Klark Teknik DN9824 User manual

Klark Teknik Group,
Klark Teknik Building,
Walter Nash Road,
Kidderminster.
Worcestershire.
DY11 7HJ.
England.
Tel:[phone]
Fax:[phone]
Email: [email protected]
Website: www.klarkteknik.com
OPERATORS MANUAL
DN9824

DECLARATION OF CONFORMITY
We,
of, Klark Teknik Building, Walter Nash Road, Kidderminster, Worcestershire, DY11 7HJ
Declare that a sample of the following product:-
to which this declaration refers, is in conformity with the following directives and/or standards:-
Signed:............................
Name: David Hoare
Authority: Technical Director, Klark Teknik Group (UK) PLC
Attention!
Where applicable, the attention of the specifier, purchaser, installer or user is drawn to special limitations of use
which must be observed when these products are taken into service to maintain compliance with the above
directives. Details of these special measures and limitations to use are available on request and are available
in product manuals.
Klark Teknik Group (UK) PLC
Walter Nash Road, Kidderminster, Worcestershire. DY11 7HJ. England
Tel: (44) (0) 1562 741515. Fax: (44) (0) 1562 745371
Company Registration No: 2414018
abc dabc
SIGNAL PROCESSING BY DEFINITION BETTERBYDESIGN DESIGNEDFOR APUREPERFORMANCE
Product Type Number Product Description Nominal Voltage (s) Current Freq
DN9824 115V AC 50/60Hz
230V AC
260mA
130mA
Directive(s) Test Standard(s)
Date: 1st July, 2000
A Subsidiary of Telex communications, Inc.
EN 55014/4 1993
EN 55022/4 1987
89/336/EEC & 92/31/EEC
{
73/23/EEC EN 60065-93

Thank you for using this Klark Teknik product
After you have unpacked the unit
Introduction
Important Notes
Front panel and controls
Rear panel connections
Operation:
Play mode (normal operation) &
Store Mode
Options mode, LCD contrast, Edit ,
VU meter, Lock mode
MIDI channel settings, send edited parameters
RS-2332 to MIDI
Description of function blocks and parameters
Access to function blocks
Master EQ1-7
Master delay, Routing and output label
Output channel EQ1-6
HiPass X-Over
LoPass X-Over
Channel delay
Compressor, Limiter
Level
DN9824
Technical specifications
Edit mode
Signal flow diagram
Page 1
Page 2
Page 3
Page 4
Page 5
Page 7
Page 8
Page 9
Page 10
Page 11
Page 12
Page 14
Page 15
Page 16
Page 18
Page 19
Page 20
Page 21
Page 22
Page 23
Page 25
Contents

1
Thank You For Using This Klark Teknik Product
Precautions
Voltage Selection and Power Connection
Safety Warning
Attention!
Do not install this unit in a location subjected to excessive heat, dust or mechanical vibration.
Connection is made by means of an IEC standard power socket. Refer to the Technical Spec for the
voltage range required for satisfactory operation of the unit.
Before connecting this unit to the mains supply, ensure the fuse fitted is the correct type and rating
as indicated in the Technical Spec..
This unit is fitted with a standard fused IEC mains inlet: For safety reasons the earth lead should
never be disconnected.
To prevent shock or fire hazard, do not expose the unit to rain or moisture. To avoid electrical shock
do not remove covers. Refer servicing to qualified personnel only.
To obtain maximum performance from this precision electronic product, please study these instructions
carefully. Installation and operating the DN9824 is not complicated, but the flexibility provided by its
operating features merits familiarisation with its controls and connections. This unit has been prepared
to comply with the power supply requirements that exist in your location.
Cables:
Electric Fields:
This product should only be used with high quality, screened twisted pair audio cables, terminated
with metal bodied 3-pin XLR connectors. Any other cable type or configuration for the audio
signals may result in degraded performance due to electromagnetic interference.
Should this product be used in an electromagnetic field that is amplitude modulated by an audio
frequency signal (20Hz to 20kHz), the signal to noise ratio may be degraded. Degradation of up to
60dB at a frequency corresponding to the modulation signal may be experienced under extreme
conditions (3V/m, 90% modulation).

