Kleenmaid DW46I User manual

Instructions for Use
DW46I
Dishwasher
Collection
   

aus Index
Safety instructions 4. . . . . . . . . . . . .
Getting to know your appliance 6. .
Adding rinse aid 7. . . . . . . . . . . . . . .
Utensils 8. . . . . . . . . . . . . . . . . . . . . .
Detergent 11. . . . . . . . . . . . . . . . . . . .
auto 3in1 12. . . . . . . . . . . . . . . . . . . . .
Programme overview 14. . . . . . . . . .
2Washing dishes 15. . . . . . . . . . . . . .
Additional functions 17. . . . . . . . . . . .
Maintenance and care 17. . . . . . . . . .
Fault finding 20. . . . . . . . . . . . . . . . . .
Customer Service 22. . . . . . . . . . . . .
Information 23. . . . . . . . . . . . . . . . . . .
Installation 23. . . . . . . . . . . . . . . . . . . .
Waste disposal 25. . . . . . . . . . . . . . . .

aus
4
Safety instructions
Delivery
Immediately check the packaging and
dishwasher for any damage which may
have been caused in transit. Do not use
a damaged appliance, but consult your
supplier.
Please dispose of packaging material
properly:
Installation
Install and connect the appliance
according to the installation and
assembly instructions.
The dishwasher must NOT be
connected to the power supply during
installation.
Ensure that the protective conductor
system of the domestic electricity
supply has been installed correctly.
Electrical connection conditions must
correspond with the specifications on
the rating plate of the dishwasher.
If the dishwasher is to be installed
in a high-sided unit, ensure that the unit
is attached properly and also at the
rear.
Built-under and built-in appliances
should always be installed under a
continuous work surface which is
attached to the adjacent cupboards, in
order to ensure that the appliance is
entirely stable.
After the appliance has been installed,
the mains plug should still be easily
accessible.
Not on all models:
The plastic housing on the water input
contains an electrically operated valve.
The connecting wires are inside the
inlet hose. Do not cut through this hose
and do not immerse the plastic housing
in water.
Warning
For safety reasons, if the appliance is not
fitted in a recess, thereby making a side
wall accessible, the door hinge area
should be covered at the side.
(Risk of injury)
Covers are available as optional
accessories from customer services or
specialist stores.
This appliance is not intended for use by
young children or infirm persons unless
they have been adequately supervised by
a responible person to ensure that they
can use the appliance safely.
Young children should be supervised to
ensure that they do not play with the
appliance.

aus
5
In daily use
Warning
Knives and other sharp-pointed utensils
must be placed with the points down
in the cutlery basket or horizontally in
the utensils basket.
Use the dishwasher only in the
household and only for its designed
purpose, i.e. for washing domestic
dishes.
Do not lean or sit on the open door.
The appliance could tip.
Please note that free-standing
appliances may tip over if the baskets
are overloaded.
The water in the appliance is not
drinking water.
Do not add any solvents to the washing
chamber. Danger of explosion!
Open the door carefully when
the programme is still running. There
is a risk of hot water spraying out of
the appliance.
To prevent injuries, e.g. caused
by stumbling, open the dishwasher
only briefly in order to load and unload
the dishwasher.
Read and observe the safety
nformation and instructions for use on
the packaging for cleaning and rinsing
agents.
Children in the household
If fitted, use the childproof lock. An
exact description can be found in the
back of the envelope.
Do not allow children to play with
or operate the appliance.
Keep children away from detergents
and rinse aid. These may cause
chemical burns in the mouth, throat and
eyes or asphyxiation.
Keep children away from an open
dishwasher. There could still be
detergent residue inside.
If the appliance is installed at eye-level,
ensure when opening and closing the
door that children are not caught
or crushed between the appliance door
and the cupboard door situated below.
Childproof lock (button lock)
You can secure your appliance from being
unintentionally switched over (e.g.
improper operation by children).
Activating the button lock:
Select the required programme.
Hold down the button Bfor
approx. 4 sec. until this is indicated
on the digital display.
If any button is pressed while the
programme is running, this is indicated
on the digital display. It is not possible to
end (reset) the programme.
Deactivating the button lock:
Hold down the button Bfor
approx. 4 sec. until the display goes
out.
At the end of the programme ( on the
digital display) the button lock is cancelled.
If there is a power failure, the button lock
is retained. Whenever a programme
is restarted, the button lock must
be reactivated.

