Koldwave 6KK21BGA2AA00 User manual

Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
1
Owner’s Manual
WPC-3000, WPC-4000, WPC-5000
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Please read and save these instructions. Read carefully before attempting to assemble, install, oper-
ate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and / or property damage! Retain instructions for future reference.
Koldwave Portable Air Condi oners feature spot cooling for
large areas where cooling of the en re area is not prac cal.
A dedicated spot cooling thermostat controls the unit in this
applica on.
These air condi oners can also be used in smaller areas for
room cooling. A control panel provides ease of use and con-
tains a self-diagnos c func on and display, showing operat-
ing modes, room and set temperatures, and faults.
If an abnormal opera on occurs, a visual display of the fault
is shown. Caster wheels are included for easy portability.
Suitable applica ons include: a factory or work place, indus-
trial kitchen, computer room, emergency cooling, outdoor
event, etc.
A er unpacking the unit, carefully inspect unit for any damage that may have occurred during
transit. Check for any loose, missing, or damaged parts.
Descrip on
Unpacking
6KK14BEA2AA00, 6KK17BGA2AA00,
6KK21BGA2AA00
Figure 1
Speci ca ons
Model No. Power Supply Ph-V-Hz Cooling Capac-
ity Btu/h
Power Con-
sump on Wa s
Rated Cur-
rent Amps
EER Btu/
Wh
6KK14BEA2AA00 Single Phase, 115V, 60Hz 13,200 1300 11.9 11.0
6KK17BGA2AA00 Single Phase, 115V, 60Hz 16,800 1700 15.5 9.8
6KK21BGA2AA00 Single Phase, 208/230V, 60Hz 21,200 2400 11.3 / 10.9 8.8
Model No. Nema Plug Power Cord
Gauge AWG
Power Cord
Length 
Dimensions
W x D x H - in. (mm)
6KK14BEA2AA00 5-15P 14 10
20.6 x 26.4 x 41
(523 x 671 x 1042)
6KK17BGA2AA00 5-20P 12 6
6KK21BGA2AA00 6-15P 14 10
Portable Air Conditioners

2 3
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Specicaons (Connued)
Model No. Weight (Net / Gross) Lbs(kg) No. of Cool Air
Outlets Pcs
Condensate tank
Gallons(Liters)
Ambient temperature
range °F( °C)
6KK14BEA2AA00 185 / 200 lbs.(84 / 91 kg)
23.17 (12) 64~113 (18~45)
6KK17BGA2AA00 190 / 205 lbs.(86 / 93 kg)
6KK21BGA2AA00 196 / 211 lbs.(89 / 96kg)
Model No. Seng temperature
(Room cool mode) °F( °C)
Seng temperature
(Spot cool mode) °F( °C)
6KK14BEA2AA00
64~86 (18~30) 32~86 (0~30) 6KK17BGA2AA00
6KK21BGA2AA00
Model No. Applicaon Area
(Room cool mode) ²(m²)
Refrigerant
Type / oz(g)
Design Pressure - Hi/
Low Psig
6KK14BEA2AA00 355 (33) R-410A / 21.2
(600) 465 / 160
6KK17BGA2AA00 430 (40) R-410A / 20.5
(580) 450 / 250
6KK21BGA2AA00 538 (50) R-410A / 24.3
(690) 484 / 148
Model No. Indoor Air Flow
(High/Low)CFM(CMM)
Wheels
pcs / diameter
Hot Air Duct Di-
ameter In.(mm)
Maximum Duct Length
(m)
6KK14BEA2AA00 405/ 345 (11.5/ 9.8)
4 / 76mm 12 (300) 50 (15)
6KK17BGA2AA00 470 / 400 (13.3 / 11.3)
6KK21BGA2AA00 560/ 465 (15.9 / 13.2)
Safety Devices
Compressor overload protector, An-freezing thermis-
ter, Full drain tank switch, Automac restart (Power
interrupon), Compressor me delay program, High
pressure switch
Features
Temperature control, Self-diagnosc funcon, Two
speed fan, Oponal drain pump kit, Washable lters,
°F( °C) display, O-mer

