KNF LAB RC 900 User manual

KNF 126291-126293 11/14
Translation of original Operating Instructions, Englis
Operating Instructions
Read and observe t ese Operating Instructions!
Rotary Evaporator
with Wireless Remote Control
RC 900
KNF Neuberger AG
Stockenstrasse 6
CH-8362 Balterswil
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.knf.c

Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
Included with the RC 900:
 Rotary evaporator and and terminal (batteries included)
 Glass set, comprised of:
- Vapor tube
- C illed condenser
- Coated collection flask, 500 ml
- Bracket for collection flask
- Evaporation flask, 1000 ml
 Heating bat
 Set of ose fittings
- 1x Hose fitting ID10 (vacuum)
- 2x Hose fittings ID8 (coolant)
- 2x Hose clamps ID8
 Protective cover (optional)
 Refilling valve (optional)
 Coolant valve (optional)
 Protective film for display (optional)
 Mains cable
 Power supply for and terminal
 Operating Instructions
 Abbreviated instructions
 Table of solvents
 CD wit digital Operating Instructions
Transportation protection
T e rotary evaporator's and terminal is secured at t e factory
in order to avoid damage during transportation.
T e transportation protection must be removed before t e
and terminal can be taken out. Refer to C apter 6
Setup and connection

Rotary Evaporator RC 900 Table of Contents
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
Contents Page
1. A out this document 4
1.1. Using t e Operating Instructions 4
1.2. Symbols and markings 4
2. Use 5
2.1. Intended use 5
2.2. Improper use 6
3. Safety 7
4. Technical data 9
4.1. Rotary evaporator 9
4.2. Rotary evaporator's and terminal11
5. Components and functions 12
5.1. Components of t e rotary
evaporator 12
5.2. Rotary evaporator functions 13
5.3. Hand terminal 14
6. Installation and connection 16
6.1. Installation 16
6.2. Connections 26
7. Operation 27
7.1. Initial start-up 27
7.2. Stopping operation 31
8. Operating the rotary evaporator 33
8.1. Hand terminal 33
8.1.1. General functions and displays 33
8.1.2. Operation 36
8.2. Operation wit out and terminal 41
8.3. C anging t e evaporation flask 41
9. Servicing 42
9.1. Servicing sc edule 42
9.2. Cleaning 42
9.2.1. Cleaning t e rotary evaporator 42
9.2.2. Cleaning glass parts 42
9.2.3. Clean seal 43
9.2.4. Clean eating bat 43
9.2.5. Cleaning protective cover
(accessory) 43
9.3. C anging vapor tube 44
9.4. C anging seal 45
9.5. C anging fuses 46
9.6. Inspecting protective conductor 47
9.7. C anging batteries on t e and
terminal 47
10. Trou leshooting 48
11. Spare parts and accessories 53
11.1. Spare parts 53
11.2. Accessories (also see c apter 6)53
11.3. Glass product 54
12. Returns 55
13. Health and safety clearance and
decontamination form 56

About t is document Rotary Evaporator RC 900
4 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
1. A out this document
1.1. Using the Operating Instructions
T e Operating Instructions are an integral part of t e rotary evapo-
rator.
 Carefully read t e Operating Instructions before bringing t e
rotary evaporator into operation.
 Keep t e Operating Instructions readily accessible at all times.
 Pass on t e Operating Instructions to t e next owner.
Rotary evaporators produced for specific customers (model desig-
nations prefixed wit "PJ" or "PM") may ex ibit differences from t e
Operating Instructions.
 W enever using custom rotary evaporators, also observe t e
agreed specifications.
Compliance wit t e Operating Instructions
is essential for safe
and reliable operation of t e rotary evaporator. Failure to
observe t e Operating Instructions may result in damage or
injury.
1.2. Sym ols and markings
Warning
WARNING
T is symbol indicates a potential danger.
It also indicates t e possible consequences of failure
to observe t e warning. T e signal word (e.g. "Warn-
ing") indicates t e level of danger.
 Here you will see actions for avoiding t e dang
er
and potential consequences.
Danger levels
Signal word Meaning Consequences if not observed
DANGER warns of immedi-
ate danger
Consequences include deat or
serious injuries and/or serious
property damage.
WARNING warns of potential
danger
Deat or serious injuries and/or
serious damage to property are
possible.
CAUTION warns of a poten-
tially dangerous
situation
Minor injuries or damage to
property are possible.
Tab. 1
Other information and sym ols
 T is indicates an activity (step) t at must be carried out.
1. T is indicates t e first step of an activity to be carried out. Any
additional steps required are numbered consecutively.
T is symbol indicates important information.
Custom systems