aus
6
Damage
The appliance may be repaired and
opened up by a technician only. First
disconnect the appliance from the
power supply. Pull out the mains plug
(do not tug the power cord!) or switch
off the fuse. Turn off the tap.
Disposal
Make redundant appliances unusable
to prevent subsequent accidents.
Dispose of the appliance in an
environmentally friendly manner.
Warning
Children could get locked in the appliance
(risk of suffocation) or get stuck in other
positions.
Therefore: Remove the mains plug, cut the
mains wire and set aside. Damage the
door lock so that the door can no longer
be closed.
Getting to know your
appliance
Diagrams of the control panel and the
interior of the appliance can be found
in the envelope at the front.
Individual positions are referred to in
the text.
Control panel
1Main switch
2Door opener
3Digital display
4Time delay
5Additional options *
6Programme buttons
7Programme sequence indicator
8Rinse-aid refill indicator
Appliance interior
20
Upper basket with 2-tiered cup rack
21
Additional cutlery basket for the top
basket *
22
Upper spray arm
23
Lower spray arm
24
Filters
25
Cutlery basket
26
Lower basket
27
Lock for detergent dispenser
28
Dispenser for rinse aid
29
Detergent compartment
30
Nameplate
* not on all models
You will need to purchase the
following before using the
dishwasher for the first time:
–detergent
– rinse-aid

aus
7
Adding rinse aid
The rinse aid is required for stain-free
utensils and clear glasses.
Use only rinse aid for domestic
dishwashers.
Open the cover on the rinse-aid
dispenser 28 . To do this, press the
mark (1 ) on the cover and
simultaneously lift the cover on the
control plate (2 ).
Carefully pour in the rinse aid to just
below the edge of the filler opening.
Close the lid, ensuring that you hear it
snap closed.
To prevent excessive foam formation
during the next rinse cycle, remove any
rinse aid which has run over with a cloth.
Adjusting the amount of
rinse-aid
The amount of rinse-aid added to the
water can be varied by adjusting the
stepless control. The rinse-aid control has
been set to ”4” in the factory.
Do not alter the setting of the rinse-aid
control unless streaks (turn knob towards
”–”) or water marks (turn knob towards ”+”)
are left on the dishes.
28
Rinse aid controller
Rinse-aid refill indicator
As soon as the rinse-aid refill indicator
lights up on the control panel
8
,
refill with rinse aid.

aus
8
Utensils
Not suitable
Cutlery and utensils made of wood.
Fragile decorative glasses,
hand-crafted and antique utensils.
These decorative items are not
dishwasher-proof.
Plastic parts sensitive to hot water.
Copper and tin utensils.
Utensils which are soiled with ash,
wax, lubricating grease or ink.
Absorbent materials such as sponges
and cloths.
Aluminium and silver parts have a
tendency to discolour and fade during the
wash cycle. Even some types of glass
(e.g. crystal glass objects) may turn cloudy
after many wash cycles.
Recommendation:
In future buy utensils which are identified
as dishwasher-proof.
Damage to glassware and other
dishes
Possible causes:
type of glass or manufacturing process
chemical composition of detergent
water temperature and duration of
dishwasher programme.
Suggested remedy:
Use glassware or porcelain dishes that
have been marked ’dishwasher–proof’
by the manufacturer.
Use a mild detergent that is described
as ’kind to dishes’. If necessary, seek
further information from detergent
manufacturers.
Select a programme with as low a
temperature and as short a duration as
possible.
To prevent damage, take glass and
cutlery out of the dishwasher as soon
as possible after the programme has
ended.
Loading the dishwasher
Remove large food remnants.
It is not necessary to rinse them off
under running water.
When loading the dishwasher, ensure
that
Dall utensils are secure and cannot
fall over.
Dthe openings of all receptacles are
face down.
Dcurved or indented utensils are at
an incline, allowing water to drain.
Dthe two spray arms can rotate freely.
Very small items should not be washed in
the dishwasher as they could easily fall out
of the baskets.
Removing the dishes
To prevent water dripping from the top
basket onto the dishes in the lower basket,
we recommend that you empty the lower
basket first and then the top basket.
Cups and glasses
Upper basket 20
*not included with all models