After You Have Unpacked The Unit
Labc
This
Side Up
2
Save all the packing materials - they will prove valuable should it become necessary to transport or
ship this product.
Please inspect this unit carefully for any signs of damage incurred during transportation. It has
undergone stringent quality control inspection and tests prior to packing and left the factory in
perfect condition.
If, however, the unit shows any signs of damage, notify the transportation company without delay.
Only you, the consignee, may institute a claim against the carrier for damage during transportation.
If necessary, contact your supplier or as a last resort, your Klark Teknik importing agent, who will
fully co-operate under such circumstances.

3
Introduction
The DN9824 is speaker processor that provides 2 inputs and 4 outputs, plus internal summing of the
inputsAand B. Via a matrix, it is possible to assign any output to any input or to the sum of the inputs. It
is further possible to establish the following configurations: Stereo or Dual 2-way systems, 3-way +
Direct and 4-way systems, each with Mono Sub-channel, and also full range systems.
Providing 48-bit filter algorithms, 24-bit AD/DA conversion and a dynamic range of 115dB, the
DN9824 sets new standards for digital loudspeaker controllers and processors. TheAD section uses 64
times oversampling, gain-ranging Sigma-Delta converters. The DA section uses 128 times
oversampling Sigma-Delta converters. The overall signal processing is performed by two 24-bit
Motorola DSP56007 signal processors.
Each input incorporates a 7-band equalizer, allowing the user to assign high and low-cut, high and low-
shelving or parametric peak-dip filters to each of the individual filter sections. Master delays are
located in each of the input channels, which can be adjusted to affect INA, INB and INA+B.
High-pass and low-pass filters are provided for the frequency crossover functions in all operation
modes. The selection includes Linkwitz-Riley, Butterworth and Bessel type filters with switchable
slopes (slopes are dependant on filter type) between 12, 18 and 24dB/oct. Also available are 6dB/
octave and 12dB/octave peaking filters.
Six additional EQ filters are included in each output channel. Each can be set by the user to function as
high-pass or low-pass, high or low-shelving, parametric peak-dip or all-pass filters. Each channel
additionally provides a delay, a polarity switch, a programmable level control and a digital
compressor/limiter with adjustable threshold, attack and release.
A total number of 70 memory addresses, (50 preset and 20 freely assignable user programs), are
available.
Additional features are:
- FLASH memory for software and preset updates via serial interfaces.
- PC-based operation and configuration software running under Windows '95 / Windows '98
- Standard MIDI-interface
- RS-232 interface
- Back-lit graphic-display with 122 x 32 pixels
- Inputs and outputs are electronically balanced, XLR-type connectors
- Transformer-balancing for the inputs is optionally available
- Input/Output level controls, Output Mute switch, and channel function indicators SUB, LO,
MID and HI
- Input/Output level meters, limiter and clipping LEDs
Within this owner's manual, many of the DN9824's extensive features are explained in detail. For a
complete understanding of its operation, please take the time to carefully read the manual. Keep the
manual stored at a safe place to have it at hand for any further reference.

