INSTALLATION & MAINTENANCE MANUAL
SPIKE4BK
IP
54
230V
50Hz

These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following product:
SPIKE4BK
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for
installation
• This product is Class I and must be earthed
• This product is IP54 rated
• Note - If this luminaire is being used in conjunction with an external PIR or sensor, please
confirm with the manufacturer of the sensors that they are compatible with LED luminaires
• Provide power to the required point of installation (refer to BS7671 for correct cabling
methods), suitable IP rated junction boxes should be used where required
• Choose a position for the luminaire ensuring the ground is suitable to firmly hold the spike
and luminaire in position. Check the ground is not liable to flooding and the spike does not
infringe with any underground pipes or cables
• The body of the product should not rest directly on the ground
• The pre-installed cable supplied is for above-ground use only. Cables that are to be routed
within walls or below ground must be protected by means of suitable conduit or trunking
(see Fig. 1)
• The spike of the luminaire is required to be pushed fully into the ground (see Fig. 2)
Fig. 1

• For wall mounting installation, unscrew the spike from the luminaire. Mark and drill the hole for
the mounting bracket ensuring it does not infringe with electrical cables, water or gas pipes
• If installing outdoors, please ensure an RCD or RCBO is used
• The power source connections should be local and accessible via a suitable IP rated enclosure
• Connect the mains supply, Live (brown), Neutral (blue) and Earth (green/yellow)
• Switch on and check for correct operation
GENERAL
WARNING
The LED lamps fitted in this product are non-replaceable. The unit should be recycled in the correct
manner when it reaches the end of its life. Check local authorities for where facilities exist
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the product
Do not use any source of high pressure washers to maintain or clean this product
This product is not suitable for installation in or near a coastal or marine environment
This product is non-dimmable
This product must be disconnected from the circuit if subjected to any high voltage or insulation
resistance testing. Irreparable damage will occur if this instruction is not followed
80mm
60mm
230mm
160mm
Fig. 2

ML Accessories Limited
LU5 4LT
www.mlaccessories.co.uk DCNOV18_V2
WARRANTY
This product has a warranty of 2 years from date of purchase. Failure to install this product in
accordance with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal
of the batch codes will invalidate the warranty. If this product should fail within its warranty period
it should be returned to the place of purchase for a free of charge replacement. ML Accessories
does not accept responsibility for any installation costs associated with the replacement product.
Your statutory rights are not affected. ML Accessories reserve the right to alter product specification
without prior notice.