aus
9
Pots and pans
Lower basket 26
Cutlery
Cutlery should be placed in the
dishwasher always unsorted and with the
eating surface pointing downwards. The
spray jet is then better able to reach the
individual parts.
To prevent injuries, place long, pointed
accessories and knives on the étagère
(some models) or on the knife shelf
(available as an accessory).
Folding spikes *
*on applicable models
To improve stacking of pots and pans, the
spikes can be folded down.
Shelf *
*not on all models
Lean tall glasses and those with long
stems against the shelf – not against other
items to be washed.
The cup shelf can be inserted into either
position 1 or 2 as shown in diagram.
Note: With the cup shelf in position 2, the
top basket must be locked into the upper
position to prevent interference with each
other.
Long items such as serving utensils,
kitchen knives, etc should be place on the
shelf and not in the cutlery baskets so they
do not obstruct the rotation of the spray
arms. When not in use the shelf can be
fold back.

aus
10
Small accessories holder*
*some models
Light-weight plastic accessories, e.g. cups,
lids, etc. can be held securely in the small
accessories holder.
Adjusting the height
of the basket *
* some models
If required, the height of the upper utensils
basket can be adjusted to provide more
space for tall utensils either in the upper
or lower basket.
Appliance height in cm 81 86
Max. ø in cm upper 20/25* 20/25*
max. ø in cm lower 30/25* 34/29*
Select one of the two following procedures
according to the design of the top basket
for your appliance model:
Top basket with upper and
lower roller pairs
Pull out the top basket.
Remove the top basket and re-attach
it to the upper or lower rollers.
Top basket with side levers
(Rackmatic)
Pull out the top basket.
To lower the basket, press in one lever
and then the other situated on the left
and right of the basket exterior, holding
the basket firmly on the sides of the
upper edge to prevent it from falling
down.
To raise the basket, hold the basket on
the sides of the upper edge and lift it
up.
Before re-inserting the basket again,
ensure that it is at the same height
on both sides. Otherwise, the appliance
door cannot be closed and the upper
spray arm will not be connected to
the water circuit.

aus
11
Detergent
You can use commercially available liquid
or powder proprietary detergents for
dishwashers or TABS (do not use
handwash!).
If phosphate-free detergents are used with
hard tap water, white deposits may be
deposited more easily on utensils and
the container walls. This can be remedied
by adding more detergent.
See detergent packaging to determine
whether a detergent is suitable for silver
parts.
If you have any other questions, we
recommend that you contact the helplines
of the detergent manufacturers.
Detergent dispenser with
dosing aid
The graduated detergent dispenser helps
you pour in the correct amount.
Lower line: 15 ml
Middle line: 25 ml
Full to the brim: 40 ml
If the detergent dispenser 29 is still
closed, press the lock 27 to open the
detergent dispenser.
Adding detergent
Fill the dispenser 29 with detergent.
Dosage: see manufacturer’s
instructions on the detergent
packaging.
Note
The cleaning tabs from various
manufacturers exhibit differing dissolving
properties, so washing power may not
develop fully during short programmes and
there may be undissolved cleaning agent
residue. It is recommended to use
washing powder for these programmes.
The Intensive programme (on some
models) requires one tab only. When using
washing powder, you can apply some
of this cleaning agent to the inside of
the appliance’s door.
Reduce costs!
If your dishes are only moderately dirty,
you may be able to use less detergent
than recommended.
Close the lid on the detergent
compartment.
Press down the lid (1) until it clicks
shut (2).
If you are using detergent in tablet form,
read the manufacturer’s
recommendations on the packaging in
order to
determine where the tablets should be
placed inside the dishwasher (e.g. in
cutlery basket, detergent compartment,
etc.).
Make sure that the lid on the detergent
compartment is closed, even if you are
using tablets.

