KLEVA QUICKPRESS POWER STATION User manual

These instructions contain important information which will help
you get the best from your equipment and ensure safe and correct
assembly, use and maintenance.
USER MANUAL
TM
For iron parts diagram and set up videos
SCAN ME


SAFETY WARNINGS
When using your Quickpress Power station™, basic safety precautions
should always be followed, including the following:
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• The iron must not be left unattended while it is connected to the supply mains.
• The plug must be removed from the socket-outlet before the water reservoir is filled with water.
• When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
• The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
• Make sure to read all the safety precautions below and look at the illustrations before you start using the
appliance.
• Use the appliance for its intended use only described in this manual.
• The appliance is intended for household use only.
• In order to protect against the risk of electric shock or damage to the unit, do not immerse iron power
base into water or any other liquids.
• Connect the appliance only to an alternating current of the voltage specified on the rating plate and only
to an earthed socket. To avoid a circuit overload, do not operate another high wattage appliance in the
same circuit.
• Turn the appliance to OFF before plugging or unplugging from outlet. Never yank cord to disconnect
from outlet; instead, grasp plug and pull to disconnect.
• Do not allow power cord or supply hose to touch hot surface.
• Unplug the appliance from main socket before filling or empty or when not in use.
• Do not operate the appliance with a damaged cord or if the appliance has been dropped or damaged. To
avoid a hazard such as the risk of electric shock, do not disassemble the appliance, it must be taken to a
qualified serviceman or manufacturer or its service agent for examination and repair. Incorrect
re-assembly can cause a risk of electric shock when the iron is used.
• Place the iron out of reach of children; close supervision is necessary for any appliance being used by or
near children. Do not leave the iron unattended while connected to the supply mains.
• During use, always place its stand on a stable, level and horizontal surface or ironing board.
• Always place the iron on its stand, and do not allow the hot soleplate to touch the power cord or supply
hose.
• Burns can occur from touching hot metal parts, hot water or steam. Use caution when using the
appliance.
• Never use the iron facing towards people because the steam can cause burns.
• The surfaces are liable to get hot during use.
• Never twist the supply hose during use.
• The appliance must be used and rested on a stable, level and horizontal surface.
• The iron shall be placed on the separate stand only.
• When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
•The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
•The iron must not be left unattended while it is connected to the supply mains.
• The appliance must be rest or stocked on a stable, level and horizontal surface.
•During use, if no water in the reservoir, it will produce a loud noise, Turn o at the power point
immediately.
• Keep the iron and its cord out of reach of children less then 8 years of age when it is energized or
cooling down.


FEATURES/PARTS
Water tank
Handle
Soleplate
Decorative cover
Heating indicator light
Steam Trigger button
Connector Hose/Connector Power
Power cord
Base handle release button
Filter
Water tank lock
Temperature control dial
1
2
3
4
5
6
7
8
9
10
11
12
Water
Capacity
Time to
heat Up
Auto
Shut O
Cord
Length
Steam
Pressure
VoltagePowerSKU
1700ml 60
seconds
20 minutes
without pressing
steam button
1.8
Meters
(Max) 6.5
bar pump
220-240V
50/60Hz
2000-2400W
QPPS001


INSTRUCTIONS
Fabric Setting Chart
Temperature
Setting
Fabric
Instructions
Steam selection
SYNTHETIC Delicates Cotton/Linen
Synthetics, Nylon,
Polyester
Wool, Silk Cotton, Linen
Dry Ironing Steam ironing on
the under side of
the fabric
Steam ironing
Ironing Temperature Setting Guide
Step 1 - Follow the ironing instructions on the
garment label. If there is not any instruction label on
the item, but you know what kind of fabric it is, please
refer to the fabric setting chart described in this
instruction manual.
Step 2 - The Fabric Setting Chart is only valid for
plain fabrics and not for materials which have textile
finishes (eg. glosses, crinkles) which have been
applied. It is best to iron these at a lower temperature.
Step 3 - Firstly, sort laundry according to ironing
temperature setting guide: wool with wool, cotton
with cotton etc.
Step 4 - The iron heats up quicker than it cools down.
Therefore start ironing the articles that need to be
ironed at the lowest temperature first. Eg. an item
made from synthetic fibers.
IRON TEMPERATURE
DIAL


