Klein Tools AESEB1S User manual

INSTRUCTION MANUAL
ENGLISH
FRANÇAIS pg. 37
ESPAÑOL pg. 19
SMART SENSE Situational
Awareness Bluetooth®Earbuds
AESEB1S
• DUAL OMNI-DIRECTIONAL MICROPHONES
• BLUETOOTH 5.3 TECHNOLOGY
• CAPACITIVE TOUCH CONTROLS
• INSTANT NOISE COMPRESSION
AND LOW LEVEL AMPLIFICATION
• 10 HOURS RUNTIME ON
SINGLE CHARGE, 30 HOURS
WITH CHARGING CASE
• NOISE REDUCTION RATING
(NRR) OF 26dB
SMART SENSE

2
GENERAL SPECIFICATIONS
Klein Tools SMART SENSE Situational Awareness Bluetooth
®
Earbuds keep
users aware of their surrounding environment while simultaneously being
able to enjoy a high-quality stereo audio via Bluetooth 5.3 technology.
Soft memory-foam tips provide hearing protection up to 26dB NRR, while
silicone tips ensure an immersive audio experience. Durable charging case
nylon carabiner strap allows for convenient carrying outside the pocket.
• Earbud Dimensions: 0.37" × 0.76" × 1.41" (9.5 × 19.35 × 35.73 mm)
• Charging Case Dimensions: 1.26" × 1.76" × 3.07" (32.0 × 44.7 × 78 mm)
• Weight (Charging Case and Earbuds): 2.75 oz (78 g)
• Bluetooth®Version: 5.3
• Bluetooth®Connection Range: 32.8 ft. (10 m) in open space
• Hearing Protection: 26dB NRR (with memory foam tips)
• Supported Proles: A2DP/AVRCP/HFP/GAVD
• Frequency Response: 20Hz – 20kHz
• Earbud Battery Type: Li-Ion Coin Cell, 3.7V / 85mAh (0.315Wh)
• Case Battery Type: Li-polymer, 3.7V / 700mAh (2.59Wh)
• Charging Requirements: Maximum 5V DC, Minimum 1A
• Charge Time: Earbuds: Approx. 2 hours Case: Approx. 2 hours
• Runtime (70% volume): ~10 hours w/ earbuds only, ~30 hours w/ charging case
• Certications: FCC, IC, DOE/CEC, NRCAN, BQB
• FCC ID: 2AI28-AESEB1S IC: 21655-AESEB1S
ENGLISH

3
GENERAL SPECIFICATIONS
• Operating/Charging Temperature: 14° to 140°F (-10° to 60°C)
• Charging Temperature: 32° to 113°F (0° to 45°C)
• Storage Temperature: -4° to 140°F (-20° to 60°C)
NOTE: Periodic recharging is recommended during prolonged storage.
• Relative Humidity: 0% to 85% non-condensing
• Drop Protection: 6.6' (2 m)
• Ingress Protection (IP) Rating (Earbuds): IP54
Specifications subject to change.
CONTENTS
• AESEB1S SMART SENSE Situational Awareness Bluetooth®Earbuds
• Charging Case
• 2' (61 cm) USB-A to USB-C Cable
• 3 Sets of Memory Foam Tips (for hearing protection)
• 3 Sets of Silicone Tips (for casual listening)
• This instruction manual
SYMBOLS ON PRODUCT
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by Klein Tools, Inc. is under license.
Warning or Caution Bluetooth®SIG Certied
Risk of Electrical Shock WEEE: Electronics Disposal
Read Instructions

4
ENGLISH
WARNINGS
Read, understand, and follow these instructions to ensure safe
operation. Keep these instructions for future reference.
These hearing protectors help reduce exposure to hazardous noise and
other loud sounds. Misuse or failure to wear hearing protection at all times
that you are exposed to noise may result in hearing loss or injury.
• Silicone tips on earbuds DO NOT provide hearing protection.
ONLY memory foam tips on earbuds provide hearing protection.
• Use only appropriately sized Klein Tools memory foam tips for hearing
protection in loud-noise environments. Improper fit of this device will
reduce its effectiveness in attenuating noise. Consult the OPERATING
INSTRUCTIONS section for proper fit.
• Prolonged exposure to high volumes can cause hearing damage.
It is the responsibility of the user to set the audio input level to the
recommended volume. See table on next page for noise exposure levels.
• DO NOT use this product in situations that require special attention:
using noise reduction equipment and listening to audio can reduce
awareness of the surrounding environment.
Failure to observe these warnings can result in risk of re or electric shock.
• DO NOT use the product if it is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire,
explosion, or injury.
• Risk of fire and burns. DO NOT open, crush, heat above specified
maximum temperature or incinerate. Prolonged exposure to direct
sunlight can result in elevated temperatures.

