TECHNICAL EDUCATION
JOB AID 4317375
KAL-6
Pro Line®
FRONT-LOADING
AUTOMATIC WASHER
MODEL KHWV01RSS

- ii -
WHIRLPOOL CORPORATION assumes no responsibility for any repairs made on
our products by anyone other than authorized In-Home Service Professionals.
FORWARD
This KitchenAid Job Aid “Pro Line® Front-Loading Automatic Washer” (Part No. 4317375), provides
the In-Home Service Professional with information on the installation, operation, and service of the
Pro Line® Front-Loading Automatic Washer. For specific information on the model being serviced,
refer to the “Use and Care Guide,” or “Tech Sheet” provided with the washer.
The Wiring Diagram used in this Job Aid is typical and should be used for training purposes only.
Always use the Wiring Diagram supplied with the product when servicing the unit.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide information that will enable the In-Home Service Professional
to properly diagnose malfunctions and repair the KitchenAid Pro Line® Front-Loading Automatic
Washer.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• Successfully troubleshoot and diagnose malfunctions.
• Successfully perform necessary repairs.
• Successfully return the washer to its proper operational status.
Copyright © 2006, Whirlpool Corporation, Benton Harbor, MI 49022

- iii -
TABLE OF CONTENTS
Page
GENERAL .............................................................................................................................. 1-1
Washer Safety .................................................................................................................... 1-1
Model & Serial Number Designations ................................................................................ 1-2
Model & Serial Number Label And Tech Sheet Locations .................................................. 1-3
Specifications ..................................................................................................................... 1-4
INSTALLATION INFORMATION ............................................................................................ 2-1
Installation Requirements .................................................................................................. 2-1
Installation Instructions ...................................................................................................... 2-5
PRODUCT OPERATION ....................................................................................................... 3-1
Theory Of Operation .......................................................................................................... 3-1
Features and Benefits ........................................................................................................ 3-7
Washer Use ....................................................................................................................... 3-9
Laundry Tips .................................................................................................................... 3-19
Washer Care .................................................................................................................... 3-20
Troubleshooting ............................................................................................................... 3-24
COMPONENT ACCESS ........................................................................................................ 4-1
Component Locations ........................................................................................................ 4-1
Removing The Control Assembly ....................................................................................... 4-2
Removing The Door Lock & Door Switch Assembly .......................................................... 4-4
Removing The Front Panel And Bellows ............................................................................ 4-5
Removing The Detergent Dispenser Motor & Assembly .................................................... 4-7
Removing The Flowmeter .................................................................................................. 4-9
Removing The Inlet Valves .............................................................................................. 4-10
Removing The Control Power Supply Board ....................................................................4-11
Removing The Central Control Unit ................................................................................. 4-12
Removing The Interference Filter ..................................................................................... 4-13
Removing The Pressure Switch ....................................................................................... 4-14
Removing The Motor Control Unit .................................................................................... 4-15
Removing The Temperature Sensor & The Heating Element .......................................... 4-17
Removing The Drain Pump Assembly ............................................................................. 4-18
Removing The Airtrap ...................................................................................................... 4-20
Removing An Interlock Switch ......................................................................................... 4-21
Removing The Drive Motor .............................................................................................. 4-23
Removing The Tub And Basket Assembly ....................................................................... 4-25
Securing A Loose Baffle ................................................................................................... 4-31

- iv -
COMPONENT TESTING ........................................................................................................ 5-1
Pressure Switch ................................................................................................................. 5-1
Detergent Dispenser Motor & Switch
................................................................................. 5-2
Inlet Valve Solenoids .......................................................................................................... 5-2
Door Lock/Switch Assembly ............................................................................................... 5-3
Drain Pump Motor
.............................................................................................................. 5-4
Interference Filter ............................................................................................................... 5-4
Heating Element & Temperature Sensor ............................................................................ 5-5
Drive Motor ......................................................................................................................... 5-6
Interlock Switch .................................................................................................................. 5-6
DIAGNOSTICS & TROUBLESHOOTING ............................................................................. 6-1
Diagnostics ........................................................................................................................ 6-1
Diagnostic Guide
............................................................................................................. 6-1
Failure/Error Display Codes
............................................................................................ 6-2
Diagnostic Test ................................................................................................................ 6-8
Overview Test Program ................................................................................................... 6-8
Electronic Assemblies Removal Or Replacement ......................................................... 6-10
Troubleshooting Guide ......................................................................................................6-11
WIRING DIAGRAM ............................................................................................................... 7-1
Page