4
Important Notes
Installation
Cables
Protection
Refer to the Technical Spec for supply voltage range and fuse rating.
To prevent any trouble or problems occurring from high temperatures inside the appliance, it is
advisable not to use the DN9824 in environments where the ambient temperature exceeds 40°C. It is
also important to provide sufficient air-flow around the unit.
It is not recommended to install or operate the DN9824 directly above or below any device that
generates a large magnetic field; e. g. power amplifiers.
For best results, the unit should be operated using balanced inputs and outputs. In this configuration,
the non-inverting conductor (+) of the cable needs to be assigned to pin 2 of the XLR type connector,
while the inverting conductor (-) is assigned to the connector's pin 3. The shielding has to be connected
to pin 1. If the input channels have transformers for galvanic isolation, the cable screen should not be
connected to the ground plain of the transmitting device.
It is also possible to operate the appliance in unbalanced input/output configuration. In this
configuration , the cable's "HOT" conductor must be connected to pin 2 and the screen to pin 1 of the
XLR connector. To prevent a 6dB level attenuation, the user must short-circuit pins 1 and 3 of the XLR
connector. On the other hand, if this measure leads to interference noise, removal this connection is
recommended.
Note - To prevent loss of higher frequencies, it is recommended that audio cables should not exceed
10m.
CAUTION: TO REDUCE RISK OF ELECTRICAL SHOCK OR FIRE, DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: THIS EQUIPMENT MUST BE EARTHED.
If the unit is subjected to extreme fluctuations of temperature, e.g. from being transported from outside
into a heated room, condensation may form. The unit should not be switched on until it has reached
room temperature.

5
Input level trim INA/ IN B
Input Level meters
Graphic display
EDIT key
SELECT key
Rotary controls set the input levels of the inputs A and B. The input signal can be
amplified by up to 6dB (input level control set fully clockwise) or attenuated to -
(input level control set fully anti-clockwise). Set the level as high as possible, without
clipping, to achieve the highest possible Signal to Noise ratio.
The level meters are for the user to monitor the input signal levels. They individually
indicate the corresponding peak value of each input signal. The input level control
should be set to a position such that the meters indicate a level between -6dB and -12dB.
To prevent internal clipping, ensure that the clip LED's are not lit. Three different meter
indication modes can be selected in the OPTIONS menu, "Normal fast", "Peak Hold" or
"Slow Decay".
In the PLAY mode (normal operation), the 32 x 122 pixel LCD shows the number and
name of the program and the current active configuration. In EDIT mode, the display
shows individual function blocks including their corresponding parameters and
parameter values. Additionally, and depending on the chosen mode, the display also
indicates option menus, status messages, etc..
This key allows the user to enter the EDIT mode. While in PLAY mode, press the EDIT
key, the last modified parameter of the active program is displayed. Using the SELECT
( or ) keys gives the user the facility to select (highlight) the next or previous
parameter in the displayed function block. The value of the highlighted parameter can
be altered by using the rotary PARAMETER encoder.
While in PLAY mode, press ENTER, then pressing the SELECT key will select the
next program in the program list. While in EDIT mode, pressing the SELECT key
selects the next parameter within the displayed function block. While in OPTIONS
mode, pressing the SELECT key will allow the user to scroll forward through the
user options.
¥
34
4
4
4
4
3
3
3
3
SELECT key
OPTION key
STORE key
While in PLAY mode, press ENTER, then pressing the SELECT key will select the
previous program in the program list. While in EDIT mode, pressing the SELECT
key selects the previous parameter within the displayed function block. While in
OPTIONS mode, pressing the SELECT key will allow the user to scroll backwards
through the user options
The OPTION key is used to enter the OPTION menu, allowing the user to view and alter
product related settings. For further details, please refer to the chapter called
"OPTIONS mode".
This key allows the user to store edited programs in one of the program presets (No. U01
U20) or to copy programs from one preset to another. For further details, please refer to
the chapter called "STORE mode".
Front panel and controls