Rotary Evaporator RC 900 Use
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 5
2. Use
2.1. Intended use
T e RC 900 rotary evaporator is designed for use in c emical,
p armaceutical, and biological laboratories. It is intended exclu-
sively for use in separation of solvents (distillation, drying, recov-
ery, extraction, etc.).
Make sure t at t e installation location is dry and t e rotary evapo-
rator is protected against water in t e form of rain, spray, splas es
and drips.
T e rotary evaporator may be used exclusively in indoor areas.
T e rotary evaporator may be used only underneat a fume ood
or properly installed protective cover (accessory).
Owner's responsi ility
Install and operate t e rotary evaporator only under t e operating
parameters and conditions described in C apter 4, Tec nical data.
Protect t e rotary evaporator from moisture.
Ensure t at no azardous materials can enter t e surrounding
environment (including eating and cooling media), even in t e
event of glass breakage, leaks, or loss of cooling.
Ensure t at no azardous materials/reactions can be produced
t roug contact of processed solutions and solvents wit t e
eating and cooling media or t e ambient air. It may be necessary
to operate t e unit only under a suitable fume ood.
W enever t e rotary evaporator is operated outside of a suitable
fume ood (after eliminating t ese sources of danger), t e protec-
tive cover must be used (refer to C apter 11, Spare parts and
accessories, pg. 53).
Before using a substance, investigate its compatibility wit t e
materials used in t e seals and tubing.
Before using a substance, investigate w et er it can be evapo-
rated wit out danger.
Make sure t e tubes for gas and cooling medium are correctly
assigned on t e c illed condenser.
Adequately cool t e c illed condenser at all times.
Laboratory equipment and supplemental components attac ed to
t e rotary evaporator must meet t e specifications provided in
C apter 4.
KNF recommends collection and evaporation flasks from Duran.
Operating parameters
and conditions
Use under a fume ood
Requirements
for processed
substances
C illed condenser
Accessories

Use Rotary Evaporator RC 900
6 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
2.2. Improper use
T e rotary evaporator may not be used in potentially explosive
atmosp eres.
T e rotary evaporator may not be used in a corrosive environment.
T e eating bat of t e rotary evaporator may not be used to warm
food. It serves exclusively to add eat to t e evaporation flask.
Never apply positive pressure to t e rotary evaporator's vacuum
connection.
T e lifting drive may not be blocked or subjected to loads.

Rotary Evaporator RC 900 Safety
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 7
3. Safety
T e rotary evaporator is constructed according to generally recog-
nised rules of tec nology and in accordance wit pertinent occupa-
tional safety and accident prevention regulations. Nevert eless,
potential dangers during use can result in injuries to t e user or
ot ers, or in damage to t e rotary evaporator or ot er property.
Use t e rotary evaporator only in a tec nically flawless condition, in
accordance wit its intended use, wit awareness of safety and
potential azards, and in observance of t e Operating Instructions.
Ensure t at only trained and instructed personnel or specially
trained laboratory personnel work on t e rotary evaporator. T is
applies also to assembly, connection and servicing work.
Make sure t at t e personnel as read and understood t e Operat-
ing Instructions, and in particular t e "Safety" c apter.
Ensure ad erence to all pertinent accident prevention and safety
regulations w en working on and operating t e rotary evaporator.
T e protective clot ing required for safety in t e laboratory must be
worn, i.e. protective glasses, gloves, etc.
Ensure t at personnel c eck before eac use of t e rotary evapo-
rator t at t ey ave t e and terminal associated wit t e rotary
evaporator. T e rotary evaporator is equipped wit a paging func-
tion for t is purpose (see Paging , page 40).
Safety regulations for andling initial substances and t ose t at are
produced in t e process must be observed. T is applies equally to
t e eating and cooling media.
Be aware t at t e rotary evaporator is not designed to be explo-
sion-proof.
Ensure t at t e distillation residue is not explosive.
Make sure t at t e temperature of t e medium is always sufficient-
ly below its ignition temperature in order to avoid ignition or explo-
sion. T is also applies to unusual operating situations.
Consider any external sources of energy, suc as sources of
radiation, t at could additionally eat t e medium.
In case of doubt, consult KNF customer service.
Proper andling of t e initial and resulting substances / eating
and cooling media must be ensured.
Manufacturer regulations must be observed w en disposing of t e
eating and cooling media. Be aware t at t e eating and cooling
media may become contaminated.
Personnel
Working in a
safety-conscious manner
Using t e rig t
and terminal
for t e rotary evaporator
Handling
dangerous media
Handling flammable
media

