KitchenAid KURS24LSBS - ARCHITECT Series II 5.7 cu. Ft.... User instructions

PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
LOCATION REQUIREMENTS
KURS24LS
KURS24RS
Electrical: A 115 Volt, 60 Hz., AC only 15 or 20
amp fused (or circuit breaker), grounded electrical
supply is required. It is recommended that a
separate circuit serving only your refrigerator be
provided. Use an outlet that cannot be turned off
by a switch. Do not use an extension cord.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 2300274
07-10-06
If your refrigerator is to be built-in, to ensure proper ventilation for
your refrigerator, allow for 1/4" in. (6.35 mm) space on each side and
at the top. When installing your refrigerator next to a fixed wall and the
hinge side is next to the wall, leave 2-1/2" (6.35 cm) minimum to allow
for the door to swing open. To open door wider, leave more space.
NOTE: Do not install the refrigerator near an oven, radiator, or other
heat source, nor in a location where the temperature will fall below
55°F (13°C).
B
overall
height
including
hardware
C
excluding
handles
A
A. Width 23 5/8"
B. Overall height 34 1/2"
C. Depth (excluding handles) 23 5/8"
D. Cabinet height 34 1/4"
Compact Refrigerator
®
D
cabinet
height
¹⁄₄" (6.35 mm)
2¹⁄₂" (6.35 cm)