6
ENTER key
Rotary PARAMETER encoder
OUTPUT level control potentiometers
Output MUTE keys
Channel function indicators SUB, LO, MID, HI
OUTPUT Level meter indicators
OUTPUT Limiter indicators
OUTPUT CLIPindication
POWER-ON switch
The ENTER key allows the user to recall a program. For further details, please refer to the chapter
called "Operation".
Press the ENTER key, and rotating the PARAMETER encoder selects a program. Press ENTER again
to activate the desired program. In EDIT mode, the encoder is used to alter parameter values or scroll
through function blocks. For further details, please refer to the chapter called "Operation".
These rotary controls are used to set the levels of output channels, allowing the user to match the
DN9824 to the input levels of the following chained devices. Correctly setting these controls results in
an improved Signal to Noise ratio. In most cases, good results are achieved when setting the controls to
their center detented position (-6dB). The digital output gain control (accessed in each output menu)
should be used only when higher output levels are needed. It is not recommended to use the digital
output gain control for large attenuation, since this would reduce the dynamic range of the D/A
converters.
These rotary controls also provide push key functionality, which, in the EDIT mode, allow the user to
switch between the same function block in different output channels.
These keys allow the user to mute the output signal of the corresponding output. Pressing a key once
switches the mute function ON, and the key's red LED lights. Pressing the key again switches the mute
function OFF and the key's LED is switched off.
These LED's indicate which frequency band each channel is set to. If a channel is configured for full
range operation, all of its' function LED's are lit simultaneously.
These meters indicate the peak level of the corresponding output. The DN9824 should be operated at a
level such that the clip LED's are not lit, as this could indicate internal clipping. The meter response can
be set to "Peak-Hold", "Normal fast" or "Slow Decay" using the OPTIONS menu.
The LIMIT LED's light when the compressor/limiter of the corresponding channel is activated; e.g.
when the audio signal level exceeded the previously set threshold and, therefore, the output level is
compressed or limited.
The CLIPindicator lights when the signal exceeds the output signal range.
This switch turns the DN9824's mains power ON and OFF. The KT logo above the switch will
illuminate when power is switched on.

7
Rear Panel Connections
Mains connector
Standard IEC mains inlet connector. See Technical Specification for fuse rating.
RS-232 interface
This interface allows connection to a PC to upload new host code and to provide a
means of editing the DN9824 functions and parameters remotely.
MIDI IN / THRU / OUT connectors
These sockets allow the user to control several DN9824 units via a single master unit.
Exchanging memory contents in both directions is possible as well. Controlling the
DN9824 is also possible from a computer's desktop, providing that a standard MIDI
interface has been installed in the user PC / Notebook.
OUT connectors
These are the electronically balanced outputs of the DN9824.
The individual configuration of the output channels is displayed through the "channel
function indicators" on the front panel.
NOTE:- Before powering the unit, please ensure that power amplifiers and/or loudspeaker systems
are always connected to the correct output channel.
IN connectors
These are the 2 electronically balanced inputs of the DN9824. Each of the inputs also
has a Direct Out connector which allows the user to feed the input signal to any other
device that needs to be operated with the unaltered source signal.
Atransformer option is available.

8
Operation
PLAY mode (normal operation)
At power on, the unit enters PLAY mode. The display shows the number and name of the last user
program to be used
To recall a program memory, press the ENTER key and step through the available program memories
using the SELECT ( or ) keys or the rotary PARAMETER encoder. At the selected memory, press
the ENTER key again. The user will be asked to confirm whether this is the required program. If so,
press ENTER key again to confirm.
Press the ENTER key to confirm and
recall the new program.
Recalling a factory preset (program memories F01 to F50) provides the easiest method of achieving
good results with the DN9824. Factory preset programs are carefully designed, and are stored,
internally, in non-volatile FLASH memory. The required loudspeaker combination can be selected
from the list of factory presets and the DN9824 will automatically set the optimum parameters for the
chosen components. To apply changes to a factory preset, it first has to be copied to a user-definable
preset location (U01 to U 20) and the name changed to make it unique (For further information refer to
chapter called STORE mode).
Possible configurations for the DN9824 are:-
- Stereo 2-way. The parameters of the inputs A and B and the Low and High outputs are
simultaneously set to identical values.
- Dual 2-way. Input and output parameters can be set separately from each other.
- Mono 3-way with Direct Out (3-Way Sub + 1). The sub channel, as well as the Direct
Out, can be assigned to IN A, IN B or to the summed, monaural signal of the two input
channels.
- Mono 4-way. The sub channel can be assigned to IN A, IN B or to the summed,
monaural signal of the two input channels.
- Full range. All outputs can be freely assigned to IN A, IN B or to a summed, monaural
signal of the two input channels.
34
NOTE: If the new program is a different configuration to the
last, the user will be asked to confirm change of configuration.
EDIT mode
Enter EDIT mode by pressing the EDIT key. To exit the EDIT mode, press EDIT again.
When in EDIT mode, use the SELECT ( or ) keys to highlight (light text on black background) the
function block title at the top of the display. Use the rotary PARAMETER encoder to scroll through
function blocks until the desired function block is selected for editing. Use the SELECT ( or )
keys to highlight the parameter for editing and then use the rotary PARAMETER encoder to change the
value/text of that parameter. When a parameter has been changed, a flashing "E" appears in the top
right corner of the LCD, informing the user that the selected program is being edited but has not been
saved.
The user now has different options to continue:-
- To store the edited program, see STORE mode. When stored, the flashing "E" will
disappear.
- To continue altering the parameter values, continue as above.
- To return to the original (unedited) program, press ENTER and enter the program recall
process. This cancels the EDIT function and discards the parameter value changes of the
selected program.
34
34
! CAUTION ! These alterations have not yet been stored and will be lost with the next
program change command.

