KitchenAid KTRC22KAWH00 User manual

c1992 KITCHENAID
REFRIGERATOR
MODEL
KTRC22KAWH00
WH−White,
AL−Almond
11−92 Litho In U.S.A. Part No. 4361366

2
CABINET PARTS
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
4361366

Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
3
CABINET PARTS
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
1 Cabinet (Not A
Serviceable Part)
2 2152011 Roller, Front
3 489393 Screw,
5/16−24 x 1−1/4
4 981122 Roller, Rear (2)
5 489339 Screw (6)
6 489242 Screw
7 Hole Plug
2151652 White
2151653 Almond
8 489385 Clamp, Tube
9 1126276 Control, Front
Cover
10 2154065 Heater, Mullion
11 1129018 Clip, Center
Rail (4)
12 2149077 Spacer (3)
13 Center Rail
1122566 White
1122569 Almond
14 489327 Screw
17 2157593 Hinge, Top
18 1123517 Shim, Hinge Top
19 Hinge Cover
2160403 White
2160404 Almond
20 489105 Screw
21 2147335 Hinge, Center
22 836155 Shim, Hinge
Center
23 2154070 Fitting−Water Tube
24 487802 Washer, 11/64
26 2148563 Hinge Butt,
Bottom
27 654366 Hinge Pin,
Bottom
28 488714 Screw,
10−32 x 5/16
29 1123379 Shim, Bottom
30 488184 Washer, 7/32
31 1121117 Spacer
33 Corner Filler,
Grille
1125665 White
1125670 Almond
34 Filler, Wrap
Corner
1118058 White
1118059 Almond
35 Grille
1125663 White
1125667 Almond
36 Hole Plug (5)
1129062 White
1129063 Almond
37 2153994 Wiring Assy.
Intermediate
38 489048 Screw, 8−32 x 1/2
39 487996 Cap
40 1106508 Gasket
41 488725 Screw
44 937360 Cord, Service
48 1105531 Cover, Unit
53 489084 Screw
59 488725 Screw,
8 x 13/16 (2)
60 489174 Screw (2)
61 2147310 Tap−Plate,
Bottom Hinge
65 2155013 Clip, Grille
Retainer (2)
68 549193 Clamp
4361366

LINER PARTS
4
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
1 Liner (Not A
Serviceable Part)
2 1127626 Wiring, Fan Motor
3 1110779 Grommet (4)
4 941839 Hole Plug (3)
5 1106612 Stud (2)
9 946356 Stud (3)
10 946357 Saddle Stud, R.S.
946358 Saddle Stud, L.S.
11 1108112 Rocker Arm Switch
12 946355 Support, Stud (6)
13 2157410 Cover, Air Duct
15 489242 Screw
16 2154977 Motor, Fan
17 1127752 Blade, Fan
18 487887 Screw,
3−48 x 1/4 (2)
19 531933 Grommet (2)
20 848445 Grommet (2)
21 489168 Screw
22 2155597 Socket, Light
23 2160644 Scroll, Fan
24 2157427 Evaporator Cover
25 489196 Screw (5)
26 1125567 Hole Cover,
Evaporator
27 1103725 Hole Plug
28 934326 Housing Plug
29 946059 Light Bulb
30 981365 Light Lens
4361366

COMPARTMENT SEPARATOR PARTS
Illus. Part
No. No. DESCRIPTION
5
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
1 1125507 Bottom,
Compartment
Separator
2 1125510 Box, Control
3 1116849 Switch, Light
4 2162044 Timer, Defrost
(10 Hour)
5 488693 Screw
6 1125964 Switch, Toggle
7 851067 Socket (2)
8 946059 Bulb, Light (2)
9 940014 Hole Plug
10 2161676 Thermostat
Assembly
11 489214 Screw (2)
12 1125511 Light Pipe (R.S.)
14 1125512 Light Pipe (L.S.)
15 1125515 Connecting Rod,
Short
16 1125514 Rod, Connecting
17 2159698 Air Diffuser
Assembly
18 2157255 Gasket, Air
Diffuser
19 1125941 Cover, Air
Diffuser
20 1125581 Pivot Arm
22 2153995 Wiring Assembly,
Control Box
23 2159684 Gasket, Bottom
Separator
24 489048 Screw,
8−32 x 1/2 (2)
25 488540 Screw
26 1108196 Insulation, Filler
27 1105464 Insulation,
Compartment
Separator
28 1125513 Slide, Thermostat
29 1125578 Slide, Air Control
30 1125579 Window, Air
Control
31 1125580 Window,
Thermostat
33 2151663 Separator,
Compartment (Top)
34 937065 Cup, Drain
36 489242 Screw
4361366

