KODAK Mini HD Video Camera
Extended user guide
Model Zm2
www.kodak.com
For interactive tutorials:
www.kodak.com/go/howto
For help with your camera:
www.kodak.com/go/support

Eastman Kodak Company
Rochester, New York 14650
© Kodak, 2010
All screen images are simulated.
Kodak is a trademark of Eastman Kodak Company.
MICROSD and MICROSDHC are trademarks of the SD Card Association.
4H7258_en

Product features
www.kodak.com/go/support i
Front view, Bottom view
Speaker
Lens
USB
USB
release
Reset
button
Card
Microphone

ii www.kodak.com/go/support
Product features
Back view, Closing the door
• Scroll
• Digital Zoom + –
• Adjust volume
during video
playback.
Power
Menu OK, Record, Shutter
button
LCD
Door
latch
Door
MICRO
SD/SDHC
Card
slot
Battery (not
user-replaceable)
USB
Scroll Mode (Video/Picture)
Strap post
USB
release
Important:
To prevent breakage,
push at a 45-degree angle.

Product features
www.kodak.com/go/support iii
Understanding the status icons
Recording
Capturemode
Elapsedtime Recording
Cardinserted
Zoom level
Batterylevel
Elapsedtime
Volume level
Batterylevel
Playback

iv www.kodak.com/go/support
Table of contents 1
1 Setting up your camera .........................................................................1
Charging the battery (1 – 2 hours).................................................................1
Inserting a MICROSD or MICROSDHC Card....................................................2
Connecting the strap.....................................................................................3
Turning on the camera ..................................................................................4
Setting the date/time.....................................................................................4
2 Using your camera ................................................................................5
Taking videos and pictures ............................................................................5
Reviewing, deleting pictures and videos.........................................................6
Changing settings .........................................................................................7
Transferring, editing, sharing online...............................................................8
3 Getting help ..........................................................................................9
Troubleshooting............................................................................................9
Getting help on the Web.............................................................................11
4 Appendix .............................................................................................12
Specifications..............................................................................................12
Safety .........................................................................................................13
Care and maintenance ................................................................................14
Limited warranty .........................................................................................15
Regulatory compliance ................................................................................16

www.kodak.com/go/support 1
1Setting up your camera
Charging the battery (1 – 2 hours)
Charge the battery when necessary. Turn off the camera, first.
Close the door properly See page ii
Check battery level See the battery icon on the LCD
Learn more about USB charging www.kodak.com/go/USBcharging
Purchase battery charging accessories www.kodak.com/go/accessories
2
1
3
4
To retract the USB, slide the USB release to
the right and push in the USB until it locks.
Slide the USB release to the right.
If necessary, gently pull out the USB until it locks.
Make sure the computer is turned on and
not in sleep, standby, or hibernate mode.

2www.kodak.com/go/support
Setting up your camera
Inserting a MICROSD or MICROSDHC Card
Your camera has limited internal memory—good for a few practice videos/pictures.
Maximum supported card size is 16 GB.
NOTE: The included MICROSD Card is already inserted.
CAUTION:
A card can only be inserted one way; forcing it may cause damage.
Inserting or removing a card while the camera is on may damage the
video/pictures, the card, or the camera.
Close the door properly See page ii
Purchase accessories www.kodak.com/go/Zm2accessories
1Turn off the camera.
2Insert the card until
it clicks and locks
into place.
To remove the card,
push and release it,
then pull it out.
NOTE: Avoid touching the
card’s metal contacts.
To clean the contacts, use a dry
cotton swab or a lint-free cloth.
Metal
contacts
face up.

Setting up your camera
www.kodak.com/go/support 3
Connecting the strap

4www.kodak.com/go/support
Setting up your camera
Turning on the camera
Setting the date/time
Change date/time later see page 7
OK
to change current field.
for previous/next field.
OK to accept.
At the prompt, press OK.

www.kodak.com/go/support 5
2Using your camera
Taking videos and pictures
to choose Picture
Take
videos
Press the OK button to start/stop recording.
Take
pictures
Press
Press the OK button to take a picture.
2
1
Digitally
zoom
Press
to choose a different recording mode.)(Press
.
to zoom in and out.

6www.kodak.com/go/support
Using your camera
Reviewing, deleting pictures and videos
Press the Menu button
Press the Menu button
to highlight Review , then press OK.
Review
pictures,
videos
Delete
pictures,
videos
• Press to scroll through pictures/videos.
• Press OK to play a video or zoom a picture.
Press
to navigate a zoomed picture.
2
1
2
• Press
1
Press
Menu
Press Menu to return to recording mode.
Press Menu to return to recording mode.
Press to highlight Delete
3
Follow the prompts to delete the picture/video.
Press to scroll through pictures/videos.
OK
to highlight Review , then press OK.
, then press OK.
.
.
• Press to adjust volume during playback.

Using your camera
www.kodak.com/go/support 7
Changing settings
Change
settings
Press to change a setting, then press OK.
2
1
to highlight a setting,
Press
then press OK.
3
Press the Menu button
Press Menu to return to recording mode.
Menu
OK
.
Review Date/Time Brightness
Sound Format
Card
Information

8www.kodak.com/go/support
Using your camera
Transferring, editing, sharing online
1Turn on the camera, then connect it.
2If this is the first time you’ve connected to this WINDOWS OS-based computer,
you’re prompted to install ARCSOFT MEDIAIMPRESSION SE for KODAK Software.
You can then transfer and share videos and pictures.
MAC OS—Videos and pictures can be used with the APPLE iLIFE suite of products.
WINDOWS VISTA/XP—Follow the prompts.
WINDOWS 7—Choose Open Folder To View Files.
Launch MI.exe, then click Yes on the User Account Control window.
Close the door properly See page ii
Get ArcSoft product support www.arcsoft.com/support
Slide the USB release to the right.
Pull the USB out until it locks. To retract the USB, slide the
USB release to the right and
push the USB in until it locks.

www.kodak.com/go/support 9
3Getting help
Troubleshooting
Icon Solution
■Low battery. Charge the battery.
■Corrupt or unusable file(s). Transfer videos/pictures to your computer, then
format the card or internal memory.
■Internal memory is full. Transfer videos/pictures to your computer, or use a
MICROSD/SDHC Card to take more videos/pictures.
■Card is full. Transfer videos/pictures to your computer or use another card.
■Unrecognized file. Transfer videos/pictures to your computer.
■An error has occurred. Transfer videos/pictures to your computer, then format
the card.