1-1
GENERAL
WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on the appliance.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word
“DANGER” or “WARNING.” These words mean:
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
You can be killed or seriously injured if you don’t
immediately follow instructions.
You can be killed or seriously injured if you don’t
follow instructions.
DANGER
WARNING

1-2
MODEL NUMBER K H W V 01 R SS 0
PRODUCT GROUP
K = KITCHENAID
PRODUCT IDENTIFICATION
H = HORIZONTAL AXIS - DOMESTIC
FEATURE CODE
W = WASHER
FEATURE CODE
V = PRO LINE
SERIES
YEAR OF INTRODUCTION
R = 2005
COLOR CODE
ENGINEERING CHANGE (NUMERIC)
MODEL & SERIAL NUMBER DESIGNATIONS
MODEL NUMBER
SERIAL NUMBER
SERIAL NUMBER MC T 26 01005
DIVISION RESPONSIBILITY
MC = American Dryer Corp.
YEAR OF PRODUCTION
T = 2006
WEEK OF PRODUCTION
26 = 26TH WEEK
PRODUCT SEQUENCE NUMBER
MODEL NUMBER (PEDESTAL)
MODEL NUMBER L A V 27 01 R
PRODUCT GROUP
L = Laundry
PRODUCT IDENTIFICATION
A = Accessory
FEATURE CODE
V = ProLine
PRODUCT WIDTH = 27"
SERIES
YEAR OF INTRODUCTION
R = 2005

1-3
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCATIONS
The Model/Serial Number label and Tech Sheet locations are shown below.
Model & Serial Number
Label Location
Tech Sheet Location
(Behind Toe Panel)

1-4
SPECIFICATIONS
Model Number
Color
Electrical Requirements
Heating Power
Max. Current
Rated Current
Voltage
Frequency
Average Water Usage/
Normal Cycle
Capacity
Volume
Max. Spin Speed
Dimensions
Height
Height (Feet Extended)
Width
Depth W/Handle
Weight
Installation Options
Programs
Program Selector
Temperature Selector
Spin Speed
KHWV01RSS
SS = Stainless Steel
1,000W
12A
15A
120V
60 Hz
14.8 Gal./56 L
19 lbs. (9 kg.)
3.8 cu. ft. (IEC equiv.)
1200 RPM
41.7ʺ (1,059mm)
42.7ʺ (1,085mm)
27.0ʺ (687mm)
32.8ʺ (833mm)
289 lbs. (132kg.)
Pedestal
Button 11 Programs
Button (6 levels)
Button (6 levels)

2-1
INSTALLATION INFORMATION
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before start-
ing installation. Read and follow the instructions
provided with any tools listed here.
Tools needed for connecting the water inlet
hoses
Pliers that open to 1-9/16˝ (39.5 mm)
Flashlight (optional)
Tools needed for installation
Adjustable or open end wrenchs 13 mm
and 9/16˝ (14 mm)
Phillips screwdriver • Level
Wood block • Tape measure
Parts supplied
Remove parts package from the washer drum.
Check that all parts are included. Remove the
optional decorative mat (included) from the top
of the washer and set aside.
•
•
•
•
•
Alternate parts
If You Have You Will Need to Buy
Laundry tub or
standpipe taller
than 96" (2.4 m)
Sump pump system (if not already
available)
Overhead sewer Standard 20 gal. (76 L), 30" (76.2 cm)
tall drain tub or utility sink and sump
pump (available from local plumbing
suppliers)
Floor drain Siphon break, Part Number 285834;
additional drain hose Part
Number 8318155; and connector kit,
Part Number 285835
Drain hose too
short
4 ft drain hose extension kit, Part
Number 285863
Water faucets
beyond reach of
fill hoses
2 longer water fill hoses:
6ft (1.8 m) Part Number 76314,
10 ft (3.0 m) Part Number 350008
A. Door handle
B. Door handle washers (2)
C. Door handle screws (2)
D. Transport bolt hole plug (4)
E. Cable tie
F
. Inlet hose (2)
G. Drain hose form
H. Decorative mat mounting
screws (2)
I. Decorative mat flat washers (2)
J. Decorative mat spacers (2)
K. Decorative mat
K
H
J
I
A
B
E
G
F
D
C
OPTIONS
A pedestal may be purchased separately for
this washer. This pedestal will add about 11˝
(27.9 cm) to the height of the unit for a total verti-
cal height of approximately 53˝ (134.6 cm).
Optional Pedestal
To order, call the dealer from whom you pur-
chased your washer or refer to the “Assistance
or Service” section of the “Use & Care Guide.”
Ask for Model Number LAV2701RSS.

