SPECIFICATIONS
Amplifier High Resolution All Digital Amplification:
400 Watts Peak
Frequency Response 26Hz-24KHz +/-3dB
Enclosure Type Bass-reflex w/ Tractrix® Port technology
High Frequency Drivers 2 x 1” (2.5 cm) Titanium diaphragm LTS compression
drivers mated to dual 90° x 90° Tractrix® Horns
Mid Frequency Drivers 2 x 3.5” (8.9 cm) Aluminum diaphragm with
Faraday Rings
Low Frequency Drivers 2 x 5.25” (13.3 cm) long-throw Subwoofers
Crossover Frequency 200Hz and 2KHz, 24dB/Octave 4th Order slopes
Maximum Acoustic Output 112dB (0.5m near field)
Inputs Airplay, DLNA, Bluetooth aptX®, Optical Digital, USB
for Digital Input from idevice, RCA analog
Accessories Included Full-function remote control, batteries, wireless
antenna, device stand, AC power cord
Finish Die cast brushed aluminum
Dimensions 8.25” (21cm)H x 21” (53.3cm)W x 8.5” (21cm)D
Weight 28.5 lbs (12.9 Kg)
Built From 2013
3502 Woodview Trace Indianapolis, IN 46268 | klipsch.com
KLIPSCH STADIUM™
The Klipsch Stadium speaker is an ultra-high-performance 2.1 home
music system with a uniquely aesthetic design that is visually domi-
nant, yet in a size suited for many different home environments. It has
the capability of reproducing stunning, live-music dynamics at even
“background” volume levels while doubling to fill even a large room
with live-concert level output with astounding clarity. Klipsch Stadium
is designed to match the performance level of a “high-end” component
audio system and is the “Modern HiFi” music system that perfectly
executes the performance levels you demand from it at any given time.
T H E L AT E S T T E C H N O L O G Y
Tractrix® Horn technology used in the Klipsch Stadium speaker as-
sures more sound being reproduced from every watt of power, with
much less distortion than any other driver design. Sound impact is
breathtaking. The Linear Travel Suspension (LTS) tweeters, derived
from our esoteric Palladium speaker line, further minimize distor-
tion with a true, piston-like driver excursion. Midrange drivers
utilize Faraday Rings, also adapted from our Palladium speakers, to
maintain a consistent voice-coil magnetic field to reduce distortion.
Tractrix port technology reduces port chuffing for the tightest, most
musical bass while the dual opposing subwoofers produce deep
bass without cabinet vibration. The high resolution, 400 watt digital
amplifier employs advanced DSP technology for balanced sound at
any volume level.
F U T U R E P R O O F C O N N E C T I V I T Y A N D C O N V E N I E N C E
Wireless music streaming via your Wi-Fi network, with the option
of streaming to multiple Klipsch Stadiums in your home via AirPlay.
Bluetooth® wireless technology audiophile aptX® and DLNA streaming,
along with a USB input for charging of most portable music sources
and wired iDevice music playback, and both an Optical Digital and Dual
RCA analog inputs to connect other devices. Download the free Klipsch
Air App on your iDevice for a tutorial of network setup, manual EQ
adjustment, custom naming of multiple Klipsch Stadiums on an Airplay
network and even a jukebox feature that allows multiple iDevices to
stream music in a group listening setting.
Our strong partnership with Live Nation Entertainment, the world’s leading
live entertainment company, has inspired a line of wireless music systems.
The Klipsch Music Center Series is named after one of the five most ticketed
live music venues in the world.
All specifications are subject to change without notice.
