KOCASO M1070 User manual

M1070 - Android 4.1 Tablet PC English
1
Contents
Contents ......................................................................................................................................1
General notices for use................................................................................................................2
Disclaimer....................................................................................................................................2
Box Contents ...............................................................................................................................2
1.0 Product basics .......................................................................................................................3
1.1 Buttons and connections..................................................................................................3
1.2 Start up and shut down....................................................................................................3
2.0 Introduction to Google Android 4.1 ........................................................................................5
2.1 The Desktop.....................................................................................................................5
2.2 The App drawer –right top corner...................................................................................6
2.3 Google Search / Voice search –left top corner...............................................................6
2.4 Navigation icons –bottom left of the screen....................................................................7
2.5 Status information area –right bottom of the screen...................................................... 7
3.0 General operation...................................................................................................................9
3.1 Battery status / Charging your tablet ............................................................................... 9
3.2 Installing Apps..................................................................................................................9
3.3 Administer / remove apps ................................................................................................ 9
3.4 Add an account............................................................................................................... 10
4.0 Basic setup...........................................................................................................................11
4.1 Changing operating language........................................................................................11
4.2 WiFi settings................................................................................................................... 11
4.3 Connecting the tablet to your PC...................................................................................12
5.0 Frequently Asked Questions................................................................................................13
6.0 Statement.............................................................................................................................13

English M1070 - Android 4.1 Tablet PC
2
General notices for use
-This product is a highly advanced electronics device, disassembly, customization or repairs without the
appropriate knowledge and pre-cautions can lead to dangerous situations with chance on damaging the
product and serious injuries.
-Avoid use in extreme conditions such as high and low temperatures, high humidityor moist
environments and aroundmagnetic fields. Also avoid long-time exposure to sunlight.
-Onlyuse bythe manufacturer permitted accessories to avoid damages to the productwith possibly
warrantyloss.
-Please follow the relevant local environmental regulations to deal with obsolete machines and
accessories.
-Use a protective folder to avoid extreme physicalshocks to the device (i.e. ofdropping).
Disclaimer
-The screenshots are for Android reference only. They maybe made on a device with a different
resolution or hardware configuration than yours and therefore can beslightlydifferent thatthe final
product.
-The manufacturer takes no responsibilityfor loss of information or data caused byhardware or software
failure. The user is responsible for performing timelybackups of important data.
-All information and images used in this user manual are provided ‘as is’ and are subject to change
without notice.
-The manufacturer accepts no liabilityfor the information offered in this document.
Box Contents
-Android Tablet PC
-Device charger (DC / 5V–2.5A)
-Instruction manual
-USB Cable
-Headphone (optional)
-MicroSD Card (optional)

M1070 - Android 4.1 Tablet PC English
3
1.0 Product basics
1.1 Buttons and connections
1
Microphone
2
Mini HDMI
3
Reset Webcam
4
Power jack
5
Micro USB
6
Headphone
7
Power
8
Volume +/-
9
Micro SD card reader
1.2 Start up and shut down
To start your device, press and hold the ‘Power button’ until the screen lights up.
To shut down your device, press and hold the ‘Power button’ until the following dialog popup
appears.

English M1070 - Android 4.1 Tablet PC
4

M1070 - Android 4.1 Tablet PC English
5
2.0 Introduction to Google Android 4.1
2.1 The Desktop
The main area of interest will be the desktop itself. Here you will place shortcuts to Apps or
widgets –a visual application that can display real-time information. There may be some pre-
installed icons and widgets on your tablet.
To change the desktop background image of your tablet return to your desktop by pressing
the ‘HOME’ icon. Press and hold an open space on the desktop (don’t press an icon) -
until a popup appears named ‘Select wallpaper from’. In the list may appear multiple options
to select an image or animated image of choice. The option ‘Live Wallpapers’ will show the
pre-installed animated desktop images. Other options such as a ‘Super-HD Player’, ‘Gallery’
or ‘Wallpapers’ allow you to select (widescreen) photos, downloaded images or other images;
depending on the features of that specific application.
To place a widget or app shortcut on the desktop, touch and hold the icon until the App
drawer fades and the desktop appears. Move your finger to the location where you want to
place the icon and release your touch to place the icon.
To move or delete icons and widgets from your desktop, touch and hold the icon until a grid
appears. Move the icon to the new location or drag it to the ‘Remove’ bar on the top of the
screen to remove it. Releasing the touch screen will confirm your action.