3
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
General Safety Informaon
Please read this manual carefully for instrucons on correct installaon and usage. Please read
all safeguards.
1. Transport and store the unit in an upright posion only. Leave unit in an upright posion for at
least 3 hours before rst use.
2. Always place the unit on an even, level surface.
3. Ensure the unit is connected to a grounded power supply of the correct rang / capacity.
4. The unit will cool when the room temperature is between 18°C (64°F) ~ 45°C(113°F) depend-
ing on the thermostat seng.
5. DO NOT use this unit for funcons other than those described in this instrucon manual.
6. DO NOT lt the unit.
7. DO NOT cover or obstruct the unit’s inlet and outlet grilles.
8. DO NOT use the unit in areas where it will be exposed to rain or water.
9. NEVER unplug the unit while it is operang.
DO NOT use the unit in wet environments, such as a laundry room, to avoid
the risk of electrical shock.
Thank you for selecng this Koldwave Portable Air Condioner. It provides you with spot
cooling for large areas where cooling of an enre area is not praccal or possible. Please
read this manual before installing the 6KK14BEA2AA00, 6KK17BGA2AA00 or 6KK21BGA2AA00
as it provides important informaon that should be followed during installaon and main-
tenance of the Portable Air Condioner, allowing you to correctly set up your system for
the maximum safety and performance. Included is informaon on customer support and
service, if it is required. If you experience a problem with the unit, please refer to the Trou-
bleshoong secon in this manual to correct the problem. If the problem is not corrected,
please collect informaon so that the Technical Support personnel can more eecvely
assist you.
DO NOT operate the unit in explosive or ammable environments.
10. DO NOT place any foreign objects on the unit.
11. DO NOT operate the unit with wet or damp hands.
12. DO NOT allow chemical substances to come into contact with the unit.
13. DO NOT operate the unit in the presence of ammable substances or vapors such as alcohols,
pescides, gasoline, etc.
14. DO NOT use the plug to start and to stop the unit. Always use the control panel to start and
to stop the unit.
15. Always turn o the unit when it is not in use and unplug the power plug from the electrical
outlet.

4 5
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
21. DO NOT operate the unit with a damaged power cord or plug, aer it malfuncons, has been
dropped or damaged.
22. Only use in the upright posion on an even, at surface. Unit must be posioned at least 24
inches (60 cm) from the nearest object in any direcon.
23. Stop operaon immediately if abnormal noise or odor is noced. Contact a local service
center.
24. Appliance is not to used by children or persons with reduced physical, sensory or mental
capabilies, or lack of experience and knowledge, unless they have been given supervision or
instrucon.
25. Children being supervised not to play with appliance.
26. That the appliance shall be installed in accordance with naonal wiring regulaons.
27. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
SAVE THESE INSTRUCTIONS
DO NOT operate a unit with a damaged power cord.
19. The lters must be used with the product at all mes. When the lters are removed for clean-
ing, always ensure that the unit has been turned o and unplugged from the electrical outlet.
20. Regularly clean the lters to maintain eciency. If the lters are not cleaned regularly, the
units output performance and eciency will decline and energy consumpon will increase.
16. Always turn the unit o and unplug the main power plug from the electrical outlet before
cleaning, moving or performing maintenance.
17. AVOID the use of adapter plugs or extension cords. If it is necessary to use an extension cord
or an adapter plug to operate the unit, ensure that they are correctly rated for the applica-
on. Consult a local qualied lectrician and all local electrical codes to ensure proper setup.
Any extension cord used with this device must be rated for a minimum of 15A.(120V)
18. DO NOT unplug the unit by pulling on the electrical cord. Keep electrical cord away from heat
sources and always completely unroll the cord to avoid overheang. If the power cord be-
comes damaged, a qualied service agent, qualied electrician, or similarly qualied person
must replace it, in order to avoid a hazard or shock.

5
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Assembly (6KK14BEA2AA00, 6KK17BGA2AA00, 6KK21BGA2AA00)
Cool air outlet hose
Front and Right Side View
Display / Control board
Top fan exhaust flange
Evaporator / filter
Guide bar for condensate water tank
Condensate water tank (Water level is
sensed, and the unit operaon is stopped
when tank is full. An alarm will be
displayed. Empty the tank and replace to
resume operaon)
1. Take out the cord holder from
the accessory box.
2. Place the cord holder on the
back side of air condioner.
3. Use screws (enclosed inside
of accessory box with cord holder)
to install the cord holder on the
air condioner as shown in Figure 4.
POWER CORD HOLDER
DISCHARGE DUCTS/SUPPLY AIR DUCT
Figure 3Figure 2
Figure 4Figure 5
Back and Le Side View
Power cord holder
Caster
Electrical access panel
Condenser / filter
1. Remove the top fan exhaust
flange from carton.
2. Place the top fan exhaust flange
on the top of air condioner.
3. Use screws (enclosed inside
of box with the top fan exhaust
flange) to install the top fan
exhaust flange on air condioner
as shown in Figure 6.
TOP FAN EXHAUST FLANGE
Figure 6Figure 7
Figure 8
AB
C
An ambient air adapter can be purchased separately. Air adapter
fits over the condenser to duct condenser air to the unit to improve
cooling efficiency.
1. Remove the Filter("A")
2. Check the Filter("C") is inserted properly in Intake Warm Air Duct("B")
3. Install "B" which contains "C" by using driver with enclosed
bolts(6EA) as Figure 8.
AMBIENT AIR ADAPTER (Oponal)
Component parts
1. Remove cool air outlet hose(s)
from carton.
2. Place the cool air outlet hose(s)
on the front top of air condioner.
3. Use screws (enclosed inside of box
with cool air outlet hose(s) to
install the cool air outlet hose(s) on
the air condioner as shown in
Figure 5.
EVAPORATOR PLENUM (Oponal)
An evaporator plenum can be purchased
separately. Plenum fits over the evaporator
to duct evaporator air to the unit to
improve cooling efficiency.
1. Remove the evaporator cover from the
unit.
2. Remove the filter from the evaporator
cover and put it into the plenum.
3. Install the plenum in front of the
evaporator.