How To Use Your Power Station™
PREPARE THE APPLIANCE FOR USE
Step 5 - If the fabric is made up of various kinds of fibers, always select the
temperature required by the most delicate fibers, i.e. the lowest temperature. Eg. an
article consisting of 60% polyester and 40% cotton, according to the Fabric Setting
Chart it should be iron for polyester and without steam.
Step 6 - When steam ironing woollen fabrics, shiny patches may occur. To prevent
this from happening turn the article inside out, ironing the reverse side.
Step 7 - After using of the steam iron for cotton fabrics, Do Not iron articles requiring
a lower temperature (such as nylon etc), immediately. It is advisable to adjust the
temperature dial to a lower setting, waiting till the power indicator light turns o and
then you can start ironing.
Step 1 - Check if the rating indicated on the
rating plate corresponds to the main voltage
in your home.
Step 2 - Press the handle buttons located on
the sides of the iron, shown in (Fig. 1) to lay
the handle down.
Step 3 - Remove the protective foil, sticker
or card from the soleplate.
Step 4 - Fully unwind and straighten the
power cord and the supply hose.
Step 5 - Place the appliance on a stable,
level and horizontal surface such as an
ironing board or bench top.
Step 6 - Place the iron onto the iron rest
plate horizontally at the base unit.
NOTE: Do not fill water tank with vinegar, perfume, starch, chemically descaled water
or descaling agents.
FIG. 


STEAM FUNCTION SETTING
After turning the power on, set the temperature dial to the steam ironing position
(the area between Wool and Max on the temperature dial). The heating indicator light
will turn on with the iron unit, this indicates the unit being heated up. When the
desired temperature has been reached, the heating indicator light will turn o, once
this happens the iron is now ready for using. During use, the heating indicator light
will cycle from ON to OFF and then OFF to ON. This indicates that the iron is heat
regulating automatically. Press the steam button to start steam ironing. When you
adjust the temperature control dial, the steam rate will be adjusted accordingly.
FILLING THE WATER TANK
Step 1 - Press the water tank lock upwards and slide
the detachable water tank outwards from the base.
(Fig. 2)
Step 2 - Take the filter upwards out from the water
fill hole. (You can take the filter out of the opening
for filling water into water tank, or fill water into
water tank directly with the filter existing in the
opening). (Fig. 3)
Step 3 - Fill the water tank up to or below the MAX
fill line with clean tap water. (Fig. 4)
Step 4 - Replace filter back into water tank. When
moving please hold the water tank with two hands.
(Fig. 5)
Step 5 - Replace the water tank into the base unit
again. You will hear a “Click” sound once the base
unit is securely locked in. (Fig. 6)
Step 6 - Always pour out the remaining water after
use. (Fig. 7)
NOTE: When the temperature control dial is located at Synthetic, it is sugested not to activate
steam ironing since temperature is too low to produce steam. this is only suited for dry ironing.
FIG. 
FIG. 
FIG.  FIG. 
FIG.  FIG. 
NOTE: When the water level reaches a low level or
empty, the pump will provide a sound to indicate
refilling. You must stop using the appliance immediately
and refill the water tank as per instructions mentioned.
Note: *Water tank shown


STEAM IRONING
Step 1 - Fill the water tank with clean tap water (refer to filling the water tank on
page 5). For better performance, please immerse the filter in water for several
minutes before installing it into the water tank.
Step 2 - Connect the unit into a suitable power socket. Turn the temperature control
dial to steam ironing position (the area between Wool and Max on the temperature
dial). The heating indicator light on the iron unit will light up to indicate that the unit
is being heated up. When it turns o, the desired temperature has been reached. It
is now ready for steam ironing. During use, the heating indicator light will cycle from
ON to OFF and then OFF to ON, this indicates that the iron is heat regulating
automatically.
Step 3 - Before using the steam iron function for the first time, please clean the iron
(refer to cleaning and maintenance on page 9). Take the iron unit from the base unit.
Press the steam button underneath the handle to allow steam release for 30
seconds and then stop for another 30 seconds. Do so as a cycle and repeat the
above cycle again. The iron is not ready for using until the heating indicator lights
turns OFF.
Step 4 - During steam ironing the steam rate will vary when the temperature control
dial is adjusted to dierent positions. This can prevent water leakage caused from
the soleplate.
Step 5 - After using, turn the temperature control dial to MIN and then unplug it
from the power socket. Take the iron unit back and place it onto the base unit.
Step 6 - Slide the water tank out from the base unit and empty it.
NOTE: For first time use it is normal that a slight vibration sound may occur from the electrical
pump inside the base unit for a few seconds when the steam iron starts. This is because there
is air inside the filter. It will stop once the air has been pumped out. If this continues to happen
for more than 60 seconds, check to see whether the filter is assembled and installed correctly.
NOTE: When the temperature dial is set at SYNTHETIC position, this is suited for dry ironing
only. MAX steam will be obtained when set at MAX position. When set at WOOL position,
steam will be gradually released slower.


