KitchenAid KTRC22MJBL01 User manual

CABINET PARTS
1
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
10−00 Litho In U.S.A. (cre) Part No. 4398925
REFRIGERATOR

CABINET PARTS
2
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT2201079 Service &
Wiring Sheet
LIT2212802 Energy Label
LIT2212447 Use & Care Guide
LIT627370 Modular Icemaker
Service Sheet
2 2189410 Hinge (Top)
3 2166108 Roller−Front (2)
5 489385 Clamp, Tube
(Water Supply Line)
10 489341 Washer
11 3400504 Screw
12 549193 Clamp−Cord
13 2179826 Rivet
15 489497 Screw
16 2183972 Hinge, Center
17 2183854 Shim, Hinge
Center
18 489464 Screw
19 487576 Washer
20 2189194 Hinge Butt
23 2172743 Shim, Bottom Hinge
24 Fitting, Water Tube
(NOT SERVICED)
27 Hole Plug (6)
2201012 White
2200924 Biscuit
2183998 Black
35 Corner Filler (2)
2201014 White
2200926 Biscuit
2201017 Black
36 Grille
2201006 White
2201020 Biscuit
2201008 Black
37 2189356 Clip−Grille
40 Cover−Hinge
2160403 White
2200937 Biscuit
2160406 Black
41 Rail, Center
(NOT SERVICED)
43 2200778 Insulation
44 2210542 Cover, Unit
45 Cabinet (Not a
Serviceable Part)

LINER PARTS
3
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925

LINER PARTS
4
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 531933 Grommet (2)
3 2189269 Gasket, Evaporator
Cover (Side)
4 2193084 Timer, Defrost
5 549512 Thermostat Tube
Barrier
6 2179834 Seal, Air
Diffuser
7 2187306 Wire Assy.
Control Box
8 2162085 Socket, Light (2)
9 2212413 Damper, Air (Slide)
10 2183833 Fan Motor
11 2163777 Fan Blade
12 2212461 Control Box
13 2204984 Thermostat Assembly
(Includes Items
5, 18, & 36)
14 2176341 Clip, Defrost
Timer
15 489412 Screw
16 2201180 Cover−Evaporator
17 527949 Light Bulb (2)
18 2200831 Weight, Thermal
19 1118894 Rocker Arm
Switch (2)
20 2187295 Wire Assembly,
Freezer Compartment
21 2176281 Cover, Air
Diffuser
22 2205094 Knob, Thermostat
23 2182340 Air Tower
24 2189452 Air Diffuser,
Bottom
25 2190589 Freezer Floor
26 2204690 Air Diffuser, Top
28 2184574 Gear Wheel,
Thermostat
29 2200641 Bracket,
Fan Motor
30 2189270 Gasket, Evaporator
Cover (Top)
32 2204951 Knob, Damper
33 489478 Screw
35 2204639 Shield, Heat
36 2205079 Seal, Rear
Thermostat
37 2204991 Control, Freezer
38 2204992 Gear Wheel,
Freezer Control
39 2201153 Housing Base
40 2205055 Air Seal, Foam
41 2187280 Wiring Harness,
Freezer Light
42 2193491 Electrical Shield,
Freezer Light
43 850166 Light Bulb
48 2166284 Gasket, Rear
49 2189449 Pullout, Freezer
Floor
50 2198768 Rear Fence, Pull−
Out Freezer Floor
51 2176246 Roller, Slide
52 2179713 Side Support,
Floor Assembly
53 2179714 Center Support,
Floor Assembly
58 2171931 Release Valve

SHELF PARTS
5
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925

SHELF PARTS
6
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION
1 2210522 Shelf, Ladder (2)
2 2202821 Shelf, Ladder
Center
4 2182730 Egg Bin
5 489478 Screw
6 2174014 Frame Assembly,
Cantilever
8 2188212 Roller & Tread
Assembly
9 2198761 Crisper Cover
(Includes Rollers)
10 2174478 Eyelet, Roller
11 2174141 Glass, Crisper
Cover
13 2179213 Gasket, Crisper
Cover (Front) (2)
15 2163832 Crisper, Support
16 2174012 Shelf Assembly,
Spillguard (3)
(Includes Rollers)
17 2184667 Shelf, Freezer
18 489211 Screw
19 2188283 Pan, Crisper
(Includes Rollers)
20 2188289 Pan, Meat
(Includes Rollers)
21 2179214 Gasket, Crisper
Cover (Side) (4)
23 2179216 Gasket, Crisper
Cover (Rear) (2)
24 2163762 Cup, Shelf Mtg.
26 2188276 Window, Crisper
27 Cap, Crisper
2174258 Left Side
2174259 Right Side
28 2188278 Window, Meat Pan
29 489261 Screw
30 489439 Screw
32 2174257 Slide, Humidity
35 2176219 Ice Bucket
36 2174253 Button, Humidity
Control
39 2174396 Gasket, Front
45 2190504 Shelf Assembly,
Spillguard
47 2179404K Wine & Egg Rack

REFRIGERATOR DOOR PARTS
7
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925