6 7
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Installaon
MOVING THE UNIT
PLUGGING IN THE UNIT
Unlock the casters and push the unit using the side handles to a at, level surface and set the
caster brakes to the locked posion.
Check the prongs and surface of the power cord plug for dust/dirt. If dust and/or dirt are pres-
ent, wipe o with a clean, dry cloth.
Check the power cord, plug and prongs for damage or excess play.
If any damage or excess play is found, contact a qualied repair technician or a qualied electri-
cian to perform replacement or repair of the power cord, plug or prongs.
NOTE: Make sure the AC outlet is free of dirt, dust, oil, water, or any other foreign material. The
unit is equipped with an approved NEMA plug conguraon. (6KK14BEA2AA00: 5-15P,
6KK17BGA2AA00: 5-20P, 6KK21BGA2AA00: 6-15P) The appropriate outlet must be used
for each plug type.
WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION
Do not use the unit in explosive environments or in areas where ammable
gas leakage may occur.
Do not use the unit in areas where it will be exposed to rain or water.
Do not use the unit in a corrosive atmosphere.
Do not use the unit above 18°C(64°F) ~ 45°C(113°F).
Do not install the unit on uneven or sloping surface. The unit may roll or
topple over even if the casters are set to the locked posion.
If the power cord or plug is damaged, repair should only be performed by
qualied electrical personnel.
Do not connect / disconnect the power cord or aempt to operate buons
with wet hands. This could result in electrical shock.

7
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Operaon
CONTROL PANEL
1. POWER BUTTON: Acvates unit when POWER BUTTON is pressed. (Fan starts on low speed). If
power buon is pressed during operaon, unit stops.
2. BLOWER BUTTON: Changes fan speed from (Low) to (High) when pressed.
3. SPOT/COOL BUTTON: Acvates compressor and begins producing cool air 5 seconds aer but-
ton is pressed. Regulates temperature based on outlet cool air temperature.
4. ROOM/COOL BUTTON: Acvates compressor and produces cool air 5 seconds aer buon is
pressed. Regulates temperature based on inlet ambient air temperature.
5. SET TEMP BUTTONS: Change target temperature/data value by +/- 1. Change data value by +/-
10 by pressing connually. Press the SET TEMP BUTTONS to set temperature. Upper buon is
to heighten temperature and Lower buon is to lower temperture.
6. ALARM: Alarm indicator lights (blinks) and indicates abnormal system operaon. If Alarm oc-
curs, compressor stops.System operaon stops when ALARM light is acvated (blinks) longer
than 3 minutes.
7. CURRENT TEMP: Displays current room temperature in display in Fahrenheit. (In Room
Cool Mode only). SPOT/COOL Mode – Displays outlet (cool air) temperature during normal
operaons. In order to change °F to °C, press SPOT/COOL and ROOM/COOL buons together
for 2 seconds. C will blink 2 mes and Figure will change to °C. ALARM codes blink and are
displayed when abnormal operaon occurs.
NOTE: Canadian version shows the temperature in Celsius rst when you turn on the unit.
8. TARGET TEMP: displays the unit set temperature for ROOM/COOL mode only.
OFF-TIMER: Enter to Timer Seng Mode if you press BLOWER Buon and SPOT/COOL Buon
together for1 seconds. Press UP/DOWN Buon to set the mer unl it shows the gure you want
to set. Aer 5 seconds,the gure will be memorized and the compressor will stop aer the me set.
AUTO RESTART: If the unit goes o due to an electrical interrupon, the unit will automacally
restart when the power resumes.
1 2
5
3 4
6
87
Figure 9