English M1070 - Android 4.1 Tablet PC
6
2.2 The App drawer –right top corner
Press the icon in the top right of the screen to open the App drawer. Here you have
access to two tabs; ‘APPS’ and ‘WIDGETS’. The ‘APPS’ tab displays all applications that are
available on the tablet. The ‘WIDGET’ tablet contains the optional widgets that can be added
to the desktop.
To place a widget or app shortcut on the desktop, touch and hold the icon until the App
drawer fades and the desktop appears. Move your finger to the location where you want to
place the icon and release your touch to place the icon.
When using apps or other parts of the operating system you often will see the ‘Extra options’
icon .
Pressing this icon will open a secondary menu with more options. Functions like opening an
advanced settings menu, switching to a different account or refreshing the displayed
information are often ‘hidden’ behind this icon.
2.3 Google Search / Voice search –left top corner
By clicking the ‘Google search’ / microphone button you can quickly type or speak keywords
of your search. The search application will automatically determine whether the keyword(s)
apply to an application or a web search. In the latter case a web browser will be opened and
the results of your query will be displayed on the Google search engine.

M1070 - Android 4.1 Tablet PC English
7
Note that both the ‘Google search’ function as well as the ‘Voice search’ requires the tablet to
have access to the internet (by WiFi).
2.4 Navigation icons –bottom left of the screen
On the left side you will find three icons: use the navigation icons ‘HOME’ or ‘RETURN’
to close the App drawer and return to your desktop. The ‘RECENT ACTIVITY’ icon
will show an overview of the active and recently opened applications. Click on the small
displayed preview to open that application.
2.5 Status information area –right bottom of the screen
The bottom icon bar will show the some system information (i.e. ) in the bottom
right corner. The contents of this area can change if installed applications place additional
information here. Pressing it will open a small overlay menu displaying the date/time
information, the tablet’s current network status, the battery status and a shortcut icon to
another quick menu where some things like ‘Airplane mode’, ‘Wifi On/Off’, the screen

English M1070 - Android 4.1 Tablet PC
8
brightness and other options can be set or toggled. Also this quick menu contains a shortcut
to the ‘Settings’ menu. Simply clicking elsewhere on the screen will close this menu.

M1070 - Android 4.1 Tablet PC English
9
3.0 General operation
3.1 Battery status / Charging your tablet
The current battery status will be always displayed in the lower right of the screen in the
system information bar. The battery icon will change accordingly to the battery status.
When connected to the DC charger, the status area on the bottom bar will display the
charging icon. Note the lightning symbol inside the battery icon.
3.2 Installing Apps
You can install your own Apps by opening the Apps shop. This button can be found in the
‘App drawer’. The Apps shop is located on the top right of the screen. Note that not all
applications may function properly for your tablet. Some are made especially for small screen
devices such as phones.
3.3 Administer / remove apps
The ‘Apps’ item in the ‘Settings’ menu will display an overview of the installed apps.
There are four tabs available which filter the displayed app list. Select an app to view its
detailed information. In the detailed information you also have the options ‘Force Stop’,
‘Uninstall’, ‘Clear data’ and ‘Move to SD card’. Moving apps to your SD card can save you
some internal storage memory on the tablet.
The ‘Clear cache’ and ‘Clear defaults’ can be used when you are experiencing issues with a
specific app. Clearing cached information and (possible wrong) default settings may solve
the problem. Clearing this information will also wipe any stored login information. i.e. clearing
the cache of your social media app will also force you to re-login afterwards.
Apps may also be removed in the apps content page of the market / shop application.