Safety Rotary Evaporator RC 900
8 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
W en ventilating t e rotary evaporator wit air or inert gas, be sure
to prevent formation of reactive or explosive media. T e maximum
permissible operating pressure of t e c illed condenser is 0.1 bar
rel.
Ensure t at t e evaporation flask rotates t roug out t e entire
eating p ase (even during submersion/lifting) in order to avoid
eating only one side of t e evaporation flask or experiencing a
vaporisation delay.
Ensure t at t e evaporation flask is immersed or lifted only at a low
speed. Increase speed only to t e extent t at no eating medium is
ejected from t e eating bat .
All replacement parts s ould be properly stored and disposed of in
accordance wit t e applicable environmental protection regula-
tions. Ensure ad erence to t e pertinent national and international
regulations. T is especially applies to parts contaminated wit toxic
substances.
T e rotary evaporator complies wit t e safety stipulations of
Directive 2004/108/EC for electromagnetic compatibility, Directive
2006/42/EC for mac ines, Directive 2011/65/EU (RoHS2) and
Directive 1999/5/EC (R&TTE). T e following armonised standards
are fulfilled:
 DIN EN 61010-1
 DIN EN 61010-2-010
 DIN EN 61326-1
T e rotary evaporator complies wit t e following according to
IEC 664:
 overvoltage category II
 contamination level 2
All repairs to t e rotary evaporator must be carried out by t e
responsible KNF Customer Service team.
Housing parts wit voltage-caring parts may be opened by trained
personnel only.
Only use genuine parts from KNF for servicing work.
Ventilating t e
rotary evaporator
Vaporisation delay
Environmental protection
Standards
Customer service and
repairs

Rotary Evaporator RC 900 Tec nical data
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 9
4. Technical data
4.1. Rotary evaporator
Materials for parts contacting the medium
Glass parts Borosilicate glass
Vapor tube seal PTFE compound
Refilling valve's fitting* PP
Fitting seal Silicone
Plug seals PTFE-coated
Coolant line materials
Fittings on condenser PP
Fitting seal Silicone
Connections on tower Nickel-plated brass/galvanized
Internal connection Norprene
®
, PA, stainless steel
Tubing Norprene
®
Vacuum line materials
Fitting on condenser PP
Connections on tower PVDF, stainless steel
Inner connections PTFE, PVDF, stainless steel
Tubing Norprene
®
Pneumatic data
Max. permissible operating
pressure [bar rel]
0.1
Electrical Data
Nominal voltage [V] See type label (+/- 10 %)
Frequency [Hz] 50-60
Heating power [W] 1300
Total power [W] max. 1500
Total operating current [A] See type label
Fuse [A] 2 x 8A delayed at 220-240V
2 x 16A delayed at 100-127V
Protection class IP20
Heating bath
Empty weig t [kg] 1.85
Volume [ml] 5000
Fill quantity [ml] 4000
Heating temperature [°C] 20 - 180
Pull-out lengt [mm] 70
Coolant supply chilled condenser)
Permissible pressure [bar rel] 3
Permissible temperature -15 °C to + 20 °C
Cooled surface [cm
2
] 1230
Tab. 2 1st part) * Accessories