8 9
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Maintenance
FILTER CLEANING (See Figures 10 and 11)
There are two lters in the unit. The evaporator lter is located at the front of the unit. The
condenser lter is located at the side of the unit.
1. loosen up 2 bolts on the front lter guard.
2. Slide lter up and use a vacuum cleaner to remove the dust from the lter.
3. If the lter is heavily covered with dust and dirt, warm water and mild soap or neutral deter-
gent may be used to wash the lter. Do not use any other chemicals to clean lter, as they will
likely damage the lter.
4. Dry the lter in a shaded area before replacing it. Do not operate the unit without the lter
installed and the lter guard in the closed posion.
5. Replace the clean lter and close the lter guard.
6. To clean the condenser lter, li up on the side lter from the middle bar slightly and then
angle the lter outwards from the boom and remove.
7.Use the same cleaning procedure as above (3 – 5).
8. To replace the condenser lter, place the top of the lter in the guide and slide the lter up
unl the boom of the lter clears the frame. Then push the boom of lter into the guide
and let lter gently fall inside the guide.
NOTE: For eecve cooling clean the lter at least every 2 weeks.
– For your convenience, record the complete model number and product name (located on the
Product Idencaon Plate), the purchase date, purchase locaon, serial number, and war-
ranty period in the table below.
– Also, aach your purchase receipt as proof of purchase to this instrucon manual for future
reference.
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Do not operate without the lter ed.
Do not operate the unit with a damaged cord or plug, aer the unit malfunc-
ons, or if the unit has been dropped or damaged.
– Loosen up 2 bolts on
the front filter guard.
– Slide filter up and use
a vacuum cleaner to remove
the dust from the filter.
– Remove dust from the filter
using a vacuum cleaner
hose aachment.
– If required wash the filter in
lukewarm water with a mild
detergent. Leave to dry in
a shaded area before
reinstalling.
Figure 10 – Removing Filters Figure 11 – Removal of Dust

9
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Maintenance (Connued)
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Product Portable Air Condioner
Model No.
Date of Purchase
Place of Purchase
Serial No.
Period of Warranty
Customer: Please read and keep this
manual for future reference and keep
sales receipt as proof of purchase.
SPRING REPLACEMENT (See Figure 12)
SELF-DIAGNOSTIC CODES (See Table 1)
The alarm light is acvated if abnormal operaon occurs, and a code is displayed on the control
panel. The compressor and condenser fan motor will stop operang. The evaporator fan will con-
nue to run for 3 minutes. If the fault is reced within 3 minutes, the unit will resume opera-
on. If the fault persists for more than 3 minutes, the evaporator fan also stops. The fault must
be reced before the unit can resume normal operaon.
There are two springs on the rear of condensate water tank guide.
1. Release the screw on the spring hook.
2. Take o the spring hook, and then pull out the opposite spring
hook from hole in the condensate water tank guide.
3. Replace with a new spring in reverse order.
4. Repeat this cycle for the other spring.
Figure 12 – The process of
spring replacement

10 11
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
SELF-DIAGNOSTIC ALARM CODES
Alarm Display Problem Cause Correcve Acon
Frost prevenon
sensor and Abnormal
temperature sensor
value
• Indoor heat
exchanger tempera-
ture too low
• TH3 temperature
sensor has a loose
or broken connec-
on
• Do not use the air
condioner if ambient
temperature is lower
than 18°C (64°F)
• Contact a qualied
service agent
Refrigerant high
pressure switch
• Blocked air lter
• Blocked / kinked
exhaust duct
• Ambient tempera-
ture is too high
• Clean air lter
• Ensure exhaust duct is
not blocked / kinked
• Do not use the air
condioner if ambient
temperature is higher
than 45°C (113°F)
Abnormal tempera-
ture sensor value
TH1(Outlet) tem-
perature sensor has
a loose or broken
connecon
Contact a qualied service
agent
Abnormal tempera-
ture sensor value
TH2(Inlet) tem-
perature sensor has a
loose or
broken connecon
Contact a qualied service
agent
Compressor over-
loaded
• Ambient tempera-
ture is too high
• Unstable voltage
supply
• Defecve compres-
sor
• Do not use the air
condioner if ambient
temperature is higher
than 45°C (113°F)
• Contact a qualied
service agent
• Replace compressor
Condensate water
level alarm Condensate tank is full
• Empty the water tank
• Aer installaon of the
water tank, press the
SPOT/COOL or ROOM/
COOL buon to resume
operaon
Drain pump alarm
Drain pump defecve
or improper hose con-
necon (including kink
or blockage)
• Check the aconnecon
and hose
• Replace drain pump
Table 1- Alarm Codes

