Klipsch Reference Series RB-81 User manual

RB-81
SPECIFICATIONS
FREQUENCY RESPONSE 46Hz-23kHz ± 3dB
POWER HANDLING 150W RMS / 600W Peak
SENSITIVITY 97dB @ 2.83V / 1m
NOMINAL IMPEDANCE 8 ohms compatible
HIGH FREQUENCY DRIVERS 1" (2.54cm) Titanium diaphragm compression
driver mated to 90˚x 60˚ square
Tractrix®Horn
HIGH FREQUENCY CROSSOVER 1800Hz
LOW FREQUENCY DRIVERS 8" (20.3cm) Cerametallic™cone woofer
ENCLOSURE TYPE Bass-reflex via front-firing port
HEIGHT 19" (48.3cm)
WIDTH 9.25" (23.5cm)
DEPTH 12.25" (31.1cm)
WEIGHT 30 lbs (13.6kg)
FINISH Cherry or Black Ash woodgrain vinyl
8" Bookshelf Loudspeaker
A towering achievement in a bookshelf design,
the Reference Series RB-81 delivers unrivaled
audio performance for those who demand the
very best. With its high-end materials and
cosmetic elegance, this flagship model is
definitely a force to be reckoned with.
Exclusive Tractrix®Horns have always been the
key component of this critically acclaimed series.
In the RB-81, this technology has been refined to
include improved throat geometry for a more
genuine, lifelike sound. Behind the horn lies a
1-inch titanium tweeter with a large ceramic
motor structure to provide a unique combination
of precision, clarity and effortless power.
The RB-81 employs an 8-inch woofer for a solid
bass foundation. This Cerametallic™ woofer
with inverted copper dust cap exhibits a very
high stiffness-to-mass ratio and superb damping
characteristics.
The RB-81’s front-firing port eliminates
turbulence noise and makes installation into
custom cabinetry a breeze. Increased baffle
ribbing around the horn mouth dramatically
improves acoustics across the sonic range. For
signal purity and perfect driver integration, the
crossover on the RB-81 features the finest
components and Klipsch custom internal wiring.
Available in either a cherry or black woodgrain
vinyl finish, the RB-81 comes with a low-
diffraction, magnetically attached grille to further
accentuate the elegance of this speaker.
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2006
• Ultra-high-performance bookshelf speaker
• Front-firing port for easy integration into cabinetry
• Tractrix® Horn eliminates acoustic interference from shelf installations