Tec nical data Rotary Evaporator RC 900
10 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
Evaporation flask parameters
Evaporation flask size 50 - 3000 ml
Speed [1/min] 25 - 250
Directional c ange interval [s] 5 - 120
Vertical travel [mm] 150
Lifting speed [mm/s] approx. 38
Angle of inclination [°] 12 - 45
General
Total weig t [kg] 9.1
Dimensions W x D x H [mm]:
- wit out glass set (footprint)
- wit glass set (approx.)
431 x 447 x 464
487 x 447 x 823
Vacuum, coolant, and
refilling connections
GL14
Maximum permissible ambient
relative umidity
80 % for temperatures up to
31 °C, decreasing linearly to
50 % at 40 °C
Maximum altitude of installa-
tion
[m above sea level]
2000
Safety functions
Drive motor fuses Electronic overcurrent protection
Protection against over eating
of eating bat
T ermal protective switc (man-
ual reset)
electronic temperature limitation
electronic switc off at an insuf-
ficient water quantity
Protection during power failure Evaporation flask automatically
lifted from t e eating bat
Protection against glass
breakage
digitally-adjustable stop
Monitoring of protective cover
(accessory)
Hall effect sensor
Tab. 2 2nd part)

Rotary Evaporator RC 900 Tec nical data
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 11
4.2. Rotary evaporator's hand terminal
Dimensions: W x H x D [mm] 91 x 190 x 65
Weig t [kg] 0.5
Operating voltage [V DC] 12
Operating current [A] 1.25
Wireless connection's frequen-
cy band [GHz]
2.4
Wireless range Approx. 50 m wit out obstacles
Approx. 10 m t roug walls
Power supply during wireless
operation
T roug integrated batteries or
included power supply
DC c arging socket
External diameter: 6.3 mm
Inside diameter: 2 mm
Batteries 4 x AA 1.2 V 2300 mA ; quick-
c arge capable; see spare
parts list in C apter 11
Battery internal resistance*
(c arged) [mΩ]
60
Battery service life* Up to 12 ours, depending on
number of entries and data
transmission
C arging time* About 7
Tab. 3 * Applies to standard included batteries
Use only t e original power supply from KNF to operate or
c arge t e and terminal w en removed from t e evaporator.
Several rotary evaporators can be operated simultaneously
using t e associated and terminals wit in t e range of t e
wireless connection.
T e wireless connection between t e and terminal and t e
rotary evaporator is robustly compatible wit mobile telep ones
and Bluetoot devices in t e immediate area.

Components and functions Rotary Evaporator RC 900
12 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
5. Components and functions
5.1. Components of the rotary evaporator
1 Terminal
2 Hand terminal (removable;
signals transmitted wire-
lessly)
3 Collection flask (coated)
4 Hand terminal older for
use in transportation
5 Flask clamp for 3
6 Refilling connection
7 C illed condenser
8 Tension nut for c illed
condenser
9 Flask mec anism
10 Tension nut for vapor tube
11 Flask nut
12 Rotary knob for pivot angle
13 Evaporation flask
14 Tower
15 Heating bat
16 Bottom cover plate
17 Power switc
18 Vacuum line
19 Coolant line
20 Rotary knob for pivot angle
21 USB connection
22 Connection for coolant
valve (accessory)
23 Coolant outlet
24 Coolant inlet
25 Vacuum connection
26 Fuses
27 Mains plug connection
Fig. 1: RC 900 rotary evaporator

