panel (3)
14 842534 Clip, Air Duct (4)
16 1112260 Support,
Evaporator
17 658944 Stud, Shelf (8)
18 487559 Screw,
8−15 x 1−1/4 (8)

Illus. Part
No. No. DESCRIPTION
8
FREEZER CONTROL PANEL PARTS
For Model: KSSS36DAW04
4379204
1 1112595 Control Panel
2 1113963 Inlay, Control
Panel
3 1113466 Thermostat &
Barrier Assembly
4 488974 Screw (2)
5 851387 Switch, Rocker Arm
(Dispenser Motor)
6 1113132 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113767 Shield, Control
Panel
11 1112613 Socket, Light
12 486194 Screw, 8 x 1/2
13 547225 Light Bulb
14 1112707 Channel, Wiring
15 1108112 Switch, Rocker Arm
(Light)
16 1112592 Knob, Thermostat
17 1115375 Clip, Wiring

9
Illus. Part
No. No. DESCRIPTION
FREEZER SHELF PARTS
For Model: KSSS36DAW04
4379204
1 1112365 Solid Shelf
2 2000885 Front, Ice
Compartment
3 1113564 Shelf, Fixed (2)
1113636 Shelf, Deep
4 2001551 Basket
5 1113642 Trim, Basket
15 1113870 Roller
16 1113871 Eyelet, Roller
17 489211 Screw, 10−16 x 3/4
18 488307 Washer
22 2000061 Slide, Basket R.S.
2000062 Slide, Basket L.S.
24 1113169 Stop, Roller
25 486194 Screw, 8 x 1/2

Illus. Part
No. No. DESCRIPTION
REFRIGERATOR CONTROL PANEL PARTS
10
For Model: KSSS36DAW04
4379204
1 1112640 Control Panel
2 2000974 Inlay, Control
Panel
3 2000789 Circuit Board
4 1116853 Control Knob
5 837444 Retainer, Knob
6 1108112 Switch, Rocker Arm
7 1113133 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113773 Shield, Control
Panel
11 1112613 Socket, Light (2)
12 547225 Light Bulb (2)
13 486194 Screw, 8 x 1/2
14 2001074 Control, Panel
Harness
15 2001141 Channel, Wiring
16 1115375 Clip, Wiring (2)

REFRIGERATOR SHELF PARTS
11
For Model: KSSS36DAW04
4379204

REFRIGERATOR SHELF PARTS
Illus. Part
No. No. DESCRIPTION
12
For Model: KSSS36DAW04
4379204
1 1113542 Frame, Shelf
2 1112297 Glass, Shelf
3 1113546 Reflector, Shelf
4 1113790 Gasket, Glass (2)
5 1125913 Rack, Wine
7 1113550 Frame, Assembly
9 1113893 Cover, Crisper
10 2000154 Glass, Crisper
11 2000742 Meat Pan,
Connector
14 2000887 Crisper Pan
15 1113870 Roller
16 1113871 Eyelet, Roller
17 489211 Screw, 10−16 x 3/4
18 488307 Washer
19 2000891 Utility Pan
20 2000815 Meat Pan
23 1112324 Retainer, Glass
25 1112165 Crisper Spacer,
Right Side (2)
27 1113169 Stop, Roller
28 1113890 Crisper Spacer,
Left Side (2)
29 486194 Screw, 8 x 1/2

REFRIGERATOR DOOR PARTS
13
For Model: KSSS36DAW04
4379204

REFRIGERATOR DOOR PARTS
Illus. Part
No. No. DESCRIPTION
14
For Model: KSSS36DAW04
4379204
1 2000693 Door Panel,
Refrigerator
(Also Order
Item 29)
2 939101 Screw Anchor (8)
3 2000696 Hinge Assembly,
Top
4 2001396 Spacer
5 489282 Screw
6 2000698 Hinge Assembly,
Bottom
7 1112533 Gasket Retainer,
Side (2)
8 1112539 Gasket Retainer,
Top & Bottom
9 2000878 Door Gasket,
Magnetic
10 489101 Screw,
7 x 1/2 (36)
11 2000388 Handle, Door
12 2000349 Tap, Plate
13 2001395 Door, Spacer
Bottom
14 2001230 Washer (6)
15 2001208 Screw
16 2001397 Trim (Top)
17 2001209 Screw
18 2000391 Trim (Side)
19 2001401 Trim (Bottom)
20 1113952 Panel, Interior
Door
21 1113951 Ladder, Shelf (2)
22 1112530 Retainer, Shelf
Ladder (2)
23 1112514 Back Up Plate (8)
24 486194 Screw, 8 x 1/2
25 1112720 Bin, Utility
26 1112735 Door, Utility Bin
27 2000911 Door Shelf (4)
28 1125936 Butter Tray
29 876029 Kit, Foam Slab
(Required When
Replacing Exterior
Door Panel)