2-2
Washer Dimensions
LOCATION REQUIREMENTS
Selecting the proper location for your washer
improves performance and minimizes noise
and possible washer “walk.”
The washer can be installed under a custom
counter, in a basement, laundry room, closet, or
recessed area. See “Drain System,” page 2-3.
IMPORTANT: Do not install or store the washer
where it will be exposed to the weather.
Companion appliance location requirements
should also be considered. Proper installation
is your responsibility.
You will need
A water heater set to deliver 120°F (49°C)
water to the washer.
A grounded electrical outlet located within
6 ft (1.8 m) of where the power cord is attached
to the back of the washer. See “Electrical
Requirements,” page 2-4.
Hot and cold water faucets located within
5 ft (1.5 m) of the hot and cold water fill
valves, and water pressure of 20-100 psi
(137.9-689.6 kPa).
A level floor with a maximum slope of 1˝
(2.5 cm) under entire washer. Installing the
washer on carpeting is not recommended.
A sturdy and solid floor to support the washer
with a total weight (washer, water and load) of
550 lbs (249 kg).
Do not operate your washer in temperatures
below 32°F (0°C). Some water can remain
in the washer and can cause damage in low
temperatures. See “Washer Care,” page 3-20
for winterizing information.
Installation Spacing
The following spacing dimensions are recom-
mended for this washer. This washer has been
tested for installation with spacing of 0˝ (0 cm)
clearance on the sides, front, rear, and top.
Recommended spacing should be considered
for the following reasons:
•
•
•
•
•
*Includes the door handle.
**Includes the feet extended 1" (2.5 cm). The optional
decorative mat (included) will add approximately ¹⁄2" (1.3 cm).
57"
(144.8 cm)
27"
(68.6 cm)
33" (83.8 cm)*
42"
(106.7 cm)**
NOTE: Door is not reversible.
Recommended installation spacing for
custom undercounter installation, washer
only
The dimensions shown are for a washer with-
out the optional decorative mat placed on top.
1"
(2.5 cm
)
1"
(2.5 cm)
42" min.
(106.7 cm)
27"
(68.6 cm)
1" (2.5 cm )
The location must be large enough to allow
the washer door to be fully opened.
Additional spacing should be considered for
ease of installation and servicing.
Additional clearances might be required for
wall, door, and floor moldings.
Additional spacing of 1˝ (2.5 cm) on all sides
of the washer is recommended to reduce
noise transfer.
Companion appliance spacing should also
be considered.
•
•
•
•
•

2-3
Recommended installation spaciing for
recessed or closet installation, with or
without a pedestal
For closet installation with a door, minimum
ventilation openings in the top and bottom of
the door are required. Louvered doors with
equivalent openings are acceptable.
•
*Required spacing
A. Recessed area
B. Side view - closet or confined area
C. Closet door with vents
AB
1"
(2.5 cm)
33"
(83.8 cm)
1"
(2.5 cm)
1"
(2.5 cm
)
27"
(68.6 cm)
4"
(10.2 cm)
C
3"
(7.6 cm)
3"
(7.6 cm)
48 in. 2
(310 cm 2)*
24 in. 2
(155 cm 2)*
Recommended installation spacing for
cabinet installation, with or without a
pedestal
For cabinet installation, with a door, the
minimum ventilation openings in the top are
required.
•
*Required spacing
A. Front view
B. Side view
C. Cabinet with vents
7" (17.8 cm)*
7" (17.8 cm)*
4"
(10.2 cm)
33"
(83.8 cm)
27"
(68.6 cm)
1"
(2.5 cm)
1"
(2.5 cm)
1"
(2.5 cm)
C
B
A
DRAIN SYSTEM
The washer can be installed using the standpipe
drain system (floor or wall), the laundry tub drain
system, or the floor drain system. Select the
drain hose installation method you need. See
“Tools and Parts,” page 2-1.
Standpipe Drain System—
Wall Or Floor (Views A & B)
The standpipe drain requires a minimum di-
ameter standpipe of 2˝ (5 cm). The minimum
carry-away capacity can be no less than 17 gal.
(64 L) per minute.
The top of the standpipe must be at least 30˝
(76.2 cm) high and no higher than 96˝ (2.4 m)
from the bottom of the washer.
30" min.
(76.2 cm)
AB
C D
30" min.
(76.2 cm)
28" min.
(71 cm)
Laundry Tub Drain System (View C)
The laundry tub needs a minimum 20 gal.
(76 L) capacity. The top of the laundry tub must
be at least 30˝ (76.2 cm) above the floor.
Floor Drain System (View D)
The floor drain system requires a siphon break
that may be purchased separately. See “Tools
and Parts,” page 2-1.
The siphon break must be a minimum of 28˝
(71 cm) from the bottom of the washer. Additional
hoses might be needed.

