Kodak 1500 User manual

8G7939-01
KODAK 1500 Intraoral Camera
User’s Guide

Notice
©Carestream Health, Inc., 2009. No part of this publication may be reproduced,
stored in a retrieval system, translated to another language, or transmitted in any form
by any means, electronic, mechanical, photocopied, recorded, or otherwise, without
prior written permission.
The information in this document is subject to change. Neither Carestream Health,
Inc. nor any of its subsidiaries shall be liable for errors contained herein or for
incidental damages in conjunction with the furnishing, performance, or use of this
material.
Carestream is a trademark of Carestream Health, Inc.
The Kodak trademark and trade dress are used under license from Kodak.
All other trademarks and registered trademarks are the property of their respective
holders.
US Federal law restricts this device to sale by or on the order of a dentist.
The Kodak 1500 intraoral camera is also marketed and sold as the STV Pro +
intraoral camera.
Manual Name: KODAK 1500 Intraoral Camera User’s Guide
Part Number: 8G7939
Revision Number: 01
Print Date: August 2009
Authorized Representative:
Carestream Health France
LES MERCURIALES
40. rue Jean Jaures
93176 BAGNOLET CEDEX
France
Handpiece:
FCC ID: U72KODAK1500H
IC: 7027A-KODAK1500
Docking Station
FCC ID: U72KODAK1500
IC: 7027A-KODAK 1500

KODAK 1500 Intraoral Camera User’s Guide (8G7939) iii
Contents
About This Guide
Chapter 1
KODAK 1500
Intraoral Camera
Overview
Camera Components . . . . . . . 1
Wireless Camera . . . . . . . . 1
Wired Camera . . . . . . . . . 3
Camera Holder Components . . . 4
Docking Station Components . . . 4
Charge Station Components . . . 7
System Components . . . . . . . 8
Chapter 2
Acquisition Module
Overview
Computer System Requirements . .11
General Software Overview . . . .11
KODAK Dental Imaging
Software . . . . . . . . . . . .11
KODAK Acquisition Module. . .12
Capture Window . . . . . .12
Settings . . . . . . . . . .13
Review Window . . . . . . .14
Image Processing Toolbar . .15
Chapter 3
Getting Started
Setting Up the KODAK 1500 Intraoral
Camera . . . . . . . . . . . . . .17
Inserting the Battery into a
Wireless Camera . . . . . . . .17
Inserting the Cable into a
Wired Camera . . . . . . . . .18
Setting up the Camera Holder . . .18
Setting up the Docking Station . .20
Connecting the Docking
Station to a Computer . . . . .20
Connecting the Docking
Station to a Video Monitor. . . .21
Status Icons . . . . . . . . . .23
Setting up the Charge Station
for a Wireless Camera . . . . . . .26
Connecting the Charge Station
to the Docking Station . . . . .27
Connecting the Antenna to the
Docking Station . . . . . . . .28

iv Contents
Using the Charge Station as a
Stand-Alone Device. . . . . . .28
Pairing the Wireless Camera
to the Docking Station. . . . . .29
Using the Camera with a
Protective Sheath . . . . . . . 30
Chapter 4
Acquiring,
Reviewing, and
Storing Images
Acquiring Images Using a Video
Monitor . . . . . . . . . . . . . .31
Acquiring Images Using a
Computer . . . . . . . . . . . . .32
Chapter 5
Maintenance
Hygiene and Disinfection. . . . . .35
Maintenance. . . . . . . . . . . 36
Daily . . . . . . . . . . . . . 36
Monthly. . . . . . . . . . . . 36
Disposing of the Battery . . . . . .37
Chapter 6
Troubleshooting
Chapter 7
Technical Features
and Specifications

KODAK 1500 Intraoral Camera User’s Guide (8G7939) v
About This Guide
This guide documents the Kodak 1500 intraoral camera and
contains the following messages to emphasize information or
indicate potential risk to personnel or equipment:
Note to the User
To use and operate your software, you must follow the
instructions contained in this guide.
Warning: Failure to heed this warning could
result in damage to property or in bodily injury.
Caution: Points out procedures that you must
follow precisely to avoid damage to the system
or any of its components, yourself, or others.
Note: Provides additional information, such as
expanded explanations, hints, or reminders.
Tip: Provides extra information to improve
workflow.