aus
12
auto 3in1
The use of so-called combined detergent
products may make the use of rinse aid
and/or salt unnecessary.
There are currently several types of
combined detergent products available.
2in1: They contain detergent and rinse
aid or salt function.
3in1: They contain detergent, rinse aid
and salt function.
4in1: They contain a detergent,
rinse-aid, salt function and an additional
glass protection component.
In addition, other combined products with
a comparable effect are offered according
to the manufacturer.
>>> Always check the type of detergent
or combined product which you
are using!
Always follow the operating instructions
or the information on the packaging.
The rinse programme is automatically
adjusted in order to obtain the best
possible rinsing and drying result.
Observe the following important
information if using combined cleaning
products:
Regeneration salt is not required up to
a water hardness of 21_dH (37_fH,
26_Clarke, 3.7 mmol/l) only. No other
settings on the appliance are required.
Salt is still required if the water
hardness is above 21_dH (37_fH,
26_Clarke, 3.7 mmol/l). Fill the salt
dispenser with salt
NO T
and select
setting 6 on the water softening system.
If in doubt, please contact the detergent
manufacturer, especially if:
the utensils are very wet at the end
of the programme.
limescale forms.
Note
Optimum rinsing and drying results can be
obtained by using standard detergents in
conjunction with separate application of
salt and rinse aid.
Observance of the operating instructions
or information on the packaging of the
combined detergents determines their
effectiveness.
Note
Even if the rinse aid and/or salt refill
indicator is lit, the rinse programme runs
correctly when 3in1 products are used.
If the rinse aid refill indicator
8
or salt
refill
NO T
indicator is defective and you
would like to switch it off, proceed as
follows:
Switching the rinse aid refill
indicator off and on
You can switch the rinse aid refill indicator
8
on or off. This function can be
changed as follows.
Close the door.
Hold down the programme button
4
and press the main switch
1
until the
digital display lights up, then release the
buttons.
3
is indicated on the digital display
(rinse aid refill indicator on).
By pressing the programme button
4
, you can switch off or switch
on the rinse aid indicator.
Switch off the main switch
1
;
the setting is saved.

aus
13
Switching the salt refill
indicator / water softening
system off and on
Close the door.
Hold down the programme button B
and switch on the main switch
1
,
then release the buttons.
The illuminated button Band the
factory-set value on the digital
display flash.
To change the setting: press the
programme button B.
Each time the button is pressed, the set
value increases by one; when the value
is reached, the display jumps
back to (the salt refill indicator /
water softening system has been
switched off).
Switch off the main switch
1
.
The set value is stored within the
device.
Approx. 4 litres of water are required to
regenerate the water softening system.
As a result, the water consumption per
rinse cycle increases by 0 to maximum
4litres depending on the water hardness
setting.
Note
If you use the detergent and rinse aid
separately or switch from combined
detergents to standard cleaning products,
ensure that the rinse aid refill indicator has
been switched on and the water softening
system has been set to the correct water
hardness.

aus
14
Programme overview
This overview lists the max. possible number of programmes. The programmes supplied with your
appliance are indicated on the fascia.
Type of crockery
e.g.china,
pots/pans,
cutlery,
glasses,
etc.
Type of food
remains
Amount of
food remains
Condition of
food remains
Wash
programme
Programme
sequence
Programme
details
Duration in
minutes
with heat exchanger
Electricity
consumption in kWh
with heat exchanger
Water consumption
in litres
with Aquasensor
Nondelicate
Soups, casseroles,
sauces, potatoes,
pasta, rice, eggs,
roast or fried food
a lot very little
stuck
on hard
Intensive
70°Eco
50°Quick
35°Pre-rinse
Rinse-aid
70°
Drying Drying
Drying
Main rinse Main rinse
Rinse-aid
55°
Wash
35°
Rinse-aid
65°
Wash
50°
Rinse off if
the dishes
have been
stacked for
several
days in the
dishwasher
prior to
washing.
Pre-rinse
Mixed Normal/
Delicate Mixed
Normal
45°
Rinse-aid
45°
Drying
a little
loosely attached
Third
rinse
Pre-rinse
50°
Wash
70°
First rinse
Second
rinse
medium
The programme sequence is
optimized and adapted with how
the appliance is loaded and how
dirty the dishes are.
Pre-rinse
Main rinse
Wash
45°
Pre-rinse
Soups, potatoes,
pasta, rice, eggs,
roast or
fried food
Coffee,
cakes, milk,
sausage, cold
drinks, salads
2:18
1,65
16
13
2:20
1,05
14
–
2:20
0,75
13,6
–
0:30
0,80
10
–
0:20
0,05
4
–
1:30-2:20
1,15-1,60
–
10-17
Laboratory measured value in accordance with AS/NZS 2007
Auto
55°/65°