Rotary Evaporator RC 900 Components and functions
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 13
T e RC 900 rotary evaporator is designed for distillation and
evaporation of solvents. T e rotary evaporator is operated via t e
and terminal (Fig. 1/2, page 12).
T e solvent t at s all be evaporated is located in t e evaporation
flask (13). T e solvent is made to evaporate t roug t e proper
combination of temperature and vacuum. T e evaporation flask is
immersed into t e eating bat (15), in w ic a eating liquid is
located, typically water or a suitable oil. T e drive (9), continually
rotates t e evaporation flask inside t e eating bat . Once t e
solvent begins to evaporate, it rises t roug t e vapor tube and
into t e c illed condenser (7), w ic is continually cooled wit
cooling water or anot er cooling medium. Here t e vapor is cooled
to t e point w ere it condenses and collects (again in liquid form)
in t e collection flask (3).
T e c illed condenser and collection flask ave a transparent
coating t at protects t em against implosion.
A protective cover (accessory) is placed onto t e eating bat to
protect t e evaporation flask from implosion and to protect against
sprays.
5.2. Rotary evaporator functions
 Evaporation flask
T e evaporation flask's angle of inclination is adjusted via
t e rotary knobs (Fig. 1/12+20). Toget er wit t e ability to
move t e evaporation flask up and down and to displace
t e eating bat , t e rotary evaporator may be adapted to
various s apes and sizes of evaporation flasks.
T e drive (9) brings t e evaporation flask into rotation,
t ereby ac ieving a ig rate of evaporation:
- A more omogeneous distribution of temperature is
ac ieved bot in t e eating bat and in t e evaporation
flask (optimisation of temperature control and eat trans-
fer).
- T e moistened surface inside t e evaporation flask is en-
larged (increases eat transfer and t e boiling surface).
- Formation of a concentration gradient in t e solvent is
avoided.
Additional advantages of rotation include:
- T e danger of evaporation delay is reduced
- No localized over eating, no crust formation
T e and terminal (2) is used to switc t e rotation of t e
evaporation flask on or off and to select t e desired speed (see
C apter 8, Operating the rotary evaporator).
In addition, t e direction of rotation may be c anged at regular
intervals. T e interval at w ic t e direction of rotation c anges
is also adjusted using t e and terminal (see C apter 8, Oper-

Components and functions Rotary Evaporator RC 900
14 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
ating the rotary evaporator). Regularly c anging t e direction
of rotation prevents deposition of salt in t e evaporation flask.
In t e event of a power failure t e evaporation flask is automat-
ically lifted from t e eating bat .
 Heating ath
T e rotary evaporator's eating bat (15) can be broug t
to and eld at a temperature according to t e requirements
of t e application in order to ac ieve optimal distillation.
T e eating bat may be pulled out on guide rails in order
to permit t e use of t e widest range of evaporation flask
sizes (see section Evaporation flasks).
T e specially s aped pouring lip makes it easier to empty
t e eating bat .
5.3. Hand terminal
Assem ly
1 Upper grip
2 Display / Touc screen
3 I/O switc
4 Power supply socket: 12 V
DC
5 Rotating knob for:
 Entering setpoints for:
- eating
- rotation
- directional c ange
interval
- immersion dept
 Fine adjustment of
immersion dept
Fig. 2: RC 900 hand terminal
Function
T e and terminal is used to set t e process parameters used by
t e RC 900 rotary evaporator.
Settings are adjusted on t e and terminal's touc screen (Fig. 2/2)
or wit t e rotary knob (5).
T e wireless and terminal may be removed from its mount on t e
rotary evaporator (observe transportation safeguard Fig. 1/4, page
12) in order to control t e rotary evaporator remotely. T is makes it

Rotary Evaporator RC 900 Components and functions
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 15
convenient to control t e evaporator w ile it is located under a
closed fume ood.
W enever t e and terminal is located in t e mount w ile t e
rotary evaporator is turned on, t e batteries in t e and terminal
will c arge automatically. T e batteries will c arge even if t e and
terminal is switc ed off. Alternatively, t e batteries can be c arged
t roug t e and terminal's included power supply (see mains
socket (4) on t e and terminal).
T e power supply also makes it possible to supply t e and termi-
nal wit electrical power directly from a mains.
A single tone on t e and terminal will indicate w en t e batteries
are nearly ex austed.

Installation and connection Rotary Evaporator RC 900
16 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
6. Installation and connection
 Connect t e rotary evaporator only under t e operating pa-
rameters and conditions described in C apter 4. Tec nical da-
ta (page 9).
 Observe all notices related to t e device's intended use and
safety procedures (see C apter 2 and 3, page 5ff).
WARNING
Damage to t e rotary evaporator may result in
personal injury caused by poisoning or explosion.
Hazardous gases and vapors may be produced
during distillation.
 Air drawn out of t e rotary evaporator must be
safely diverted.
6.1. Installation
T e rotary evaporator may be carried only by t e components
labeled in Fig. 3. Carrying t e rotary evaporator by any spot ot er
t an t e indicated spots may result in damage to t e unit.
Fig. 3: Carrying the rotary evaporator
 Before installation, allow t e rotary evaporator to come to
ambient temperature at t e installation location.
 Make sure t at t e installation location is dry and t e rotary
evaporator is protected against water in t e form of rain, spray,
splas es and drips.
S ipment
Installation location