vi About This Guide
Warning and Safety Instructions
When operating the Kodak 1500 intraoral camera, observe the
following warning and safety instructions:
DANGER OF ELECTRIC SHOCK
This is an electrical unit. DO NOT expose it to
water spray. Such action may cause an electric
shock or a malfunction of the unit.
CAUTIONS:
•You are responsible for the operation and maintenance
of this camera. Only qualified persons can operate this
camera. They MUST have training to use the camera.
When necessary, have a trained authorized service
technician carry out inspection and maintenance
operations.
•DO NOT place the computer and the peripheral
equipment connected to it in the immediate vicinity of
the patient. Leave at least 1.83 m distance between the
patient and the equipment..
•See your computer installation guide for details of the
data processing system, computer and screen. Leave a
sufficient amount of clear space around the computer
to ensure that it is properly ventilated.
•To obtain maximum image quality and visual comfort,
position the screen to avoid direct light reflections from
internal or external lighting.

KODAK 1500 Intraoral Camera User’s Guide (8G7939) vii
•DO NOT place objects within the field of operation of
the equipment.
•Disinfect any parts of the camera that come into
contact with the patient and the operator after each
patient has been exposed to the camera.
•Always use a new protective sheath for each patient.
•Turn off the camera before charging. Failure to do so
will shorten the life of the battery.
•The surface temperature of the LED window can rise up
to 39°C. Do not allow the window to come in contact
with the patient’s mouth for more than 10 minutes.
•When the camera is not in use, ensure that the ON/OFF
button is set to OFF.
•Ask the patient to refrain from moving during the entire
period of exposure.
•The power adapter is certified by IEC 60601-1. You
MUST use the provided AC Mains adapter only.
Marking and Labeling Symbols
Type BF device symbol complying
with the IEC 60601-1 standard

viii About This Guide

KODAK 1500 Intraoral Camera User’s Guide (8G7939) 1
1 KODAK 1500 Intraoral
Camera Overview
The Kodak 1500 intraoral camera is compliant with the
requirements of the EEC and international medical standards.
The camera has been designed to carry out the following
functions:
•Acquire still images and video
•Review images
•Store images
Camera Components
The camera is available in two models: wired and wireless.
Although they look similar, the buttons and LEDs have different
functions for different modes. The following illustrations
describe the components and functions for wired and wireless
models.
Wireless Camera
The wireless camera may be powered by a battery or a cable. If
you use a cable, the functions of the LEDs and buttons are the
same as those described for the wired camera.

2 Chapter 1 KODAK 1500 Intraoral Camera Overview
Figure 1 Camera Components—Wireless
1LED and Lens
window
View white LEDs that illuminate the
oral cavity.
2Power On/Off
button
Press 3 seconds to power on. Press
5 seconds to power off.
3Battery Release
button
Press button and pull battery out.
4Shutter Release
button
Press halfway down to perform auto
focus. Press all the way down to
capture an image. Press halfway
down and release to return to video
mode.
5Battery indicator Green indicates the battery is working
properly; blinking orange indicates
the battery is low.
6Wi-Fi indicator Solid blue indicates the connection is
working properly; blinking blue
indicates a communications problem.
7Battery Insert rechargeable cylindrical
Lithium-ion battery into bottom of
camera until it fits tightly in place.
1
2
3
4
5
6
7

KODAK 1500 Intraoral Camera User’s Guide (8G7939) 3
Wired Camera
Figure 2 Camera Components—Wired
1LED and Lens
window View white LEDs that illuminate the oral cavity.
2Power On/Off
button Press 3 seconds to power on. Press 5 seconds to power off.
3Cable Release
button Press button and pull cable out.
4Shutter
Release
button
Press halfway down to perform auto focus.
Press all the way down to capture an
image. Press halfway down and release it
to return to video mode.
5Power
indicator Green indicates the camera is powered on; no light indicates the camera is powered
off.
6USB
Connection
indicator
Solid blue indicates the connection is
complete; blinking blue indicates the
connection is in progress.
7Cable Insert cable into bottom of camera until it
fits tightly in place.
1
2
3
4
5
6
7

4 Chapter 1 KODAK 1500 Intraoral Camera Overview
Camera Holder Components
Place the camera in the holder when you are not using the
camera. See “Setting up the Camera Holder” on page 18.
Figure 3 Camera Holder Components
Docking Station Components
The docking station provides connectivity and power for the
camera. It lets you connect to a computer or a video monitor.
The docking station contains the SD card slot and all of the
connections for using the camera.
1Opening to fasten the holder securely to the surface
2Adhesive tape
12
Note: After the camera is idle for 1.5 minutes,
it goes into sleep mode. To use it again, pick it
up or press the Shutter Release button. After
the camera is idle for 1 hour, it shuts down.