5
NOISE EXPOSURE VALUES
EXPOSURE
TIME
EXPOSURE LEVEL PER NIOSH
RECOMMENDED EXPOSURE LIMIT EXPOSURE LEVEL PER OSHA
PERMISSIBLE EXPOSURE LIMIT
8 hours
85 dBA 90 dBA
4 hours
88 dBA 95 dBA
2 hours
91 dBA 100 dBA
1 hour
94 dBA 105 dBA
30 minutes
97 dBA 110 dBA
15 minutes
100 dBA 115 dBA
See www.cdc.gov/niosh/topics/noise/reducenoiseexposure for more details.
WARNINGS
• DO NOT immerse in water or other liquids.
• Properly seal the charging port cover to achieve specified water & foreign
object ingress protection. Keep seal free of dirt, oil, sand, or other material
that interferes with proper sealing. Failure to do so can result in risk of fire
or electric shock.
• DO NOT open the charging port cover if wet or in a wet environment.
Thoroughly dry the unit and the seal around water-resistant cover
completely before opening water resistant cover
• DO NOT subject to impacts or drops greater than 6.6ft (2m). Drops larger
than this may not show signs of damage, but internal components may
have been compromised. It is advisable to replace the unit if any such
severe events occur.
• DO NOT attempt to repair the product or charging cable. There are no
user-serviceable parts.

6
FEATURE DETAILS
NOTE: There are no user-serviceable parts inside.
ENGLISH
10
5
6
79
8
1
2
34
11
12

7
FEATURE DETAILS
1
Capacitive Touch Area (on each earbud)
2
Dual-Color Earbud LED (on each earbud)
3
Omni-Directional Microphone (on each earbud)
4
Bluetooth®Microphone (on each earbud)
5
Charging Case Cover
6
Charging Case LED
7
USB-C Silicone Port Cover
8
USB-C Port
9
Nylon Carabiner Strap
10
USB-A to USB-C cable
11
Memory Foam Tips (3 sets)*
12
Silicone Tips (3 sets)*
*NOTE: Silicone Tips
12
are intended for casual listening only.
When hearing protection is required, use the Memory Foam Tips
11
.

8
NOISE REDUCTION RATING (NRR)
The NRR for the AESEB1S SMART SENSE Situational Awareness
Bluetooth®Earbuds is 26dB. It is tested and in accordance with ANSI
S3.19-1974. To ensure adequate hearing protection, the provided memory
foam tips must be used with the Bluetooth®Jobsite Earbuds.
ANSI S3.19-1974 TESTING
Frequency
(Hz) 125 250 500 1000 2000 3150 4000 6300 8000 NRR
Mean
Attenuation 29.7 29.3 26.3 27.3 33.8 37.5 34.5 40.1 40.9
26
Standard
Deviation
3.6 2.8 3.5 3.3 2.9 2.3 2.2 3.6 2.5
The level of noise entering a person’s ear when the hearing protector is
worn as directed, is closely approximated by the difference between the
A-Weighted environmental noise level and the Noise Reduction Rating
(NRR).
EXAMPLE:
• The environmental noise level as measured at the ear is 93dB(A).
• The NRR is 26dB.
• The level of noise entering the ear is approximately equal to 67dB(A).
ENGLISH

9
NOISE REDUCTION RATING (NRR)
CAUTION: For noise environments dominated by frequencies below 500
Hz, the C-weighted environmental noise level should be used.
NOTE: Although hearing protectors can be recommended for protection
against the harmful effects of impulsive noise, the Noise Reduction Rating
(NRR) is based on the attenuation of continuous noise and may not be
an accurate indicator of the protection attainable against impulsive noise
such as gunfire. The Environmental Protection Agency uses the Noise
Reduction Rating (NRR) as a rating of a hearing protector’s noise-reducing
performance. Klein Tools cannot guarantee the suitability of the NRR as a
method of rating protection as protection relies on the level and exposure
of sound and how well a product fits.
AUDIO INPUT LEVEL
The audio level in the hearing protector is dependent on the audio input
level. To prevent harmful noise levels, the AESEB1S SMART SENSE
Situational Awareness Bluetooth®Earbuds automatically default to
85dB when connected to music device. If the hearing protector is
connected to a music device with a high audio output level, it is the
user’s responsibility to set the audio input level to safe level. See table in
WARNINGS section for noise exposure levels.

