Kodiak PWP3HX User manual

Water Flow
(gpm)
1" 1.5" 2" 3" 4"
10 7
20 26
30 56 8
40 96 13
50 144 20 5
100 72 18
150 153 38 5
200 64 8.9
250 97 14
300 19 4
350 25 6
400 32 8
450 10
500 12
550 14
Hose Friction losses
Pressure Drop in psi per 100 ft of hose with typical flow rates
Losses are expressed in feet of head loss
Values are based on the Hasen-Williams Equation and are close approximations
Centrifugal Pump Reference Information
Losses due to hose friction
Losses due to elevation
Pressure can be designated in many units from bar (si), psi (imperial) or also in high
of a water column (feet or metres). In imperial units the weight of one foot of water
is equal to .4328 psi. In other words for every foot of elevation change from the
discharge of the pump to the point of discharge of the hose there is a pressure of
.4328 psi applied to the pump.
1 foot of water (head) = .4328 psi
Specifications/Reference
PWP3HX
Port Size
3" NPT M
Seal Material
Carbon Ceramic
Impeller Material
Cast Iron
Volute Material
Cast Iron
Pump Casing Material
Aluminum
Sucon Li(m)
26 (8)
Max Head (m)
106 (32)
Max Flow gpm (lt/min)
264 (1000)
Solids Capacity in (mm)
N/A
Weight lbs (kg)
66 (30)
size inches ( mm)
LxWxH
21x15x17.7 (550x
390x450)
Engine
Honda GX160
Engine Spec #
K1WKT2
Engine type
4 stroke
oil Alert
Yes
Engine output hp(kw)
5.5(4.1)
Fuel Tank Capacity gal (l)
1(3.8)

Pump Curve PWP3HX
PWP3HX
0
10 20 30 40 50 60 70 80 90
100 110
0 20 40 60 80 100 120 140 160 180 200 220 240
GPM
HEAD (ft.)

Parts Illustration PWP3HX
１
２
３
４
５
６
７
８
９
１０ １１
１２
１２
１３
１４
１５
１６
１３
１７
１８
１８
１９
２０
２１
２２
２３
２１
２２
２３
２４
２５

Parts Illustration PWP3HX
N/A DEALER ONLY
HONDA GX160 1
1
PWP200200190
CASING 1
2
PWP502004
CASING COVER 1
3
PWP801009
IMPELLER 1
4
PWP801011
INNER CASING 1
5
PWP801019A
BEND 1
6
PWP801013
VALVE CASE 1
7
PWP201100031
MECHANICAL SEAL 1
8
PWP200900350
PACKING,CASING 1
9
PWP801012
PACKING, INNER CASING 140
10
PWP801020
PACKING, BEND 110
11
PWP801015
CHECK VALVE 1
12
PWP200800020
O-RING 2
13
PWP200500040
PLUG ASSY 2
14
PWP203000100
CASING BOLT ASSY 4
15
PWP801030
FRAME(WHITE) 1
16
PWP801014
HEX.BOLT 3
17
PWP501014 HEX.BOLT WITH WASHER
4
18
PWP501014 HEX.BOLT WITH WASHER
8
19
PWP501023
HEX.BOLT 4
20
PWP501024
FLANGE NUT 4
21
PWP801017
PACKING, COUPLING 2
22
PWP801018
HOSE COUPLING 2
23
PWP801016ALUM
COUPLING HANDLE 2
24
PWP801028
HOSE BAND 3
25
PWP801029
STRAINER 1
3"
M8×30 P=3
3"J
M8×25 P=2
NPSH3
M8
M8×40 P=2
NBR
ABS
M8×25 P=3
SCQ-80
Remarks
M8×50
REF No.
EX-NPT3
EX-NPT3
Parts No.
Parts name
Q'ty
P-24
