KLIQ METROTUNER+ User manual

ç
ç
Location
Using the product in the following locations could result in a malfunction:
• Locations of extreme temperature or humidity
• Excessively dusty or dirty locations
• Location of excessive vibration
• In direct sunlight
Power supply
The product is equipped with a built-in lithium polymer battery. Charge the
product when the low battery indicator shows it is necessary. (See the section
titled “Recharging and low power alarm.”) For optimal battery life, it is
recommended to charge at least once every 6 months.
Interference with other electrical devices
Please use this product at a safe distance from radios and televisions.
Handling
To avoid damage to the unit, please do not apply excessive force to the
switches or other controls.
Care
• If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not apply
liquid cleaners such as: benzene, solvents or other cleaners that contain
flammable compounds.
• Keep foreign matter out of your product.
• Do not set any container with liquid in it close to the device. If liquid gets
into the device, it may cause a malfunction, fire, or electrical shock.
• Be careful not to let metal get into the device. This may cause electrical
shock or injury.
MAIN FEATURES
• Easy-view screen for clear and wide range of viewing angles.
• High-definition color screen.
• Built-in high-volume lithium battery that provides maximum work time
between charges.
• Human voice counting.
• Standard micro-USB charging jack.
• Tuner vibration pick-up by built-in microphone.
• Clock and alarm function.
PARTS AND FUNCTIONS
RECHARGING AND LOW POWER ALARM
KLIQMusicGear KLIQMusicGear.com
KLIQMusicGear
KLIQ Music Gear
METROTUNER+
RECHARGEABLE
METRONOME / TUNER / CLOCK
Dear Musician,
Thank you for purchasing the Rechargeable MetroTuner+ multifunction
system, and welcome to the KLIQ!
To register your product warranty, please visit
www.kliqmusicgear.com/warranty. To get the most out of your new
Metronome/Tuner/Clock, please carefully read this manual prior to first
use, and keep it for later reference. Should you ever need anything, please
reach out to us at [e-mail] or call us at 800.316.9651.
We are always glad to help!
©2020 KLIQ Music Gear
www.kliqmusicgear.com
PRECAUTIONS
Package contents: (1) MetroTuner+, (1) Micro-USB cable, (1) Owner’s manual
Dimensions: 6.0”x 2.7” x 2.2” (152 X 68 X 57 mm)
Net Weight: 5.2 oz (168g)
Battery Spec: 3.7V/1300mAH
8. LED indicator
9. Microphone pickup
10. Screen
11. Speaker
12. Mode Switch
13. 3.5mm earphone
jack
14. Volume Control
15. Power ON/OFF
16. Micro-USB
recharging port
POWER SAVE FUNCTION
• METRONOME mode: Auto-off if metronome is not used for 3 minutes.
• TUNER mode: Auto-off if there is no signal input for 3 minutes.
• CLOCK mode: Auto-off if no buttons are pressed for 10 seconds (the
backlight will turn off and enter ready mode.)
METRONOME
• Tempo Range: 40-208 BPM
• Beats: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
• Rhythm:
• Metronome “bell” sound
adjustment
• Tap Function
• Earphone: 3.5mm jack, stereo
• Volume Control
TUNER
• Tuning mode: Chromatic
• Tuning range: A0 (27.5Hz)-C8
(4186.00Hz)
• Tuning method: built-in
microphone pick-up
• Reference pitch: 430Hz-450Hz
• Tuning tolerance: +/- 0.5cent
• Tuning indication screen meters
& LED indicators
• Tuning Cent indicator
CLOCK
• 12 hours standard, AM/PM
• Alarm function
PACKAGE CONTENTS
Þ100% charged (full power volume)
Þ67% charged
Þ34% charged
Þ10% charged (low power alarm, the product will turn off in 10 seconds)
ÞRecharging
• Use the included USB cable to connect with your smartphone adapter,
your computer or portable power bank to recharge.
• Power volume indicator:
SEE INSTRUCTIONS FOR EACH FUNCTION ON REVERSE SIDE
“bell” sounds
adjustment

1. Move Mode Switch to METRO/TUNER mode.
2. Press and hold the button to switch between
the Metronome and Tuner Function.
(Make sure the metronome function is on.)
3. Press the button to select tempo (from
40PBM to 208BPM) or press the TAP button to
manually input your own tempo (the unit will take
an average of the inputs and calculate the BPM).
4. Press the button to select beat. (from 0-9).
5. Press the button to select the rhythm.
Rhythm options:
6. Press the button to start the METRONOME.
(The screen indicators will now move to the beat
and LED indicators will flash to tempo and beat
settings. (Press the again to stop metronome.)
7. Once the METRONOME is functioning, press the
button to change the sound of the “bell.” Press
again to cycle through the various “bell” options.
8. Use the volume control switch to adjust the
metronome volume.
9. Optional: Use a 3.5mm gauge headphone to
connect to the metronome. (If headphone jack is
connected, the speaker will be muted.)
Note: if the power switch is turned to the OFF position, all
settings will revert to factory presets
HOW TO USE THE METRONOME
METRONOME
Tempo Range: 40-208 BPM
Beats: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
Rhythm:
Metronome “bell” sound adjustment
Tap Function
Earphone: 3.5mm jack, stereo
Volume Control
HOW TO USE THE TUNER
TUNER
Tuning mode: Chromatic
Tuning range: A0 (27.5Hz)-C8 (4186.00Hz)
Tuning method: built-in microphone pick-up
Reference pitch: 430Hz-450Hz
Tuning tolerance: +/- 0.5cent
Tuning indication screen meters LED indicators
Tuning Cent indicator
1. Move Mode Switch to METRO/TUNER mode.
2. Press and hold the button to switch between
the Metronome and Tuner Function.
(Make sure the tuner function is on.)
3. Press the button to select the reference pitch
(440Hz -standard, range from 430Hz-450Hz)
4. Place the tuner as close to the instrument as
possible to make sure the built-in microphone picks
up the instrument sound. (Ambient noise may
affect tuning accuracy)
5. Tuning process:
• IN TUNE: Note name appears, green LED on the
screen lights up, cent indicator shows +/- 3
cents or less
• FLAT: Red tuning indicators stay left, red LED on
the unit lights up, cent indicator shows in the
negative range
• SHARP: Yellow tuning indicators stay right, red
LED on the unit lights up, cent indicator shows
in the positive range
Note: if the power switch is turned to the OFF position, all
settings will revert to factory presets
CLOCK
12 hours standard, AM/PM
Alarm function
HOW TO USE THE CLOCK
1. Move Mode Switch to CLOCK position.
2. For the first use it is necessary to set the clock. Setting the
alarm is optional.
TIME:
• Press and hold the TAP button for 2 seconds to enter
the time setting mode. The minutes will begin to
flash. Press the button to set the correct
number of minutes.
• Press the TAP button to set hour digit. When hour
digit flashes, press the button to set the right
hour. AM/PM will change as the hours are cycled
through.
• If no input is received, after 5 seconds the clock will
revert to standard mode.
ALARM:
• Press and hold the button to set alarm. The
screen will show a red alarm clock symbol, .
• Press and hold the button for 2 seconds to enter
the alarm setting mode. Once minute digits flash,
press the button to set the minutes.
• Press TAP button, once the hour digits will flash, press
the button, to set the hour. AM/PM will
change as the hours are cycled through.
• All the settings will now be saved automatically.
• When the alarm sounds, press the button to stop
the alarm. Otherwise, the alarm will sound for 5
minute and then turn itself off.
Note: if the power switch is turned to the OFF position, all
settings will revert to factory presets