9
When in EDIT mode, pressing an output level control pot will enable the user to quickly get to an output
function block for that particular output, which can then be edited. Pressing another output pot will take
the user to the same function block but in the new output channel.
The user is able to access and edit all parameters in the user memories U01 to U20. The user can copy
factory presets (F01 to F 50) to user-definable presets (U01 to U20) and then edit them. All parameters
and their individual setting ranges and effects are described in the section headed "Description of
Function Blocks and Parameters".
To save an edited program, or to copy a program from one location to another.
Select a preset to be edited and stored.
Press the STORE key to enter STORE mode from any other mode.
The display now shows the user destination memory number (U01 to U20), its' current name and the
name for the new memory location. Use the rotary PARAMETER encoder to select the destination
memory number.
When the destination memory number has been selected, press SELECT to access and edit the first
letter of the new title. Rotate the rotary PARAMETER encoder to scroll throughASCII characters until
the required character is displayed. Press SELECT to move along to the next available space (and
SELECT to scroll back through the name). A name of up to sixteen ASCII characters can be
displayed and stored. NOTE, up to this point, the STORE process can be cancelled by pressing the
EDIT or OPTION keys.
Press the STORE key to initiate the store.
Press the STORE key again to confirm the store and exit the store mode. The "PROGRAM
STORED…." message will be displayed.
Afterwards, the unit enters the PLAY mode and it is ready for operation.
STORE mode
4
4
3
!CAUTION! This procedure overwrites the program that was previously saved under this preset
number. Its contents will be erased and all data will be lost! Therefore, ensure that the selected
destination program number is correct.

10
OPTIONS mode
LCD contrast
EDIT mode
No Edit
Full Edit
dB from Clip
dBu
Volts
VU meter mode
normal fast
peak hold
slow decay
LOCK code
Temperature units
Celsius Fahrenheit
Press the OPTION key to select the OPTIONS menu. The last used option program will appear on the
display. Press SELECT ( or ) keys to scroll through the options. Use the rotary PARAMETER
encoder to adjust each option value/function. The user can leave the OPTION mode by pressing the
OPTION key again, or the user can press any other MODE key (i. e. pressing the EDIT key switch to
Edit mode).
The LCD contrast or viewing angle can be set in a range of -10 (angle down) and +10 (angle up).
By selecting , the EDIT, SELECT ( or ), STORE and ENTER keys are inoperative
(unless in OPTION menu), but remote program change is possible.
By selecting , all function blocks and parameter setting are accessible.
This function allows setting the measurement units of the compressor threshold.
. Threshold setting in dB relative to full modulation. (0dB = full
modulation).
. The threshold value is displayed in dBu (0dBu = 0.775V).
. The threshold value is displayed in volts.
. The peak hold function is off; the levels are displayed with a fast decay
rate of approximately 600dB/s.
. The peak hold function is on for a more convenient level setting.
. With this setting, levels are displayed with a longer decay rate of
approximately 60dB/s, i. e. with lower signal levels the meters drop more slowly.
A four digit code which is factory set to 0000. After power on, this display defaults to 0000.
Rotate the rotary PARAMETER encoder to select a lock code value. When this code has been
set (after exit from the OPTION menu), the unit is locked and none of the front panel controls or
parameters can be accessed and adjusted. However, remote programme change is possible.
To unlock, press OPTION key, scroll through the options until LOCK CODE is displayed,
rotate the rotary PARAMETER encoder until the lock code is displayed and then press the
STORE key.
These are the units for the environmental temperature. Options are or .
3
3
4
4
! CAUTION ! Do not forget your code number. If the code number is lost, the unit can only be
unlocked after contacting your local Klark Teknik distributor.
COMPRESSOR and Limiter threshold units

