KOCOM KCC-D400 User manual

Mini Dome Color Camera
Monitor screen cant
be turned on
Images on monitor
screen isnt clear and
image quality isnt
good
Product Name
Model Name
Purchase Date
Terms of Warranty
Selling Agent Name
Selling Agent Address
1. Please pay great attention not to drop or give a strong impact to the camera when
installing, because it is made up of very elaborate components for reproduce of
clear image with high resolution.
2. Please avoid installing the camera at place on which sunlight directly shine lest
camera lens be exposed to direct ray of sunlight.
3. Please avoid installing the camera at place shake or sway frequently takes place.
4. Do not forcibly pull out cables. It may cause snapping of cables.
5. Do not open the case of camera even when camera is out of order.
Bring a camera to the nearest A/S center for repair.
6. Carefully install the camera to avoid water infiltration into it. In water infiltration,
please bring the camera to the nearest A/S center or selling agent for repair.
7. Temperature at installation place shall be within the range specified in product
specification.
8. When mechanical or functional troubles take place, first of all, cut off power
supply and then bring the camera to the nearest A/S center.
Continuous use even in troubles may cause more serious damages to the camera.
9. Before installing the camera, please check whether power supply is cut off and
grounding is carried out.
 Check power connection is correctly made.
(DC12V / 300mA Adapter supplies power).
 Check wiring is correctly performed.
 Check lens focus is correctly set.
 When a stained part is seen on monitor screen after
installation, clean up lens focus part of dome camera
with soft cloth to remove a stain.
Trouble Check Items
 Product design and specification subject to change or modification
for product enhancement without notice in advance.
Warranty
Warranty Card
Precautions in Installation
Installation
Please check before A/S request
www.kocom.co.kr e-mail:[email protected]
KOCOM Warranties the original purchaser of this product
as follows.
1) This product is produced under strict quality control and inspection procedures.
2) If this product breaks down during proper use as a result of product defect, KOCOM
will repair it within one year from date of purchase free of charge.
3) The following cases will be subject to charge, even during warranty period:
a. Breakdown during transport, or through careless treatment, by consumer.
b. Breakdown cause by unauthorized repair, or system modification.
c. Breakdown caused by natural disaster or power disorder.
KCC-D400 03.07
To receive after-Sale service, have the following ready when you
contact our branches
1. Name of the product
2. Model number of the product
3. The area of problem
4. Phone number and address at which you can be contacted.
KCC-D400
User’s Guide
 This manual is based on the date as shown in the right and specifications
are subject to change without notice for quality improvement.
1. Pull out power and video cables
into installation place.
2. Attach mount angle on ceiling
using screws.
3. Fix camera on mount angle by
using screw lockup part on the
bottom side of camera.
4. Set up-down and left-right angles
of camera by unloosening screws.
After setting camera angles, fix
the camera by tightening up screws.
5. Put a dome cover.
6. Fix dome cover with cover ring.
Please be careful for dome cover
not to block camera lens.
7. After installing camera, connect it to
monitor and test real images on
monitor screen.
All manuals and user guides at all-guides.com
all-guides.com

DC 12V 1V
Max 1.5W(150mA)
-10C+50C
(recommended temperature;0C+40C)
1/3, 410K pixels (N) 470K pixels (P)
0.45
VBS 1.0V p-p Composite 75
0.3 Lux at F1.2 (30IRE)
Internal Synchronous Method
50dB
480 TV Lines or over
ATW / AWB
Fixed Focus Lens 92/ Focal Length 3.6mm F2.0
F2.0
1/60~1/120,000 Sec
RCA Connector
RCA Connector
5,5 JACK
92
0~90(manual)
158g(excluding Adapter)
86(W) x 67mm(H)
83
KCC-D400
Front Side
Dome
Lens
Cover ring C.Mic
Audio
Base
Screw hole
Video
GND
GND
DC 12V
(-)
(+)
Rear Side
Power Supply
Current(Input) Consumption
Operation Temperature
Guaranteed
CCD (Charge-Coupled Device)
Gamma Correction
Image Output Signal
Minimum Illumination
Synchronous Method
S/N Rate
Resolution
White Balance
Lens
ESC
Video Output Terminal
Audio Output Terminal
Power Input Terminal
Angle of View (Diagonal View)
Movable Angle (Up-Down)
Weight
Dimension
Dome
Model No.
unit : mm
67
86
83
18.2
1. Simple Components
This color dome camera is composed of single PCB on which various
devices are intensified in a optimal state. It also has IRIS function
built-in to adjust brightness automatically.
2. High Resolution and High Image Quality
This color dome camera has high resolution over 480TV lines
(410,000pixels[N], 470,000pixels[P]) and thus realizes clearer images
of high quality.
3. Compact Size and Sensitive Operation in Low Illumination
This color dome camera is miniaturized by optimally composing
various devices and can detect a subject clearly and sensitively even in
low illumination.
4. Backlight and Compensation Function
This color dome camera has backlight correction and enhancement
function within itself. Through these functions, it removes blurring of
images even in lighter places and thus realizes clearer images of a
subject on screen.
5. Graceful Dome-Type Design and Easy Control of Lens
Graceful dome-type exterior of this camera is well matched to any
environments, which makes a difference from other cameras already
marketed. Users can adjust lens angles freely for all directions (up-
down and left-right) according to their own environment.
Components Included in Product Package
Product Features Name of Each Product Part
Product Specification
Elevation of Product / Front View of Product
Camera
Screws
 Product design and specification subject to change or modification
for product enhancement without notice in advance.
User Manual
User Manual