10
OPERATING INSTRUCTIONS
CHARGING THE CASE
Open the USB-C Port Cover
7
and insert the USB-C end of the included
charging cable
10
into the USB-C Port
8
of the charging case. Connect
the USB-A end of the cable into an appropriate charging source (not
included, see GENERAL SPECIFICATIONS section).
While the case is charging (0% to 99%), the Charging Case LED
6
will
breathe red (dim to bright). Once the case is fully charged (100%), the
Charging Case LED
6
will turn green.
CHARGING THE EARBUDS
Provided the charging case has been charged, open the Charging Case
cover
5
and place the earbuds in their respective slots. The Charging
Case LED
6
will flash white indicating the earbuds are successfully
charging, and will stop flashing once fully charged.
ENGLISH

11
FIG. A FIG. CFIG. B
FIG. E
OPERATING INSTRUCTIONS
FIG. D
30s
FPOFPO FPOFPO FPOFPO
FPOFPOFPOFPO

12
ENGLISH
OPERATING INSTRUCTIONS
USING MEMORY FOAM TIPS
11
FOR HEARING PROTECTION
WARNING: Inspect before each use. Damage to the memory foam tip
can reduce noise reduction performance.
INSERTING EARBUDS INTO EARS
The AESEB1S comes with three silicone
12
and three memory-foam
11
eartip sets:
The silicone eartips
12
are best suited for casual or leisure use.
The memory foam
11
eartips must be worn for hearing protection (NRR):
1. Choose the eartip size (S/M/L) that best fits your ear canal and install onto
the earbuds (FIG. A). Inspect each tip for dirt and damage before use.
2. With clean hands, roll and compress the memory foam tips along the
stem of the earbud (FIG. B).
3. Reach over your head with free hand to pull your ear up and back and
insert the memory foam tip portion of the earbud as deep as possible
(FIG. C).
4. Hold the earbud and wait 30 seconds, until the memory foam tips are
fully expanded (FIG. D).
5. Rotate the earbud if necessary to make sure the earbuds rest firmly and
securely inside the inner ear (FIG. E).
6. Repeat process for other earbud.

13
OPERATING INSTRUCTIONS
TURNING EARBUDS ON/OFF
ON: If the earbuds are inside the charging case, opening the Charging Case
Cover
5
, will automatically power on the earbuds. If the earbuds are not
inside the case, touch and hold the Capacitive Touch Area
1
on either
earbud for 1.5 seconds.
OFF: Placing both earbuds into the charging case and closing the Charging
Case Cover
5
will automatically power off the earbuds. Alternatively, touch
and hold the Capacitive Touch Area
1
on either earbud for 5 seconds.
PAIRING
After successfully powering on, the earbuds will automatically enter
Bluetooth®pairing mode. “Pairing” voice prompt will be heard and the
Earbud LEDs
2
will alternate between flashing Red and Blue every
0.5 seconds. To pair with your device:
1.Ensure that Bluetooth is enabled on your device and it has discovered
“Klein SMART SENSE Buds” in the pairing list.
2.Select “Klein SMART SENSE Buds” and upon successful connection,
“Connected” voice prompt will be heard, and the Earbud LEDs
2
will
turn solid blue for three seconds, then turn off.
NOTES: 1) In the event auto pairing fails, power the earbuds off and on again.
2) The earbuds will automatically attempt to connect to the last paired wireless
device when turned on, but are ready to pair with any compatible device within
two minutes of powering on if the last paired device is not detected.
AUTO POWER-OFF
If no Bluetooth device is connected and situational awareness is off, the
earbuds will automatically power off after 10 minutes.

14
OPERATING INSTRUCTIONS
LEFT EARBUD
Music Controls:
Play/Pause: Single-tap Capacitive Touch Area
1
.
Next Track: Double-tap Capacitive Touch Area
1
.
Previous Track: Triple-tap Capacitive Touch Area
1
.
Controls During Phone Calls:
Answer / End Call: Single-tap Capacitive Touch Area
1
.
Reject Call: Touch & hold Capacitive Touch Area
1
for one second.
End Current Call, Answer Incoming Call: Single-tap Capacitive Touch Area
1
.
Hold Current Call, Answer Incoming Call: Double-tap Capacitive Touch Area
1
.
Switch Between Two Active Calls: Double-tap Capacitive Touch Area
1
.
End Current Call and Other Call on Hold: Touch & hold Capacitive Touch Area
1
for one second to end new call, then
single-tap
to end initial call.
Cancel Outgoing Call: Single-tap Capacitive Touch Area
1
.
ENGLISH

15
OPERATING INSTRUCTIONS
RIGHT EARBUD
Ambient Controls:
Ambient On/Off: Touch & hold Capacitive Touch Area
1
for 1.5 seconds.
Volume Up: Single-tap Capacitive Touch Area
1
.
Volume Down: Double-tap Capacitive Touch Area
1
.

