HOOD PARTS
For Model: KHTU105RSS1, KHTU165RSS1
(Stainless) (Stainless)
12−05 Litho in U.S.A. (jac) Part No. 8191119
30" or 36" WALL CANOPY
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
9763380 Instruct, Install
8191019 Wiring Diagram
6 8190560 Damper
7 8190358 Damper, Hood
8 Hood
8190559 30" Model
8191027 36" Model
9 4360156 Nut
10 4360005 Washer
12 8189602 Transformer, 120V
13 8191022 Support
14 8190403 Screw
15 4360062 Relief, Strain (2)
16 8190562 Cover, Wire

VENTILATION PARTS
2
For Model: KHTU105RSS1, KHTU165RSS1
(Stainless) (Stainless)
8191119

VENTILATION PARTS
3
For Model: KHTU105RSS1, KHTU165RSS1
(Stainless) (Stainless)
8191119
Illus. Part
No. No. DESCRIPTION
1 8189594 Filter, Grease
2 − 30" Model
3 − 36" Model
2 8190557 Panel, Spacer
(30" Model Only)
3 8190555 Button, Plug
4 8189593 Bulb, Halogen
5 8190542 Holder, Bulb
6 8189854 Support, Bulb
7 Support, Light
8190558 30" Model
8191026 36" Model
8 4360048 Screw (3)
(Hinge Pin)
9 8189616 Nameplate
10 8189614 Cover, Inlet
11 8190381 Connector
12 8190567 Cover, Switch
13 8190566 Support, Switch
14 8189621 Switch, On−Off
15 8189622 Switch, Motor
16 8190563 Button, On/Off
17 8190564 Box, Control
18 4360028 Lens, Indicator
19 8190565 Button, Mtr Speed
20 8190389 Housing, Upper
21 8190388 Support, Motor−SX
22 8190390 Motor, Blower
23 8190391 Support, Motor−DX
24 8190387 Housing, Lower
25 8190392 Cover, Wire
26 8190393 Connector
27 8190386 Cover, Wire
28 8190385 Capacitor
29 8190384 Cover, Box
30 8190383 Cover, Wire
31 8191023 Bracket, Mounting
32 8190582 Screw (2)
33 8190409 Connector, Female
34 8190408 Connector, Male
37 Panel, Bottom
8190553 30" Model
8191024 36" Model
38 Cover, Front
8190554 30" Model
8191025 36" Model
ACCESSORY PARTS
4396565 Filters w/Grate
Ductless Operation