2-4
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, fire, or electrical shock.
A 120-volt, 60-Hz., AC-only, 15- or 20-am-
pere, fused electrical supply is required.
A time-delay fuse, or circuit breaker, is
recommended. It is recommended that a
separate circuit serving only this appliance
be provided.
This washer is equipped with a power supply
cord having a 3 prong grounding plug.
To minimize possible shock hazard, the cord
must be plugged into a mating, 3 prong,
grounding-type outlet, grounded in accor-
dance with local codes and ordinances. If a
mating outlet is not available, it is the personal
responsibility and obligation of the customer
to have the properly grounded outlet installed
by a qualified electrician.
If codes permit and a separate ground wire
is used, it is recommended that a qualified
electrician determine that the ground path
is adequate.
•
•
•
•
Do not ground to a gas pipe.
Check with a qualified electrician if you are
not sure the washer is properly grounded.
Do not have a fuse in the neutral or ground
circuit.
•
•
•
For a grounded, cord-connected washer:
This washer must be grounded. In the event
of a malfunction or breakdown, grounding will
reduce the risk of electrical shock by providing
a path of least resistance for electric current.
This washer is equipped with a cord having
an equipment-grounding conductor and a
grounding plug. The plug must be plugged
into an appropriate outlet that is properly
installed and grounded in accordance with
all local codes and ordinances.
WARNING: Improper connection of the
equipment-grounding conductor can result in
a risk of electric shock. Check with a quali-
fied electrician or serviceman if you are in
doubt as to whether the appliance is properly
grounded.
Do not modify the plug provided with the ap-
pliance. If it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
For a permanently connected washer:
This washer must be connected to a grounded
metal, permanent wiring system, or an equip-
ment-grounding conductor must be run with
the circuit conductors and connected to the
equipment-grounding terminal or lead on the
appliance.
ELECTRICAL REQUIREMENTS
GROUNDING INSTRUCTIONS
WARNING

2-5
INSTALLATION INSTRUCTIONS
Excessive Weight Hazard
Use two or more people to move and
install washer.
Failure to do so can result in back or
other injury.
IMPORTANT: Position the washer so that the
rear of the unit is within approximately 3 feet
(90 cm) of the final location.
There are 4 bolts in the rear panel of the
washer that support the suspension system
during transportation. These bolts also retain
the power cord inside the washer until the bolts
are removed.
WARNING
1. Using a 13 mm wrench, loosen each of the
bolts.
2. Once the bolt is loose, move it to the cen-
ter of the hole, and completely pull out the
bolt, including the plastic spacer covering
the bolt. The power cord will be attached
to all 4 bolts inside the washer.
3. Once all 4 bolts are removed, discard the
bolts and spacers. Then pull the power cord
through the opening of the rear panel and
close the hole with the attached cap.
4. Close the bolt holes with the 4 transport
bolt hole plugs.
NOTE: If the washer is to be transported at
a later date, call your local service center. To
avoid suspension and structural damage, the
machine must be properly prepared (transport
system installed) for relocation by a certified
technician.
ROUTE THE DRAIN HOSE
Proper routing of the drain hose helps avoid
floor damage due to water leakage. Read and
follow these instructions.
The drain hose is connected to your washer.
Gently pull the corrugated drain hose from the
shipping clips.
ATTACH DOOR HANDLE
1. Insert the 2 screws through the holes in
the door.
2. Place the plastic washers onto the
screws.
3. Attach the handle by hand tightening the
screws, first the top then the bottom.
4. Push the handle against the door. Using a
Phillips screwdriver, tighten the screws.
NOTE: Do not overtighten.
REMOVE TRANSPORT SYSTEM

