Kodak PIXPRO SP360 4K User manual

Ver. 1.1
User Manual
PIXPRO SP360 4K
(Smart Device Version)
For
KODAK PIXPRO SP360 4K Action Cam

1
Before You Start
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
Company Website: http://kodakpixpro.com
About this Manual
JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be reproduced, transmitted, transcribed,
stored in a retrieval system or translated into any language or computer language, in any form, by any means, without the prior written
permission of JK Imaging Ltd..
All trademarks mentioned in this manual are used for identification purposes only and are properties of their respective owners.
This manual will instruct you on how to operate the PIXPRO SP360 4K. JK Imaging Ltd. has tried its utmost to ensure the correctness of
the user manual contents, but reserves the right to modify as necessary.
Throughout this manual, the following symbols are used to help you locate information quickly and easily:
Indicates useful information.
Indicates long pressing a certain point.
Indicates tap a certain point.

2
Matters needing attention
Your smart device operating system version needs to be iOS 7 or higher, or Android 4.3 or higher. iPad mini1 / iPad 2 / iPhone 4s and
earlier models (any system versions) do not support this App.
Please do not use in places having high intensity magnetic field, electrostatic and electric wave interference (for example near a
microwave oven), which may cause failure in receiving signals.
Please do not use Wi-Fi or NFC connection functionality on a plane.
When using the Wi-Fi or NFC connection, the camera and the smart device can only be connected one to one, please keep the camera
within 10 meters (32.8 feet) without signal shielding interference.
When the smart device judges the system to be out of memory, the App will not be able to run normally. Please clean up the memory of
the smart device.
We will update the App from time to time. Some new features require you to synchronously update the firmware version of the camera,
in order to ensure the stability of the system. Please note for the prompt on the App.

3
Contents
Before You Start.......................................................................................................................................... 1
Contents....................................................................................................................................................... 3
Connecting the Camera with the Smart Device .................................................................................. 6
Download and Install App .................................................................................................................................................................................................6
Establish a Connection .......................................................................................................................................................................................................7
Wi-Fi Connections (iOS System and Android System).....................................................................................................................................7
NFC Connections (Android System).....................................................................................................................................................................7
Operation Methods ................................................................................................................................... 9
Position Service Function ...................................................................................................................................................................................................9
Remote Viewfinder..............................................................................................................................................................................................................9
Remote Viewfinder Interface..................................................................................................................................................................................9
Parameter Settings...................................................................................................................................................................................................11
Shooting Mode ...............................................................................................................................................................................................11
Unfold Mode ..................................................................................................................................................................................................13

4
View Mode .....................................................................................................................................................................................................14
Field Of View..................................................................................................................................................................................................15
Level Sensor ...................................................................................................................................................................................................16
EV settings .....................................................................................................................................................................................................16
White Balance ...............................................................................................................................................................................................17
Menu................................................................................................................................................................................................................18
Shooting Method.....................................................................................................................................................................................................26
Shooting..........................................................................................................................................................................................................26
Video Recording ............................................................................................................................................................................................27
Playback...............................................................................................................................................................................................................................28
Switching of the Remote Viewfinder Mode and the Playback Mode...........................................................................................................28
Switching Camera and Smart Device Index Playback .....................................................................................................................................29
Introduction of the Icons in the Playback Mode...............................................................................................................................................30
Single Playback..............................................................................................................................................................................................30
Index Playback...............................................................................................................................................................................................31
Description of the Functions in the Playback Mode ........................................................................................................................................32
Gestures in the Playback Mode .................................................................................................................................................................32
Rotate (Smart device single playback mode).................................................................................................................................32

5
Select One or More File(s) (Camera and Smart device index playback mode)..............................................................................33
Download (Camera Single playback and index playback mode)...............................................................................................35
Share ........................................................................................................................................................................................................37
Delete ......................................................................................................................................................................................................38
Play the Video (Camera and Smart device single playback mode)...........................................................................................40
Menu (Camera and Smart device index playback mode) ...........................................................................................................41

6
Connecting the Camera with the Smart Device
Download and Install App
Please download App installation package (App name: PIXPRO SP360 4K) to your smart device from the path below and install it.
Android system
For Android devices, search and download the App “PIXPRO SP360 4K” in Google play, and install it following the instructions on
the interface.
iOS system
For Apple devices, search and download the App “PIXPRO SP360 4K” in App store, and install it following the instructions on the
interface.
After successful installation, this icon will appear on the smart device screen.
https://play.google.com/store/apps/details?id=com.jkimaging.pixproremoteviewer
https://itunes.apple.com/us/app/pixpro-remote-viewer/id833154167?mt=8

7
Establish a Connection
Wi-Fi Connections (iOS System and Android System)
1. Camera: Check SSID (PIXPRO-SP360-4K_XXXX) and password (initial password: 12345678) indicated on the label in the
battery compartment of the camera. In the main interface, press the button to switch to Wi-Fi mode.
2. Smart Device: Enable Wi-Fi mode, it will automatically search the nearby Wi-Fi hotspots. Select the camera’s SSID (PIXPRO-
SP360-4K_XXXX) and input the password.
To optimize Wi-Fi performance, please close other unnecessary programs running on the smart device.
For an Android system smart device, you can directly tap the App icon to enter the “Select connecting device” screen.
Select the SSID name of the camera to be connected, enter an eight-digit password, and tap “Connect”.
NFC Connections (Android System)
1. Enable NFC mode on your smart device.
2. Use your smart device to slightly touch the NFC mark on the camera; if the smart device has a prompt tone or vibration, it means
the connection is successful.
3. The App will open automatically on your smart device.
The NFC feature will only be available when your smart device's screen is unlocked.
1
2

8
If connection fails, tap to try to reconnect.
Connection Failed!
XXXXXXXXXXXXXXXXXXXX
•XXXXXXXXXXXXXXXXX
•XXXXXXXXXXXX
•XXXXXXXXXXX
•XXXXXXXXXXXXXXXXX
•XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXX
When it is unnecessary to connect to the camera or unable to connect the camera, tap the icon on the screen of the smart
device to perform related operations under the playback mode of the smart device.

9
Operation Methods
Position Service Function
When connected successfully, you can tap the App icon ( ) to start it. Enable the GPS function on the smart device by following the
prompts on the interface, PIXPRO SP360 4K can record GPS location on picture files. This function is not available for video files.
Remote Viewfinder
Remote Viewfinder Interface
On the Remote Viewfinder interface, tap , EV value and White balance icons to hide, and tap to restore display.
01:27:26 01:27:26 01:27:26
1