10 www.kodak.com/go/support
Getting help
NOTE: If problems persist, go to www.kodak.com/go/support and click Step-by-Step Solutions & Repair.
Problem Solution
Camera will not turn on. ■Ensure that the battery is charged.
■Ensure the camera is clean and dry. (If it’s wet inside, let it dry
for 24 hours.)
Videos are choppy or
jumpy when played on a
computer.
■Use ARCSOFT MEDIAIMPRESSION SE for KODAK Software for
video playback (see page 8).
■Ensure that the computer system requirements are met. Go to
www.arcsoft.com/support.
Videos are blurry. ■Ensure that the lens is clean.
■Ensure that the subject is at least 1 m (3.3 ft) from the lens.
Problems with ARCSOFT
MEDIAIMPRESSION SE for
KODAK Software.
■Go to www.arcsoft.com/support. (For other applications, go
to their support sites.)

Getting help
www.kodak.com/go/support 11
Getting help on the Web
Get support for your product (FAQs,
troubleshooting information, etc.)
www.kodak.com/go/Zm2support
See step-by-step solutions and repair information www.kodak.com/go/stepbystep
Purchase camera accessories www.kodak.com/go/Zm2accessories
Download the latest camera firmware and software www.kodak.com/go/Zm2downloads
See online demonstrations of your camera www.kodak.com/go/howto
Register your camera www.kodak.com/go/register
Chat, email, write, or phone Kodak
(Chat not available in all languages.)
www.kodak.com/go/contact
Get information on ARCSOFT Software www.arcsoft.com/support

12 www.kodak.com/go/support
4Appendix
Specifications
Image Sensor—1/4-inch CMOS
Lens—f/2.8; 35 mm equivalent: 39 mm
Zoom—3X digital
LCD—4.6 cm (1.8 in.); 61.4K pixels
Image Storage—128 MB internal memory (approximately 64 MB available for
image storage. 1 MB equals one million bytes); optional MICROSD/SDHC Card
(The SD logo is a trademark of the SD Card Association.) Maximum supported
size: 16 GB MICROSD/SDHC.
Focusing System—Fixed
Focus Range—50 cm (1.6 ft)–infinity
White Balance—Auto
Exposure—Auto
File Format—■Video: .AVI Motion JPEG; 1280 x 720 @ 24 fps and
640 x 480 @ 30 fps
■Audio: PCM, 16 KHz
■Still: JPEG/EXIF V2.21; 922 KP (1280 x 720)
Shutter Speed—Auto
Microphone—Mono
Speaker—Yes
I/O Interface—USB 2.0 (high speed)
Tripod Mount—No

Appendix
www.kodak.com/go/support 13
Power—Internal, rechargeable Li-Ion battery; in-camera charging via USB connector
Battery life—Approximately one hour
Waterproof capability—Conforms to IEC60529 IPX8, up to 3 meters (9.8 ft)
Dust resistance—Conforms to IEC60529 IP6X
Size—9.5 x 85 x 56 mm (0.4 x 3.3 x 2.2 in.)
Weight—70 g (2.5 oz) with battery, card
Operating temperature—0–40°C (32–104°F); do not expose camera to higher
temperatures.
Safety
CAUTION:
Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. KODAK AC
Adapters and battery chargers are intended for indoor use only. The
use of controls, adjustments, or procedures other than those specified
herein may result in exposure to shock and/or electrical or mechanical
hazards. If the LCD breaks, do not touch the glass or liquid. Contact
Kodak customer support.
■The use of an accessory that is not recommended by Kodak may cause fire, electric
shock, or injury. For approved accessories, go to
www.kodak.com/go/Zm2accessories.
■Use only a USB-certified computer equipped with a current-limiting motherboard.
Contact your computer manufacturer if you have questions.
■In the unlikely event that battery fluid leaks onto your skin, wash immediately with
water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.

14 www.kodak.com/go/support
Appendix
■Go to www.kodak.com/go/reach for information about the presence of substances
included on the candidate list according to article 59(1) of Regulation (EC) No.
1907/2006 (REACH).
■If using this product in an airplane, observe all instructions of the airline.
■For more information, go to www.kodak.com/go/batteries.
Care and maintenance
■Before inserting or removing a card, make sure your hands, the camera, and the
card are completely dry.
■If water has entered the camera, remove the card. Allow all components to air-dry
for at least 24 hours before using the camera.
■Wipe off dirt or sand from the door seals—debris could compromise the seal and
cause a leak in water.
■Do not subject the camera to temperatures lower than 0 (32°F) or higher than
40°C (104°F) for an extended time—the integrity of the seals may be
compromised. Wait until camera reaches operating temperatures before using.
■Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,
lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.
■Service agreements may be available in your country. Contact a dealer of KODAK
Products for more information.
■For camera disposal or recycling information, contact your local authorities. In the
US, go to the Electronics Industry Alliance Web site at www.eiae.org or Kodak at
www.kodak.com/go/support.