aus
15
2Washing dishes
Pr/ogramme selection
The most appropriate programme can be
identified by comparing the type of
crockery, cutlery, etc., as well as the
amount and condition of food remains,
with the details contained in the
programme overview.
The corresponding programme sequence,
duration and consumption details are
shown in the bottom half of the overview.
For example:
For a mixture of various types of crockery
and utensils with plenty of food remains
that are not stuck on fast, use the
Auto programme.
Reduce costs!
If only a small number of dishes have
been loaded into the dishwasher, selecting
a programme that operates at the next
lowest temperature will usually suffice.
Programme data
The stated programme data are based on
standard operating conditions. The values
can vary considerably according to:
different amounts of dishes
temperature of mains water supply
pressure of mains water supply
ambient temperature
fluctuations in mains voltage
machine-related factors (e.g.
temperature, water volume, ...).
Aqua sensor *
* some models
The Aquasensor is an optical measuring
device (light barrier) which measures
the turbidity of the rinsing water.
The Aqua sensor is used according
to the programme. When the Aqua sensor
is active, “clean” rinsing water may be
transferred into the next rinsing bath
and/or the temperature adjusted. If the
turbidity is greater, the water is drained
and is replaced with fresh water. In this
way water consumption can be reduced
by approx. 4 litres.
Switching the dishwasher ON
Turn on the tap.
Set main switch
1
to ON.
Indicators light up according to the last
programme that was selected.
This same programme will run again if
no other programme button
6
is
pressed.
The numerical display
3
shows the
expected duration of the programme.
The programme starts automatically.
Programme sequence indicator
7
Your dishes are being cleaned.
Your dishes are being dried.
Your dishes are being rinsed.
Remaining running time display
When the appliance has started, the
expected programme running time is
displayed. The programmed running time
is affected by the water temperature, the
number of dishes, as well as the degree
of soiling. If these conditions are changed,
the running time (depending on the
selected programme) can vary greatly.
As the effect is not detected until a
programme is running, the time may
be longer or shorter than expected.

aus
16
Time delay
You can delay the start of the programme
in 1-hour steps up to 24 hours.
Switch on the appliance.
Press the timer programming button
4
until the digital display
3
jumps
to .
Keep pressing the timer programming
button until the required time is
displayed.
To delete the timer programming,
keep pressing the button until
is displayed.
You can change your programme
selection at any time until the
programme starts.
End of programme
The programme has ended when a figure
appears in the numerical
display
3
.
Switching the dishwasher OFF
Several minutes after the programme has
ended:
Set the main switch
1
to OFF.
Turn the water tap off.
(Does not apply when Aqua-Stop unit
has been fitted)
Remove dishes, etc. when they have
cooled down.
At the end of the programme please open
the door fully and not partially when
emptying the dishwasher. Any escaping
water vapour could damage sensitive
worktops.
Interrupting the programme
Switch off the main switch
1
.
The lit display goes out. The programme
is saved.
If there is a warm water connection or if
the machine has already heated up and
the appliance door was opened, leave
the door open for several minutes and
then close. Otherwise, expansion may
cause the appliance door to spring open.
Switch on the main switch again.
Terminating the programme
(Reset)
Simultaneously press programme
buttons Aand Cfor approx. 3 sec.
The numerical display indicates .
The programme sequence lasts
approx. 1 min.
Switch off the main switch
1
.
Changing the programme
When the appliance is switched on, the
programme can be changed
within minutes.
If the programme is changed
subsequently, programme sections
(e.g. Cleaning) which have already started
run to the end. The new remaining time
consists of the remaining time of the
previous programme section and the
remaining time of the newly selected
programme.
Intensive drying
In the final rinse the appliance operates
at a higher temperature and therefore an
improved drying result is obtained.
(Caution if utensils are fragile!)
Close the door.
Hold down programme button Aand
press main switch until
1
the digital
display illuminates.
Release both buttons.
The LED for button Aflashes and
the digital display
3
displays the factory
setting (off) or (on).
To change the setting, press
programme button A.
Switch off the main switch
1
.

