Knightsbridge OWALL2P Series Instruction Manual

OWALLxxP INSTRUCTIONS_SPREADS.indd 1-3OWALLxxP INSTRUCTIONS_SPREADS.indd 1-3 24/03/2021 11:19:3024/03/2021 11:19:30

INSTALLATION & MAINTENANCE MANUAL
These instructions should be read carefully and retained after installation by the end user for future reference
and maintenance.
These instructions should be used to aid installation of the following product range:
OWALL2xxP
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of
the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
•This product is Class I and must be earthed
•This product is IP54 rated
INSTALLATION
Note - Round cable should be used for the mains supply. The use of flat cable will cause water ingress into the
fitting
•Provide power to the required point of installation. Suitable IP rated junction boxes should be used
where required
•Remove the baseplate from the luminaire by loosening the screws on either side of the base
•Using the baseplate as a template, mark the location for, and drill the fixing holes ensuring not to
infringe with any gas/water pipes or electrical cables
•Feed the mains cable through the rubber grommet to retain IP rating
•Fix the baseplate using the screws and wall plugs provided (see Fig. 1)
Fig. 1
•Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown)
E - Earth (green/yellow) N - Neutral (blue)
•Align the luminaire with the baseplate and refasten the screws
•Insert suitable GU10 lamps
•Switch on and check for correct operation
Note –The photocell switches the light on when the light level drops to below 10-30 lux, and off when the light
level reaches 30-60 lux (these settings are not adjustable). It is sensitive to artificial light as well as natural
daylight.