FREEZER DOOR PARTS
15
For Model: KSSS36DAW04
4379204

FREEZER DOOR PARTS
Illus. Part
No. No. DESCRIPTION
16
For Model: KSSS36DAW04
4379204
1 2001136 Exterior Door
Panel, Freezer
(Includes
Insulation)
2 1112997 Tube, Wiring
3 1112928 Retainer, Tube
6 2000720 Hinge, Bottom
7 489282 Screw
8 2000721 Hinge, Top
9 2001396 Door Spacer
10 2001031 Overlay, Shelf
11 2001323 Wiring Harness,
Freezer Door
12 1112533 Gasket Retainer,
Side (2)
13 1112538 Gasket Retainer,
Top & Bottom
14 2000877 Door Gasket,
Magnetic
15 489101 Screw,
7 x 1/2 (34)
16 2000389 Handle, Door
17 2000349 Tap, Plate
18 2001395 Door, Spacer
19 2001230 Washer (6)
20 2001208 Screw
21 2001406 Trim (Top)
22 2001209 Screw
23 2001409 Trim (Bottom)
24 2000390 Trim (Side)
26 1113945 Panel, Interior
Door
28 1112765 Door Shelf,
Outer Trim
29 1112770 Door Shelf,
Inner Trim
31 1112763 Support, Trim
Ends
32 227991 Wire Connector
33 939101 Screw Anchor
34 2000798 Ice Chute

DISPENSER AND FRONT PARTS
17
For Model: KSSS36DAW04
4379204

DISPENSER AND FRONT PARTS
Illus. Part
No. No. DESCRIPTION
18
For Model: KSSS36DAW04
4379204
1 1124715 Housing, Dispenser
2 987049 Bracket, Water
Fitting
3 2155020 Water Fitting
Assembly (Includes
Water Tube)
4 487916 Screw, 8 x 3/8
5 Water Tube
(See Item #3)
9 488316 Screw, 8−18 x 3/4
10 987048 Grommet
11 2001334 Heater, Ice
Dispenser
12 2147167 Ice Door Mechanism
13 2147168 Door, Ice
14 1129333 Shroud
16 489000 Screw, 9−12 x 1/2
17 2155815 Lever, Ice
Dispenser
19 987917 Bearing, Clip
20 2159199 Lever, Water
Dispenser
21 488307 Washer
22 983696 Spring, Lever
23 983697 Bearing, Lever
24 1120581 Delay Mechanism
25 1107454 Bracket, Control
26 841336 Switch
27 984683 Insulation, Switch
28 488361 Screw, 4−40 x 1
29 987265 Lamp Holder
30 488500 Screw, 8−32 x 3/8
31 851386 Light Switch
32 1107457 Plunger, Extension
33 983986 Spring, Plunger
34 983987 Retainer, Pin
35 2001350 Wiring Harness,
Door
36 984494 Wiring Shield
37 2147479 Guiding, Ice
38 2147480 Glass Stop
39 488892 Screw
40 487052 Screw
41 851389 Light Bulb
42 2001413 Front Cover,
Housing
44 1112836 Cover, Dispenser
Opening
45 2001159 Trim, Front (2)
46 487052 Screw, 8−15 x 1/2
47 1126120 Grille, Overflow
48 934316 Switch
49 2001175 Overlay, Cover
53 487944 Washer (2)
54 488568 Screw (2)
55 482672 Seal

UPPER UNIT PARTS
19
For Model: KSSS36DAW04
4379204

UPPER UNIT PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
20
For Model: KSSS36DAW04
4379204
1 2000681 Assembly, Unit
Base
2 1113386 Assembly, Sound
Barrier
3 4318252 Compressor
(Includes Items
8, 9, 10, 11,
12, 13 & 21)
(Also Order
876765 Tube Kit)
4 1105220 Bracket, Mounting
5 1105219 Grommet, Bracket
6 1105200 Grommet, Mounting
7 489334 Screw
8 1112956 Overload
(Production)
(Includes Relay)
1101000 Overload
(Service)
(Includes Relay)
9 Terminal Cover
1105221 Production
2154452 Service
10 1105222 Strap, Cover
11 Relay
(See Overload)
12 1105212 Running Capacitor
13 1108065 Starting Capacitor
14 1108033 Clamp
15 487869 Screw, 8 x 3/8
16 1113015 Condenser
17 943447 Grommet (4)
18 1113019 Clamp (4)
19 487522 Screw,
8−32 x 5/8 (4)
20 1113228 Wire Tie (2)
21 1108023 Drier
22 2000358 Mounting Bracket,
Motor
23 2002409 Motor, Fan
24 2000352 Blade, Fan
25 2000351 Orifice, Fan
26 1113303 Gasket, Orifice
27 488130 Nut (3)
28 489368 Screw, 8 x 1/2 (3)
29 486692 Speed Nut
30 2162044 Defrost Timer
31 488911 Screw, 6−20 x 3/8
32 2000645 Sleeve,
Condenser
33 1113066 Clamp, Tube (2)
34 1113059 Process, Tube
35 486194 Screw, 8 x 1/2
36 2000853 Cover, Fan
37 1113028 Cover, Condenser
38 1113076 Extension, Housing
39 937360 Service Cord
40 2001503 Seal Strip (2)
41 1113162 Clamp, Cord (2)
42 1113229 Switch, Power
Disconnect
43 488879 Screw, Ground
44 653035 Clip, Cord Plug
45 2001077 Wiring Harness,
Unit Compartment
46 486899 Screw
47 2001079 Gasket (2)
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
11.5 oz.
Production Compressor Requires Production Electrical Components.
Service Compressor Requires Service Electrical Components.
For Further Information, Refer to Filmcard 19.1.