aus
17
Additional functions
*on some models additional functions
5
can be set with the buttons.
Time Saver *
The >>Time Saver<< function can reduce
the running time by approx. 20% to 50%
depending on the selected rinse
programme. The particular change in
the running time is indicated on the time
remaining display. To obtain optimum
cleaning and drying results at a reduced
running time, water and energy
consumption are increased.
Half load*
If you have only a few items to wash (e.g.
glasses, cups, plates), you can switch to
“Half load”. The “half load” additional
function saves water, energy and time. It is
recommended to put a little less detergent
in the detergent dispenser than for a full
load.
Maintenance and care
Aregular inspection and maintenance of
your machine will help to prevent faults.
This saves time and prevents problems.
Overall condition of the
machine
Check washing chamber for grease
and limescale deposits.
If you find such deposits:
Fill the detergent dispenser with
detergent, start the appliance without
utensils in the programme which has
the highest wash temperature.
Clean the appliance with detergents/
appliance cleaners which are particularly
suitable for use with dishwashers.
Regularly wipe the door seal with a
damp cloth.
Never use a steam cleaner to clean your
dishwasher. The manufacturer is not liable
for any consequential damage.
Regularly wipe the front of the appliance
and panel with a damp cloth; water and
a little washing-up liquid will suffice.
Do not use sponges with a rough surface
or abrasive detergents, as these could
scratch the surfaces.
Attention!
Never use other chlorinated household
detergents! Health hazard!
Rinse-aid
As soon as the rinse-aid refill indicator
lights up on the control panel
8
,
refill with rinse aid.
Filters
The filters 24 prevent larger remnants of
food or other objects from getting inside
the pump. This residue can occasionally
clog up the filters.
The filter system consists of a filter
cylinder, a flat fine filter and, depending on

aus
18
the model, a microfilter (*).
Inspect the filters for obstructions every
time the dishwasher has been used.
By unscrewing the filter cylinder, you
can remove the filter system. Remove
any food remnants and clean the filters
under running water.
Reassembly:
Insert the filter system and screw down
with the filter cylinder.

aus
19
Spray arms
Lime and remnants of food in the washing
water can block the nozzles in the spray
arms 22 and 23 and the arm
mountings .
Inspect the nozzles in the spray arms
for blocked holes due to remnants of
food.
If necessary, pull the lower arm 23
upwards and lift it off.
Unscrew the upper spray arm 22 .
Clean both spray arms under running
water.
Refit the spray arms. Ensure that the
lower arm has locked into place and the
upper one is screwed tight.
Pump *
*on applicable models
Larger remnants of food that have not
been trapped by the filters and have been
left in the water can cause a blockage in
the pump. The water is no longer pumped
out of the dishwasher and it can be seen
covering the filter.
Proceed as follows:
First, always disconnect the appliance
from the power supply.
Ladle out as much water as possible.
Remove the filters 24 .
Undo the screw in the cover (Torx T 20)
and remove the cover.
Inspect the inside and remove any
obstructions that you find.
Re-insert the cover and screw down.
Re-insert the filters and screw down.
Torx T20
2
1

aus
20
Fault finding
Resolving minor problems
yourself
Experience has shown that you can
resolve most problems that arise during
normal daily usage yourself, without
having to call out a service engineer. Not
only does this save costs, but it also
means that the appliance is available for
use again that much sooner. The following
list of common occurrences and their
remedies should help you identify the
causes of most problems.
Problems ...
Attention
Remember: Repairs may be carried out by
a technician only. If a component has to be
replaced, ensure that only original spare
parts are used. Improper repairs or use of
non-original spare parts may cause
considerable damage and put the user at
considerable risk.
... when the appliance
is switched on
The appliance does not start.
The mains fuse has tripped.
The appliance plug has not been
inserted.
The appliance door has not been
shut properly.
The tap has not been turned on.
The filter on the water supply hose
is blocked.
Switch off the appliance and pull
out the mains plug. Turn off the
tap. Then clean the filter which is
situated at the connection of the
supply hose. Finally, restore the
power, turn on the tap and switch
on the appliance.
... with the appliance itself
Lower spray arm rotates with
difficulty
Spray arm is blocked by small
items or food remains.
Lid in detergent compartment
cannot be closed
Detergent compartment has been
overfilled.
Mechanism is clogged with
remnants of detergent.
Indicator lamps do not extinguish
after washing has finished.
Indicator lamps do not extinguish
after washing has finished
Main switch is still set to ON.