11
Midi channel settings Rx and Tx
OFF
OMNI
1to16
Send edited parameters
off To MIDI To RS-232
RS-232 to MIDI
On Off
Software revision
The DN9824 will transmit and receive MIDI program change messages on a specified channel.
Here, the user is able to set the MIDI channel for the unit to send and receive MIDI data. The
selected channel also transmits the MIDI System Exclusive messages (SysEx).
The following settings can be selected.
- The DN9824 does not react to MIDI data. No MIDI data is sent and SysEx is off.
- The DN9824 receives MIDI data from all 16 MIDI channels (OMNI MODE).
MIDI data is sent via channel 1.
- The DN9824 sends and receives MIDI and SysEx data only via the selected
MIDI channel (1 to 16).
Options are , and
During editing and program changes, the DN9824 is capable of transmitting parameters, in 'real
time', via the serial port(s). At program change, a complete parameter dump can be sent out.
The option menu allows the user to program whether data is being transmitted, and, if so, which
interface is to be used.
Options or
This function provides the facility to pass data that is received at the RS-232 port directly onto
the MIDI OUT port. This effectively creates a "RS-232 to MIDI bridge". In this way, the user
can control more DN9824 units from a PC.
It allows transfer of all user programs and system data of the unit via MIDI. Therefore, the
MIDI OUT of the unit has to be connected to the MIDI IN of a unit that is capable of receiving
MIDI data (e.g. another DN9824, a computer, etc..). NOTE, please make sure that both units
are on the same MIDI channel.
This option shows the revision of the DN9824 host software. E.g. SOFTWARE REV: 1.00
Klark Teknik ID (hex):00 20 1E
DN9824 device ID (hex):48

RECALL
STORE
12
Description of Function Blocks and Parameters
The following pages provide the user with descriptions of all function blocks that can appear in any
selected mode, including all available parameters, value ranges and default settings.
In EDIT mode, the input/channel identification is indicated in the top left corner of the display while the
function block name (MASTER EQ, MASTER DELAY, CHANNEL EQ, ROUTING, etc…) is shown
next to it.
The corresponding parameters for each function block appear in the second and third line of the display.
The system function blocks are accessed using the rotary PARAMETER encoder in the following menu
sequence:-
INA:MASTER EQ1
INA:MASTER EQ2
INA:MASTER EQ3
INA:MASTER EQ4
INA:MASTER EQ5
INA:MASTER EQ6
INA:MASTER EQ7
INA:MASTER DELAY
IN B:MASTER EQ1
IN B:MASTER EQ2
IN B:MASTER EQ3
IN B:MASTER EQ4
IN B:MASTER EQ5
IN B:MASTER EQ6
IN B:MASTER EQ7
IN B:MASTER DELAY
INA+B:MASTER DELAY
OUT1:ROUTING
OUT1:CHANNELEQ1
OUT1:CHANNELEQ2
OUT1:CHANNELEQ3
OUT1:CHANNELEQ4
OUT1:CHANNELEQ5
OUT1:CHANNELEQ6
OUT1:HIPASS XOVER
OUT1:LOPASS XOVER
OUT1:CHANNELDELAY
OUT1:COMPRESSOR
OUT1:LIMITER
OUT1:LEVEL
Access to function blocks