Handle
Step 1 - Press down the two handle buttons
simultaneously and then lay the handle down. (Fig. 9)
Step 2 - After use, allow the appliance to completely cool
down, then wind the power cord around the cord storage
located at the base of the unit and put the iron onto the
base unit.
Step 3 - Lift the handle up until you hear a “pa” sound,
this indicates that the handle has been locked in place
and you can now safely carry the appliance by the
handle. (Fig 10)
The handle is attached to the base unit used to carry the
appliance, before use please put the handle down as the
following method shows:
DRY IRONING
Step 1 - Connect the appliance to a suitable power socket.
Step 2 - Set the temperature control dial to the desired position according to the
ironing instructions on the garment label or fabric setting chart. The heating
indicator light (Red) on the iron unit will light up to indicate that the unit is being
heated up. When the heating indicator light turns OFF, the desired temperature has
been reached. During use, the heating indicator light will cycle from ON to OFF and
then OFF to ON. This indicated the unit is self heat regulating.
Step 3 - After using, take the iron unit back to the base unit, turn the temperature
control dial to MIN and then unplug from the main socket.
NOTE: When changing your temperature setting from a higher setting to lower, it is proposed
that you should not start the iron immediately since this may cause burns to your fabric. Please
wait until the temperature indicator lights up steadily, then proceed to start ironing.
FIG. 
FIG. 
VERTICAL STEAM IRONING
Follow the steam ironing process, and then hold the iron
in a vertical position between 5cm - 15cm away from the
hanging fabrics. Press down the steam button which will
create a vertical steam. This feature is especially used for
removing creases from hanging clothes and curtains.
Never directly perform steam ironing on People. (Fig. 8)
FIG. 


Cord Storage
NOTE: Immerse the filter in the water tank for several minutes in to achieve better performance
for future use.
Step 1 - After use, allow for the unit to completely cool down. Unplug the unit from the
power socket and pour out the remaining water from the water tank.
Step 2 - Place iron on the base unit. Fold the supply hose and wind it clockwise around the
cord slot of the base unit. Tie the power cord and folded supply hose together. Then wind
the power cord clockwise around the cord slot of the base unit. Lock the plug with the
supply hose. (Fig. 11- Fig. 14)
Replacement of the Filter
Auto Shut O Function
Step 1 - Slide the water tank out from the base unit and take the filter out from the water
tank. Then replace it with a new one.
Step 2 - After a new filter has been installed well into the water tank, fill the water tank to
the MAX level, then slide the water tank into the base unit.
The Iron is designed to have an Auto Shut O Function where it will Shut O after 20
minutes if the steam button is not pressed. For another cycle please re-set the steam
button.
FIG.  FIG.  FIG.  FIG. 


NOTE: Never submerge the appliance under water. Never clean or place the appliance
under tap water.
Anti-Calc System
The filter is designed to reduce the build-up of limestone which occurs during
steam ironing which would generally prolong the life of your iron. However, please
note that the filter will not completely stop the natural process of limestone
build-up.
The filter should be properly maintained and replaced with a new one every 2-3
months if used often (once every 1-2 days). Before replacing, the filter it can be
used continuously and the working life of the filter does depend on the water you
use. However the limestone will most likely be built up in the steam chamber and
this may happened depending on your local water quality. It is suggested that you
replace the water filter as soon as possible or mix with 50% proportion of distilled
water.
Emptying and Storing
Step 1 - Disconnect the appliance from the power supply and allow the appliance
to completely cool down.
Step 2 - After use, slide out the water tank and pour out all the remaining water.
Step 3 - Wind the power cord around the cord storage located on the base unit.
Step 4 - The iron should be placed on the iron rest plate, lay the handle down.
Cleaning and Maintenance
Step 1 - Disconnect the appliance from the power supply and allow the appliance
to completely cool down.
Step 2 - Clean the iron with a damp cloth.
Step 3 - Wipe o the scale and other deposits on the soleplate with a damp cloth
or non abrasive (liquid) cleaner.

HINTS & TIPS

PROBLEM POSSIBLE CAUSE SOLUTION
Iron Won’t
Heat up
No steam comes
out when pressing
the steam button
after the desired
temperature is
reached
Water leakage
from the
soleplate
Incorrect connection to the
main socket
Temperature Dial is set to
MIN position
Unknown malfunctions
Temperature control dial is at
SYNTHETIC position
No water in the water tank
Filter has been incorrectly
installed on the water tank
Water tank has not been
installed correctly
Iron has not been heated up
to the desired temperature
Unknown malfunctions
Turn o at the power socket, Unplug
and re-connect to the main socket
Ensure the wall socket is now turned
Set the temperature control dial to
the desired position according to the
fabric setting chart
Contact our customer service team
on 0293874100 or email
[email protected]
Set the temperature control dial to
the desired position according to the
fabric setting chart
Fill water in the water tank
Install the filter into the water
tank, then slide the water tank
back into the unit
Install the water tank back
into the unit, ensuring it clicks
back into place
The desired temperature has
been reached when heating
indicator light turn OFF
Contact our customer service
team on 0293874100 or email
[email protected]



www.klevarange.com.au
02 9387 4100
[email protected]
Suite 301 / 209 Oxford St
Bondi Junction NSW 2022 Australia
You MUST read all instructions before using any equipment.
We assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
TM
For iron parts diagram and set up videos
SCAN ME