Rotary Evaporator RC 900 Installation and connection
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 17
 C oose a safe location (flat, stable surface) for t e rotary
evaporator.
 Protect t e rotary evaporator from dust.
 Protect t e rotary evaporator from vibration and impact.
 Attac to t e rotary evaporator only t ose components t at are
designed for t e rotary evaporator's pneumatic data and/or
coolant-supply parameters (see C apter 4, page 9).
T e rotary evaporator's and terminal is secured at t e factory in
order to prevent damage during transportation. T e transportation
safeguard must be disengaged before t e and terminal can be
removed. To do t is, rotate t e knurled knob (Fig. 1/4, page 12) out
until t e and terminal can be removed.
T e transportation safeguard can be screwed back in before
transporting t e rotary evaporator in t e future.
Place t e included eating bat (Fig. 1/15, page 12) onto t e base
connector.
Once in place, t e eating bat can be s ifted along t e axis of
rotation (see C apter 4 Technical data for maximum pull-out
lengt ).
W en installing glass parts, observe an adequate amount of
space above t e rotary evaporator because t e glass structure
may exceed t e dimensions of t e rotary evaporator itself.
Connected
components
Remove transportation safe-
guard
Installing t e
eating bat
Installing t e c illed condenser

Installation and connection Rotary Evaporator RC 900
18 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
T e c illed condenser (Fig. 1/7, page 12) is delivered uninstalled.
Install as follows:
1. Loosen tension nut (10) for c illed condenser until t e c illed
condenser can be inserted.
2. Insert c illed condenser (7).
3. Retig ten tension nut (10) for c illed condenser.
To finis tig tening t e tension nut, grasp t e c illed conden-
ser wit your ot er and and use it as a lever (see Fig. 4).
- - - - Tig ten tension nut
——
Use c illed condenser to
aid in fully tig tening t e
tension nut.
Fig. 4: Fully tightening the tension nut

Rotary Evaporator RC 900 Installation and connection
Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14 19
4. Attac tubing (Fig. 5/1 and 2) or fill t e cold trap wit dry ice.
WARNING
Extreme cold may cause personal injury
T ere is a danger of serious local freezing w en
andling dry ice.
 Observe t e manufacturer's azard notices.
T e oses and connections are color-coded to simplify as-
signment (see Legend in Fig. 5).
Connect t e vacuum lines only to t e left side of t e tower (see
Fig. 5). T e internal connection ere as elevated c emical
resistance (see C apter 4, Technical data).
1 Vacuum - black
2 Coolant inlet - blue
3 Coolant outlet - red
Fig. 5: Attaching lines for coolant and vacuum

Installation and connection Rotary Evaporator RC 900
20 Translation of original Operating Instructions, Englis , KNF 126291-126293 11/14
T e c illed condenser is now fastened to t e rotary evaporator.
In order to ensure a proper seal, retig ten t e tension nut once
more w ile under vacuum.
Requirements:
 Loosen tubing
 Remove collection flask (see below)
1. Loosen tension nut (8) until t e c illed condenser may be
pulled out.
W en loosening t e tension nut, grasp t e c illed condenser
wit your ot er and and
use it as a lever (refer to Fig. 4).
2. Remove c illed condenser (7).
Install t e separately included collection flask (Fig. 1/3, page 12)
using t e included flask clip (Fig. 1/5, page 12).
Requirements:
 Rotary evaporator must be ventilated
WARNING
Potential for personal injury by poisoning
W en opening t e process space, suc as w en
removing t e flasks, residual solvent vapor may
enter t e surrounding atmosp ere.
 Vacuum out any solvent vapors (under fume
ood, for example).
WARNING
Potential for personal injury by azardous materials
T e distillate located in t e collection flask may be a
azardous material.
 Observe all safety regulations and disposal
requirements for t e distillate!
Loosen t e flask clip (Fig. 1/5, page 12) and remove t e collection
flask (Fig. 1/3, page 12). Empty t e collection flask if necessary.
Installing t e collection flask
Removing t e
c illed condenser
Remove collection flask
and empty if necessary