11
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Wiring Diagram
136
116
바이어명
Model WIRING DIAGRAM
PART NO.
웰템
라벨 사이즈 136x116
적용모델
WPC-3000
WPC-4000
WPC-5000
작 성 검 토 확 인
수정사항
1
2
3
4
5
6
7
8
1
2
3
4
5
1. 재질 : 은무데드롱 25미크론
2. 인쇄방법: 씨링인쇄
3. 인쇄색상: 흑색 1도
4. 표면처리: 라미네이팅(OPP코팅)
5. 인쇄기준 : 도면 및 설계 제공 필름
6 외곽의 치수선(붉은선)은 인쇄후 절단선임.
W - 4,5 P
MCCB
Power
1P AC 115V-60Hz
1P AC 208-230V
(50/60Hz)
E
L
N
T (AC) S
CP
PU
HT
EXT
COM
EMC
L
H
TH1
TH1
OUT_TEMP
SENSOR
SEN1
SEN2
SEN3
TH2
TH2
TH3
TH3
IN_TEMP
SENSOR
ICE_TEMP
SENSOR
MC 1 OCR 1
C
FAN'
MOTOR
C
C
R
S
COMP'
Spark
Arrestor
FND
PS (HP)
COM COM
EXT
FU FT
CO COM
DRAIN
PUMP
(Option)
L - 2
N - 2
COM
L
H
COM
L
H
COM CP
N-1
L-1
COM CO
COM
Power Remote
Control (Option)
EXT
COM
(FUSE)
(FUSE)
F L OAT
SWITCH
PRESSURE
SWITCH
COM
PS
WIFI & RF
ON/OFF
SWITCH
(Option)
FU
FT
Figure 13 - Circuit Wiring Diagram (6KK14BEA2AA00,6KK21BGA2AA00)

12 13
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Wiring Diagram
Figure 14 - Circuit Wiring Diagram (6KK17BGA2AA00)

13
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Troubleshoong chart
Symptom Possible Cause(s) Correcve Acon
Water leakage
High water level in con-
densate tank
1. Remove blockage from drain
hose
2. Remove any object stuc undeer-
neath of the black panel nuder
the water tank
The unit doesn’t work
1. Check the power supply
to verify that power is
available to the unit
1. Reset the circuit breaker and
restart the unit
2. Verify that the power
cord is connected
2. Connect power cord
No cold air ows from the
cold air outlet
1. Ambient air cannot be
properly cooled if the
lter is dirty and not
regularly cleaned
1. Clean the lter
2. Compressor will not
work if the unit is
turned o and on
quickly.
2. Wait 2 minutes aer unit is
turned o before turning the
unit back on.
3. The ambient air tem-
perature may be too
high
3. The temperature of the com-
pressor can be higher when
the ambient temperature is
too high. The compressor will
not work unless the ambient
air temperature is within the
acceptable operang range of
the unit
Water ow can be heard
aer compressor shuts o
No cause Common to hear coolant owing
aer unit shuts o
Alarm displays “FT”with
less than half of condensate
water in the tank
Spring is possibly broken
Spring is possibly broken Replace a new spring
(See Maintenance page 8)

14 15
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
OBTAINING SERVICE
If the Koldwave Portable Air Condioner requires Service:
1. Use the TROUBLESHOOTING secon in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the
problem, call Koldwave Portable Air Condioner Technical Support at 214-638-6010. Please
have the following informaon available BEFORE calling the Technical Support Department:
a. Your name and address.
b. The serial number of the unit.
c. Where and when the unit was purchased.
d. All of the model informaon about your Koldwave Portable Air Condioner.
e. Any informaon on the failure, including LED’s that may or may not be illuminated.
f. A descripon of the protected equipment, including model numbers if possible.
SHIPPING LIST
• (1) PORTABLE AIR CONDIRIONER
• (1) Owner’s Manual
• (1) POWER CORD HOLDER
• (2) DISCHARGE / SUPPLY AIR DUCTS
• (1) EXHAUST FLANGE

15
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
For Koldwave warranty please visit
hp://koldwave.com/html/literature.asp

16 PB
Owner’s Manual
6KK14BEA2AA00 / 6KK17BGA2AA00 / 6KK21BGA2AA00
Printed in April, 2019
KOLDWAVE
125 North Elm St.
Wesield, Ma 01085, USA
PH: 252-753-1921 Fax: [phone]
www.koldwave.com