KODAK 1500 Intraoral Camera User’s Guide (8G7939) 5
Figure 4 Docking Station Components
6
7
8
9
10
11 12
Front View
Back View
2
3
4
5
1
13
Bottom View

6 Chapter 1 KODAK 1500 Intraoral Camera Overview
1USB connector to camera
2SD card socket
3Power indicator: green = power normal; dark = no power
4
USB connection indicator (wired): blue = normal; blinking
= not normal
Wi-Fi indicator (wireless): blue = normal; blinking = not
normal
5Antenna connector (wireless)
6USB connector to computer
7VGA connector
8S-video connector
9AV-out connector
10 Power DC-in connector
11 Footpedal connector (optional accessory)
12 DC-out connector (wireless)
13 Output switch: NTSC, PAL, S-Video, VGA

KODAK 1500 Intraoral Camera User’s Guide (8G7939) 7
Charge Station Components
The charge station is used to charge the wireless camera and
the additional battery at the same time or separately. You can
use the charge station as a stand-alone unit or attach it to the
docking station. The unit is used for wireless configuration only.
Figure 5 Charge Station Components
1Camera port
2Battery port
3Battery charging indicator: green = charge complete;
orange = charging
4Power input
4
1
3
2
Note: If the camera is in the charge station for
more than 1 hour, it shuts down.

8 Chapter 1 KODAK 1500 Intraoral Camera Overview
System Components
The Kodak 1500 intraoral camera consists of a camera that
captures video or still images when connected wirelessly or
cabled to a computer or video monitor. If you use a computer,
Kodak dental imaging software is required to view images. If you
use a video monitor, additional software is not required.
Table 1 shows the system components for the Kodak 1500
intraoral camera.
Table 1 System Components
Item Description
1camera
1 camera cable
2 rechargeable cylindrical Lithium-ion
batteries (wireless)
1 camera holder
Disposable sheaths

KODAK 1500 Intraoral Camera User’s Guide (8G7939) 9
1 docking station
1 DC power cable and adapter
1 AV cable
1 S-video cable
1 USB cable
1 antenna (wireless)
1 2G SD card
Table 1 System Components (Continued)
Item Description

10 Chapter 1 KODAK 1500 Intraoral Camera Overview
1 charge station (wireless)
Charge station power cord
Document and
Software Package
CD containing:
•User’s guide
•Safety and Regulatory guide
•Accessory Information
Printed copies:
•Quick Start guide
•Safety Information sheet
•Warranty sheet
Table 1 System Components (Continued)
Item Description

KODAK 1500 Intraoral Camera User’s Guide (8G7939) 11
2 Acquisition Module
Overview
Computer System Requirements
The computer must meet the following requirements:
•Intel Pentium IV, 1.8 GHZ or higher
•512 MB RAM (1 G RAM for Windows Vista Ultimate,
32 bits)
•DVD drive
•Standard CRT/LCD monitor with a minimum of
1024 X 768 screen resolution
•Direct X 9.0c supporting video board
•USB 2.0 high-speed port
General Software Overview
The Kodak 1500 intraoral camera operates with the following
software:
•Kodak dental imaging software, version 6.11 or higher
•Acquisition module
For more information, see the KODAK Dental Imaging Software
Quick Start Guide.
KODAK Dental Imaging Software
The Kodak dental imaging software is a user-friendly working
interface, which is the common imaging platform for all of our
digital systems for dentistry.

12 Chapter 2 Acquisition Module Overview
KODAK Acquisition Module
The following windows and settings are used in the Kodak
acquisition module.
Capture Window
The Capture window icon is located in the upper-left corner of
the screen. Across the bottom of the window is a series of still
thumbnail images of the entire exam.
Figure 6 Capture Window
1Capture button Displays the Capture window.
2Preview screen Displays either live video or captured
images.
3Captured Images Displays or hides thumbnails of captured
images and videos.
4Delete button Deletes an image.
1
2
34
5
6
7
8
9
10
11
12
