Klima C16 User manual

Page 1 of 11
C16 SIMPLIFIED INSTRUCTIONS
C16 Thermostat
Index:
1) Explanation of symbols
2) Start-up Wizard
3) Programming
4) Trouble shooting
1 Explanation of symbols

Page 2 of 11
2 Start-up Wizard
Clock
This section allows the day of the week to be
changed. The day can be changed by pressing
the up or down arrow. When the correct day
has been selected press the middle. button.
This section allows the hour to be changed.
The hour can be changed by pressing the up
and down arrow. When the right minutes
have been selected press the middle button.
This section will allow the minutes to be
changed. The minutes can be changed by
pressing the up and down arrow. Press the
middle button when the correct minute is
selected.
When the thermostat is connected to the Wi-Fi
thermostat it will automatically update the day,
hour and minutes.

Page 3 of 11
Sensor Selection
Floor temperature limit
(This only happens if Both sensors are chosen e.g. Room sensor and
floor sensor)
Select a temperature limit as this is needed to protect the floor.
Thermostat location
Either select it for home use or office use so it will follow default factory set office or
home hours and can be changed.
00 => Floor Sensor: run by floor sensor(default)
01 => Room-in Sensor: run by built-in room sensor (built into thermostat)
02 => Room-in sensor and floor sensor: run by built-in sensor with floor
temp limit.
03 => Room-out sensor: Run by external room sensor
04 => Room-out sensor and floor sensor: Run by external room sensor
with floor temp limit
Home

Page 4 of 11
3 Program
3.1 Temporary Override Temperature:
.
3.2 Mode:
To select a mode, press the
Office
press the or change the temperature and this
will act as a temporary boost. This boost will only be on
during that time period.
Anti-frozen mode: During this
mode the thermostat will run
with a low setting temp. The
maximum is 15°C
Manual mode: Will act like a manual
thermostat and will heat to the set
temperature.
Default mode: This will follow the program which
has been programmed in by yourself or the default
program

Page 5 of 11
3.3 Key-Lock
This allows the thermostat buttons to be locked and no buttons to be pressed. To
lock the thermostat press and hold and for 3 seconds to lock the
thermostat to unlock the thermostat repeat the same process.
3.4 Menu
On the main page of the thermostat press and hold the for 3 seconds to enter
menu.
CLK (Clock)
EVE(Evening)
rEAD(READ)
Allows the time and day to be set (See
8.4.1 on how to set the clock)
Allows the event parameters
(See 8.4.2 on how to program
times and temperature)
It will read heating time of a
certain period (Duration of
underfloor being on)

Page 6 of 11
SET
Various Settings (Further
settings for the thermostat)
1) Sensor Selection (allows the
sensor to be changed)
2) Room temperature calibration
3) Floor temperature Calibration
4) Floor temperature Limit
5)Schedule selection (program days of the week)

Page 7 of 11
END
3.4.1 Clock
The default interface of the menu is CLK(Clock). The day and time are set in this
setting.
•Press the to enter the setting to set the day
•Press the or to change the day
6)Used for heating or cooling
7)Adaptive function
8) Thermostat located in home or
office
9)Reset to factory settings
Back to main app page

Page 8 of 11
•Press the to enter the hour setting
•Press the or to change the hour
•Press the to enter the minute setting
•Press the or to set the minutes
•Press the to go back to the main page
3.4.2 Event setting
Default parameters
To change the parameter and set Events. In Automatic mode, the thermostat will run
according the times set. On the clock interface, press the or to select ‘EVE’.
- Press the to allow a day to be selected
- Press or to select a day or to end the selection
- Press the to enter the timing for that day, or to go back to the main page
- Press or to select event
- Press to select the program start time
- Press or to set the hour for the program starting time

Page 9 of 11
- Press to enter the minute’s
- Press or to set the minute for the program starting time
- Press to enter the temperature setting
- Press or to select a temperature
- Press to go back the Event menu setting, or to go back to day selection
if it’s on the last event
3.4.3 Readout
- Work out the time of which the thermostat is on for as a percentage, E.G. the
underfloor heating is on 1 day out of 7 days
- On the main page press the or to select READ
- Press to enter readout menu, the interface will show the heating timings
from the previous day
-Press or to choose 1 day, 30 days (1 month), 365 days (1 year) it
will show when the heating is on within certain times.
3.4.4Advanced Setting
- On the interface press the or to select ‘SET’
- Press for advanced settings
- Press go through the list of settings
- Each setting can then be changed by pressing or
- View next page to help identify what page you require to change your
thermostat accordingly

Page 10 of 11
1.Sensor Selection:
There are 5 options:
00 => Floor sensor (default setting)
01 => Room-in Sensor (Ran by built in air sensor)
02 => Room-in Sensor and Floor Sensor (Ran by built in air sensor with floor
temp limit)
03 => Room-out Sensor (Ran by an external room sensor)
04 => Room-out Sensor and Floor Sensor (Ran by external room sensor with
floor temp limit)
2.Room temp calibration done by room sensor
3.Floor temp calibration done by floor sensor
4.Floor temp limit only done when using both room and floor sensor
5.Select to set everyday individually or set the weekdays and weekends
individually
6. Used for heating or cooling

Page 11 of 11
7. Adaptive function learns over time when it is the best time to come on and
heat the floor to reach the required temperature at the next period.
8. Thermostat located in office or home
9.Reset thermostat to factory defaults
8.5 Open Window Detection
This function only works when Room sensor OR floor and room sensor are
selected. The thermostat will shut off for 15 minutes when the windows are
open. As it will detect the room temperature decreasing.
4 Troubleshooting
E1: Room-in Sensor Error
E2: Floor Sensor Error
E4: Room-out Sensor Error