SHELF PARTS
6
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
4361366

SHELF PARTS
7
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Customer Touch−Up Material
REFINISHING MATERIAL
Caution: The Spray Paint Is Not
To Be Used Where The Paint
May Make Contact With The
Door Gaskets
LITERATURE PARTS
FIELD INSTALLABLE
ICE MAKER
TORX SCREW WRENCH
MISCELLANEOUS 799344 Enamel, White
(1 Qt. Uncut)
978883 Enamel, Almond
(1 Qt. Uncut)
833938 Kit, Terminal
Connector
KIMS8
Part No. 1129318
1117510 Torx Key
350942 Primer, White
(13 Oz. Spray Can)
350941 Leveler, Enamel
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
350956 Enamel, Almond
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−Up Kit
(Black)
72107 Brush Touch−Up Kit
(Almond)
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
x 2−5/8")
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4" x 108")
876305 Kit, Insulation
(14 Pcs.
3" x 24" x 48")
876370 Kit, Insulation
(2 Pcs.
3" x 24 " x 48")
876029 Kit, Foam Slab
(30" x 32−1/2" x
1−1/2")
505587 Sealer, Mastic
(1 Qt.)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
503695 Cork Sealer
(1/4 Pound)
LIT2161697 Energy Guide
LIT1126426 Care & Use Guide
LIT2154861 Service & Wiring
Sheet
677969 Do−It Yourself
1 1114466 Shelf, Ladder (2)
2 1114465 Shelf, Ladder
Center
3 520965 Screw, Support (4)
5 489345 Screw (3)
6 488163 Screw,
8 x 1−1/4 (3)
7 1125520 Shelf,
Cantilever (2)
8 1125782 Gasket (Front)
9 1126311 Pan Cover Assembly
10 1116512 Gasket, Pan Cover
(Front)
11 1126310 Glass, Pan Cover
12 1126267 Pan Shelf,
Cantilever
13 1105653 Gasket, Pan Cover
(Rear) (2)
15 1106613 Crisper, Support
16 1125521 Glass, Shelf
17 1125540 Shelf, Freezer
19 1108688 Pan, Crisper
20 1126270 Pan, Meat
21 1125561 Ice Cube Pan
22 841180 Ice Tray (4)
23 1110744 Retainer, Shelf
24 1125523 Shelf, Full
Cantilever
25 1125783 Gasket (Front)
26 1125524 Glass, Full Shelf
27 1125525 Retainer, Shelf
30 1125542 Divider
31 1125543 Shelf, Ice Tray
36 1125913 Wine & Egg Rack
37 1119480 Trim, Crisper
38 1126307 Front, Crisper
39 1124819 Slide, Humidity
Control
40 1124820 Housing, Control
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
4361366
LIT4361366 Parts List