16
ENGLISH
COMPLIANCE
FCC COMPLIANCE
This device complies with part 15 of the FCC RULES. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

17
COMPLIANCE
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC RF EXPOSURE STATEMENTS:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment and meets the FCC RF Exposure Guidelines.
This device must not be co‐located or operated in conjunction with any
other antenna or transmitter.
IC COMPLIANCE
This device contains license-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development Canada’s
license-exempt RSS(s). Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation of the device.
This device complies with RSS-247 of Industry Canada. Operation is subject
to the condition that this device does not cause harmful interference. This
Class B digital apparatus complies with Canadian ICES-003.
IC RADIATION EXPOSURE STATEMENT:
The equipment complies with SAR limits set forth for an uncontrolled
environment and meets the RSS-102 of the IC RF Exposure Rules. This
transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.

18
ENGLISH
MAINTENANCE
CLEANING: Be sure earbuds are turned off and case is unplugged, and wipe
with a clean, dry lint-free cloth.
Do not use abrasive cleaners or solvents.
STORAGE: If the earbuds are to be left unused for an extended period of
time, charge before storing, and recharge periodically during storage, to
maintain battery’s charging capacity.
WARRANTY
www.kleintools.com/warranty
DISPOSAL / RECYCLE
Do not place equipment and its accessories in the trash. Items
must be properly disposed of in accordance with local regulations.
Please see www.epa.gov/recycle for additional information.
CUSTOMER SERVICE
KLEIN TOOLS, INC.
450 Bond Street
Lincolnshire, IL 60069
1-800-553-4676
www.kleintools.com

ESPAÑOL
AESEB1S
SMART SENSE
MANUAL DE INSTRUCCIONES
Audífonos Bluetooth®
SMART SENSE de
conciencia situacional
• MICRÓFONOS OMNIDIRECCIONALES
DUALES
• TECNOLOGÍA BLUETOOTH 5.3
• CONTROLES TÁCTILES CAPACITIVOS
• COMPRESIÓN INSTANTÁNEA DEL
RUIDO Y AMPLIFICACIÓN DE
SONIDOS DE BAJO NIVEL
• 10HORAS DE AUTONOMÍA TRAS
UNA SOLA CARGA, 30HORAS
CON ESTUCHE DE CARGA
• NIVEL DE PROTECCIÓN DE RUIDO
(NRR) DE 26 dB

20
ESPAÑOL
ESPECIFICACIONES GENERALES
Los audífonos Bluetooth
®
SMART SENSE de conciencia situacional mantienen
a los usuarios atentos al entorno que los rodea mientras que simultáneamente
les permite disfrutar de un audio de sonido estéreo de alta calidad a través
de la tecnología Bluetooth 5.3. Las almohadillas de espuma viscoelástica
proporcionan protección auditiva hasta 26dBNRR (Nivel de protección
de ruido), mientras que las almohadillas de silicona aseguran una experiencia
de audio inmersiva. La resistente correa de nylon para mosquetón del estuche
de carga permite un transporte práctico por fuera del bolsillo.
• Dimensiones de los audífonos: 0,37"×0,76"×1,41"(9,5×19,35×35,73mm)
• Dimensiones del estuche de carga: 1,26"×1,76"×3,07"(32,0×44,7×78mm)
• Peso (estuche de carga y audífonos): 2,75oz (78g)
• Versión de Bluetooth
®
:5.3
• Alcance de la conexión Bluetooth
®
:32,8' (10m) al aire libre
• Protección auditiva: 26dBNRR (con almohadillas de espuma viscoelástica)
• Perles compatibles: A2DP/AVRCP/HFP/GAVD
• Respuesta de frecuencia: 20Hz – 20kHz
• Tipo de batería de los audífonos: batería de iones de litio tipo botón,
3,7V/85mAh (0,315Wh)
• Tipo de batería del estuche: polímero de litio, 3,7V/700mAh (2,59Wh)
• Requisitos de carga: máximo 5V de CD, mínimo 1A
• Tiempo de carga: Audífonos: aprox. 2horas Estuche: aprox. 2horas
• Tiempo de funcionamiento (al 70% del volumen): aprox. 10horas solo
los audífonos, aprox. 30horas con el estuche de carga
• Certicaciones: FCC, IC, DOE/CEC, NRCAN, BQB
• ID de FCC: 2AI28-AESEB1S IC: 21655-AESEB1S
Table of contents
Languages:
Other Klein Tools Headphones manuals