2-6
Connect the inlet hoses to the washer
H. Hot water inlet C. Cold water inlet
HC
1. Attach the red water inlet hose to the
washer’s hot (H) water inlet valve. Screw
on coupling by hand until it is seated on
the washer.
Laundry tub drain or standpipe drain
Connect the drain hose form to the corrugated
drain hose.
A. Snap either end of the drain hose form to the drain hose at
the point where the corrugation begins.
B. Bend drain hose over drain hose form and snap into place.
A B
To keep drain water from going back into
the washer:
Do not straighten the drain hose, and do
not force excess drain hose into standpipe.
Hose should be secure, but loose enough to
provide a gap for air.
Do not lay excess hose on the bottom of the
laundry tub.
Floor drain
You may need additional parts. See Floor drain
under “Tools and Parts,” page 2-1.
CONNECT THE INLET HOSES
IMPORTANT: Verify that there are rubber
washers installed in both ends of both of the
inlet hoses.
•
•
Connect the inlet hoses to the water
faucets.
Make sure the washer drum is empty.
1. Attach the red inlet hose to the hot water
faucet. Screw on coupling by hand until it
is seated on the washer.
2. Attach the blue inlet hose to the cold water
faucet. Screw on coupling by hand until it
is seated on the washer.
A
. Coupling B. Washer
NOTE: Do not overtighten or use tape or seal-
ants on the valve. Damage to the valves can
result.
Clear the water lines
Run water through both faucets and inlet
hoses, into a laundry tub, drainpipe or bucket,
to get rid of particles in the water lines that
might clog the inlet valve screens.
Check the temperature of the water to make
sure that the hot water hose is connected to
the hot water faucet and that the cold water
hose is connected to the cold water faucet.
•
•
3. Using pliers, tighten the couplings with an
additional two-thirds turn.

2-7
2. Attach the blue water inlet hose to the
washer’s cold (C) water faucet. Screw on
coupling by hand until it is seated on the
washer.
3. Using pliers, tighten the couplings with an
additional two-thirds turn.
NOTE: Do not overtighten. Damage to the
coupling can result.
4. Turn on the water faucets completely and
check for leaks.
NOTE: Replace original inlet hoses after 10 years
of use to reduce the risk of hose failure. Record
hose installation or replacement dates on the
hoses for future reference.
Periodically inspect and replace hoses if bulges,
kinks, cuts, wear, or leaks are found.
SECURE THE DRAIN HOSE
1. Drape the power cord over the washer
top.
2. Secure the drain hose to the laundry tub
leg or standpipe with the cable tie provided.
See illustrations A and B.
A B C
If the washer faucets and the drain stand-
pipe are recessed (see illustration C), put
the hooked end of the drain hose in the
standpipe. Tightly wrap the cable tie around
the water inlet hoses and the drain hose.
NOTES:
Do not force excess drain hose back into the
rear of the washer.
Do not force excess drain hose into the
standpipe.
To avoid siphoning, do not seal the drain hose
into the standpipe.
•
•
•
ATTACH DECORATIVE MAT
1. Locate the 2 holes in the back of your
washer.
Back view of washer
2. Place the flat washer and then the spacer
on the mounting screw and attach to the
washer using a Phillips screwdriver.
3. Check that the top of the washer and the
bottom of the mat are clean.
4. Set the mat in place on top of the washer.
Hook the back edge of the decorative mat
over the mounting screws.