13
OUT2:ROUTING
OUT2:CHANNELEQ1
OUT2:CHANNELEQ2
OUT2:CHANNELEQ3
OUT2:CHANNELEQ4
OUT2:CHANNELEQ5
OUT2:CHANNELEQ6
OUT2:HIPASS XOVER
OUT2:LOPASS XOVER
OUT2:CHANNELDELAY
OUT2:COMPRESSOR
OUT2:LIMITER
OUT2:LEVEL
OUT3:ROUTING
OUT3:CHANNELEQ1
OUT3:CHANNELEQ2
OUT3:CHANNELEQ3
OUT3:CHANNELEQ4
OUT3:CHANNELEQ5
OUT3:CHANNELEQ6
OUT3:HIPASS XOVER
OUT3:LOPASS XOVER
OUT3:CHANNELDELAY
OUT3:COMPRESSOR
OUT3:LIMITER
OUT3:LEVEL
OUT4:ROUTING
OUT4:CHANNELEQ1
OUT4:CHANNELEQ2
OUT4:CHANNELEQ3
OUT4:CHANNELEQ4
OUT4:CHANNELEQ5
OUT4:CHANNELEQ6
OUT4:HIPASS XOVER
OUT4:LOPASS XOVER
OUT4:CHANNELDELAY
OUT4:COMPRESSOR
OUT4:LIMITER
OUT4:LEVEL

The following provides the user with a description of all function blocks that can appear in the EDIT
mode. The list includes all available parameters, value ranges, and settings.
Master EQ1-7
Type
Freq
Q
Gain
Slope
Each input channel of the DN 9824 has 7 bands of parametric EQ. Each band can be set up to be one of
the following EQ function blocks.
describes the selected filter type. When selecting BYPASS, no equalisation effect is applied to
the signal. PEQ provides a parametric Peak/Dip Filter with programmable frequency, Q and gain.
LOSLV/HISLV are Low Shelving or High Shelving equalizers respectively. Their parameters are
frequency, slope, and gain. The parameters of the LOPASS/HIPASS filters are frequency and slope (Q
is only available with 12dB slope).
sets the center frequency of parametric EQ's and the cutoff frequency of LOSLV/HISLV and
LOPASS/HIPASS filters.
The value of the parameter determines the quality or bandwidth of parametric EQs. Higher Q values
result in a narrow banded filter while smaller Q values result in an increased bandwidth. The Q
parameter also describes the quality and, therefore, the graph of LOPASS/HIPASS filters.
sets the degree of amplification or attenuation of the parametric EQ or the low shelving and
high shelving equalizers. The stepwidth is 1 dB.
The parameter describes the steepness, or order, of the filter for the LOSLV/HISLV and
LOPASS/HIPASS equalizers.
Function Block Settings/Value Range Default
HISLV Freq 20Hz to 20kHz 1.00kHz
Slope 6dB, 12dB 6dB
Gain -12dB to +12dB 0.0dB
(+6dB max with slope 12dB)
HIPASS Freq 20Hz to 20kHz 1.00kHz
Slope 6dB, 12dB 6dB
Q 0.4 to 2.0 0.7
(Q only with slope 12dB)
LOPASS Freq 20Hz to 20kHz 1.00kHz
Slope 6dB, 12dB 6dB
Q 0.4 to 2.0 0.7
(Q only with slope 12dB)
PEQ Freq 20Hz to 20kHz 1.00kHz
Q 0.4 to 20.0 0.7
Gain -12dB to +12dB 0.0dB
LOSLV Freq 20Hz to 20kHz 1.00kHz
Slope 6dB, 12dB 6dB
Gain -12dB to +12dB 0.0dB
Type & Parameter BYPASS, PEQ, LOSLV, HISLV, BYPASS
HIPASS, LOPAS
14