REFRIGERATOR DOOR PARTS
8
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes #6 & #8)
2205214 White
2205215 Biscuit
2205217 Black
2212418 Stainless Steel
2 1123293 Divider,
Door Bin
4 2189202 Bracket, Door
Stop
5 489276 Screw
6 2183003 Thimble
7 Hole Plug
844478 White
2200934 Biscuit
2160808 Black
8 Door Gasket,
Magnetic
2159061 Mist Beige
2177311 Black
9 End Cap
2205188 White
2205189 Biscuit
2205191 Black
10 2171064 Bin, Door Shelf (2)
11 2195948 Shelf, Trim
12 2182399 Door Compartment
14 Hole Plug, Handle
2204837 White
2204838 Biscuit
2204840 Black
15 2165792 Butter Dish
18 2159124 Gasket, Door
Compartment
19 2171062 Bin, Door Shelf (1)
20 2156006 Plug−Trim
21 2193409 Beverage Holder

UNIT PARTS
9
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
PUSH THIS END
TO REAR
FRONT

UNIT PARTS
10
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2205340 Plate, Unit
Mounting
2 2182380 Defrost Bimetal
3 2212599 Condenser
4 2166124 Heater, Defrost
5 2195390 Evaporator Assy.
6 489494 Screw
7 2172620 Drain Pan
8 2176301 Bracket, Heater
9 489478 Screw
10 2163780 Extension, Air
Baffle
12 4387731 Cover
(Service Only)
13 Overload
4387766 Service
(Includes Relay)
14 Grommet (4)
1100826 Production
4387558 Service
16 489373 Screw
17 2150304 Roller (2)
18 981126 Rivet
19 2182338 Clip, Heater
20 2188391 Start−Device
Combination
(Start Relay and
Overload for
Production
Compressor Only)
21 Nut
(Not Serviced)
22 2201185 Support
23 2214857 Cover, Unit
25 2166683 Clip
28 2204851 Compressor
(Includes Items
12, 13, 14, 16, 29,
32, 38 & 56)
(Also Order
482801
Installation Kit
& 876765
Tube Kit)
29 2199167 Drier
30 2155774 Clamp
32 Capacitor
2169373 Production
38 2172890 Wire Assembly
39 2198921 Air Baffle
40 2183437 Motor, Condenser
42 2187341 Wire Assy. Unit
43 2190685 Fan Blade
44 486692 Nut
45 2212603 Tube, Transition
46 2205384 Tube, Discharge
47 2205385 Tube, Suction
48 2154109 Tube, Process
56 488500 Screw
58 2200946 Evap. Tray
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
482278 Start Kit
REFRIGERANT CHARGE
4.0 Ozs.
(R134A)

ICEMAKER PARTS
11
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925

ICEMAKER PARTS
12
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION
1 488878 Clamp, Tube
4 2181939 Insert, Tube
5 628379 Clip, Fuse
7 2181943 Tube Water
9 489478 Screw
10 2182104 Valve Solenoid
11 627018 Nut Compression
14 489385 Clamp, Tube
18 2174157 Cover
19 489464 Screw
20 628228 Mold & Heater
Assembly (Also
Order 542638
Silicone Grease)
22 628356 Cup, Water Fill
23 2194711 Ejector
24 2182124 Ice Striper
25 2194712 Support
26 627796 Retainer
Thermostat
27 628397 Thermostat (Also
Order 542369
Cement
Alumilastic)
28 489322 Screw
30 489276 Screw
31 627792 Shut Off Arm
32 628256 Harness, Wiring
33 628320 Bracket
35 628399 Module Assembly
(Includes Item 38)
38 489136 Screw,
3−24 x 23/64
39 488208 Screw
40 488886 Screw, 8−18 x 1/2
100 4317943 Icemaker, Complete
Assembly

FREEZER DOOR PARTS
13
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Freezer Door
(Includes #6 & #8)
2202520 White
2204854 Biscuit
2204856 Black
2212419 Stainless Steel
4 2189202 Bracket, Door
Stop
5 489276 Screw
6 2183003 Thimble
7 Hole Plug
844478 White
2200934 Biscuit
2160808 Black
8 Door Gasket,
Magnetic
2159060 Mist Beige
2177310 Black
9 End Cap
2205184 White
2205185 Biscuit
2205187 Black
10 2159292 Trim, Door
11 Nameplate
2212760 White
2212761 Biscuit
2212762 Black

OPTIONAL PARTS
14
For Models: KTRC22MJWH01,KTRC22MJBT01, KTRC22MJBL01, KTRC22MJSS01
(White) (Biscuit) (Black) (Stainless Steel)
4398925
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Miscellaneous
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
x 2−5/8")
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4" x 108")
876305 Kit, Insulation
(14 Pcs.
3" x 24" x 48")
876370 Kit, Insulation
(2 Pcs.
3" x 24 " x 48")
876029 Kit, Foam Slab
(30" x 32−1/2" x
1−1/2")
505587 Sealer, Mastic
(1 Qt.)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
799832 Kit, Porcelain
Repair (White)
503695 Cork Sealer
(1/4 Pound)
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
4392901 Enamel, Biscuit
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−Up Kit
(Black)
4392899 Brush Touch−Up Kit
(Biscuit)
Refinishing Material
799344 Enamel, White
(1 Qt. Uncut)
4392900 Enamel, Biscuit
(1 Qt. Uncut)
799340 Enamel, Black
(1 Qt. Uncut)
833938 Kit, Terminal
Connector
Caution: The Spray Paint Is Not
To Be Used Where The Paint
May Make Contact With The
Door Gaskets
TORX SCREW WRENCH
1117510 Torx Key