English M1070 - Android 4.1 Tablet PC
10
3.4 Add an account
The best way to fully make use of your Android tablet is by linking your Google / Gmail
account to your device. Open the ‘Settings’ menu and choose the ‘Accounts & sync’ item.
Without any added accounts the right pane will display nothing. Instead select the option
‘Add account’ in the top right corner. To add a Google / Gmail account please select ‘Google’
in the pop-up and follow the instructions on the screen. After entering your Google username
and password you have the option to automatically back-up your apps, settings (i.e.
bookmarks and WiFi passwords) and other data.
You can also add a POP3, IMAP or Exchange email account by selecting ‘Email’. The pop-
up option ‘Corporate’ will setup a ‘Microsoft Exchange’ link.
Your system or network administrator can supply you with the server information and login
credentials. Follow the steps displayed on-screen to complete the account linking process.
After you successfully linked your account(s) with the tablet you can toggle the automatic
synchronisation on and off by using the switch next to the ‘Add account’ option.

M1070 - Android 4.1 Tablet PC English
11
4.0 Basic setup
4.1 Changing operating language
Press the icon in the top right of the screen to open the App drawer. Select the ‘Settings’
option to open the Android settings menu.
When selecting the option ‘Language & input’ the contents will be displayed in the right
pane. Now open the option ‘Language’ and choose a language for your tablet to operate in.
This pane also displays the keyboard settings which you can customize, enable or disable.
4.2 WiFi settings
Press the icon in the top right of the screen to open the App drawer. Select the ‘Settings’
option to open the Android settings menu. When selecting the option ‘WiFi’ the contents
will be displayed in the right pane. The switch allows you to quickly toggle WiFi on
and off.
In the ‘WiFi’ content panel you can view the formerly used WiFi networks and the WiFi
networks that have been detected by the tablet. To research for new available networks;
please press ‘SCAN’ located in the right top corner. The option ‘ADD NETWORK’ allows you
to add a network by manually inputting the SSID network and security method.
Whether manually added or automatically detected, you may need to fill in a password to be
accepted on the network. Please contact your system or network administrator for the correct
information.
Advanced network settings can be found by clicking the options icon .

English M1070 - Android 4.1 Tablet PC
12
4.3 Connecting the tablet to your PC
When connecting the tablet to your PC through USB, no drivers are needed to access the
tablet’s internal memory or inserted microSD card. However, you do need to confirm the USB
connection: click the notification area in the system information bar at the bottom of the
screen . Now select the option ‘Select to copy files to/from your computer’.
If your PC still asks for the device drivers, it may be that the tablet is Android debugging
mode. To change this, please go to the ‘Settings’ menu and open the ‘Developers
options’ item. In the right pane you can (un)check ‘USB debugging’.

M1070 - Android 4.1 Tablet PC English
13
5.0 Frequently Asked Questions
1) Is there a software update available for mytablet?
All tablet firm wares are posted on http:// www.kocaso.com
2) I downloaded [app name] and now it doesn’t work (properly)?
Android software was initially developed for mobile phones and some have no
support for Android devices with larger screens. Try to update the software or find a
compatible alternative app. This incompatibility also sometimes occurs with software
written for previous Android versions.
3) How can I manuallyinstall an APK file?
By default, it is not possible to manually install APK files. To enable this you have to
enable the setting ‘Unknown sources’. This can be found in the settings menu ->
Security.
4) Mybatteryis onlylasting xx hours!
The operating time of the tablet on one battery load depends very much on the
specific tasks that is has to perform.WiFi, Bluetooth and other wireless
communication technologies are known to consume a lot of energy. Also CPU
intensive applications such as games and HD video clips can use up the energy of
the battery fast.
To maximize the duration of your battery, you can optimize the following settings:
- Choose a low or dynamic screen brightness
- A short press on the power button will directly place the tablet in standby mode
- Download an ‘App killer’ to clear the memory from previous started apps
- Disable Wireless devices when not using them
- Remove USB devices (these use power as well)
- Avoid use/charging extremely hot or cold environments
5) Can the tablet charge throughUSB?
Yes, however it will charge quite slow due to the limited power the USB port (500mAh)
can supply. The charger can supply up to 2.5A and will charge much faster.
6.0 Statement
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and

English M1070 - Android 4.1 Tablet PC
14
used in accordance with the instructions, maycause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TVtechnician for help.
To assure continued compliance, any changes or modifications not expressly approved by
the party Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to computer or
peripheral devices).
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can
be used in portable exposure condition without restriction.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment.