8
UNIT PARTS
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
4361366

UNIT PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
9
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
1 486692 Speed Nut
2 851732 Fan, Blade
3 2154010 Condenser
Assembly
4 489337 Screw
5 548745 Clip, Wire (2)
6 489019 Screw,
8−32 x 3/8
7 2153974 Drain Pan &
Heat Shield
8 2159720 Tube Clamp (2)
9 2149670 Dampener
11 938384 Spring, Relay
Case
12 1108115 Case, Relay
13 2159596 Overload
15 1108143 Relay
16 1118850 Housing Plug
17 2154565 Running Capacitor
18 981629 Drain Fitting
19 509812 Grommet, Screw
20 548744 Clip, Unit
Cover (2)
22 2153978 Evaporator
24 2154798 Fan, Motor
25 2154114 Tray, Evaporator
27 2154002 Drier
28 4317961 Compressor
(Includes Items 43,
44, 45, 46, 47,
56, 57 & 59)
(Also Order
876765 Tube Kit)
29 2149120 Support−Heater
30 1127944 Unit Mounting
Frame
31 2155774 Strap
32 2162062 Fan, Motor Bracket
33 2162019 Heater−Defrost
35 2149643 Bi−Metal, Defrost
37 489373 Screw, 1/4−28 x 1
38 1127675 Wire Asm.
39 1100826 Grommet (4)
40 489340 Screw
41 2155566 Air Baffle
42 488687 Screw, 8 x 5/8
43 1108143 Relay
44 1108114 Overload
45 1108115 Cover
46 938384 Strap
47 1118581 Capacitor
48 2149717 Unit Mounting
Rail
49 489337 Screw
50 1105612 Guard, Fan
51 2154119 Drain Extension
53 488454 Screw,
1/4−28 x 1/2 (2)
54 Support−Evaporator
1118805 R.S.
2159708 L.S.
Baffle (2)
55 488687 Screw,
8−32 x 1/2 (2)
56 487240 Screw
57 1100826 Grommet
59 1114190 Overload Spring
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
4361366

10
REFRIGERATOR DOOR PARTS
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
4361366

REFRIGERATOR DOOR PARTS
Illus. Part
No. No. DESCRIPTION
11
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
1 Panel, Refrigerator
Door
1122549 White
1122658 Almond
(Also Order
Item 27)
2 534927 Hole Plug (2)
3 943185 Plate, Tap (4)
4 944036 Bracket, Door
Stop
5 488921 Screw, 8 x 1/2
6 489028 Screw, 8−15 x 1/2
7 Hole Plug
844478 White
989196 Almond
8 2148565 Door Gasket,
Magnetic
9 489101 Screw, 7 x 1/2
489084 Screw (Repair)
10 1107209 Retainer, Insert
11 1107236 End Cap, Handle
12 2161508 Handle
13 2151813 Shim, End Cap
14 1107192 Spacer, Handle
15 2151669 Screw Anchor (2)
16 489006 Screw, 8 x 5/8
17 487909 Screw, 8 x 1/2
18 1107650 Spacer, Handle
19 1126203 Interior Door
Panel
20 Insert, Handle
2161513 White
2161514 Almond
21 1125695 Gasket, Door Util.
22 1125733 Utility Door
23 1126206 Shelf Bin (Wide)
24 Hole Plug, Handle
1122653 White
1122654 Almond
26 1125676 Shelf Bin (2)
27 876029 Foam Insulation
(Required When
Replacing Exterior
Door Panel)
28 1122551 Retainer, Gasket
29 1125557 Trim, Door Shelf
30 1122552 Retainer, Gasket
33 1126497 Trim, Door Shelf
4361366

FREEZER DOOR PARTS
12
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
For Model: KTRC22KAWH00, KTRC22KAAL00
(White) (Almond)
1 Panel, Freezer
Door (Also
Order Item 21)
2159160 White
2159163 Almond
2 Hole Plug (2)
534927 White
989197 Almond
3 943185 Plate, Tap (4)
4 944035 Bracket, Door
Stop
5 488921 Screw, 8 x 1/2
6 489028 Screw
7 Hole Plug
844478 White
989196 Almond
8 2148567 Door Gasket,
Magnetic
9 489101 Screw, 7 x 1/2
489084 Screw (Repair)
10 Insert, Handle
2161540 White
2161541 Almond
12 2161517 Handle
13 2151813 Spacer, Handle
14 1107628 Spacer, Handle
15 1117940 Interior Door
Panel
16 489006 Screw, 8 x 5/8
17 1125557 Shelf Bin (2)
18 1126363 Nameplate
20 1125577 Dike, Door (2)
21 876029 Kit, Foam Slab
(Required When
Replacing Exterior
Door Panel)
22 1122553 Retainer, Gasket
23 1122552 Retainer, Gasket
4361366