2-8
COMPLETE INSTALLATION
1. Check the electrical requirements. Be sure
that you have the correct electrical supply
and the recommended grounding method.
See “Electrical Requirements,” page 2-4.
2. Check that all parts are now installed. If
there is an extra part, go back through the
steps to see which step was skipped.
3. Check that you have all of your tools.
4. Remove any protective film or tape remain-
ing on the washer.
5. Dispose of, or recycle all packaging materi-
als.
6. Check that the water faucets are on.
7. Check for leaks around faucets and inlet
hoses.
LEVEL THE WASHER
One foot has been installed at a different
height on your new washer. The other three
feet were preset at the factory. Properly level-
ing your washer will minimize excessive noise
and vibration.
1. Using a 9/16˝ (14 mm) open-end wrench,
verify that the nuts on the three preset feet
are tightened against the cabinet.
2. Slide the washer to its final location.
3. Push on the upper front panel to be sure
that the washer is on the rear feet. Lower
the right front foot until it contacts the floor.
By hand, firmly rotate the foot up to an ad-
ditional 1-1/2 turns.
6. After the washer is level, use a 9/16˝
(14 mm) open-end wrench to turn the
nuts on the feet tightly against the washer
cabinet.
4. Check the levelness of the washer by plac-
ing a level on the top edge of the washer,
first side to side, then front to back.
5. Rock washer gently front to back, side to
side and diagonally to make sure that all
four feet are in firm contact with the floor.
IMPORTANT: All four feet must be tight-
ened. If the nuts are not tight against the
washer cabinet, the washer may vibrate.
7. If the washer is not level, move the washer
out slightly and first prop the front with a
wood block and adjust the feet as neces-
sary. Then prop the back and adjust feet
as necessary. Repeat this step until the
washer is level.

2-9
8. Plug into a grounded 3 prong outlet.
9. Read “Washer Use,” page 3-9.
10. To test and to clean your washer, measure
1/2 the detergent manufacturer’s recom-
mended amount of HE High Efficiency
detergent for medium sized loads. Pour
the detergent into the detergent dispenser.
Select NORMAL/CASUAL, and then select
START. Allow the washer to complete one
whole cycle.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, fire, or electrical shock.
WARNING
Use only HE High Efficiency detergent.

2-10
— NOTES —

3-1
PRODUCT OPERATION
THEORY OF OPERATION
WATER SYSTEM
The water system consists of the hot and cold
water inlet valves, a water temperature sensor, a
water flowmeter and control, and the dispenser
distribution system along with a traditional pres-
sure switch.
WATER INLET VALVES
The hot and cold water inlet valves are located
at the back of the washer. These valves receive
a control signal from the Central Control Unit
to manage the temperature of incoming water.
The temperatures are determined by the specific
wash cycle selected and a temperature sensor
located in the wash tub. To improve cleaning of
heavily soiled clothing and to provide a sanitizing
feature, the water temperature can be increased
through the use of a heating element located
in the bottom of the tub.
FLOWMETER
Water flow, or the quantity of water introduced
throughout any cycle, is monitored by a flow-
meter and Central Control Unit. When the
flowmeter registers a maximum of 10.5 gal. (40 L),
and the Central Control Unit has not detected
the pressure switch trip, the water valves will
be shut off and an error code will show in the
digital display.
DISPENSER DISTRIBUTION
SYSTEM
All wash and rinse water is introduced into
the wash tub through a Dispenser Distribution
System located in the top left corner of the
washer. The system consists of a motor that
turns a cam gear. The cam follower will divert
the incoming water to one of the follow water
inlet modes:
Detergent Dispensing
Bleach Dispensing
Fabric Softener Dispensing
•
•
•
The flowmeter is also used to introduce addi-
tional water into the tub for higher water levels,
based on cycle requirements.
Dispenser
Motor
Water
Distribution
Lever
Cam
Follower
Cam
Actuator
Flowmeter

3-2
The dispenser drawer has four separate com-
partments for adding laundry products to the
wash load. These compartments are:
1. Prewash Detergent Compartment
2. Main Wash Detergent Compartment
3. Bleach Compartment
4. Fabric Softener Compartment
Laundry products are diluted and dispensed
automatically at the proper time during the wash
cycle. The separator in the Prewash and Main
Wash Detergent Compartment can be moved
to accommodate either liquid or powdered
detergents.
The water enters the wash tub through the
main inlet tube.
AIR VENT SYSTEM
As a safety feature, the washer is designed to
allow fresh air to circulate through the tub. An
inlet vent at the rear of the washer brings air
into the tub. The fresh air is vented through the
dispenser assembly vent hose and out the front
of the dispenser drawer cutout.
1
24
3
Main Inlet
Tube
Release Lever
Air Vent
Vent Hose
Vent Tube
